3GPP Long Term Evolution A Technical Study

1
3GPP Long Term Evolution A Technical Study

• EEL 6936 Advanced Topics in Wireless
  Communications
• Spring 2009
• Advised by Dr. Hüseyin Arslan
• Presented by Divya Ramamoorthy

2
Main Topics

• Introduction to LTE
• LTE Network Architecture
• LTE Physical Layer
• SC-FDMA
• Channel Dependent Scheduling
• Cognitive Radio for LTE RRM
• Multiple antenna schemes in LTE
• LTE-Advanced
• Conclusion

3
Introduction to LTE

• 3GPP Long Term Evolution - the next generation of
  wireless cellular technology beyond 3G
• Initiative taken by the 3rd Generation
  Partnership Project in 2004
• Introduced in Release 8 of 3GPP
• Mobile systems likely to be deployed by 2010

4
Requirements to be met by LTEFast, Efficient,
Cheap, Simple

• Peak Data Rates
• Spectrum efficiency
• Reduced Latency
• Mobility
• Spectrum flexibility
• Coverage
• Low complexity and cost
• Interoperability
• Simple packet-oriented E-UTRAN architecture

5
LTE Network Architecture

• Simple Architecture
• Flat IP-Based Architecture
• Reduction in latency and cost
• Split between
• EPC and E-UTRAN
• Compatibility with 3GPP and non-3GPP technologies
• eNB-radio interface-related functions
• MME-manages mobility, UE identity and security
  parameters
• S-GW-node that terminates the interface towards
  E-UTRAN

6
LTE Network Architecture
7
LTE Frame Structure

• LTE Frame Structure
• Type I (FDD)
• LTE Frame Structure
• Type II (TDD)

8
Concept of Resource Blocks (RB)

• Downlink Resource Grid
  Reference Signals for MIMO

9
Single-Carrier Frequency Division Multiple Access
(SC-FDMA)

• Motivation for SC-FDMA
• SC-FDMA utilizes single carrier modulation at the
  transmitter and frequency domain equalization at
  the receiver.
• It has the best of both worlds - the low PAPR of
  single carrier systems and the multipath
  resistance and channel dependent subcarrier
  allocation features of OFDM.
• Same complexity and performance as OFDMA

10
The SC-FDMA System

• DFT-Spread OFDMA Mapping of spread
• symbols , not original symbols to subcarriers!!!

11
Subcarrier Mapping Schemes

• Localized (LFDMA)
• Distributed (DFDMA)
• Interleaved (IFDMA)

12
Frequency and Time Domain Representation

• Frequency Time

13
Time domain signals of LFDMA, DFDMA and IFDMA20
14
PAPR characteristics of an SC-FDMA signal 20

• Comparison of the CCDF of PAPR for LFDMA, DFDMA,
  IFDMA and OFDMA

15
Effect of roll-off factor, alpha on the PAPR20
16
Why does SC-FDMA have a low PAPR?

• OFDMA
• Parallel Transmission
• Multi carrier structure
• Increase in M gt
• high PAPR
• SC-FDMA
• Serial Transmission
• Each symbol
• represented by a
• wide signal DFT spreads
• symbols over all subcarriers
• PAPR not affected by
• increase in M
• Both occupy the same bandwidth with same
  symbol durations

17
SC-FDMA in comparison with OFDMA and DS-CDMA/FDE

• DS-CDMA/FDE

18
Channel Dependent Scheduling

• Channel is highly frequency selective
• Resources in deep fade for one user could be
  excellent for another user
• Frequency selectivity of the channel can be
  exploited by using CDS to maximize throughput
• LFDMA frequency selective diversity
• IFDMA Multi user diversity (inherently
  frequency diversity is obtained)

19
Cognitive RRM in LTE

• Link adaptation possible as network segments in
  LTE adapt to the environmental changes
• System can learn from solutions that were
  provided in the past
• Faster response, improved performance,
  intelligent system
• Decisions reg. apt BW,DSA,APA and AM

