Socket Programming

1
Socket Programming

• CS 204 Advanced Programming
• Erkay Savas
• Expanded by Berrin Yanikoglu (2nd half)

2
Overview of Network Protocols

• The Internet is a collection of networks,
  including local networks at a number of
  University and research institutions, and a
  number of military networks. The term "Internet"
  applies to this entire set of networks.
• All of these networks are connected to each
  other. Users can send messages from any of them
  to any other, except where there are security or
  other policy restrictions on access.
• The "Internet protocol suite is a set of
  protocols developed to allow cooperating
  computers to communicate and share resources
  across a network.
• TCP and IP are two protocols in this suite.

3
Overview of Network Protocols

• IP, TCP, and UDP provide "low- level" functions
  needed for many applications. Other protocols are
  for specific tasks, e.g. transferring files
  between computers (FTP), sending mail (SMTP)

4
ftp server
telnet server
web server
5
A TCP/IP Network
application
TCP
IP
(e.g. Ethernet)
Router
6
Communication Protocols
Application protocol
Web client
Web server
HTTP
7

• The application protocols run "on top" of
  TCP/IP.
• They open a connection to a specified computer,
  log into it, tell it what file you want, and
  control the transmission of the file.
• When they want to send a message, they give the
  message to TCP.
• Because TCP and IP take care of all the
  networking details, the applications protocols
  can treat a network connection as if it were a
  simple byte stream, like a terminal or phone
  line.

8
Internet Protocol Suite

• Application protocol such as HTTP, FTP
• TCP (the "transmission control protocol")
  responsible for breaking up the message into
  datagrams, reassembling them at the other end,
  resending what gets lost, and putting things back
  in the right order.
• Information is transfered as a sequence of
  "datagrams (a collection of data sent as a
  single message) that are sent through the network
  individually. Datagrams can come in any order and
  are reordered at the receiving end.
• TCP puts a header at the front of each datagram.
  This header actually contains at least 20 octets,
  but the most important ones are a source and
  destination "port number, a "sequence number
  and a checksum. The port numbers are used to
  keep track of different conversations. Suppose 3
  different people are transferring files. Your TCP
  might allocate port numbers 1000, 1001, and 1002
  to these transfers.
• IP (the "internet protocol") responsible for
  routing individual datagrams, often over several
  networks.
• Find a route for the datagram and get it to the
  other end.
• In order to allow gateways or other intermediate
  systems to forward the datagram, it adds its own
  header. The main things in this header are the
  source and destination Internet address (32-bit
  addresses, like 128.6.4.194), the protocol
  number, and another checksum.

9
Internet Protocol Suite

• Ethernet is a "broadcast medium".
• When you send a packet out on the Ethernet, every
  machine on the network sees the packet. So
  something is needed to make sure that the right
  machine gets it. As you might guess, this
  involves the Ethernet header.
• Every Ethernet packet has a 14-octet header that
  includes the source and destination Ethernet
  address, and a type code. Each machine is
  supposed to pay attention only to packets with
  its own Ethernet address in the destination
  field.
• Note that there is no connection between the
  Ethernet address and the Internet address.
• When these packets are received by the other end,
  all the headers are removed.
• The Ethernet interface removes the Ethernet
  header and the checksum. It looks at the type
  code. Since the type code is the one assigned to
  IP, the Ethernet device driver passes the
  datagram up to IP.
• IP removes the IP header. It looks at the IP
  protocol field. Since the protocol type is TCP,
  it passes the datagram up to TCP.
• TCP now looks at the sequence number. It uses the
  sequence numbers and other information to combine
  all the datagrams into the original file.

10
Application Layer

• Suppose you want to send a file to a computer
  whose Internet address is 128.6.4.7. To start the
  process, you need more than just the Internet
  address. You have to connect to the FTP server at
  the other end.
• In general, network programs are specialized for
  a specific set of tasks. Most systems have
  separate programs to handle file transfers,
  remote terminal logins, mail, etc.
• When you connect to 128.6.4.7, you have to
  specify that you want to talk to the FTP server.
• Recall that TCP uses port numbers to keep track
  of individual conversations. User programs
  normally use more or less random port numbers.
  However specific port numbers are assigned to the
  programs that sit waiting for requests.
• For example, if you want to send a file, you will
  start a program called "ftp". It will open a
  connection using some random number, say 1234,
  for the port number on its end. However it will
  specify port number 21 for the other end. This is
  the official port number for the FTP server.
• Note that there are two different programs
  involved.
• You run ftp on your side. This is a program
  designed to accept commands from your terminal
  and pass them on to the other end.
• The program that you talk to on the other machine
  is the FTP server. It is designed to accept
  commands from the network connection, rather than
  an interactive terminal. There is no need for
  your program to use a well-known socket number
  for itself. Nobody is trying to find it. However
  the servers have to have well-known numbers, so
  that people can open connections to them and
  start sending them commands. The official port
  numbers for each program are given in "Assigned
  Numbers".

11
Application Protocol (what is a protocol?)

• Once TCP has opened a connection, we have
  something that might as well be a simple wire.
  All the hard parts are handled by TCP and IP.
  However we still need some agreement as to what
  we send over this connection (this is the
  protocol). In effect this is simply an agreement
  on what set of commands the application will
  understand, and the format in which they are to
  be sent. Generally, what is sent is a combination
  of commands and data. They use context to
  differentiate.
• For example, the mail protocol works like this
• Your mail program opens a connection to the mail
  server at the other end.
• Your program then sends the mail server
• your machine's name,
• the sender of the message, and
• the recipients you want it sent to.
• It then sends a command saying that it is
  starting the message. At that point, the other
  end stops treating what it sees as commands, and
  starts accepting the message. Your end then
  starts sending the text of the message.
• At the end of the message, a special mark is sent
  (a dot in the first column).
• After that, both ends understand that your
  program is again sending commands. This is the
  simplest way to do things, and the one that most
  applications use.

