Chapter 4

• Protein trafficking between membranes
• By
• Graham Warren Ira Mellman

2
4.1 Introduction

• Eukaryotic cells have an elaborate system of
  internal membrane-bounded structures called
  organelles.
• Each organelle
• has a unique composition of (glyco)proteins and
  (glyco)lipids
• carries out a particular set of functions

3
4.1 Introduction

• An organelle comprises one or more
  membrane-bounded compartments.
• Organelles may act autonomously or in cooperation
  to accomplish a given function.
• In the endocytic and exocytic pathways, cargo
  proteins are transferred between compartments by
  transport vesicles.

4
4.1 Introduction

• The vesicles form by budding from an organelles
  surface.
• They subsequently fuse with the target membrane
  of the acceptor compartment.

5
4.1 Introduction

• Transport vesicles can selectively
• include material destined for transfer
• exclude material that must remain in the
  organelle from which they bud
• Selective inclusion into transport vesicles is
  ensured by signals in a proteins amino acid
  sequence or carbohydrate structures.
• Transport vesicles contain proteins that target
  them specifically to their intended destinations
  with which they dock and fuse.

6
4.2 Overview of the exocytic pathway

• All eukaryotes have the same complement of core
  exocytic compartments
• the endoplasmic reticulum
• the compartments of the Golgi apparatus
• post-Golgi transport vesicles

7
4.2 Overview of the exocytic pathway

• The amount and organization of exocytic
  organelles varies from organism to organism and
  cell type to cell type.
• Each organelle in the exocytic pathway has a
  specialized function.
• The endoplasmic reticulum is the site for the
  synthesis and proper folding of proteins.

8
4.2 Overview of the exocytic pathway

• In the Golgi apparatus, proteins are
• Modified
• Sorted
• carried by the post-Golgi transport vesicles to
  the correct destination.
• Cargo transport to the plasma membrane occurs
• directly by a constitutive process or
• indirectly by a regulated process.
• This involves temporary storage in secretory
  granules until the cell receives an appropriate
  stimulus.

9
4.3 Overview of the endocytic pathway

• Extracellular material can be taken into cells by
  several different mechanisms.
• The low pH and degradative enzymes in endosomes
  and lysosomes are important in processing some
  endocytosed material.

10
4.4 Concepts in vesicle-mediated protein transport

• Transport vesicles move proteins and other
  macromolecules from one membrane-bounded
  compartment to the next along the exocytic and
  endocytic pathways.
• Coats formed from cytoplasmic protein complexes
  help to
• generate transport vesicles
• select proteins that need to be transported

11
4.4 Concepts in vesicle-mediated protein transport

• Proteins destined for transport to one
  compartment are sorted away from
• resident proteins
• proteins that are destined for other compartments
• Transport vesicles use tethers and SNAREs to dock
  and fuse specifically with the next compartment
  on the pathway.
• Retrograde (backward) movement of transport
  vesicles carrying recycled or salvaged proteins
  compensates for anterograde (forward) movement of
  vesicles.

12
4.5 The concepts of signal-mediated and bulk flow
protein transport

• Soluble secretory proteins, especially those
  secreted in large amounts, may not require
  specific signals to traverse the exocytic pathway.

13
4.5 The concepts of signal-mediated and bulk flow
protein transport

• Sorting signals may be restricted to membrane
  proteins and endocytosed receptors
• particularly those that are targeted to some
  intracellular destinations, such as lysosomes.
• Some soluble proteins have signals that allow
  them to interact with receptors that mediate
  their transport to lysosomes.

14
4.6 COPII-coated vesicles mediate transport from
the ER to the Golgi apparatus

• COPII vesicles are the only known class of
  transport vesicles originating from the
  endoplasmic reticulum.
• Assembly of the COPII coat proteins at export
  sites in the endoplasmic reticulum requires a
  GTPase and structural proteins.

15
4.6 COPII-coated vesicles mediate transport from
the ER to the Golgi apparatus

• Export signals for membrane proteins in the
  endoplasmic reticulum are usually in the
  cytoplasmic tail.
• After scission, COPII vesicles may cluster, fuse,
  and then move along microtubule tracks to the
  cis-side of the Golgi apparatus.

