Inside the Internet and the Web

1
Chapter 10

• Inside the Internet and the Web

2
Topics
Its a bit like climbing a mountain. You dont
know how far youve come until you stop and look
back. Vint Cerf

• The Internet A Network of Networks
• Internet Applications Communication and
  Connection
• Inside the World Wide Web
• The Evolving Internet

3
The Internet A Network of Networks

• The Internet is an interconnected network of
  thousands of networks linking academic, research,
  government, and commercial institutions.

4
Internet Services

• The Internet provides scientists, engineers,
  educators, students, business people, and others
  with a variety of services such as
• Electronic mail (send/receive mail messages)
• Remote login (Telnet - access to other computers)

5
Internet Services

• Transferring files (FTP - accessing archives of
  data)
• Newsgroups (Usenet - on-line public discussions)
• World Wide Web (a collection of multimedia
  documents)

6
Counting Connections

• Today, the Internet connects computers to about
  every country in the world. However, the
  Internet is
• growing too fast to measure its growth
• too decentralized to quantify
• a network with no hard boundaries

7
Internet Protocols

• The language at the heart of the Internet is
  TCP/IP
• Transmission Control Protocol/Internet Protocol
• Allows cross-network communication

8
Internet Protocols

• TCP breaks messages into packets
• Each packet has all the information needed to
  travel from network to network
• Host systems called Routers determine how to
  route transmissions

9
Internet Protocols

• IP is the address for the packets
• Each Internet host computer has a unique IP
  Address
• Each address is comprised of four sets of numbers
  separated by periods, such as 123.23.168.22

10
Internet Addresses

• The host is named using DNS (domain name system),
  which translates IP addresses into a string of
  names.

Each person on the Internet has a unique
e-mail address created by having a squirrel run
across a computer keyboard. Dave Barry
11
Internet Addresses

• Top level domains include

• .edu - educational sites
• .com - commercial sites
• .gov - government sites
• .mil - military sites
• .net - network administration sites
• .org - nonprofit organizations

12
Country Top-Level Domains
ISO approved country domains

• ccTLDs Country Code Top-Level Domains
• Follows ISO 3166-1
• ca -- Canada
• jp Japan
• nu -- Niue
• uk United Kingdom
• us United States
• tv Tuvalu
• And more

13
Internet Addresses

• An Internet address includes username_at_hostname.su
  b.dom

• username is the persons mailbox
• hostname is the name of the host computer and is
  followed by one or more domains separated by
  periods
• host.subdomain.domain
• host.domain
• host.subdomain.subdomain.domain

14
Internet Addresses
Examples
User President whose mail is stored on the host
whitehouse in the government domain

• president_at_whitehouse.gov

User hazel_filbert at the server for Lane County,
Oregon, k-12 school district
hazel_filbert_at_lane.k12.or.us
15
Internet Access Options

• Direct (dedicated) Connection

• Computer has its own IP address and is attached
  to a LAN
• No need to dial up
• Files are stored on your computer
• Response time is quick

16
Internet Access Options

• Dialup Connections
• limited connection using a modem
• Full access dial up uses SLIP or PPP via modem
• Broadband Connections
• DSL service is newer, faster, and cheaper than
  ISDN
• Can share phone line with voice traffic

17
Internet Access Options

• Cable Modem Connection
• allow Internet connections using shared TV cables
• can exceed DSL speeds
• Carry increased privacy and security risks
• Satellite Connections
• provides connections using DirecTV satellite
  dishes

18
Internet Access Options

• Internet Service Providers (ISPs)
• local ISPs provide connections through local
  telephone lines
• national ISPs offer connections on a nationwide
  scale

19
Internet ApplicationsCommunication and
Connection

• The Internet use the client/server model for most
  Internet applications.
• In the client/server model a client program asks
  for information, and a server program fields the
  request and provides the requested information
  from databases and documents.

20
Internet ApplicationsCommunication and
Connection

• An email server acts like a local post office for
  a particular Internet hosta business, an
  organization, or an ISP.
• File servers are common within LANs, but theyre
  also used to share programs, media files, and
  other computer data across the Internet.

21
Internet ApplicationsCommunication and
Connection

• File transfer protocol (FTP) allows users to
  download files from remote servers to their
  computers and to upload files.
• File compression saves storage space on disk and
  saves transmission time when files are
  transferred through networks.

22
Internet ApplicationsCommunication and
Connection

• An application server stores applications- PC
  office applications, databases, or other
  applications - and makes them available to client
  programs that request them.
• An application server might be housed at an
  application service provider (ASP) - a company
  that manages and delivers application services on
  a contract basis.
• A Web server stores Web pages and sends pages to
  client Web browsers.

23
Inside the Web

• WWW is a distributed browsing and searching
  system developed at CERN
• System was designed to give Internet documents
  unique addresses
• HTML language was created for encoding and
  displaying documents
• Browser software was built for viewing documents
  from remote locations

24
Inside the Web
Web site Jargon

• Web pages are made up of text and images
• A Web site is a collection of web pages
• A Home page is the main entry to a Web site
• A Web browser like Netscape Communicator or
  Internet Explorer allows you to explore the Web
  by clicking links

25
Inside the Web
Hyperlinks (links) are words or pictures that
act as buttons, allowing you to go to another Web
page

• Links are typically underlined or displayed in a
  different color

26
Inside the Web

• More Web site Jargon
• Links allow you to locate information without
  knowing its exact location (it may move from time
  to time)
• Back and Forward buttons let you retrace your
  steps
• Bookmarks and Favorites can be set up to mark
  your favorite Web locations

27
Web Addresses
Pronounced Earllike the name
A typical URL looks like this http//www.prenhall
.com.beekman
28
Web Addresses

• Dissecting Web Page address

• Protocol for Web pages

Resource Page
29
Publishing on the Web
HTML (Hypertext Markup Language)

• An HTML document includes codes that determines
  the format, layout, and structure of a Web
  document

HTML is not WYSIWYG
30
Publishing on the Web

• This text coded as HTML

ltH1gtWelcome to Computer Confluencelt/H1gtltbgtPublish
ing on the Weblt/bgt
Appears like this on the screen
31
Publishing on the Web

• Alternatives to HTML
• Programs that convert document format features
  into HTML codes
• Microsoft Word, FileMaker
• Web authoring programs
• HomePage, GoLive, FrontPage

32
From Hypertext to Multimedia
Typical Web pages can contain

• Tables
• Frames
• Forms
• Downloadable audio and video

• Streaming audio and video
• Real-time live audio or video
• 3-D environments

33
From Hypertext to Multimedia

• Plug-Ins are software extensions that add new
  features. Examples include

• QuickTime
• Shockwave/Flash
• RealPlayer
• Acrobat

34
Beyond HTML

• Dynamic HTML
• adds more programming power to HTML by allowing
  code to automatically modify itself under certain
  circumstances

JavaScript a simple language for enhancing HTML
Web pages
35
Beyond HTML

• WML
• Wireless Markup Language helps create Web
  documents containing stock quotes, phone numbers,
  and other small nuggets of information
• XML
• Will replace HTML plus provide additional
  features and extensions
• VRML
• Virtual Reality Modeling Language creates 3-D
  virtual worlds

36
Beyond HTML

• Java
• A full-featured, cross platform, object-oriented
  programming language
• Java applets
• Small Java programs that can be automatically
  downloaded onto your client computer and can run
  on any platform

37
