Sending Email on MVS via SMTP

1
Sending Email on MVS via SMTP

• -Or-
• Youve Got Mail!
• (from the mainframe)
• -or-
• Sleepless in SMTP
• Jon Gibbens
• jon_at_provista.com

2
A Familiar Phone Conversation?

• Hello, this is Jon..
• Yes, this is Steve Bigwig here, did my extracts
  run last night??
• Let me check. ltclick clickgt Yes, they are
  done..the job ran last night at 3am
• Ok, and could you tell me how many records were
  on it?
• ltclick clickgt Yeah, 500.
• Thanks
• Next week..same exact phone call!!!

3
Introduction

• Need to notify users when certain conditions have
  been met, such as...
• Reports Printed/Ready
• Files transferred
• Jobs completed/failed
• Provide some kind of automated reporting -
  ie..send data to someone on a regular basis

4
How about using Email?

• Email can help bridge the communication gap
  between you (the developer) and end users.
• The rest of the world uses email to notify people
  about things, why not you and your MVS-based
  FOCUS programs?

5
Presentation Agenda

• How does it work?
• Note Control File
• Sample JCL (Inline Procedure)
• Sample FOCEXEC code
• Sending a report via email
• Advanced Usage (URLs, HTML)
• WWW resources
• Q A

6
How does it work?

• In a nutshell
• 1 - Dynamically create your NOTE CONTROL FILE or
  use one that you have already created.
• 2 - NOTE CONTROL file contains the secret
  handshake as well as your note body text.
• 3 - Send NOTE CONTROL file off to SMTP via
  IEBGENER.
• SMTP allows for sending of email to any connected
  Intranet or Internet host.

7
Note Control File - REQUIRED ELEMENTS(or....What
s the secret handshake?)

• 1. HELO HOST - HOST is name of the MVSHOST
  (defined in SYS1.PARMLIB(IEFSSNxx)
• 2. MAIL FROMltemail addressgt -sender of note
• 3. RCPT TOltemail addressgt - 1 line per email
  recipient (as many recipients as you want)
• 4. DATA - seperator between RCPT TO SUBJECT
• 5. SUBJECT - subject line of note
• 6. Note Body

8
Sample Note Control file
HELO HOST
MAIL FROMltJON_at_PROVISTA.COMgt
RCPT
TOltJONATHAN.GIBBENS_at_SCHWAB.COMgt
DATA
SUBJECT TEST OF MAILING
OUT THIS IS A TEST OF EMAIL ) JON GIBBENS

• Note Control file generated with FOCUS/Dialogue
  Manager (using -WRITE statements)

9
JCL section of a procedure
//
// PS020 EXECUTE
IEBGENER PROGRAM TO SEND EMAIL NOTIFICATION VIA
SMTP //
//PS020 EXEC
PGMIEBGENER
//
//SYSIN DD
DUMMY
//SYSUT1 DD DSNWKPDS..NOTECNTL.TEST,
DISPSHR //SYSUT2 DD
SYSOUT(B,SMTP)
//SYSOUT DD SYSOUTX
//SYSPRINT DD
SYSOUTX

• IEBGENER - copies sequential dataset from any
  device to any device.
• Input step in SYSUT1 - location of Note Control
  File
• Output step in SYSUT2 - passes control to SMTP
  program

10
JCL with note control file included inline
//MAJOGA1 JOB (TEST,MF1),'JON MAIL
TEST',CLASS9,MSGCLASST, // NOTIFYMFJOG,USERM
FJOG
//IEBGENER EXEC PGMIEBGENER
//SYSIN DD DUMMY
//SYSUT1 DD
HELO
HOST
MAIL FROMltJON_at_PROVISTA.COMgt
RCPT TOltJONATHAN.GIBBENS_at_SCH
WAB.COMgt DATA

SUBJECT TEST OF MAILING OUT THIS IS A TEST
OF EMAIL ) JON GIBBENS
/
//SYSUT2 DD SYSOUT(B,SMTP) //SYSOUT DD
SYSOUTX //SYSPRINT DD SYSOUTX
11
Sample Note generated by JCL( as viewed in
Exchange)
12
Sample Scenario

• Want to let Steve Bigwig know when his job ran,
  and how many records it pulled.
• Sample Focexec to follow writes out the system
  time date, and the of records in a flat file.
  Also creates our NOTE CONTROL FILE.

