Advanced Machine Learning

1
Advanced Machine Learning Perception
Instructor Tony Jebara
2
Topic 12

• Manifold Learning (Unsupervised)
• Beyond Principal Components Analysis (PCA)
• Multidimensional Scaling (MDS)
• Generative Topographic Map (GTM)
• Locally Linear Embedding (LLE)
• Convex Invariance Learning (CoIL)
• Kernel PCA (KPCA)

3
Manifolds

• Data is often embedded in a lower dimensional
  space
• Consider image of face being translated from
  left-to-right
• How to capture the true coordinates of the data
  on the
• manifold or embedding space and represent it
  compactly?
• Open problem many possible approaches
• PCA linear manifold
• MDS get inter-point distances, find 2D data with
  same
• LLE mimic neighborhoods using low dimensional
  vectors
• GTM fit a grid of Gaussians to data via
  nonlinear warp
• Linear after Nonlinear normalization/invariance
  of data
• Linear in Hilbert space (Kernels)

4
Principal Components Analysis

• If we have eigenvectors, mean and coefficients
• Getting eigenvectors (I.e. approximating the
  covariance)
• Eigenvectors are orthonormal
• In coordinates of v, Gaussian is diagonal, cov
  L
• All eigenvalues are non-negative
• Higher eigenvalues are higher variance, use those
  first
• To compute the coefficients

5
Multidimensional Scaling (MDS)

• Idea capture only distances between points X
• in original space
• Construct another set of low dim or 2D Y points
  having
• same distances
• A Dissimilarity d(x,y) is a function of two
  objects x and y
• such that
• A Metric also has to satisfy triangle inequality
• Standard example Euclidean l2 metric
• Assume for N objects, we compute a dissimilarity
  D
• matrix which tells us how far they are

6
Multidimensional Scaling

• Given dissimilarity D between original X points
  under
• original d() metric, find Y points with
  dissimilarity D under
• another d() metric such that D is similar to D
• Want to find Ys that minimize some difference
  from D to D
• Eg. Least Squares Stress
• Eg. Invariant Stress
• Eg. Sammon Mapping
• Eg. Strain

Some are global Some are local Gradient descent
7
MDS Example 3D to 2D

• Have distances from
• cities to cities, these
• are on the surface of
• a sphere (Earth) in
• 3D space
• Reconstructed 2D
• points on plane
• capture essential
• properties (poles?)

8
MDS Example Multi-D to 2D

• More
• elaborate
• example
• Have
• correlation
• matrix between
• crimes. These
• are arbitrary
• dimensionality.
• Hack convert
• correlation
• to dissimilarity
• and show
• reconstructed Y

9
Locally Linear Embedding

• Instead of distance, look at neighborhood of each
  point.
• Preserve reconstruction of point with neighbors
  in low dim
• Find K nearest neighbors
• for each point
• Describe neighborhood as
• best weights on neighbors
• to reconstruct the point
• Find best vectors that still
• have same weights

Why?
10
Locally Linear Embedding

• Finding Ws (convex combination of weights on
  neighbors)

3) Find l 4) Find w
1) Take Deriv Set to 0
2) Solve Linear system
11
Locally Linear Embedding

• Finding Ys (new low-D points that agree with the
  Ws)
• Solve for Y as
• the bottom d1
• eigenvectors of M
• Plot the Y values

12
LLE Examples

• Original X data are raw
• images
• Dots are reconstructed
• two-dimensional Y
• points

13
LLEs

• TopPCA
• BottomLLE

14
Generative Topographic Map

• A principled altenative to the Kohonen map
• Forms a generative
• model of the
• manifold. Can
• sample it, etc.
• Find a nonlinear
• mapping y() from
• a 2D grid of Gaussians.
• Pick params W of mapping such that mapped
  Gaussians in
• data space maximize the likelihood of the
  observed data.
• Have two spaces, the data space t (old notation
  were Xs)
• and the hidden latent space x (old notation
  were Ys).
• The mapping goes from latent space to observed
  space

15
GTM as a Grid of Gaussians

• We choose our priors and
• conditionals for all
• variables of
• interest
• Assume Gaussian
• noise on the
• y() mapping
• Assume our prior latent variables are a grid
  model
• equally spaced in latent space
• Can now write out the full likelihood

16
GTM Distribution Model

• Integrating over delta functions makes a
  summation
• Note the log-sum, need to apply EM to maximize
• Also, use the following parametric
• (linear in the basis) form of the mapping
• Examples of
• manifolds for
• randomly chosen
• W mappings
• Typically, we are
• given the data and
• want to find the maximum likelihood mapping W
  for it

17
GTM Examples

• Recover non-linear
• manifold by warping
• grid with W params
• Synthetic Example
• Left Initialized
• Right Converged
• Real Example
• Oil Data
• 3-Classes
• Left GTM
• Right PCA