20
Cognitive Features to enhance RRM in LTE
21
Enhanced context acquisition mechanism
architecture for cognitive intra-cell RRM
22
Simulation Results27

• Success Probability slowly increases with time
  and
• mean response time decreases as more and more
• familiar contexts are encountered. Cognitive RRM
• with the context matching techniques understands
• and learns from previous interactions

23
Multiple Antenna Schemes in LTE

• In DL Tx diversity, Rx diversity, Spatial
  multiplexing (2x2,4x2 configurations SU-MIMO
  and MU-MIMO) supported
• In UL Only 1 Transmitter (antenna selection Tx
  diversity ), MU-MIMO possible, Rx diversity with
  2 or 4 antennas at eNB supported

24
LTE Advanced

• LTE doesnt fulfill the requirements of
  IMT-Advanced
• 3GPP has also started work on LTE-Advanced, an
  evolution of LTE, as a proposal to ITU-R for the
  development of IMT Advanced.
• LTE Advanced is envisioned to be the first true
  4G technology.

25
Requirements of LTE Advanced

• Peak data rates 1Gbps in DL and 500 Mbps in UL
• Cell edge user data rates twice as high and
  average user throughput thrice as high as in LTE
• Peak spectrum efficiency DL 30 bps/Hz, UL 15
  bps/Hz
• Operate in flexible spectrum allocations up to
  100 MHz and support spectrum aggregation (as BW
  in DL gtgt20 MHz)
• An LTE-Advanced capable network must appear as a
  LTE network for the LTE UEs

26
Technological proposals for LTE Advanced

• Larger BW can be used for high date rates and
  more coverage at cell edges
• Advanced repeater structures
• Relaying for adaptive coding based on link
  quality
• CoMP

Carrier aggregation and
Spectrum aggregation
27
(Extra Slides)
28
LTE Physical Layer

• Enables exchange of data control info between
  eNB and UE and also transport of data to and from
  higher layers
• Functions performed include error detection, FEC,
  MIMO antenna processing, synchronization, etc.
• It consists of Physical Signals and Physical
  Channels
• Physical Signals are used for system
  synchronization, cell identification and channel
  estimation.
• Physical Channels for transporting control,
  scheduling and user payload from the higher
  layers
• OFDMA in the DL, SC-FDMA in the UL
• LTE supports FDD and TDD modes of operation

29
LTE Physical Signals in DL and UL
30
LTE Physical Channels in DL and UL
31
Modulation

• QPSK, 16 QAM and 64 QAM used for the payload
  channels (spectrally efficient)
• BPSK and QPSK used for the control channels
  (Reliability and coverage)
• Adaptive modulation and coding

32
CDS algorithms -Localized FDMA
Rk average data rate of user k Ich,k chunk
set of user k Pk transmit power of user k

• Marginal utility is defined by
• -gt
• This is computed for each chunk n and each user
  k
• N best users for each chunk become candidates for
  that chunk
• Find the chunk n with highest marginal utility
  and for each of the N users obtained above, find
  the user k who gives the max improvement in
  utility and assign n to k
• Remove n from the set of available chunks and
  repeat for the remaining chunks

33
Interleaved FDMA
Rk average data rate of user k Nch,k no. of
chunks for user k

• Marginal utility is defined by -gt
• For each user, the utility is found when the
  chunk is assigned to the user and the utility
  when there is no chunk allocation at all. N best
  users are the candidate for chunk allocation.
• Now it is required to find the number of chunks
  to give to each of these above users The Greedy
  alloc computes this figure

34

• Localized FDMA CDS much better than IFDMA CDS
  due to frequency selective scheduling

35
Channel Dependent Scheduling

• No CDS gt IFDMA is better
• With CDS gt LFDMA is better
• Algorithms for Localized FDMA
• FME First Maximum Expansion
• RME Recursive Maximum Expansion