13
FOCUS code to create NOTE Control File

• Focexec is EMLSAMP1
• Includes a utility I use for creating most of my
  email related variables
• This code would go AFTER data extract portion
  of the program.
• Would be part of a JCL job/procedure

14
EMLSAMP1 Focexec
- TABLE FILE ltwhatevergt SUM CNT.ACCOUNTS BY
CODE - -EMLSAMP1 JONATHAN GIBBENS -FOCEXEC
ABOVE DOES EXTRACT FOR STEVE BIGWIG - END -

- SET THE SYSTEM TIME VARIABLE -

-SET STIME ' ' -SET STIME
HHMMSS(STIME) - -
- SET UP 3 BODY LINES
FOR EMAIL MESSAGE - - DATE/TIME/RECORDS/LINES -

-SET NEATDATE EDIT(YYMD,'9999/99/99') -SE
T BODY1 ' YOUR EXTRACT RAN ON ' NEATDATE
' AT ' - STIME -SET BODY2 '
THE NUMBER OF LINES IN YOUR EXTRACT WAS ' -
LINES -SET BODY3 ' THE NUMBER OF
RECORDS IN YOUR EXTRACT WAS '
RECORDS - -
- SET UP THE RECIPIENTS OF
THE NOTE, AND THE SUBJECT -
-SET
RCPT1'JONATHAN.GIBBENS_at_SCHWAB.COM' -SET
RCPT2'STEVEB_at_COMPANY.COM' -SET SUBJECT
'FILE EXTRACTS FOR ' NEATDATE - -
-
- NOTE CONTROL FILE UTILITY - JON
GIBBENS - PROVISTA SOFTWARE INTL. -
JON_at_PROVISTA.COM - - SET UP VARIABLES FOR
CREATION OF NOTE CONTROL FILE - NOTE ALL OF
THESE -SETS COULD BE INSIDE OF AN INCLUDE -
FILE FOR CONVENIENCE AND CODE
PORTABILITY - - INPUTS - RCPT1-5 UP
TO FIVE VALID EMAIL ADDRESSES - SUBJECT
THE SUBJECT OF THE NOTE - - OUTPUTS
ESSENTIAL VARIABLES FOR AN EMAIL MESSAGE - -
HELOLINE 'HELO HOST' - FIRST LINE OF EMAIL
MESSAGE - WHERE HOST IS THE
MAIL SUBSYSTEM - RCPTLNE1'RCPT
TOltRPCT1gt' FIRST RECIPIENT -
RCPTLNE2'RCPT TOltRPCT2gt' 2ND RECIPIENT -
RCPTLNE3'RCPT TOltRPCT3gt' 3RD "" -
RCPTLNE4'RCPT TOltRPCT4gt' 4TH "" -
RCPTLNE5'RCPT TOltRPCT5gt' 5TH "" -
SUBLINE 'SUBJECT SUBJECT' - TOEND
'gt' - THE END OF THE 'TO' LINE -
DATALINE 'DATA' - PUT AFTER 'TO' LINE(s) -
SUBBEG 'SUBJECT' - BEGINNING OF SUBJECT
LINE - SIGLINE1'THANKS! HAVE A NICE
DAY!' - BLANKLINE ' ' -
SPACES/BLANKS -
-DEFAULT THE
ESSENTIAL ELEMENTS-
-DEFAULTS
HELOLINE 'HELO HOST' -DEFAULTS TOBEG
'RCPT TOlt' -DEFAULTS TOEND 'gt' -DEFAULTS
DATALINE 'DATA' -DEFAULTS SUBBEG
'SUBJECT ' -DEFAULTS RCPT1' ' -DEFAULTS
RCPT2' ' -DEFAULTS RCPT3' ' -DEFAULTS
RCPT4' ' -DEFAULTS RCPT5' ' -DEFAULTS
SUBJECT ' ' -DEFAULTS BLANKLINE ' ' -RUN
15
EMLSAMP1 Focexec
- - -------------------------------------------
----------------- - SET UP THE RCPT TO LINES -
UP TO 5 PEOPLE CAN BE SENT THE EMAIL - READ IN
THE RCPT1,RCPT2,RCPT3,RCPT4,RCPT5
VARIABLES - OUTPUT IN THE FORMAT RCPT
TOltEMAIL ADDRESSgt - ----------------------------
-------------------------------- - -SET
RCPTLNE1 TOBEG RCPT1 TOEND -SET
RCPTLNE2 TOBEG RCPT2 TOEND -SET
RCPTLNE3 TOBEG RCPT3 TOEND -SET
RCPTLNE4 TOBEG RCPT4 TOEND -SET
RCPTLNE5 TOBEG RCPT5 TOEND - -
--------------------------------------------------
---------- - SET UP THE SUBJECT LINE - READ IN
SUBJECT - -------------------------------------
----------------------- - -SET SUBLINE
'SUBJECT ' SUBJECT -
-INS
TALLATION SPECIFIC VARIABLES - FROMLINE -
EMAIL ADDRESS FOR THE SENDER (CAN BE ANY
EMAIL - ADDRESS) - SIGLINE1 -
LINE TO END THE EMAIL
- -DEFAU
LTS FROMLINE 'MAIL FROMltTHEBIGMAINFRAME_at_COMPAN
Y.COMgt' -DEFAULTS SIGLINE1 'THANKS! HAVE A
NICE DAY!!' -DEFAULTS SIGLINE2
'QUESTIONS/PROBLEMS? EMAIL TECHSUPPORT_at_COMPANY.COM
' -
- - -------------------
-------------------------------------------- -
WRITE OUT THE NOTE CONTROL FILE NOTECNTL -
NOTE CONTROL FILE IS A FLAT FILE ALLOCATED AS
MOD - FOR SIMPLE NOTES, IT CAN BE FIXED
FORMAT, 80 CHARACTERS, 27920 BLKS
-
- -----------------------------------------------
---------------- -
- WRITE OUT THE HELOLINE
THE FROM LINE -
- -WRITE NOTECNTL
HELOLINE -WRITE NOTECNTL FROMLINE - -