16
4.7 Resident proteins that escape from the ER are
retrieved

• Abundant, soluble proteins of the endoplasmic
  reticulum (ER) contain sequences (such as KDEL or
  a related sequence).
• These sequences allow them to be retrieved from
  later compartments by the KDEL receptor.

17
4.7 Resident proteins that escape from the ER are
retrieved

• Resident membrane proteins and cycling proteins
  are retrieved to the ER by a dibasic signal in
  the cytoplasmic tail.
• The ER retrieval signal for type I transmembrane
  proteins is a dilysine signal.
• Type II transmembrane proteins have a diarginine
  signal.

18
4.8 COPI-coated vesicles mediate retrograde
transport from the Golgi apparatus to the ER

• COPI coat assembly is triggered by a
  membrane-bound GTPase called ARF.

19
4.8 COPI-coated vesicles mediate retrograde
transport from the Golgi apparatus to the ER

• ARF recruits coatomer complexes, and disassembly
  follows GTP hydrolysis.
• COPI coats bind directly or indirectly to cargo
  proteins that are returned to the endoplasmic
  reticulum from the Golgi apparatus.

20
4.9 There are two popular models for forward
transport through the Golgi apparatus

• Transport of large protein structures through the
  Golgi apparatus occurs by cisternal maturation.
• Individual proteins and small protein structures
  are transported through the Golgi apparatus
  either by cisternal maturation or
  vesicle-mediated transport.

21
4.10 Retention of proteins in the Golgi apparatus
depends on the membrane-spanning domain

• The membrane-spanning domain and its flanking
  sequences are sufficient to retain proteins in
  the Golgi apparatus.
• The retention mechanism for Golgi proteins
  depends on the ability to form oligomeric
  complexes and the length of the membrane-spanning
  domain.

22
4.11 Rab GTPases and tethers are two types of
proteins that regulate vesicle targeting

• Monomeric GTPases of the Sar/ARF family are
  involved in generating the coat that forms
  transport vesicles.
• Another family, the Rab GTPases, are involved in
  targeting these vesicles to their destination
  membranes.

23
4.11 Rab GTPases and tethers are two types of
proteins that regulate vesicle targeting

• Different Rab family members are found at each
  step of vesicle-mediated transport.
• Proteins that are recruited or activated by Rabs
  (downstream effectors) include
• tethering proteins such as long fibrous proteins
• large multiprotein complexes
• Tethering proteins link vesicles to membrane
  compartments and compartments to each other.

24
4.12 SNARE proteins likely mediate fusion of
vesicles with target membranes

• SNARE proteins are both necessary and sufficient
  for specific membrane fusion in vitro, but other
  accessory proteins may be needed in vivo.
• A v-SNARE on the transport vesicle interacts with
  the cognate t-SNARE on the target membrane
  compartment.

25
4.12 SNARE proteins likely mediate fusion of
vesicles with target membranes

• The interaction between v- and t-SNAREs is
  thought to bring the membranes close enough
  together so that they can fuse.
• After fusion
• the ATPase NSF unravels the v- and t-SNAREs
• the v-SNAREs are recycled to the starting
  membrane compartment

26
4.13 Endocytosis is often mediated by
clathrin-coated vesicles

• The stepwise assembly of clathrin triskelions may
  help provide the mechanical means to deform
  membranes into coated pits.
• Various adaptor complexes provide the means of
  selecting cargo for transport by binding both to
• sorting signals
• clathrin triskelions

27
4.13 Endocytosis is often mediated by
clathrin-coated vesicles

• GTPases of the dynamin family help release the
  coated vesicle from the membrane.
• Uncoating ATPases remove the clathrin coat before
  docking and fusion.

28
4.14 Adaptor complexes link clathrin and
transmembrane cargo proteins

• Adaptor complexes bind to
• the cytoplasmic tails of transmembrane cargo
  proteins
• clathrin
• Phospholipids
• Adaptors of the AP family are heterotetrameric
  complexes of two adaptin subunits and two
  smallerproteins.

