Offset Printing

1
Offset Printing

• Graphic Communications
• Mr. Brown

2
Examples of Offset Printing

• Newspapers
• Flyers
• Magazines
• Business cards

3
How it works

• 1) Two Primary components of offset printing
• A) Oil-based ink
• B) Water Fountain Solution
• Oil and Water DO NOT MIX

4
How it works - Chemicals

• Add PLATE ETCH to plate after attaching plate
• Add a layer of fountain solution to plate after
  Etch

5
How it works- Chemicals

• Blanket Wash
• Use Blanket Wash to clean up and wipe off any
  excess ink.

6
Operating the Press

• Adjusting Amount of Ink
• Adjust Tension Screws underneath the ink tray

7
How it works

• Gear must be in Neutral when turning machine on
  and off
• Two on-off switches
• 1) Machine Motor
• 2) Vacuum pump

8
How it works adding plate

• Line up the plate with the holes and make crease
• Pull tight as you roll in the plate
• Attach lower plate Tighten screws

9
(No Transcript)
10
How it works - Procedures

• Add FOUNTAIN SOLUTION
• Add/Check Ink Levels
• Attach Plate PROPERLY

11
How it works - Procedures

• Add PLATE ETCH to plate after attaching plate
• Add a layer of fountain solution to plate after
  Etch

12
How it works - Procedures

• Make Sure Blanket is CLEAN
• Check to see if ALL gates are shut
• Lever is in NEUTRAL
• Turn Press ON
• Move Lever to INK for 5 Rotations
• Move Lever to NEUTRAL
• Turn OFF Press and Inspect

13
How it works - Procedures

• Check to see if any stray marks
• Adjust Ink or Fountain Solution if necessary

14
How it works - Procedures

• After Inspection Close gates, Lever in Neutral
  and Turn Press ON
• Lever to INK then to IMAGE for 5 Rotations
• Move Lever to NEUTRAL and Turn Press OFF

15
How it works - Procedures

• Inspect Blanket for Flaws
• Close Gates
• Make sure Lever is in NEUTRAL and turn Press ON

16
How it works - Procedures

• Move Lever to INK
• Check to see if Paper is loaded and in Proper
  Place
• Turn Vacuum ON
• Send paper through by lifting Lever on RIGHT SIDE

17
How it works - Procedures

• When Printing is DONE
• Move Lever to NEUTRAL turn OFF
• Clean Plate and Blanket with BLANKET WASH
• Remove Plate
• Remove Paper from Tray
