Invariant Local Feature for Object Recognition

• Presented by Wyman
• 2/05/2006

2
Introduction

• Object Recognition
• A task of finding 3D objects from 2D images (or
  even video) and classifying them into one of the
  many known object types
• Closely related to the success of many computer
  vision applications
• robotics, surveillance, registration etc.
• A difficult problem that a general and
  comprehensive solution to this problem has not
  been made

3
Introduction

• Two main streams of approaches
• Model-Based Object Recognition
• View-Based Object Recognition
• 2D representations of the same object viewed at
  different angles and distances when available
• Extract features (as the representations of
  object) and compare them to those in the feature
  database

4
Matching with Local Features

• One of the possible solution
• Matching with invariant local features
• Robust to Occlusion, clutter background
• cf. global features

• Three phases
• Detection
• Description
• Matching

Accurate, Fast
Distinctive
Invariance
5
Research Direction

• Study and improve the invariant local features
• Detection, description and matching
• Study and improve object recognition / matching
  using invariant local features
• Area to improve
• Distinctiveness
• Invariance
• Efficiency

6
Outline

• State-of-the-art techniques
• Descriptor
• Matching
• Conclusion Future Works

7
Outline

• State-of-the-art techniques
• Descriptor
• Performance evaluation
• Current extension using color
• Possible way to improve Color Orientation
• Matching
• Conclusion Future Work

8
Outline

• State-of-the-art techniques
• Descriptor
• Performance evaluation
• Current extension using color
• Possible way to improve Color Orientation
• Matching
• Cross-bin distance
• Performance evaluation
• Possible way to improve Aggregation of Content
• Conclusion Future Work

9
Performance Evaluation of Descriptors

• We aim to compare the performance of three
  state-of-the-art local feature descriptors SIFT,
  PCA-SIFT and GLOH
• Same experimental setup as that used in
  Performance Evaluation of Local Descriptors
  TPAMI 2005
• Different evaluation criterion
• Different result
• In each experiment, each descriptor describe
  features from
• Harris corner detector
• Harris-affine covariant detector
• Output regions that are invariant to viewpoint
  change

10
SIFT Scale Invariant Feature Transform
Detector Descriptor Descriptor Descriptor
Invariance Scale Rotation Illumination Viewpoint

• Descriptor overview
• Find local orientation as the dominant gradient
  direction ? Rotation Invariant
• Compute gradient orientation histograms of
  several small windows (128 values for each point)
  relative to the local orientation ? Viewpoint
  Invariant
• Normalize the descriptor to make it invariant to
  intensity change ? Illumination

D.Lowe. Distinctive Image Features from
Scale-Invariant Keypoints. IJCV 2004
11
PCA-SIFT

• Rotate feature region to dominant gradient
  direction same as SIFT
• Pre-compute an eigenspace for local gradient
  patches of size 41x41
• 2x39x393042 elements
• Only keep 20 components
• A more compact descriptor
• Sensitive to viewpoint change

Y. K. Rahul. Pca-sift A more distinctive
representation for local image descriptors. CVPR
2004
12
GLOH (Gradient location-orientation histogram)

• Different from SIFT in sampling method
• 17 log-polar location bins
• 16 orientation bins
• Analyze the 17x16272 Dimensions
• Apply PCA analysis, keep 128 components

PCA on Orientation Histogram VS PCA on Gradient
Patch
17 Log-polar location bins
C. S. Krystian Mikolajczyk. A performance
evaluation of local descriptors. TPAMI 2005
13
Performance Evaluation
Scale Rotation (bark)

• Data Set
• From Visual Geometry Group

Viewpoint change (graf)
Illumination change (leuven)
Viewpoint change (wall)
Blur
Blurring (bikes)
14
Performance Evaluation

• Evaluation Criteria
• Match features from first image to the second one
  based on the nearest neighbor distance ratio
• That is, two features are matched if first
  nearest neighbor is much closer than the second
  nearest neighbor
• This is different from the threshold-based
  criterion used in A Performance Evaluation of
  Local Descriptors TPAMI 2005
• Count the number of correct matches and the
  number of false matches obtained for an image
  pair
• The results are plotted in form of recall versus
  1-precision curves

15
Performance Evaluation
Viewpoint change (wall)
Scale Rotation (bark)
Illumination change (leuven)
Blurring (bikes)
16
Performance Evaluation Result
Descriptor Distinctiveness Complexity Feature Size
SIFT High Medium 128
PCA-SIFT Medium Low 20
GLOH High High 128

• For accuracy ? SIFT
• For speed ? PCA-SIFT
• In large database ? ?