29
4.14 Adaptor complexes link clathrin and
transmembrane cargo proteins

• The AP adaptors bind to sorting signals in the
  cytoplasmic tails of cargo proteins.
• The best-characterized of these signals contain
  tyrosine or dileucine residues.
• Adaptor complexes allow for the selective and
  rapid internalization of receptors and their
  ligand.

30
4.15 Some receptors recycle from early endosomes
whereas others are degraded in lysosomes

• Early endosomes are mildly acidic and lack
  degradative enzymes, so
• internalized ligands can be dissociated without
  degradation of their receptors.
• Many receptors are recycled to the cell surface
  in transport vesicles that bud from the tubular
  extensions of early endosomes.

31
4.15 Some receptors recycle from early endosomes
whereas others are degraded in lysosomes

• Dissociated ligands are transferred from early
  endosomes to the more acidic and hydrolase-rich
  late endosomes and lysosomes for degradation.
• Receptors that are not recycled
• are segregated into vesicles within
  multivesicular bodies
• move to late endosomes and lysosomes for
  degradation

32
4.15 Some receptors recycle from early endosomes
whereas others are degraded in lysosomes

• Recycling endosomes are found adjacent to the
  nucleus.
• They contain a pool of recycling receptors that
  can be transported rapidly to the cell surface
  when needed.

33
4.16 Early endosomes become late endosomes and
lysosomes by maturation

• Movement of material from early endosomes to late
  endosomes and lysosomes occurs by maturation.
• A series of ESCRT protein complexes sorts
  proteins into vesicles that bud into the lumen of
  endosomes.
• This forms multivesicular bodies that facilitate
  the process of proteolytic degradation.

34
4.17 Sorting of lysosomal proteins occurs in the
trans-Golgi network

• All newly synthesized membrane and secretory
  proteins share the same pathway up until the TGN.
• There they are sorted according to their
  destinations into different transport vesicles.
• Clathrin-coated vesicles transport lysosomal
  proteins from the trans-Golgi network to maturing
  endosomes.

35
4.17 Sorting of lysosomal proteins occurs in the
trans-Golgi network

• In the Golgi apparatus, mannose 6-phosphate is
  covalently linked to soluble enzymes destined for
  lysosomes.
• The mannose 6-phosphate receptor delivers these
  enzymes from the trans-Golgi network to the
  endocytic pathway.

36
4.17 Sorting of lysosomal proteins occurs in the
trans-Golgi network

• Lysosomal membrane proteins are transported from
  the trans-Golgi network to maturing endosomes.
• But, they use different signals than the soluble
  lysosomal enzymes.

37
4.18 Polarized epithelial cells transport
proteins to apical and basolateral membranes

• The plasma membrane of a polarized cell has
  separate domains with distinct sets of proteins.
• This necessitates a further sorting step.
• Depending on the cell type, sorting of cell
  surface proteins in polarized cells can occur at
• the TGN
• endosomes
• one of the plasma membrane domains
• Sorting in polarized cells is mediated by
  specialized adaptor complexes and perhaps lipid
  rafts and lectins.

38
4.19 Some cells store proteins for later secretion

• Some cargo molecules are stored in secretory
  granules, which
• fuse with the plasma membrane
• release their contents only upon stimulation
• Storage of proteins for regulated secretion often
  involves a condensation process.
• Cargo self-associates, condensing to form a
  concentrated packet for eventual delivery to the
  outside of the cell.

39
4.19 Some cells store proteins for later secretion

• Condensation of proteins for regulated secretion
  often
• begins in the endoplasmic reticulum
• continues in the Golgi apparatus
• is completed in condensing vacuoles that finally
  yield secretory granules
• Condensation is accompanied by selective membrane
  retrieval at all stages of exocytosis.

40
4.19 Some cells store proteins for later secretion

• Fusion of synaptic vesicles with the plasma
  membrane involves SNARE proteins.
• But it is regulated by calcium-sensitive proteins
  such as synaptotagmin.
