Topic Models Conditioned on Arbitrary Features with Dirichlet-multinomial Regression

1
Topic Models Conditioned on Arbitrary Features
with Dirichlet-multinomial Regression

• David Mimno Andrew McCallum

2
(No Transcript)
3
Topic Models
Latent Dirichlet Allocation (Blei, Ng, Jordan,
2003)

• Bayesian mixture model with multinomial
  components.

Per-topic multinomial over words
Document
Dirichlet
Per-document multinomial over topics
Word
Topic
4
Example Topics from CS Research Papers
models model hidden markov mixture vector support
machines kernel svm fields extraction random
conditional sequence models conditional
discriminative maximum entropy speech recognition
acoustic automatic features carlo monte sampling
chain markov bias variance error cross
estimator reinforcement control agent rl
search language word words english
statistical expression gene data genes
binding software development computer design
research
5
Uses of topic models

• Summarization Pattern Discovery
• Browsable interface to document collection
• Identifying trends over time
• Discovering low-dimensional representation for
  better generalization
• Expanding queries for information retrieval
• Semi-supervised learning
• Disambiguating words
• LDALatent Dirichlet Allocation?Linear
  Discriminant Analysis?

6
Structured Topic Models
Words Additional Meta-data
Author Blei, Ng, Jordan Year 2003 Venue
JMLR Cites de Finetti 1975 Harman
1992
7
Words and Images

• CorrLDA
• (Blei and Jordan, 2003)

Model can predict image captions and support
image retrieval by ad hoc queries
8
Words and References

• Mixed Membership Model
• (Erosheva, Fienberg, Lafferty, 2004)

Model identifies influential papers by
Nobel-winning authors that are not the most
cited.
9
Words and Dates

• Topics over Time (ToT)
• (Wang and McCallum, 2006)

Topics over Time
LDA
Model distinguishes between historical events
that share similar vocabulary.
10
Words and Votes

• Group-Topic
• (Wang, Mohanty and McCallum, 2005)

Model discovers a group of maverick
Republicans, including John McCain, specific to
domestic issues.
11
Words and Named Entities

• CorrLDA2
• (Newman, Chemudugunta, Smyth, Steyvers, 2006)

Model can predict names of entities given text
of news articles.
12
Words and Metadata

• Supervised LDA
• (Blei and McAuliffe, 2007)

Data specified by choice of exponential family
distribution. (e.g. Gaussian for ratings)
13
What do all these models have in common?
Downstream model

• Words and other data are generatedconditioned on
  topic.
• other data authors, dates, citations, entities,

14
Problems with Downstream Models

• Balancing influence of modalities requires
  careful tuning
• Strong independence assumptions among modalities
  may not be valid

It can be difficult to force modalities to
share topics
15
Another way to introduce other data
Upstream model

• Condition on other data to select topic.Then
  generate word conditioned on topic.

16
Words and Authors

• Author-Topic
• (Rosen-Zvi, Griffiths, Steyvers and Smyth, 2004)

Model discovers topics along with prominent
authors.
17
Words and Email Headers

• Author-Recipient-Topic (McCallum,
  Corrada-Emmanuel and Wang, 2005)

Model analyzes email relationships using text as
well as links, unlike traditional SNA.
18
Words and Experts

• Author-Persona-Topic
• (Mimno and McCallum, 2007)

Model distinguishes between topical personas of
authors, helping to find reviewers for conference
papers.
Expert Finding
19
Words and Citations

• Citation Influence
• (Dietz, Bickel and Scheffer, 2007)

Model can estimate the relative impact of
different references on particular papers.
20
How do you create a new topic model?

1. Create a valid generative storyline
2. Write down a graphical model
3. Figure out inference procedure
4. Write code
5. (Fix errors in math and code)

21
What type of model accounts for arbitrary,
correlated inputs?
Naïve Bayes MaxEnt
HMM Linear-chain CRF
Down-stream
Topic models ??