12
TSP/IP Highlights

• In the Internet protocol suite, TCP is the
  intermediate layer between the Internet Protocol
  (IP) below it, and an application above it.
  Applications often need reliable pipe-like
  connections to each other, whereas the Internet
  Protocol does not provide such streams, but
  rather only best effort delivery (i.e.,
  unreliable packets).
• The Transmission Control Protocol (TCP)
  guarantees reliable and in-order delivery of data
  from sender to receiver.
• TCP also distinguishes data for multiple
  connections by concurrent applications (e.g., Web
  server and e-mail server) running on the same
  host.
• Applications send byte streams to TCP for
  delivery through the network, and TCP divides the
  byte stream into appropriately sized segments.
  TCP then passes the resulting packets to the
  Internet Protocol, for delivery through a network
  to the TCP module of the entity at the other end.

• TCP checks to make sure that no packets are lost
  by giving each packet a sequence number, which is
  also used to make sure that the data are
  delivered to the entity at the other end in the
  correct order. The TCP module at the far end
  sends back an acknowledgement for packets which
  have been successfully received.

13
Alternatives to TCP

• For many applications TCP is not appropriate. One
  big problem is that the application cannot get to
  the packets that come after a lost packet, until
  the retransmitted copy of the lost packet is
  received. This causes problems for real-time
  applications such as streaming multimedia (such
  as Internet radio) and voice over IP (VoIP) where
  it is sometimes more useful to get most of the
  data in a timely fashion than it is to get all of
  the data in order.
• Where TCP is unsuitable, the User Datagram
  Protocol (UDP) is used. This provides the
  application multiplexing and checksums that TCP
  does, but does not handle building streams or
  retransmission, giving the application developer
  the ability to code those in a way suitable for
  the situation and/or to replace them with other
  methods like forward error correction or
  interpolation.

14
What is a Socket?

• An Internet socket (or commonly, a network socket
  or socket) is the endpoint of a bidirectional
  communication flow across an Internet
  Protocol-based computer network, such as the
  Internet.
• Sockets are a software interface that connects an
  application program to a network protocol.
• Two processes can communicate by creating sockets
  and sending messages through sockets
• Information written to a socket by an application
  on one machine can be read by an application on
  another machine, and vice versa.

15

• Communicating local and remote sockets are called
  socket pairs. Each socket pair is described by a
  unique 4-tuple struct consisting of source and
  destination IP addresses and port numbers, i.e.
  of local and remote socket addresses.
• There are two important socket types
• stream sockets (uses TCP is reliable)
• datagram sockets (uses UDP)

16
Socket API (1)
TCP ports
IP
17
Overview

• Steps of a TCP Server
• socket() - Get a socket
• bind() - bind to the socket
• listen() - listen for traffic on the socket
• accept() - accept incoming connections on the
  socket
• recv() - receive incoming traffic
• send() - send traffic to connection
• Steps of a TCP Client
• socket() - Get a socket
• connect() - Connect to a server
• send() - send traffic to server
• recv() - receive traffic from server

18

• socket() creates a new socket of a certain socket
  type, identified by an integer number, and
  allocates system resources to it.
• bind() is used on the server side, and associates
  a socket with a socket address structure, i.e. a
  specified local port number and IP address.
• listen() is used on the server side, and causes a
  bound TCP socket to enter listening state.
• connect() is used on the client side, and assigns
  a free local port number to a socket. In case of
  a TCP socket, it causes an attempt to establish a
  new TCP connection.
• accept() is used on the server side. It accepts a
  received incoming attempt to create a new TCP
  connection from the remote client, and creates a
  new socket associated with the socket address
  pair of this connection.
• send() and recv(), or write() and read(), or
  recvfrom() and sendto(), are used for sending and
  receiving data to/from a remote socket.
• close() causes the system to release resources
  allocated to a socket. In case of TCP, the
  connection is terminated.

19
Defining a Socket

• Defining a socket
• include ltsys/types.hgt
• include ltsys/socket.hgt
• int mySocket // a socket descriptor
• SOCKET mySocket // using winsock.h
• CSocket mySocket // MFC sockets

20
Creating a Socket
int socket(int protocolFamily,int type,int
protocol)

• First parameter usually PF_INET
• Second parameter socket type
• SOCK_STREAM (TCP)
• SOCK_DGRAM (UDP)
• Third parameter end-to-end protocol.
• Use constants IPPROTO_TCP or IPPROTO_UDP for TCP
  or UDP.
• Return value is an integer.
• A nonnegative value mean success and can be used
  as a handle (similar to file descriptor)
• (-1) indicates a failure

mySocket socket(PF_INET, SOCK_STREAM,
IPPROTO_TCP)
21
Socket API
mySocket socket(PF_INET, SOCK_STREAM,
IPPROTO_TCP)

• Sockets API provides a generic interface for a
  large number of protocol families.
• PF_INET for network protocol
• PF_INET6
• PF_UNIX for local socket (using a file).
• Usually, PF_INET is used to specify a socket that
  uses protocols from the Internet protocol family.