36
Figures for explanation of FME and RME

•


37
Packet Scheduling using buffer and channel status

• UE buffer status and
• channel status (CQI)
• must be considered
• UE sends CQI and BSR
• to the eNB CQI used in PHY and MAC
• (eNB Scheduler) layers for transmission and
• scheduling decisions

38
CABA Scheduling Algorithm

• Channel adapted factor
• Denominator ensures fairness
• Buffer Aware factor
• of user i
• Priority Function
• involves BSR, CQI
• and RT/NRT

Buffi (Lbuff Ncurr)/Lbuff, for
i1,2,,M
39
Impact of feedback delay in CDS

• CSI becomes obsolete
• Throughput degradation
• Fast UEs get affected more

40
Impact of delay and mobile speed
41
Hybrid Subcarrier Mapping

• LFDMA is best in maximizing throughput when CDS
  is used but is highly sensitive for large mobile
  speeds so low mobility is best for LFDMA
• For high mobility, Distributed mapping of IFDMA
  with static scheduling is preferred
• Using both subcarrier mappings at once is
  preferable but can conflict exclusive allocation
  requirement
• Hybrid subcarrier mapping uses direct sequence
  spread spectrum technique prior to SC-FDMA
  modulation

42
Single carrier code-frequency division multiple
access (SC-CFDMA)
43
Spatial Multiplexing in SC-FDMA(UL)

44
Simulation Conclusions 20

• Averaging and Quantization leads to performance
  loss
• Feedback delay affects high speed users
• PAPR of the MIMO case increases due to precoding
  compared to single antenna transmission

45
Efficient feedback of precoder matrix

• SVD of averaged channel matrix
• Channel correlation matrix R
• Jacobi matrix J can also be used to
• diagonalize R it can be used as the
  precoder matrix
• At instant n, J(n) is obtained
• At instant n1, instead of sending
• J(n1), J is sent
• Transmitter can compute the new
• J(n1) using J(n) and J
• Scheme works only for low speeds
• and less feed back delays
• To prevent error propagation
• and accumulation, combined differential and
  non-differential feed back is employed

46
Transmit Antenna Selection Mode in SC-FDMA Systems
47
Spatial Multiplexing in DL using SIC

• Data vector corresponding to each transmit
  antenna
• The complete data vector, on subcarrier l
• The received vector
• Frequency domain samples at the receiver, after
  DFT
• In a SIC MMSE receiver, a weight vector is
  applied to the received vector
• A new received data vector is got by removing the
  effect of the previously detected symbol from the
  current received vector
• Data symbol with max SNR can be detected first to
  help improve SNR of future iterations

48
Relation of DS-CDMA and IFDMA
49
Conclusion

• 3GPP Long Term Evolution has a large amount of
  potential to become the technology of the future
  whose success will definitely guarantee that 3GPP
  has a significant edge over all its competitors.
• With LTEAdvanced also adopting SC-FDMA as the
  uplink technology, SC-FDMA seems to be an
  important future technology and it is expected
  that the future would see a lot of research
  activity in this field.
• LTE and LTE Advanced together seem to be very
  promising in fulfilling all the requirements set
  forth by ITU for IMT Advanced