• Conditional models take real valued features,
  which can be used to encode discrete,
  categorical, and continuous inputs

22
What type of model accounts for arbitrary,
correlated inputs?
Naïve Bayes MaxEnt
HMM Linear-chain CRF
Down-stream
Topic models THIS PAPER
Conditional models take real valued features,
which can be used to encode discrete,
categorical, and continuous inputs
23
THIS PAPERDirichlet-multinomial Regression (DMR)
24
THIS PAPERDirichlet-multinomial Regression (DMR)

• This part same as LDA

25
THIS PAPERDirichlet-multinomial Regression (DMR)

• Features for each document.
• Real-valued vector of length F.

26
Encoding Features

• Binary Indicators
• Does N. Wang appear as an author? Does the paper
  cite Li and Smith, 2006?
• Log position within an interval
• (i.e. beta sufficient statistics)
• Year within a range
• Survey response
• 2 strongly for 0 indifferent-2 strongly
  against

27
THIS PAPERDirichlet-multinomial Regression (DMR)

• Dirichlet parameters
• from which ? is sampled.
• Document specific.
• Depends on document features x

28
THIS PAPERDirichlet-multinomial Regression (DMR)
Vector of parameters for each topic. Matrix of
size T x F.
29
Topic parameters for feature published in JMLR
2.27 kernel, kernels, rational kernels, string kernels, fisher kernel
1.74 bounds, vc dimension, bound, upper bound, lower bounds
1.41 reinforcement learning, learning, reinforcement
1.40 blind source separation, source separation, separation, channel
1.37 nearest neighbor, boosting, nearest neighbors, adaboost
-1.12 agent, agents, multi agent, autonomous agents
-1.21 strategies, strategy, adaptation, adaptive, driven
-1.23 retrieval, information retrieval, query, query expansion
-1.36 web, web pages, web page, world wide web, web sites
-1.44 user, users, user interface, interactive, interface
30
Topic parameters for feature published in UAI
2.88 bayesian networks, bayesian network, belief networks
2.26 qualitative, reasoning, qualitative reasoning, qualitative simulation
2.25 probability, probabilities, probability distributions,
2.25 uncertainty, symbolic, sketch, primal sketch, uncertain, connectionist
2.11 reasoning, logic, default reasoning, nonmonotonic reasoning
-1.29 shape, deformable, shapes, contour, active contour
-1.36 digital libraries, digital library, digital, library
-1.37 workshop report, invited talk, international conference, report
-1.50 descriptions, description, top, bottom, top bottom
-1.50 nearest neighbor, boosting, nearest neighbors, adaboost
31
Topic parameters for feature Loopy Belief
Propagation (MWJ, 1999)
2.04 bayesian networks, bayesian network, belief networks
1.42 temporal, relations, relation, spatio temporal, temporal relations
1.26 local, global, local minima, simulated annealing
1.20 probabilistic, inference, probabilistic inference
1.20 back propagation, propagation, belief propagation, message passing, loopy belief propagation
-0.62 input, output, input output, outputs, inputs
-0.65 responses, signal, response, signal processing
-0.67 neurons, spiking neurons, neural, neuron
-0.68 analysis, statistical, sensitivity analysis, statistical analysis
-0.78 number, size, small, large, sample, small number
32
Topic parameters for feature published in 2005
2.04 semi supervised, learning, data, active learning
1.94 ontology, semantic, ontologies, ontological, daml oil
1.50 web, web pages, web page, world wide web
1.48 search, search engines, search engine, ranking
1.27 collaborative filtering, filtering, preferences
-1.11 neural networks, neural network, network, networks
-1.16 knowledge, knowledge representation, knowledge base
-1.17 expert systems, expert, systems, expert system
-1.25 system, architecture, describes, implementation
-1.31 database, databases, relational, xml, queries
33
Topic parameters for featurewritten by G.E.
Hinton
1.96 uncertainty, symbolic, sketch, primal sketch
1.70 expert systems, expert, systems, expert system
1.35 recognition, pattern recognition, character recognition
1.34 representation, representations, represent, representing, represented, compact representation
1.22 high dimensional, dimensional, dimensionality reduction
-0.67 systems, system, dynamical systems, hybrid
-0.77 theory, computational, computational complexity
-0.80 general, case, cases, show, special case
-0.80 neurons, spiking neurons, neural, neuron
-0.99 visual, visual servoing, vision, active
34
Dirichlet-multinomial Regression (DMR)

• The a parameter for each topic in a document is
  the exponentiated inner product of the features
  (x) and the parameters (?) for that topic.