22
Socket Addressing
mySocket socket(PF_INET, SOCK_STREAM,
IPPROTO_TCP)

• When a socket is first created, it has an
  associated protocol but no IP address or port
  number
• A socket descriptor is used by the application to
  identify a socket (similar to a file descriptor)
• So it can be closed later
• A socket is later bound to an address and a port
  number
• Otherwise it cannot send/receive messages

23
Addresses

• Needed to locate applications running on other
  machines
• Two pieces of address in TCP/IP
• Internet (or IP) address
• 32-bit binary number (Four 8-bits number)
• dotted-quad notation (e.g. 10.1.2.3)
• refer to a connection (thus, a host can have more
  than one IP address)
• Port number
• 16-bit unsigned numbers (1 to 65535)
• used by UDP and TCP
• There are multiple ways to specify an address for
  a socket
• // include ltarpa/inet.hgt
• Res inet_pton(AF_INET, "192.168.1.3",
  stSockAddr.sin_addr)

24
Internet Addresses

• This is an address that looks like 128.6.4.194.
  It is actually a 32-bit number. However it is
  normally written as 4 decimal numbers, each
  representing 8 bits of the address.
• The term "octet" is used by Internet
  documentation for such 8-bit chunks. The term
  "byte" is not used, because TCP/IP is supported
  by some computers that have byte sizes other than
  8 bits.)
• Generally the structure of the address gives you
  some information about how to get to the system.
  For example,
• 128.6 is a network number assigned by a central
  authority to Rutgers University.
• Rutgers uses the next octet to indicate which of
  the campus Ethernets is involved. 128.6.4 happens
  to be an Ethernet used by the Computer Science
  Department.
• The last octet allows for up to 254 systems on
  each Ethernet.

25
Ethernet Addresses Advanced (you may skip)

• This is a 48-bit number that is unique to the
  Ethernet controller.
• The people who designed Ethernet wanted to make
  sure that no two machines would end up with the
  same Ethernet address. Furthermore, they didn't
  want the user to have to worry about assigning
  addresses. So each Ethernet controller comes with
  an address built-in from the factory. In order to
  make sure that they would never have to reuse
  addresses, the Ethernet designers allocated 48
  bits for the Ethernet address.
• People who make Ethernet equipment have to
  register with a central authority, to make sure
  that the numbers they assign don't overlap any
  other manufacturer.

26
Specifying Addresses

• Applications using sockets need to specify
  Internet addresses and port numbers to the
  kernel.
• A client must specify the address of a server
  application with which it needs to communicate.
• The sockets API defines a generic data type for
  specifying addresses associated with sockets

struct sockaddr / Structure used by kernel to
store most addresses / unsigned short
sa_family / Address family (AF_INET)/ char
sa_data14 / Family-specific address
/ /
information /
27
Internet Address Structure
struct sockaddr_in /socket address
internet style / unsigned short sin_family
/ Address family (AF_INET)/ unsigned short
sin_port / Address port (16 bits) / struct
in_addr sin_addr / Internet Addr (32 bits
/ char sin_zero8 / Not
used/ struct in_addr unsigned long s_addr
28
Details of the Address Structure

• These are details showing you that the address
  structure are defined as a union to be used in
  different ways. But you can specify a given IP
  number easily through several Winsock functions.
• struct in_addr
• union struct u_char s_b1,s_b2,s_b3,s_b4
  S_un_b
• struct u_short s_w1,s_w2 S_un_w
• u_long S_addr
• S_un
• define s_addr S_un.S_addr
• struct sockaddr_in
• short sin_family
• u_short sin_port
• struct in_addr sin_addr
• char sin_zero8

The union stores one of the values defined by
that type 4 bytes or 2 words or 1 long.
You can also set the address using the Winsock
function inet_pton(AF_INET, "192.255.100.4",
stSockAddr.sin_addr)
29
gethostname gethostbyname

• The gethostname() function retrieves the standard
  host name for the local computer (localhost)
• The gethostbyname() function retrieves host
  information corresponding to a host name string
  from a host database.
• You can for instance get your host name, and then
  call gethostbyname() to find out your IP address.


30
inet_addr

• The inet_addr function converts a string
  containing an IPv4 dotted-decimal address into a
  proper address for the IN_ADDR structure.
• unsigned long inet_addr( const char cp )
• If no error occurs, inet_addr returns an unsigned
  long value containing a suitable binary
  representation of the Internet address given.
• Declared in winsock2.h
• If the string in the cp parameter does not
  contain a legitimate Internet address, for
  example if a portion of an "a.b.c.d" address
  exceeds 255, then inet_addr returns the value
  INADDR_NONE.
• http//msdn.microsoft.com/en-us/library/ms738563(V
  S.85).aspx
• USE inet_ntop or inet_pton that replaced these
  functions

31
Gethost demo

• char buffer128
• //gets the name of the localhost
• gethostname (buffer,strlen(buffer))
• printf("My hostname s\n", buffer)
• //fills in the hostent structure (see next
  slide)
• //with the host name
• HOSTENT  lpHostEnt gethostbyname(buffer)

32
(No Transcript)
33
Hostent structure

• typedef struct hostent
• char FAR h_name
• char FAR FAR h_aliases
• short h_addrtype
• short h_length
• char FAR FAR h_addr_list
• HOSTENT, PHOSTENT, FAR LPHOSTENT
• Note that the possible names we can use for this
  struct.

34
Getting the Host AddressOther Useful Functions

• The getaddrinfo function provides
  protocol-independent translation from host name
  to address.
• Prototype
• int getaddrinfo( const char nodename, const
  char servname, const
  struct addrinfo hints, struct addrinfo res)
• Parameters
• nodename Pointer to a null-terminated string
  containing a host (node) name or a numeric host
  address string. The numeric host address string
  is a dotted-decimal IPv4 address or an IPv6 hex
  address.
• servname Pointer to a null-terminated string
  containing either a service name or port number.
• hints Pointer to an addrinfo structure that
  provides hints about the type of socket the
  caller supports.
• res out Pointer to a linked list of one or
  more addrinfo structures containing response
  information about the host.