50
References

• http//www.3gpp.com/article/lte
• http//www.3gpp.com/article/lte-advanced.
• http//en.wikipedia.org/wiki/LTE_Advanced
• UTRA-UTRAN Long Term Evolution (LTE) and 3GPP
  System Architecture Evolution (SAE) - Technical
  paper from http//www.3gpp.com/article/lte
• Overview of the 3GPP Long Term Evolution Physical
  Layer White paper by Jim Zyren, freescale
  semiconductor, Document Number 3GPPEVOLUTIONWP
  http//www.freescale.com/files/wireless_comm/doc/w
  hite_paper/3GPPEVOLUTIONWP.pdf
• 3GPP TR 25.913 V8.0.0 (2008-12), Requirements
  for Evolved UTRA (E-UTRA) and Evolved UTRAN
  (E-UTRAN) (Release 8)
• 3GPP TS 36.300 v8.7.0, E-UTRA and E-UTRAN
  Overall Description Stage 2
• 3GPP TS 36.401 V8.4.0 (2008-12), Evolved
  Universal Terrestrial Radio Access Network
  (E-UTRAN) Architecture description (Release 8)
• 3GPP TS 36.410 V8.1.0 (2008-12), Evolved
  Universal Terrestrial Radio Access Network
  (E-UTRAN) S1 General aspects and principles
  (Release 8)
• 3GPP TS 36.420 V8.1.0 (2008-12), Evolved
  Universal Terrestrial Radio Access Network
  (E-UTRAN) X2 general aspects and principles
  (Release 8)
• 3GPP TS 36.201 V8.2.0 (2008-12), Evolved
  Universal Terrestrial Radio Access (E-UTRA) LTE
  Physical Layer General Description (Release 8)
• 3GPP Long-Term Evolution (LTE) Qualcomm
  Incorporated, January 2008 http//www.qualcomm.co
  m/common/documents/white_papers/3GPP_LTE.pdf
• Technical Overview of 3GPP LTE Hyung G. Myung
  http//www.scribd.com/doc/5539254/3gpp-LTE-Overvie
  w
• LTE Overview NEC Corporation By K. Jay
  Miyahara http//www.nsma.org/conf2008/Presentatio
  n/2-1045-Miyahara-LTE_Overview_NMSA2021March08_fi
  nal.pdf
• Agilent 3GPP Long Term Evolution System
  Overview, Product Development, and Test
  Challenges http//cp.literature.agilent.com/litwe
  b/pdf/5989-8139EN.pdf
• Ekstrom, H. Furuskar, A. Karlsson, J. Meyer,
  M. Parkvall, S. Torsner, J. Wahlqvist, M.,
  Technical solutions for the 3G long-term
  evolution Communications Magazine, IEEE Volume
  44,  Issue 3,  March 2006 Page(s) 38 - 45
• http//wiki.hsc.com/LTE
• Long Term Evolution (LTE) A Technical Overview
  Technical White Paper http//www.motorola.com/s
  taticfiles/Business/Solutions/Industry20Solutions
  /Service20Providers/Wireless20Operators/LTE/_Doc
  ument/Static20Files/6834_MotDoc_New.pdf
• 3GPP LTE Introducing Single - Carrier FDMA By
  Moray Rumney, Agilent Technologies
  http//cp.literature.agilent.com/litweb/pdf/5989-7
  898EN.pdf

