Class 14: Internetworking with Remote Access, Wireless Networking

1
Class 14 Internetworking with Remote Access,
Wireless Networking
2
Connecting to the Network at My Workplace

• Virtual Private Networking (VPN)
• Trend in mobile computing
• Employs the Internet as long-distance carrier to
  enable distant, secure LAN connections
• Windows XP VPN
• Encrypts all traffic
• Setup with New Connection Wizard

3
Setting Up an Advanced Connection

• Used to
• Establish direct connection between two systems
• Transfer large amount of data with no network
  connection
• Use serial or parallel cable
• Configure system to answer inbound dial-up calls
• Can act as remote access server for single
  incoming connection
• Only for special-purpose applications

4
Alternate IP Configuration

• Available whenever networking connection object
  uses DHCP
• Preconfigure alternate default IP configuration
  if DHCP fails
• Prevents APIPA address from being assigned

5
Remote Access Security

• Built on Windows XP local and network security
• Dial-up connection objects
• Authentication and encryption security options
• VPN
• Used to secure remote access

6
Certificates

• Provide proof of identity for network and
  Internet communications
• Allow systems to trust unknown online parties for
  the purposes of
• Exchanging information
• Exchanging Data
• Performing e-commerce
• Product of cryptographic mechanism known as
  public key infrastructure (PKI)

7
Certificates (continued)

• Certificate Authority (CA)
• Responsible for
• Creating
• Issuing
• Managing
• Revoking certificates
• Can be server computer system within
  organizations network or service offered by
  independent third-party organization

8
Internet Options Applet

• Used to define settings for Internet Explorer and
  general Internet access
• Four Web zones
• Internet
• Local intranet
• Trusted sites
• Restricted sites

9
Internet Options Applet (continued)

• Security restrictions
• Low
• Medium Low
• Medium
• High

10
Windows XP and the Internet

• Tools to help access the Internet
• Internet Explorer
• Outlook Express
• FTP client,
• Telnet client
• Internet Information Server (IIS)

11
Internet Explorer

• Version 6.0 is included
• State-of-the-art Web browser
• Tightly integrated with other Windows
  applications
• Wide range of security related configuration
  options
• Can be used as FTP client.

12
Outlook Express

• Popular e-mail client utility
• Part of Microsoft Office
• Outlook Express included in Windows XP
• Used to read and write e-mail
• Used to file and sort messages
• Contact management tool

13
FTP Client

• Command-line implementation of FTP client
  included in Windows XP
• Numerous freeware and shareware GUI
  implementations
• More user-friendly

14
Telnet Client

• Simple tool provided in Windows XP
• Attempts to establish Telnet session with remote
  system based on domain name or IP address

15
Internet Information Server

• Reduced functionality version of Internet
  Information Server (IIS) included with Windows XP
• Allows system to host Web and FTP services
• Limited to 10 simultaneous connections
• Not designed or intended for public Web/FTP site
  hosting

16
Client Vs. Server-based Remote Access

• Limited to a single incoming dial-up connection
• Can support only 10 simultaneous network
  connections
• Can share an Internet link with a workgroup

17
Wireless Networking

• Access Points
• Can Be Part of a SOHO Router
• Host requires a Wireless Card
• AKA WiFi
• Fully Supports TCP/IP

18
Wireless 802.11b

• First Widely Used Standard
• Frequency 2.4 GHz
• Speed 11mb
• Range100ft indoors / 1000 outdoors
• Pros lowest cost signal range is best and is
  not easily obstructed
• Cons slowest maximum speed supports fewer
  simultaneous users appliances may interfere on
  the unregulated frequency band

19
Wireless 802.11a

• Implemented simultaneously though not adopted as
  readily as -a
• Speed 54mb
• Hybrids of Best of Breed a b also made, but
  not integrated
• Pros fastest maximum speed supports more
  simultaneous users regulated frequencies prevent
  signal interference from other devices
• Cons highest cost shorter range signal that is
  more easily obstructed

20
Wireless 802.11g

• First Widely Used Standard
• Speed 54mb
• Frequency 2.5GHz Best Penetrating Power
• Hybrids of Best of Breed a b also made, but
  not integrated
• Pros fastest maximum speed supports more
  simulatenous users signal range is best and is
  not easily obstruct
• Cons costs more than 802.11b appliances may
  interfere on the unregulated signal frequency

21
Wireless Bluetooth

• Short Range 10 Meters
• Speed 1mb
• Used mostly to connect two devices (typically
  PDAs, phones, and wearable scanners in
  industrial applications
• Low cost

22
Wireless Other Setup Parameters

• Infrastructure Mode
• Use Access Points to Communicate With Other
  Wireless Devices and to Network
• Ad-Hoc Mode
• Peer to Peer network where Devices Communicate
  Without an Access Point

23
Wireless Some Pictures
24
Wireless Some Pictures
25
Wireless Some Pictures
26
Wireless Some Pictures
27
Wireless Some Pictures
28
Wireless Security

• None
• WEP 64 bit
• WEP 128 bit
• WPA
• RADIUS, PAP, CHAP
• MAC Inclusion Exclusion
• IPSec

29
Wireless Security

• SSID The Broadcast Name Can be set to not
  reveal name
• Change Default Base Station Name
• Encrypt Wireless Password Using WPA
• Allow Only Authorized MACs
• Network Secure
• Password Discipline - Used, Changed, Strong

30
Wireless Other Issues

• Troubleshooting Connections
• Using Multiple Locations Can Reset Security
• Settings Variances Between AP and Wireless Card
• MAC List Usage
• 3rd Party Firewalls
• WID Devices
• ???