This function replaces (is the new version for)
the gethostbyname function (which is commonly
used). See sample codes for complete solutions
for obtaining or setting addresses.
35
Resolving Host Addresses

• Code from MSDN library to handle different ways
  the address structure can be filled (given a host
  name or an IP address). You do not need to be
  this complete (in error types or diff address
  families).
• include ltwinsock2.hgt
• include ltws2tcpip.hgt
• include ltstdio.hgt
• include ltwindows.hgt
• pragma comment(lib, "wininet.lib")
• int main(int argc, char argv)
• //-----------------------------------------
• // Declare and initialize variables
• WSADATA wsaData
• int iResult
• DWORD dwError
• int i 0

• // If the user input is an alpha name for the
  host, use gethostbyname()
• // If not, get host by addr (assume IPv4)
• if (isalpha(host_name0)) / host
  address is a name /
• remoteHost gethostbyname(host_name)
• else
• addr.s_addr inet_addr(host_name)
• if (addr.s_addr INADDR_NONE)
• printf("The IPv4 address
  entered must be a legal address\n")
• return 1
• else
• remoteHost
  gethostbyaddr((char ) addr, 4, AF_INET)
• if (remoteHost NULL)
• dwError WSAGetLastError()
• if (dwError ! 0)
• if (dwError WSAHOST_NOT_FOUND)
• printf("Host not found\n")
• return 1

36
Windows Sockets Client Example 1

• Example
• //Create a socket
• SOCKET theSocket socket (PF_INET,
  SOCK_STREAM,
  IPPROTO_TCP)
• SOCKADDR_IN saServer
• saServer.sin_family AF_INET
• //retrieve host information corresponding to
  host name string
• LPHOSTENT lpHostEntry gethostbyname(serverName)

• //set the Servers address and port
• saServer.sin_addr.s_addr ((LPIN_ADDR)lpHostEn
  try-gth_addr_list)
• //convert 32-bit values between host and network
  byte order
• saServer.sin_port htons(nPort)

37
htons

• Htons() converts a u_short from host to TCP/IP
  network byte order (which is big-endian).
• Little Endian (Little End In) the least
  significant bytes are stored first in memory
• the Hex value 0x1234 is stored in memory as (0x34
  0x12).
• the Hex value 0x12345678 would be stored as (0x78
  0x56 0x34 0x12).
• Big Endian (BigEnd In) Most significant bytes
  are stored first
• 0x1234 is stored as (0x12 0x34) in memory.

38
(No Transcript)
39
Client
40
TCP Client

• A typical TCP client goes through four basic
  steps
• Create a TCP socket using socket().
• Establish a connection to the server using
  connect().
• Communicate using send() and recv().
• Close the connection with close().

41
Functions for TCP Client - 1/2
int socket(int protocolFamily, int type, int
protocol)
int connect(int socket, struct sockaddr
serverAddress, unsigned int addressLength)

• Parameters
• First parameterthe descriptor obtained as a
  return value of a successful socket creation
  operation
• Second parameter the address of the server (the
  struct data type must appropriately filled by the
  server address)
• Third parameter always use sizeof(sockaddr).

42
What Happens After Connect
socket()
connect()
When a socket is first created, queues
(illustrated above) are closed. During connect,
local port and local IP address is assigned to
it, as well as the remote IP/port.
43
Functions for TCP Client - 2/2
int send(int socket, constant void msg,
unsigned int msgLength, int
flags) http//msdn.microsoft.com/en-us/library/m
s740149(VS.85).aspx int recv(int socket, void
rcvBuffer, unsigned int
bufferLength, int flags) http//msdn.microsoft.c
om/en-us/library/ms740121(VS.85).aspx

• Default behavior for send() is to block until all
  of the data is sent
• Default behavior for recv() is to block until at
  least some bytes are received.
• flags (default 0) provides a way to change the
  default behavior
• If no error occurs, recv returns the number of
  bytes received and the buffer pointed to by the
  buf parameter will contain this data received. If
  the connection has been gracefully closed, the
  return value is zero. Otherwise, a value of
  SOCKET_ERROR is returned, and a specific error
  code can be retrieved by calling WSAGetLastError.
  If no incoming data is available at the socket,
  the recv call blocks and waits for data to arrive
  according to the blocking rules defined for
  WSARecv with the MSG_PARTIAL flag not set unless
  the socket is nonblocking.
• send() returns almost immediately, except when
  the send buffer is full. If the send buffer is
  full, send() blocks until the send buffer is
  freed to enqueue another packet. If no error
  occurs, send returns the total number of bytes
  sent, which can be less than the number requested
  to be sent in the len parameter. Otherwise, a
  value of SOCKET_ERROR is returned, and a specific
  error code can be retrieved by calling
  WSAGetLastError.

44
Server
45
TCP Server

• Four steps of constructing a TCP server
• Create a TCP socket using socket().
• Assign a (local) port number to the socket with
  bind().
• Tell the system to allow connections to be made
  to that port, using listen().
• Repeatedly do the following
• Call accept() to get a new socket for each client
  connection
• Communicate with the client via that new socket
  using send() and recv().

46
Bind

• int bind(int socket, struct sockaddr
  localAddress, unsigned int
  addressLength)

• First parameter the descriptor returned by an
  earlier call to socket().
• Second parameter a pointer to a sockaddr. For
  TCP/IP applications, it will actually point to a
  sockaddr_in containing IP address of the server
  and a port number to listen on
• Third parameter use sizeof(sockaddr_in)
• Return value 0 for success 1 for failure

47
Windows Sockets Server Example 1(code demoed
in class)

• SOCKET listenSocket
• listenSocket socket (PF_INET, // Address
  family
• SOCK_STREAM, // Socket type
• IPPROTO_TCP) // Protocol
• ...
• SOCKADDR_IN saServer
• saServer.sin_family AF_INET
• saServer.sin_addr.s_addr INADDR_ANY // Let
  WinSock supply address
• saServer.sin_port htons(nPort) // Use port
  from command line
• // bind the name to the socket
• int nRet bind (listenSocket, // Socket
• (LPSOCKADDR)saServer, // Our
  address
• sizeof(struct sockaddr)) // Size of address
  structure

48
Listen
int listen(int socket, int queueLimit)

• Incoming TCP connection requests will be handled
  and then queued for acceptance by the program
• The queueLimit specifies an upper bound on the
  number of incoming connections that can be
  waiting at any time
• The current socket is only used for listening to
  incoming connections and it is not used for
  sending and receiving actual data.