35
Dirichlet-multinomial Regression (DMR)

• Given the a parameters, the rest of the model is
  a standard Bayesian mixture model (LDA).

36
DMR understood as an extension of Dirichlet
Hyperparameter Optimization

• Commonly, Dirichlet prior on ?Symmetric,
  flat.All topics equally prominent.

37
Training the model

• Given topic assignments (z), we can numerically
  optimize the parameters (?).
• Given the parameters, we can sample topic
  assignments.
• alternate between these two as needed.
• Note that this approach combines two
  off-the-shelf components L-BFGS and a Gibbs
  sampler for LDA!

38
Log likelihood for topics and parameters
Dirichlet-multinomial distribution (aka Polya,
DCM) with exp() instead of a
39
Log likelihood for topics and parameters
Gaussian regularization on parameters
40
Gradient equation for a single ? parameter
Gradient is quite simple. Can plug into standard
optimizer we have for MaxEnt classifier
41
Training the model
Model likelihood (top) and held-out likelihood
jump at the first round of parameter optimization
and improve with subsequent rounds.

• (maybe show a figure with model likelihood and EL
  to demonstrate that this is working)

42
Effect of different features on document-topic
Dirichlet prior
Document features
2.10 Models model gaussian mixture generative
.93 Bayesian inference networks network probabilistic
.69 Classifier classifiers bayes classification naive
.64 Probabilistic random conditional probabilities fields
.61 Sampling sample monte carlo chain samples
4.05 Kernel density kernels data parametric
2.06 Space dimensionality high reduction spaces
1.78 Learning machine learn learned reinforcement
1.50 Prediction regression bayes predictions naive
.88 Problem problems solving solution solutions
2003JMLRD.Blei A.Ng M.I.Jordan
2004 JMLR M.I.Jordan F. Bach K. Fukumizu
43
Evaluation

• Difficult with topic models
• Exponential number of possible topic assignments,
  over which we cannot marginalize.
• We use two methods on held-out documents

44
Evaluation Half-Held-Out Perplexity
Half of test document
Dirichlet prior

• Measures
• the quality of the topic-word distributions
• the ability of the model to adapt quickly to
  local context.

Estimated topic distn
?
Rest of test doc
Topic-word distns
Estimated P(docmodel)
45
Evaluation Empirical Likelihood
Diggle Gratton, 1984
Dirichlet prior

• Measures
• the quality of the topic-word distributions
• the prior distribution.

Sampled topic distn
?
Test doc
Topic-word distns
Estimated P(docmodel)
46
ResultsEmulating Author-Topic
DMR
Author-Topic
LDA

• By using author indicator features, we can
  emulate the Author-Topic model. (Rosen-Zvi,
  Griffiths, Steyvers and Smyth 2004)

47
Results Emulating Author-Topic
DMR
Author-Topic
LDA

• DMR shows better perplexity, and similar
  empirical likelihood to AT.
• LDA is worse in both metrics.

48
ResultsEmulating Citation model
DMR
Cite-Topic
LDA

• Citation authors have much better perplexity
  results than author features.
• EL similar, DMR slightly worse.
• LDA is worse in both metrics.

49
ResultsEmulating Topics over Time
DMR
ToT
LDA

• DMR shows better perplexity and EL.
• LDA is worse in both metrics.

50
Arbitrary Queries

• Previous evaluations on ability to predict words
  given features.
• Can also predict features given words.

51
ResultsPredict Author Given Document
DMR
Author-Topic

• DMR predicts author better than Author-Topic

52
Efficiency
Even with tricks to reduce complexity to O(A T)
from O(AT), DMR is faster

• As upstream models include more features,
  sampling grows more complicated because more
  variables must be sampled(e.g. author and topic
  for every token).
• DMR sampling is no more complicated than LDA.

A-T
40 mins
DMR
32 mins
At 100 topics, 38 of training wall-clock time is
sampling, the rest is parameter optimization
Optimization time could be improved by using
stochastic gradient for L-BFGS.
53
Summary

• DMR benefits
• Simple to implement
• Simple to use
• Fast
• Expressive

LDA L-BFGS
Just add features!
Toss in everything but the kitchen sink!
Faster sampling than Author-Topic