- WRITE OUT THE RECIPIENT(S) -

- -WRITE NOTECNTL RCPTLNE1 -WRITE NOTECNTL
RCPTLNE2 - -
- WRITE OUT THE DATA
SEPERATOR SUBJECT LINE -
- -WRITE
NOTECNTL DATALINE -WRITE NOTECNTL SUBLINE - -

- WRITE OUT THE BODY OF THE NOTE -

- -WRITE NOTECNTL BLANKLINE -WRITE NOTECNTL
BODY1 -WRITE NOTECNTL BODY2 -WRITE NOTECNTL
BODY3 -WRITE NOTECNTL BLANKLINE -WRITE NOTECNTL
SIGLINE1 -WRITE NOTECNTL SIGLINE2 - - -

- END OF JOB EMLSAMP1 -


16
Resulting file from EMLSAMP

• HELO HOST

• MAIL FROMltTHEBIGMAINFRAME_at_COMPANY.COMgt

• RCPT TOltJONATHAN.GIBBENS_at_SCHWAB.COMgt

• RCPT TOltSTEVEB_at_COMPANY.COMgt

• DATA

• SUBJECT FILE EXTRACTS FOR 1999/09/10

•

• YOUR EXTRACT RAN ON 1999/09/10 AT 16.53.44

• THE NUMBER OF LINES IN YOUR EXTRACT WAS 27

• THE NUMBER OF RECORDS IN YOUR EXTRACT WAS
  1000
•

• THANKS! HAVE A NICE DAY!!

• QUESTIONS/PROBLEMS? EMAIL TECHSUPPORT_at_COMPANY.COM

17
Sending a report via email

• To send a small report (less than the maxiumum
  line length of your email client)
• 1. Turn off page-breaks (SET PAGENOPAGE )
• 2. Put NOTE CONTROL FILE elements into your
  HEADER (ie..HELO,MAIL FROM,RCPT TO,DATA)
• 3. Save file in WP format and then send off to
  IEBGENER using JCL in examples.

18
Advanced Usage

• URLs - Exchange/Outlook or Netscape mail (other
  mail clients as well) will read any URLs you
  include in your note and will activate them
• So, if you are doing Intranet type reporting, you
  can point users to where the reports are.
• Can do fancier HTML formatting if include MIME
  tags and HTML code (example to follow)
• Only really works if email client fully supports
  HTML, or at least, supports the features that YOU
  need.

19
Note Control File with a URLalong with resulting
note.

• HELO HOST

• MAIL FROMltJON_at_PROVISTA.COMgt

• RCPT TOltJONATHAN.GIBBENS_at_SCHWAB.COMgt

• DATA

• SUBJECT TEST OF USING URL IN NOTE

•

• A good site to visit for FUSE-related information
  is
• http//www.csuhayward.edu/FOCUS/ncalfuse.htm

•

•


20
Note Control File with HTMLalong with resulting
note.

• HELO HOST

• MAIL FROMltTHEBIGMAINFRAME_at_SCHWAB.COMgt

• RCPT TOltJONATHAN.GIBBENS_at_SCHWAB.COMgt

• DATA

• SUBJECT A HTML TEST NOTE
• MIME-Version 1.0
• Content-type text/html charsetus-ascii
• ltHTMLgt
• ltBODYgt
• ltH1gtHeres the big header of the notelt/H1gt
• ltPgt
• Hey, heres an HTML note that will have you
  seeing ltfont faceArial size5
  colorredgtREDlt/fontgt
• lt/BODYgt
• lt/HTMLgt
•


21
WWW Resources

• Daves MVS Mail Page - http//users.ticnet.com/da
  vea/mvs/mvsmail

• Decoding Internet Attachments -
  http//pages.prodigy.net/michael_santovec/decode.h
  tm - To find out more about MIME tags, and
  different compatibility issues with different
  email clients

22
Questions?
23
Download this presentation

• Northern California FUSE Homepage
• http//www.csuhayward.edu/FOCUS/mvsmail.ppt