49
Server Side Under the Hood
socket()
bind()
listen()
50
Accept
int accept(int socket, struct sockaddr
clientAddress, unsigned int
addressLength)

• It removes one connection request from the queue.
• If no pending connections are present on the
  queue and the socket is not marked as
  non-blocking, accept() blocks until a connection
  is present.
• If the socket is marked as non-blocking and no
  pending connections are present on the queue,
  accept() returns an error.
• When successful, accept()
• creates a new socket with the same properties of
  socket, and returns a new handle to the socket
• fills in the sockaddr structure pointed by the
  clientAddress.
• returns a descriptor for a new socket that is
  connected to the client
• The accepted socket is used to read and write
  data to and from the socket that connected to it.
• The original socket is returned to the listening
  state.

51
Windows Sockets Server Example 2

• nRet listen (listenSocket, // Start listening
  to this socket
• SOMAXCONN) // Number of
  connection request queue
• ...
• SOCKET remoteSocket
• remoteSocket accept (listenSocket, //
  Listening socket
• NULL, // Optional client address
• NULL)
• ...

52
Server Side Under the Hood
listen()
accept()
53
Client/Server Interaction
54
TCP Server vs. TCP Client

• Creating the socket, sending, receiving, and
  closing are the same in both party.
• The differences
• The server binds an address to the socket
• By calling bind() function
• We say that the server listens to this address
• i.e. underlying TCP protocol implementation waits
  for connections from clients by calling listen()
  on the socket
• The server accepts the connection request
• It gets a new socket for the incoming connection
  by calling accept().

55
Review

• Steps of a TCP Server
• socket() - Get a socket
• bind() - bind to the socket
• listen() - listen for traffic on the socket
• accept() - accept incoming connections on the
  socket
• recv() - receive incoming traffic
• send() - send traffic to connection
• Steps of a TCP Client
• socket() - Get a socket
• connect() - Connect to a server
• send() - send traffic to server
• recv() - receive traffic from server

56
Windows Sockets

• Windows Sockets are based on the UNIX sockets
  implementation in the Berkeley Software
  Distribution (BSD, release 4.3)
• Two socket types are available
• Stream sockets provide for a data flow without
  record boundaries a stream of bytes. Streams
  are guaranteed to be delivered and to be
  correctly sequenced and unduplicated.
• Datagram sockets support a record-oriented data
  flow that is not guaranteed to be delivered and
  may not be sequenced as sent or unduplicated.
• Sequenced means that packets are delivered in
  the order sent.
• Unduplicated means that you get a particular
  packet only once.

57
Windows Sockets

• Both kinds of sockets are bi-directional they
  are data flows that can be communicated in both
  directions simultaneously (full-duplex).
• The network transport layer may break up or group
  data into packets of reasonable size.

58
Windows Sockets Client Example 1

• Example
• //Create a socket
• SOCKET theSocket socket (PF_INET,
  SOCK_STREAM,
  IPPROTO_TCP)
• SOCKADDR_IN saServer
• saServer.sin_family AF_INET
• //retrieve host information corresponding to
  host name string
• LPHOSTENT lpHostEntry gethostbyname(serverName)

• //set the Servers address and port
• saServer.sin_addr.s_addr ((LPIN_ADDR)lpHostEn
  try-gth_addr_list)
• //convert 32-bit values between host and
  network byte order
• saServer.sin_port htons(nPort)

59
Windows Sockets Client Example

• ...
• nRet connect (theSocket,
• (LPSOCKADDR)saServer, // Server address
• sizeof(struct sockaddr)) // Length
  of server address structure
• ...
• ...

60
Windows Sockets Client Example

• printf("Enter the data to be sent to the
  server(up to 256 bytes)\n")
• gets(szBuf)
• nRet send (theSocket, // Connected socket
• szBuf, // Data buffer
• strlen(szBuf), // Length of data
• 0) // Flags
• ...
• nRet recv (theSocket, // Connected client
• szBuf, // Receive buffer
• sizeof(szBuf), // Max length of
  buffer
• 0) // Flags
• ...
• closesocket(theSocket)

61
Windows Sockets Server Example 1(code demoed
in class)

• SOCKET listenSocket
• listenSocket socket (AF_INET, // Address
  family
• SOCK_STREAM, // Socket type
• IPPROTO_TCP) // Protocol
• ...
• SOCKADDR_IN saServer
• saServer.sin_family AF_INET
• saServer.sin_addr.s_addr INADDR_ANY // Let
  WinSock supply address
• saServer.sin_port htons(nPort) // Use port
  from command line
• // bind the name to the socket
• int nRet bind (listenSocket, // Socket
• (LPSOCKADDR)saServer, // Our
  address
• sizeof(struct sockaddr)) // Size of address
  structure

62
Windows Sockets Server Example 2

• nRet listen (listenSocket, // Start listening
  to this socket
• SOMAXCONN) // Number of
  connection request queue
• ...
• SOCKET remoteSocket
• remoteSocket accept (listenSocket, //
  Listening socket
• NULL, // Optional client address
• NULL)
• ...

