Title: Welcome to Veterinary Anatomy


1
Welcome to Veterinary Anatomy
2
Introduction to Anatomy
Objectives
  • Define Anatomy
  • Identify the levels of organization
  • Anatomical and directional terminology to be used
    during course
  • Review body cavities and lining membranes

3
Anatomy
  • Is the study of structure of the body and the
    relations among structures
  • Greek means to cut
  • Latin means to dissect
  • Physiology is the study of function.
  • Structure and function are inseparable.

4
Subdivision of Anatomy
  • Gross anatomy the study of structures that can
    be dissected and observed with the unaided eye or
    with a hand lens.
  • Topographical anatomy the anatomy of one part in
    relation to other parts of the body .
  • Applied anatomy the practical application of
    such knowledge in the diagnosis and treatment of
    pathological conditions
  • Neuroanatomy deals with connections of cells with
    CNS

5
Subdivision of Anatomy
  • Cytology deals with structure of individuals
    cells
  • Histology is the study of organization of cells
    and extracellualr material into complex tissue
    and organs
  • Embryology examine the development of the adult
    structure from fertilized ovum to birth

6
Methods of studying Anatomy
  • 1- Dissection of the fixed cadaver
  • remains the most important single method for
    examining the organization of the body at the
    level of the naked eye
  • 2- Surface anatomy the observation of the intact
    body at rest and in action
  • 3- Endoscopy the observation of some parts of
    living body, such as stomach or knee joint, by
    means of special instruments

7
Methods of studying Anatomy
  • 4- Organ imaging is non destructive technique
  • Radiology
  • Carried out by a X ray
  • Ultrasound
  • By the ultrasound waves

8
Levels of Organization
COHN 99.5
99.9
9
Vocabulary of the anatomy
  • Anatomy has a highly specialized vocabulary,
    inherited from previous centuries much of Greek
    and Latin
  • Many of the words have precise meaning, and their
    accurate use is important

10
Vocabulary of the anatomy
  • If everyone uses the same terminology, then it is
    easier to understand what each of us is trying to
    say.

11
Vocabulary of the anatomy
  • For the purpose of description, the body is
    considered as being in what is called the.
    "anatomical position".
  • In this Anatomical Position, the body is assumed
    to be standing (animal stands on his four limbs,
    the feet together, the head and eyes facing
    forwards and palms of the hands facing downwards.
  • To ensure consistency of description it is
    important to keep the anatomical position
    constantly in mind.

12
DIRECTIONAL TERMS
  • Terms that described the position of one body
    part relative to another.

13
DIRECTIONAL TERMS
  • PLANE A surface, real or imaginary along which
    any two points can be connected by a straight
    line.
  • Median Plane Divides the head, body, or limb
    longitudinally into equal right and left halves.
  • Sagittal Plane Passes through the head, body, or
    limb parallel to the median plane.
  • Transverse Plane Cuts across the head, body, or
    limb at a right angle to its long axis or across
    the long axis of an organ or a part. Divides the
    body into cranial and caudal.

14
(No Transcript)
15
DIRECTIONAL TERMS
  • Dorsal Plane Runs at right angles to the median
    and transverse planes and thus divides the body
    or head into dorsal and ventral portions.

16
(No Transcript)
17
DIRECTIONAL TERMS
  • DORSAL Toward or relatively near the back and
    corresponding surface of the head, neck, and
    tail
  • VENTRAL Toward or relatively near the belly and
    the corresponding surface of the head, neck,
    thorax, and tail. This term is never used for the
    limbs.

18
(No Transcript)
19
DIRECTIONAL TERMS
  • MEDIAL Toward or relatively near the median
    plane.
  • LATERAL Away from or relatively farther from the
    median plane

20
(No Transcript)
21
(No Transcript)
22
DIRECTIONAL TERMS
  • CRANIAL Toward or relatively near the head on
    the limbs it applies proximal to the carpus and
    tarsus. When referring to the head it is replaced
    by the term rostral.
  • ROSTRAL Toward or relatively near the nose
    applies to the head only
  • CAUDAL Toward or relatively near the tail on
    the limbs it applies proximal to the carpus and
    tarsus.

23
(No Transcript)
24
DIRECTIONAL TERMS
  • INTERNAL OR INNER Close to, or in the direction
    of the center of an organ, body cavity, or
    structure.
  • EXTERNAL OR OUTER Away from the center of an
    organ or structure.
  • SUPERFICIAL Relatively near the surface of the
    body or the surface of a solid organ.
  • DEEP Relatively near the center of the body or
    the center of a solid organ.

25
DIRECTIONAL TERMS
  • PROXIMAL Relatively near the main mass or
    origin in the limbs and tail is the attached
    end.
  • DISTAL Away from the main mass or origin in the
    limbs and tail is the free end.

26
(No Transcript)
27
Basic Movements
  • FLEXION The movement of one bone in relation to
    another in such a manner that the angle formed at
    their joint is reduced.
  • EXTENSI0N The movement of one bone upon another
    such that the angle formed at their joint
    increases. The limb reaches out or is extended

28
(No Transcript)
29
Basic Movements
  • ABDUCTI0N The movement of a part away from the
    median plane.
  • ADDUCTI0N The movement toward the median plane.

30
(No Transcript)
31
Major parts of the Body
  • Head
  • Fore limbs
  • Hind limbs
  • Trunk
  • Abdomen
  • Thorax
  • Diaphragm

32
Body Cavities
Fig 1.14
