LOCOMOTION

1
LOCOMOTION REGULATION
2
Locomotion

• Locomotion is the ability of an organism to move
  from one place to another.
• Why would organisms carry out locomotion?
• Motile capable of locomotion
• Sessile organisms NOT capable of locomotion

3
Locomotive System

• The locomotive system consists of a skeletal
  system, muscular system and a nervous system.

4
Human Skeletal System
5
Skeletal System

• Humans have 206 bones
• Babies have MORE
• Bones are made of calcium and phosphorus
• Bones support and protect body structures
• Can be endoskeletal OR exoskeletal
• Osteoporosis is loss of bone mass due to lack of
  calcium

6
(No Transcript)
7
Cartilage

• Found between bones
• Acts as a cushion between bones
• A developing embryo has cartilage instead of bone
• Gives ears and nose their shape
• Arthritis is deteriorating cartilage

8
Muscles

• Humans have over 300 muscles
• Muscles work by contracting (shortening) or by
  relaxing
• Muscles are found as opposing pairs
• Flexors-contract (ex. Bicep)
• Extensors-relax/expand (ex. Tricep)

9
Flexor and Extensor
10
Types of Muscle

• There are three types of muscle cells
• Skeletal
• Cardiac
• Smooth

11
Skeletal Muscle

• Skeletal muscle is also called striated muscle
• Found surrounding bones
• Looks striped
• Controls voluntary movements

12
Skeletal Muscle
13
Cardiac Muscle

• Cardiac muscle is found in the heart
• Cardiac muscles are involuntary, but look like
  striated muscle

14
(No Transcript)
15
Smooth Muscle

• Smooth muscle is also called visceral muscle
• Found in the walls of internal organs
• Control involuntary movements
• Ex. Stomach, Small intestine, arteries, lymph
  vessels, etc

16
Connective Tissue

• There are three kinds of connective tissues that
  connect bones and muscles together.
• Ligaments
• Tendons
• Joints

17
Ligaments

• Ligaments
• Connect bone to bone
• Think L for Ligament
• A sprain is an over stretched ligament

18
Tendons

• Connects muscles to bones
• Tendonitis is an inflammation of a tendon

19
(No Transcript)
20
Joints

• Where two bones meet
• 3 kinds of joints
• Immovable (fixed)
• Hinge
• Ball and socket
• Gliding
• Pivot

21
Joints

• Immovable
• No movement
• Found in cranium/skull

22
Joints

• Hinge
• Movement back and forth
• Found in elbow and knee

23
Joints

• Ball and socket
• Movement in all directions
• Found in shoulder and hip

24
Joints

• Gliding
• Limited movement in all directions
• Found in wrist and ankle

25
Joints

• Pivot
• Limited rotation
• Found in the neck

26
Skeletal Structures

• Exoskeleton
• Protective covering outside the body
• Provides a surface for muscular attachment
• Made of chitin
• Can be thin and light (insects) or thick and
  heavy (lobster)
• Molting is losing exoskeleton to allow for body
  growth

27
Exoskeleton
28
(No Transcript)
29
Protist

• Amoeba
• Paramecium
• Euglena
• Whip-like tail called a

30
Hydra

• They are SESSILE, but fibers allow a
  somersault-type movement (like a slinky)

31
Earthworm

• Earthworms have setae (little bristles) that
  stick into the ground like anchors to allow
  locomotion, segment by segment
• Muscles are attached to each pair of setae

32
Setae
33
Grasshopper

• Have jointed appendages
• Have wings
• Have muscles inside the exoskeleton

34

• What makes your muscles move?
• What organs allow you to respond to your
  environment?

35
Regulation

• Define regulation.
• What part of your body carries out regulation?

36
The Nervous System

• Consists of
• CNS
• Central Nervous System
• Brain and Spinal cord
• PNS
• Peripheral Nervous System
• All nerves outside of the brain and spinal cord

37
C.N.S.
38
P.N.S.
39
The Nervous System

• Parts of a nervous system
• Brain
• Nerve Cells called Neurons

40
Brain
41
Brain
42
Brain

• Made up of 2 halves
• Weighs about 3 pounds
• Protected by _________________
• Made up of neurons

43
Brain

• Made up of 3 parts
• 1. Cerebrum/Cerebral Cortex
• Controls thinking, memory, reasoning,
  imagination, personality, site of consciousness
• Interprets what your 5 senses detect

44
Brain

• 2. Cerebellum
• Controls voluntary movements (motor activities)
• Controls balance and coordination

45
Brain

• 3. Medulla
• Controls involuntary activities
• Such as breathing, digestion, heartbeat, hormone
  production, etc
• Called brain stem and connects to the spinal cord

46
Neuron

• A neuron is a nerve cell
• They send and receive chemical and electrical
  messages, called impulses.

47
Neuron
48
Parts of a neuron

• Dendrites
• Receive impulses
• Cyton
• Cell body-contains nucleus
• Axon
• Carries impulses away from cyton
• Myelin
• Fatty covering on the axon that increases speed
  of electrical impulse
• Terminal Branches
• End point of a neuron that sends messages to
  dendrites of next neuron

49
Synapse

• The synapse is the gap between two neurons.

50
Close-up of synapse

• Neurotransmitters-chemicals secreted into synapse

51
Close-up of a synapse
52
Stimulants and Depressants

• Drugs can affect how the neurotransmitters pass
  their message
• Stimulants __________ speed of message
  transmission.
• Depressants _________ speed of message
  transmission.

53
Reflex Arc

• A reflex is a response to a stimulus.
• Ex. Knee jerk, hand on a hot stove
• A reflex involves the spinal cord but NOT the
  brain.

54
(No Transcript)
55
Reflex Arc
56
Reflex Arc

• Drawing

57
Disorders of the Nervous System

• Meningitis
• Swelling of the membranes that surround the brain
• Polio
• Virus that inflames spinal cord tissue
• Cerebral Palsy
• Disorder of central nervous system
• Can be congenital (exists before birth) or caused
  during birth
• Multiple Sclerosis
• Problem with impulse transmission due to
  inflammation of myelin sheath.

58
Endocrine System

• System of ductless glands that secrete hormones.
• Hormones are chemical messengers that are
  released directly into blood stream.
• Hormones are sent DIRECTLY to a target tissue

59
(No Transcript)
60
Testes and Ovaries

• Ovaries make _______________ _________________
• Testes make ________________
• These hormones stimulate secondary sexual
  characteristics

61
Adrenal Glands

• Located on top of kidneys
• Produces hormone called adrenaline

62
Pancreas

• The pancreas produces digestive enzymes and also
  the hormones called glucagon and insulin.
• The part of the pancreas that produces hormones
  is called the Islets of Langerhans
• Glucagon and insulin control blood sugar

63
(No Transcript)
64
Thyroid Gland

• Located in neck
• Thyroid controls metabolism
• Thyroid produces thyroxin (hormone)
• Goiter is enlarged thyroid gland

65
Goiter
66
Parathyroid

• Located in neck
• Smaller than thyroid
• Produces parathormone which controls calcium
  balance

67
Pituitary Gland

• The master gland (controls all other glands)

68
Pituitary Gland

• Produces stimulating hormones that cause glands
  to secrete their hormones.
• Ex.
• TSH thyroid stimulating hormone

69
Pituitary Gland

• Also produces growth hormone (GH)
• Gigantisism and Dwarfism comes from growth
  hormone problems

70
Hypothalmus

• Produces RFs (releasing factors), which help
  stimulate hormone production

71
Representative Organisms