63
Windows Sockets Server Example 3

• nRet recv (remoteSocket, // Connected client
• szBuf, // Receive buffer
• sizeof(szBuf), // Length of buffer
• 0) // Flags
• ...
• nRet send (remoteSocket, // Connected socket
• szBuf, // Data buffer
• strlen(szBuf), // Length of data
• 0) // Flags
• ...
• closesocket(remoteSocket)
• closesocket(listenSocket)

64
Winsock DLL

• The WSAStartup function must be the first Windows
  Sockets function called by an application or DLL.

• WORD wVersionRequested MAKEWORD(1,1)
• //include winsock.h if higher versions, may
  need winsock2.h
• WSADATA wsaData
• int nRet
• // Initialize WinSock and check version
• nRet WSAStartup(wVersionRequested, wsaData)
• if (wsaData.wVersion ! wVersionRequested)
• fprintf(stderr,"\n Wrong version\n")
• return
• Complete info (latest versions etc)
• http//msdn2.microsoft.com/en-us/library/ms742213.
  aspx

65
Winsock DLL

• The WSACleanup function terminates use of the
  Winsock 2 DLL (Ws2_32.dll).
• Sockets that were open when WSACleanup was called
  are reset and automatically deallocated as if
  closesocket were called.
• //Release Winsock DLL
• WSACleanup()
• Complete info (latest versions etc)
• http//msdn2.microsoft.com/en-us/library/ms741549.
  aspx

66

• You are given the necessary info to setup a
  socket connection
• You will need to check the MSDN documentation to
  find more details.

67

• We must close all opened sockets when done.
• Closing a socket

int close(int socket) //for UNIX int
closesocket(SOCKET socket) //for Windows

• the parameter is the socket descriptor obtained
  as return value of a successful socket creation
  operation
• Return value of (0) means success, (-1) indicates
  a failure

closesocket(mySocket)
68
Code Samples

• See the sample code in SocketExample
• This is a basic code using all of the Winsock API
  that is necessary to setup a very simple socket
  connection
• You are also shown hw5-2007
• You can run two versions of this program
  (hw5exe)
• Start one as server
• Star one as client (even though they are more
  like peers)
• Think about what are the threads running in this
  program
• One thread handles the user interface and does
  the send operation
• One thread listens to any incoming messages (from
  the other party)
• You should be able to answer the following
• How many threads do you need? For what?
• Can send and receive be in the same thread?

69
Hw5-2009
70
Socket Program Example

• Hw5 2007
• (Not this years homework)

71
Demo Hw5

• Run (using !) hw5-demo.exe
• Start as server
• Run (using !) hw5-demo.exe
• Start as client //must come after the server
• Draw shapes and see the server and client
  communicate
• Once the communication is done, each program
  should work as before , on its own

72
(No Transcript)
73
Hints Socket Class for Hw5

• class CClientSocket
• SOCKET mySocket
• int Port //port number
• char Server //server's name
• char Buffer //buffer is char array
• int MaxBuffer //maximum buffer
  size
• ..
• public
• CClientSocket(..) //constructor
• virtual CClientSocket() //destructor
• void Connect()
• int Read()
• void Send(.)
• //You will need to fill-in parameters where dots
  are.

74
Hints Starting as Server or Client

• Start as server or client
• client new CClientSocket("localhost",9999,256,
  this)
• server new CServerSocket(9999,256,this)
• You may connect to localhost which is a
  reserved name for your own computer (where the
  program refering to localhost is running)
• You may also connect to your friends machine as
  needed, by specifying the server (through command
  line arguments or program settings, as we have
  done before)

75
Hint Start as Server

• The relationship between the socket and thread
  may be as follows (but can be different as well)
• void CDrawViewOnStartAsServer()
• .
• //create a socket using arbitrary parameters
• server new CServerSocket(9999,1000,this)
• //Listen and accept
• server-gtListen()
• if(connected)
• MessageBox("A Client Connected") //inform the
  user
• myThread new CMyThread(this) //create
  thread to read messages
• myThread-gtStart() //start thread

76
Hint thread class

• class CMyThread
• public
• CMyThread(CDrawView parent) virtual
  CMyThread()
• int Start()
• void Run()
• void Close()
• private
• CDrawView Parent //handle to CDrawView
• static UINT ThreadFunc (LPVOID pParam)
• Note this is just one possibility, you can
  construct your thread differently

77
Hint thread class

• int CMyThreadStart()
• pThreadAfxBeginThread()
• UINT CMyThreadThreadFunc(LPVOID pParam)
• .
• You would need to fill these out, if you use this
  class given as hint.

78
Hints Starting as Server or Client

• void CMyThreadRun()
• char buffer
• while (1)
• try
• if (Parent-gtIsServer())
• nRet Parent-gtserver-gtRead(buffer)
• if (nRet -1)
• throw ..
• else
• nRet Parent-gtclient-gtRead(buffer)
• if (nRet -1)
• throw ..
• catch (char str)
• Parent-gtMessageBox(str)

79
Synchronization

• You dont need synchronization (Mutex objects)
  for this homework.
• There may be a slight need , like elements being
  inserted into the list in the wrong order if both
  parties draw at the same time, but this is too
  small, unimportant for this homework

80

• Winsock reference and info can be found at
• http//msdn.microsoft.com/en-us/library/ms738524(V
  S.85).aspx
• This is where you will find non-specified usage
  specs for wisnsock related functions (e.g.
  Gethostbyname, hostent struct, htons, inet_ntoa,
  WSAStartup)
• The gethostbyname function cannot resolve IP
  address strings passed to it. Such a request is
  treated exactly as if an unknown host name were
  passed. Use inet_addr to convert an IP address
  string to an actual IP address, then use another
  function, gethostbyaddr, to obtain the contents
  of the hostent structure.