51
References

• Myung, H.G. Kyungjin Oh Junsung Lim Goodman,
  D.J., Channel-Dependent Scheduling of an Uplink
  SC-FDMA System with Imperfect Channel
  Information Wireless Communications and
  Networking Conference, 2008. WCNC 2008. IEEE
  March 31 2008-April 3 2008 Page(s)1860 - 1864
• Junsung Lim Myung, H.G. Kyungjin Oh Goodman,
  D.J., Proportional Fair Scheduling of Uplink
  Single-Carrier FDMA Systems Personal, Indoor and
  Mobile Radio Communications, 2006 IEEE 17th
  International Symposium on 11-14 Sept. 2006
  Page(s)1 - 6
• Junsung Lim Myung, H.G. Kyungjin Oh Goodman,
  D.J., Channel-Dependent Scheduling of Uplink
  Single Carrier FDMA Systems Vehicular Technology
  Conference, 2006. VTC-2006 Fall. 2006 IEEE 64th
  25-28 Sept. 2006 Page(s)1 - 5
• Yan Lin Guangxin Yue, Channel-Adapted and
  Buffer-Aware Packet Scheduling in LTE Wireless
  Communication System Wireless Communications,
  Networking and Mobile Computing, 2008. WiCOM '08.
  4th International Conference on 12-14 Oct. 2008
  Page(s)1 - 4
• Ruiz de Temino, L. Berardinelli, G. Frattasi,
  S. Mogensen, P., Channel-aware scheduling
  algorithms for SC-FDMA in LTE uplink Personal,
  Indoor and Mobile Radio Communications, 2008.
  PIMRC 2008. IEEE 19th International Symposium
  on15-18 Sept. 2008 Page(s)1 - 6
• Saatsakis, A. Tsagkaris, K. von-Hugo, D.
  Siebert, M. Rosenberger, M. Demestichas, P.,
  Cognitive Radio Resource Management for
  Improving the Efficiency of LTE Network Segments
  in the Wireless B3G World New Frontiers in
  Dynamic Spectrum Access Networks, 2008. DySPAN
  2008. 3rd IEEE Symposium on14-17 Oct. 2008
  Page(s)1 - 5
• Jung-Lin Pan Olesen, R. Grieco, D. Chia-Pang
  Yen, Efficient Feedback Design for MIMO SC-FDMA
  Systems Vehicular Technology Conference, 2007.
  VTC2007-Spring. IEEE 65th22-25 April 2007
  Page(s)2399 - 2403
• Liu, Jin Wang, Liang You, Mingli Wen,
  Pingping, A Special Open-Loop Transmit Antenna
  Selection Mode in the SC-FDMA Systems for 3G LTE
  Military Communications Conference, 2007. MILCOM
  2007. IEEE 29-31 Oct. 2007 Page(s)1 - 5
• Tavangaran, N. Wilzeck, A. Kaiser, T., MIMO
  SC-FDMA system performance for space time /
  frequency coding and spatial multiplexing Smart
  Antennas, 2008. WSA 2008. International ITG
  Workshop onVolume , Issue , 26-27 Feb. 2008
  Page(s)382 386
• Zijian Bai Berkmann, J. Spiegel, C. Scholand,
  T. Bruck, G.H. Drewes, C. Gunzelmann, B.
  Jung, P.,   On MIMO with successive interference
  cancellation applied to UTRA LTE Communications,
  Control and Signal Processing, 2008. ISCCSP 2008.
  3rd International Symposium on 12-14 March 2008
  Page(s)1009 - 1013
• Ribeiro, C.B. Hugl, K. Lampinen, M. Kuusela,
  M., Performance of linear multi-user MIMO
  precoding in LTE system Wireless Pervasive
  Computing, 2008. ISWPC 2008. 3rd International
  Symposium on 7-9 May 2008 Page(s)410 - 414
• LTE-Advanced takes an important step forward-
  http//www.telecommagazine.com/Newsglobe/article.a
  sp?HH_IDAR_4623
• 3GPP Presentation on the LTE-Advanced as an
  IMT-Advanced Technology Solution (RP-080756)
  http//groups.itu.int/Portals/17/SG5/WP5D/Workshop
  /3GPP20-20LTE-Advanced20as20an20IMT-Advanced
  20Technology20Solution20-20N20Magnani.pdf
• Progress on LTE Advanced- the new 4G standard
  By Eiko Seidel, Nomor Research GmbH
  http//www.nomor.de/uploads/_c/V1/_cV1fTZl6MtFnAHV
  XltStg/LTEAdvanced_2008-07.pdf
• Parkvall, S. Dahlman, E. Furuskar, A. Jading,
  Y. Olsson, M. Wanstedt, S. Zangi, K.,
  LTE-Advanced Evolving LTE towards IMT
  Advanced Vehicular Technology Conference, 2008.
  VTC 2008-Fall. IEEE 68th 21-24 Sept. 2008
  Page(s)1 5.
• Single Carrier FDMA By Hyung G. Myung, May 18,
  2008 http//www.scribd.com/doc/13905822/Single-Ca
  rrier-FDMA hgmyung.googlepages.com/scfdma.pdf

52

• Thank You !
