Storage Area Networks and Fibre Channel

1
Storage Area Networks and Fibre Channel

• Steven Wilson
• Preetham Gopalaswamy
• Brocade Communications Systems, Inc.

2
Todays Topics

• Storage Area Networks
• Fibre Channel Technology
• Fibre Channel Management
• Common Information Model (CIM)

3
The Server-to-Storage Bottleneck
4
1990s Technology Does Not Scale
5
What is a SAN?

• Open Systems Model for Network Storage
• Enhanced Storage Management
• Flexibility to add or reconfigure storage as
  needed without downtime
• Independent Scaling of CPU and Storage capacity
• De-couples servers and storage so that either can
  be scaled separately
• Easy Migration
• Current applications run without software changes
• Incremental deployment allows flexible adoption

6
SAN Benefits

• Dynamic Allocation of Resources (storage and
  applications)
• High Data/Application Availability
• Non-disruptive Maintenance
• Continuous operations if server or storage has to
  be removed from cluster
• Add, delete storage on the fly
• Cost Savings
• Shared Storage

7
What is Fibre Channel

• Open standard, ratified in 1993
• Optimized for large block transfer with built-in
  reliability
• Distance¾for disaster tolerant configurations
• Independent scaling of servers and
  storage¾creating the virtual private data
  center/Virtual Private SANs
• Adopts legacy environments and applications
• Concurrency of networking and storage protocols
  on single NIC¾reducing costs of ownership SCSI,
  IP, VI, FICON, Etc.
• Single technology for server-storage area
  networking, clustering (server-server)

8
Fibre Channel Standards Activities
T11

• Fibre Channel transport,Topology, Generic
  Services, physical, media standards

SNIA

• SAN Application,discovery,security, management
  Standards. Not yet an accredited standards body,
  but provides input to other standards bodies

IETF

• IP related standards and MIBs and Storage over IP
  efforts

T10

• SCSI storage protocols for Fibre Channel and
  others

DMTF

• Fibre Channel work group, Common Information
  Model (CIM)

FCIA

• Fibre Channel technology road maps,
  interoperability specifications and plug-fests

9
Important T11 Standards

• FC-FS Framing and Signaling, Replaces FC-PH,
  FC-PH-2, and FC-PH-3
• FC-SW-2 and FC-SW-3 Switch Fabric Standard,
  Describes How Switches Communicate with One
  Another
• FC-GS-3 and FC-GS-4 Generic Services, Describes
  the Well-Known Server Architecture and Related
  Transports
• FC-BB-2 Backbone, Describes How Fibre Channel
  Frames are Transported Over WAN Connections
• FC-MI Methodologies for Interconnects,
  Interoperability Profile, FC HBA API
• FC-SP Security Protocols, Authentication,
  Authorization, Policy Management, Confidentiality

10
Fibre Channel- Hybrid Transport System -
11
Multiple Protocols On Common Fibre Channel
Transport
Multiple Mapping Standards
Streams Transfer
FICON
CT
Single Transport Standard
10 GB
12
FC-0

• Physical Variants
• Optical (Laser, LED)
• Copper (Coax, Twisted Pair)
• Single Mode vs Multi-mode Fibre

13
FC-1

• 8B10B Encoding
• Running Disparity
• Ensures Virtually An Equal Number of 1s and 0s
• DC-Balanced
• Facilitates Amplifier Design Lower Power
• Ensures Synchronization For Clocking Purposes
• IBM Holds the Patent

14
Fibre Channel Information Transfer FC-2
Layer¾Framing and Protocol
Sequence 3
Sequence 2
Packets (Large Blocks)
Exchange (Protocol Operation)
Sequence 1
Sequence
FC Frame (Max. 2112 Bytes)
Device 2
(server/storage/WS)
Device 1
(server/storage/WS)
15
FC-4 Mappings

• Maps Upper Level Protocols to Fibre Channel
• Examples are SCSI, IP, VI, FICON
• FC-CT is Mapped for Inband Management Use

16
Fibre Channel Ports and Nodes

• N_Port, NL_Port, F_Port, FL_Port, E_Port, B_Port
• Each Nx_Port Has a Fabric Unique 24 Bit Address
• Each Nx_Port Has a Unique WWN
• Nx_Ports Must Login With One Another Prior to
  Data Transfer
• When a Fabric Exists, Ports Also Login to the
  Fabric
• A Node is a Collection of Ports
• Each Node Has a Unique WWN

17
Data Transport Services- Meet Different
Application Needs -
18
Fibre Channel Topologies

• Point-to-point¾two devices connected together

19
Fibre Channel Topologies

• Arbitrated loop
• Up to 126 devices on a shared media for small
  systems at reduced cost and reduced performance
  level

20
Fibre Channel Topologies¾the Fabric

• Large connectivity on non-shared media, which
  allows concurrent communicating pairs
• Highest performance level
• High scalability
• Good fault isolation
• Embedded management and services

21
Fibre Channel Services

• Login Server
• Fabric Controller
• Common Transport
• Name Server
• Alias Server
• Time Server
• Management Server