81
UNIX Examples

• SKIP IF NOT INTERESTED
• The concepts are the same, but the API is
  different

82
UNIX example TCPEchoClient.c - 1/4

• include ltstdio.hgt / for printf()
  /include ltsys/socket.hgt / for
  socket(), connect(), send()
  and recv() / include
  ltarpa/inet.hgt / for sockaddr_in and inet_addr()
  /include ltstdlib.hgt / for atoi()
  /include ltstring.hgt / for
  memset() /include
  ltunistd.hgt / for close()
  /
• define RCVBUFSIZE 32 / Size of receive buffer
  /
• void DieWithError(char errorMessage) / error
  handling function /
• int main(int argc, char argv)
• int sock struct sockaddr_in echoServAddr
  unsigned short echoServPort char servIP
  ...

83
TCPEchoClient.c - 2/4

• ...int main(int argc, char argv) ...
• char echoString char echoBufferRCVBUFSIZE
  unsigned int echoStringLen int bytesRcvd,
  totalBytesRcvd
• if (argc ! 2)) printf(Usage s
  ltServer IPgt ltEcho Wordgt \n, argv0)
  exit(1)
• servIP argv1 echoString argv2
  echoServPort 7 / well-known port for echo
  service / ...

84
TCPEchoClient.c - 3/4

• ... / Create a reliable, stream socket using
  TCP / if(sock socket(PF_INET, SOCK_STREAM,
  IPPROTO_TCP)) lt 0) DieWithError(socket()
  failed)
• / Construct the server address structure /
  memset(echoServAddr, 0, sizeof(echoServAddr)
  echoServAddr.sin_family AF_INET / Convert
  Servers IP address string to proper IP address
  /
• echoServAddr.sin_addr.s_addr
  inet_addr(ServIP)
• / Convert the port num to proper order /
• echoServAddr.sin_port htons(echoServPort)
• / Establish a connection to the echo server
  / if(connect(sock, (struct sockaddr )
  echoServAddr, sizeof(echoServAddr)) lt 0)
  DieWithError(socket() failed)
• echoStringLen strlen(echoString) /Determine
  the input length /
• ...

85
TCPEchoClient.c - 4/4

• ... / Send the string to the server /
  if(send(sock, echoString, echoStringLen, 0)) !
  echoStringLen) DieWithError(send()
  failed)
• / receive the same string back from the server
  / totalBytesRcvd 0 printf(Received )
  while (totalBytesRcvd lt echoStringLen)
  if(bytesRcvd recv(sock, echoBuffer, RCVBUFSIZE
  - 1, 0)) lt 0) DieWithError(socket()
  failed)
• totalBytesRcvd bytesRcvd
  echobufferbytesRcvd \0
  printf(echoBuffer)
• prinft(\n) close(sock) exit(0)

86
TCPEchoServer.c 1/4

• include ltstdio.hgt / for printf() and
  fprintf() /include ltsys/socket.hgt / for
  socket(), connect(), send()
  and recv() / include
  ltarpa/inet.hgt / for sockaddr_in and inet_addr()
  /include ltstdlib.hgt / for atoi()
  /include ltstring.hgt / for
  memset() /include
  ltunistd.hgt / for close()
  /
• define MAXPENDING 5 / Maximum outstanding
  conn. requests /
• void DieWithError(char errorMessage) / error
  handling func. /void HandleTCPclient(int
  clntSocket) / for TCP client handling
  function /
• int main(int argc, char argv)
• int ServSock, clntSock
• struct sockaddr_in echoServAddr
• struct sockaddr_in echoClntAddr
• unsigned short echoServPort unsigned int
  clntLen / Length of client address data
  structure
  / ...

87
TCPEchoServer.c 2/4

• ...int main(int argc, char argv) ...
• echoServPort 7 / well-known port for echo
  service /
• / Create socket for incoming connections /
  if((servSock socket(PF_INET, SOCK_STREAM,
  IPPROTO_TCP)) lt 0) DieWithError(socket()
  failed)
• / Construct Local address structure /
  memset(echoServAddr, 0, sizeof(echoServAddr)
  echoServAddr.sin_family AF_INET
  echoServAddr.sin_addr.s_addr htonl(INADDR_ANY)
  echoServAddr.sin_port htons(echoServPort)
  ...

88
TCPEchoServer.c 3/4

• ...int main(int argc, char argv) ...
• / Bind to the local address /
  if(bind(servSock, (sturct sockaddr )
  echoServAddr, sizeof(echoServAddr)) lt 0)
  DieWithError(bind() failed)
• / Mark the socket so it will listen for
  incoming connections / if(listen(servSock,
  MAXPENDING) lt 0) DieWithError(listen()
  failed) ...

89
TCPEchoServer.c 4/4

• ...int main(int argc, char argv) ...
• for()
• / Wait for a client to connect /
  if((clntSock accept(servSock, (struct
  sockaddr ) echoClntAddr, sizeof(echoClntAddr))
  lt 0) DieWithError(bind() failed)
• / clntSock is connected to a client /
• printf(Handling client s\n,
  inet_toa(echoClntAddr.sin_addr))
• HandleTCP(clntSock) / NOT
  REACHED /

90
HandleTCPClient.c 1/2

• include ltstdio.hgt / for printf() and
  fprintf() /include ltsys/socket.hgt / for
  send() and recv() / include
  ltunistd.hgt / for close()
  /
• define RCVBUFSIZE 32
• void DieWithError(char errorMessage) / error
  handling func. /
• void HandleTCPclient(int clntSocket)
• char echoBufferRCVBUFSIZE int
  recvMsgSize
• / Receive message from client /
  if((recvMsgSizerecv(clntSocket, echoBuffer,
  RCVBUFSIZE, 0)) lt 0) DieWithError(recv()
  failed)
• ...

