Disaster Recovery and Business Continuity Planning in a University Environment

1
Disaster Recovery and Business Continuity
Planningin a University Environment

• Mardecia Bell
• Ann Harris

2

• The realization of a single point of failure
  with one data center for both the central
  academic and administrative IT environments,
  prompted NC State University to implement a
  disaster recovery strategy for communications and
  critical applications residing on the mainframe
  open systems computing environment.

3
History/Timeline
1997 Initiated with the administrative environment Mainframe environment recovery test
1999 Y2K - Business Continuity concept Acquired central repository software (LDRPS)
2001 Scheduled annual Mainframe recovery test Included communications academic environment
2002 Expanded to include Enterprise Business Continuity/Disaster Recovery Planning
2004 Successful DR test of ERP systems
2005 Co-processing of production services began in Data Center II

4
Implementation Steps

• Gain Sponsorship
• Establish Steering Committees
• Develop University Policy/Regulation
• Create DR Structure/Establish Staffing
• Market Program
• Establish Central Repository
• Review Test Plans Regularly

5
Gain Sponsorship

• Office of the President University System
• Chancellor
• Executive Management
• Present your Business Case
• Identify the roles involved
• Provide Executive Summary of BC/DR Program
• Present Statement of Work and Project Plan
• Add responsibilities to staff work plans

6
Establish Steering Committees

• IT Steering Committee
• Business/Service Steering Committee
• Both committees are comprised of
• Vice Chancellor/Vice Provost Level
• Representatives from Critical Areas of the Campus
• Ex Officio members from IT areas
• Mission of IT Steering Committee
• Provide guidance and oversight for the combined
  academic and administrative Disaster Recovery
  Plan.

7
Policy/Regulations/Rule

• Develop a Policy or Regulation to affirm the
  mandate and promote cooperation

8
Divide Campus Into Groupings

• Space/Facilities
• Teaching and Academic Programs
• Academic IT
• Administrative IT
• Environmental Health and Public Safety
• Business Administration
• Research Programs
• Student Affairs
• Extension and Engagement

9
Resource Projections

• Hire Full-Time Business Continuity and Disaster
  Recovery Personnel
• Director of Business Continuity (plus 1 Business
  Analyst)
• Admin IT DR Coordinator (plus 1 Business Analyst)
• Academic DR Coordinator (part-time)
• Add BC/DR responsibilities to work plan of
  existing staff
• Identify Coordinators for each business unit

10
Marketing

• Present at campus departmental meetings
• Create a Website
• Utilize listserves
• Campus Newspaper
• Network with peer institutions
• Remain abreast of industry standards
• Attend conferences, workshops and seminars

11
Establish Central Information Repository
Continuous Implementation
12
Accomplishments

• Disaster Recovery and Business Continuity Plan
• Risk Assessments for Critical Business Units
• Successful Mainframe Recovery Tests
• Designed and implemented infrastructure for
  central computing environment (academic
  administrative) in secondary data center.
• Implementation of recovery strategies in
  secondary data center
• Creation of Administrative IT Disaster Recovery
  Unit

13
Illustration of Various DR Deployments
14
Enterprise Resource Planning (ERP) Deployment
DC II
15
Summary and Future Steps
16
Administrative IT Disaster Recovery Unit Mission

• Ensure minimal risk of major disruptions to
  critical University systems and processes in the
  event that all or part of its computer operations
  are rendered inoperable.
• Ensure timely recovery of infrastructure and
  services in the event of a disruption.
• Ensure that business continuity plans are
  available and viable relative to its scenario.

17
(No Transcript)
18
Risk Management

• Identify
• Mitigate
• Process Mapping

19
Risk Management

• Risk Mitigation
• Prioritize Actions
• Evaluate recommended Control Options
• Conduct Cost-Benefit Analysis
• Select Controls
• Assign Responsibility
• Develop Safeguard Implementation Plan
• Implement Selected Controls

• Risk Assessment
• System Characterization
• Threat Identification
• Vulnerability Identification
• Control Analysis
• Likelihood Determination
• Impact Analysis
• Risk Determination
• Control Recommendations
• Results Documentation

NIST SP 800-30
20
Process Mapping
21
Infrastructure

• Total DR through distributed high availability
• Client Recovery Solutions
• Application Restoration
• Establish collaborative partnerships with other
  Universities

22
Client Recovery Solution(s)
23
Application Restoration

• Event
• Time
• Scope of Impact
• Infrastructure
• Software
• Hardware

24
Collaborative Partnerships
25
Vaulting

• Readily accessible
• Secure
• Onsite
• Offsite

26
Critical Business Units

• Enterprise Technology Services and Support
• Facilities - Construction Management
• Facilities - Design and Construction Services
• Facilities - Operations
• Facilities - University Architect
• Fire Protection
• Foundations Accounting Investments
• HR - Benefits
• HR - Employment Compensation
• HR - Human Resource Information Management
• HR - Payroll
• ITD - Business Services
• ITD - Computer Operations
• ITD - Computer Services
• ITD - Systems
• Libraries - Administration
• Materials Management - Materials Support
• Materials Management - Purchasing
• Materials Management - University Graphics

• Advancement Services
• All Campus Network
• Budget Office
• College of Agriculture and Life Sciences -
  Personnel Office
• ComTech - Data Networking
• ComTech - Telecommunications
• Contracts and Grants
• Controller's Office
• Enterprise Application and Database Services
• EHS - Business Continuity
• EHS - Campus Police
• EHS - Emergency Response
• EHS - Environmental Affairs
• EHS - Health and Safety
• EHS - Industrial Hygiene
• EHS - Insurance and Risk Management
• EHS - Radiation Safety
• EHS - Transportation
• EHS - Waste Management

27
Business Continuity Planning
28
Communication

• Consistency in plan updating
• Training
• Partnering
• Emergency Communication standardization
• Call Trees
• Mobile Devices
• Website
• Incident Command System Call Center
• Incident Report Plan

29
IT Disaster Categorization

• Category 1 A single person or group in a
  Critical Business Unit (CBU) is unable to perform
  their critical functions
• Category 2 An entire CBU is unable to perform
  its critical functions
• Category 3 Multiple CBUs are unable to perform
  their critical functions
• Category 4 Non CBUs are not able to perform
  their critical functions
• Category 5 A wide spread event that impacts the
  entire University

30
Goals

• Total DR through distributed high availability
• Standardized Emergency Communications
• Immediate Client Recovery Solutions
• Improved RTO

31

• Ann Harris
• Asst Dir, Administrative IT Disaster Recovery
• 919-515-9228
• ann_harris_at_ncsu.edu
• http//www.fis.ncsu.edu/dr