22
Port Interfaces
NL_Port
F_Port
N_Port
23
Point-to-Point Remote Connection between Fibre
Channel Systems Through WAN
Fibre Channel switch
Fibre Channel switch
ATM/ SONET/IP network
Fibre Channel switch
FC-BB-2 and FCIP Standards
Fibre Channel switch

• Remote Backup
• Remote Mirroring
• Disaster Recovery

WTU Wan Tunneling Unit
24
Characteristics of FC Switches

• Switches Connect to One Another Using E_Ports and
  Inter Switch Links (ISLs)
• Switches Route Frames Based on the 24 Bit DID
• DID Consists of 8 Bit Domain ID, 8 Bit Area ID,
  and 8 Bit Port ID
• Each Switch Has a Unique Domain ID (239 Max)
• Switch to Switch Communication Uses Class F Which
  is Similar to Class 2
• Switches Implement a Fabric Controller and other
  Well-Known Servers
• Switches Allow Inband and Out-Band Management

25
Functions of the Fabric

• Switch Port Initialization
• Fabric Configuration
• FSPF
• Zoning
• Distributed Server
• RSCN

26
Zoning

• Similar To VLANs in the Networking World
• Provides an Access Control Mechanism
• Allows End-Devices to Only Communicate With
  End-Devices in the Same Zone
• Two Types of Enforcement
• Hard
• Soft
• Affects the Discovery Process
• May Eventually be Applied to Resources Behind the
  N_Port (e.g. LUNs)

27
Zoning Structure
28
Fibre Channel Generic Services

• Registry and directory service to discover nodes
  and their attributes (connected to Fabric)
• Integrated with Fabric and
• Distributed
• Operational in Nature

• Registration and discovery of Switches, Fabric
  ports and their attributes.
• Configuration Management
• Fabric Device Management
• Zone Management
• Integrated with Fabric and
• distributed

• Discovery of Physical topology
• Discovery of Logical association between devices
• Acquires topology information from Simple Name
  Service and Management service

N_Port
FC-GS-3 FC-GS-4 Standards
Fibre Channel Fabric (Distributed Services)
N_Port
N_Port
29
Brocade Software Stack
S A M S
Kernel Drivers
Platform Group
OS Kernel
Hardware
30
Traditional Fibre Channel Management

• Common Transport (FC-CT)
• Standardized Native Inband Management
• IP over FC
• Proprietary In-band Management
• WEB Based Management
• Out of Band Proprietary Management
• SNMP
• Standardized (Almost) Out of Band Management
• Telnet/CLI
• Proprietary Out of Band Management
• API Based Management
• Proprietary Management Out of Band Management

31
Post Modern Fibre Channel Management

• Object Based Management
• CIM/WBEM (Web-based Enterprise Management)
• Combines Management Capabilities Exposed Through
  Other Interfaces
• CIM Capabilities Can be Provided By Agents or
  Integrated Directly Into SAN Products

32
Managing Brocade Fabrics
API
SNMP
WebTools
Fabric Manager
Management Agent
Brocade Data Model
Fabric
RPCd
SNMPd
HTTPd
Switch Unified Data Access Layer
33
CIM Common Information Model

• It is a Data Model, not an implementation
• There are two parts to CIM
• The CIM Specification
• CIM Schema
• CIM Specification (currently 2.2) describes the
  language, naming, Meta Schema (a formal
  definition of the model)
• Formal definition of the CIM Schema is expressed
  in a Managed Object File (MOF)

34
Everything about CIMthat you really did not want
to ask
35
Everything about CIMthat you really did not want
to ask

• Objects have inheritance
• Abstract and Concrete
• Objects have methods Intrinsic and Extrinsic
• Objects can maintain backward compatibility and
  support deprecation
• Associations are objects which means they can
  have properties
• Events are Objects
• CIM Schema provides the actual model descriptions
• Core Schema
• Common Schema (System, Network, Devices,)
• Extension Schema
• CIM 2.7 has simplified the Fibre Channel model
  and added Zoning

36
Everything about CIMthat you really did not want
to ask

• The methods supported by a class vary with what
  interfaces/interface methods a given provider
  supports for that class.
• Instance Provider
• deleteInstance
• createInstance
• getInstance
• setInstance
• enumerateInstanceNames
• enumerateInstances
• PropertyProvider
• setProperty
• getProperty
• Method Provider
• invokeMethod
• Query Provider
• invokeQuery

37
CIM-based Management Solution
Access Protocol and Data Format
Data Information Model
Customer Deliverables
Agent
Client I/F
Object Manager
Higher Level Services
Provider I/F
Device Provider
Fabric Data Access
Fabric Layer
38
Peeking under the hood
To Provider
Host
Fabric
RPC Daemon
Http Daemon
SNMP Agent
39
Why move to a CIM-agent solution?

• Looser linkage between application and Brocade
  library
• Less integration headaches
• More flexible application interfaces (i.e. java
  and other compilation environments)
• Agent can support multiple applications
  simultaneously
• Delivers a standards-compatible interface (e.g.
  CIM)

40
Questions
41
Thank You!