17
Start from Scratch

• Comparison of my descriptor with SIFT
• Simply designed vs carefully designed
• Result
• SIFT is a carefully designed descriptor, it
  remains robust when the degree of transformation
  increases

Increasing illumination change
Increasing affine change
Increasing affine change
Increasing blur
18
Extension using Color

• Weijier extends local feature descriptors with
  color information, by concatenating a color
  descriptor, K, to the shape descriptor, S,
  according to
• where B is the combined color and shape
  descriptor and is a weighting parameter and
  indicates that the vector is normalized.

J. van de Weijer and C. Schmid. Coloring local
feature extraction. ECCV2006.
19
Proposed Extension using Color

• Problem statement
• Orientation of local feature patch are obtained
  from the monochrome intensity image
• Color feature patches on the right has the same
  grayscale patches shown on the left. Thus, they
  are assigned the same orientation histogram
• If we can generate significant orientation
  histogram for each of them, we can further
  improve the distinctiveness of the shape
  descriptor, SIFT

20
Feature Matching

• Original distance metric designed for SIFT,
  PCA-SIFT and GLOH is bin-to-bin Euclidean
  distance
• Problems
• Sensitive to quantization effects
• Sensitive to distortion problems due to
  deformation, illumination change and noise

21
Feature Matching Diffusion Distance

• Haibin Ling proposed a new distance metric for
  histogram-based descriptor called diffusion
  distance
• Summing value in all layers of the distance
  pyramid with exponentially decreasing size

Gaussian Blur In 3 directions 3D case
Gaussian Blur In 1 direction 1D case
H. Ling and K. Okada. Diffusion distance for
histogram comparison. CVPR06.
22
Feature Matching Performance Evaluation

• Same setup as the previous experiment
• Recall vs 1-prevision curve for image pair with
  affine transformation

23
Feature Matching Performance Evaluation
Data set. The synthetic deformation data set from
Haibin Ling
Images in the data set and the evaluation method
needs to be improved
24
Proposed Extension

• Robust aggregation of the histogram, such as
  average orientation direction and center of mass
  of derivatives, can be also used in comparison
• Diffusion distance can be viewed as a form of
  comparison using the aggregate information
• Its aggregation of histogram bins is obtained by
  repeatedly convolving the histogram with Gaussian
  kernels
• Summation of the distance between each
  aggregation pair of two histograms gives the
  diffusion distance

Histogram A
Histogram B
128 bins
128 bins
64 bins
64 bins
32 bins
32 bins
Aggregation 1. Average of gradient magnitude
over location bins 2. Bin reduction in
orientation bins
25
Conclusion and Future Work

• Presented
• Result of performance evaluation of some
  state-of-the-art descriptors and feature matching
  distance metric
• Possible way to improve the description and
  matching step
• TODO
• Incorporate color information into local features
• Improve features distinctiveness
• Design a distance metric for comparing SIFT
  features histogram
• Invariant to deformation (like diffusion
  distance)
• Improve features distinctiveness

26
Q A

• Thank you very much!

27
Models of Image Change

• Geometry
• Rotation
• Similarity (rotation uniform scale)
• Affine (scale dependent on direction)valid for
  orthographic camera, locally planar object
• Photometry
• Affine intensity change (I ? a I b)

28
Image Alignment

• Many applications
• 3D reconstruction, motion tracking, indexing and
  database retrieval, robot navigation
• Image alignment for building panorama

29
Image Alignment

• Detect features in both images

30
Image Alignment

• Detect features in both images
• Find corresponding pairs

31
Image Alignment

• Detect features in both images
• Find corresponding pairs
• Use these pairs to align images

32
Difficulties

• Problem 1
• Detect the same point independently in both images

no chance to match!
We need a repeatable detector
33
Difficulties

• Problem 2
• For each point correctly recognize the
  corresponding one

?
We need a reliable and distinctive descriptor
34
Difficulties

• Problem 3
• Image transformation may exist in the two images
• Change in scale, rotation, illumination and
  viewpoint

?
We need an invariant local feature descriptor