91
HandleTCPClient.c 2/2

• ...
• / Send received string and receive again until
  the end of transmission /
  while(recvMsgSize gt 0) / zero indicates end of
  transmission /
• / Echo message back to client /
  if(send(clntSock, echoBuffer, recvMsgSize, 0)) !
  recvMsgSize) DieWithError(send()
  failed)
• / Receive message from client /
  if((recvMsgSizerecv(clntSock, echoBuffer,
  RCVBUFSIZE, 0)) lt 0) DieWithError(recv()
  failed)
• close(clntSocket)

92
MFCs CSocket Class

• This class has some problems (did not work for us
  and is reported to have some problems), so we
  will skip this. Anyway it is just a wrapper
  around the Windows sockets.

93
MFC CSockets

• Class based on Windows Sockets
• CSocket mysocket
• Main gain is that CSockets allows you to use
  CArchive to send/receive Serializable objects,
  without converting them into a byte string.
• e.g. a rectangle shape object is sent
  automatically (not first sending the top-left
  point coordinates, then ...)

94
Csocket Class
95
Csocket Class

• A CArchive object manages a buffer. When the
  buffer of a storing (sending) archive is full, an
  associated CFile object writes out the buffer's
  contents.
• Flushing the buffer of an archive attached to a
  socket is equivalent to sending a message. When
  the buffer of a loading (receiving) archive is
  full, the CFile object stops reading until the
  buffer is available again.
• Class CSocketFile derives from CFile, but it does
  not support CFile member functions (Seek,
  GetLength, ...).
• All the CSocketFile object must do is write or
  read sequences of bytes to or from the associated
  CSocket object. Because a file is not involved,
  operations such as Seek and GetPosition make no
  sense.
• CSocketFile is derived from CFile, so it would
  normally inherit all of these member functions.
  To prevent this, the unsupported CFile member
  functions are overridden in CSocketFile to throw
  a CNotSupportedException.
• The CSocketFile object calls member functions of
  its CSocket object to send or receive data.

96
Csocket Class http//msdn.microsoft.com/library/d
efault.asp?url/library/en-us/vccore98/HTML/_core_
windows_sockets.3a_.sequence_of_operations.asphtt
p//msdn.microsoft.com/library/default.asp?url/li
brary/en-us/vccore/html/_core_Windows_Sockets_in_M
FC.asp

• SERVER
• // construct a socket
• CSocket sockSrvr
• // bind to the port
• sockSrvr.Create(nPort)1,2
• // start listening
• sockSrvr.Listen( )
• -------

• CLIENT
• // construct a socket
• CSocket sockClient
• // create the SOCKET
• sockClient.Create( )2
• -------
• // seek a connection
• sockClient.Connect(svrAddr,nPort)3,4

same
97
Csocket Class

• CLIENT ctd.
• -------
• // construct file object
• CSocketFile file(sockClient)

• SERVER ctd.
• ...
• // construct a new, empty socket
• CSocket sockRecv
• // accept connection
• sockSrvr.Accept(sockRecv) 5
• // construct file object
• CSocketFile file(sockRecv)

98
Csocket Class

• SERVER OR CLIENT
• // construct an archive
• CArchive arIn (file,CArchiveload) or
• CArchive arOut (file,CArchivestore)
• // use the archive to pass data
• arIn gtgt dwValue or
• arOut ltlt dwValue6

99
Footnotes for the Previous Slides

• 1. Where nPort is a port number.
• 2. The server must always specify a port so
  clients can connect. The Create call sometimes
  also specifies an address. On the client side,
  use the default parameters, which ask MFC to use
  any available port.
• 3. Where nPort is a port number and strAddr is a
  machine address or an Internet Protocol (IP)
  address.
• 4. Machine addresses can take several forms
  ftp.microsoft.com, ucsd.edu. IP addresses use
  the dotted number form 127.54.67.32. The
  Connect function checks to see if the address is
  a dotted number (although it doesnt check to
  ensure the number is a valid machine on the
  network). If not, Connect assumes a machine name
  of one of the other forms.
• 5. When you call Accept on the server side, you
  pass a reference to a new socket object. You must
  construct this object first, but do not call
  Create for it. Keep in mind that if this socket
  object goes out of scope, the connection closes.
  MFC connects the new object to a SOCKET handle.
  You can construct the socket on the stack, as
  shown, or on the heap.
• 6. The archive and the socket file are closed
  when they go out of scope. The socket objects
  destructor also calls the Close member function
  for the socket object when the object goes out of
  scope or is deleted.

100
CSocket.Create()

• BOOL Create (          UINT nSocketPort 0,
           int nSocketType SOCK_STREAM,
           long lEvent FD_READ FD_WRITE
  FD_OOB FD_ACCEPT FD_CONNECT FD_CLOSE,
           PCTSTR lpszSocketAddress NULL)
• nSocketPort - A port for our socket. If zero (it
  is the default) MFC will choose it automatically.

• nSocketType -  Type of our socket. SOCK_STREAM
  for connection oriented sockets and SOCK_DGRAM
  for connections message oriented sockets.
• lEvent - Events that user wants receive
  notifications for them. For example if FD_READ is
  included then OnReceive method will be called (of
  course when this event will occur). Default value
  means that all notifications are included.
• lpszSocketAddress - Address of our host to which
  we want bind our socket. If it's NULL (it's
  default) then one can bind socket with Bind
  method.
• Returned value is non zero on success and zero
  otherwise. Specific error code can be accepted
  through GetLastError method.

101
Further Info - Useful Sites

• MSDN help files or on the web
• http//msdn.microsoft.com
• http//www2.rad.com/networks/1999/sockets/SockMFC
  .htm
