THE MOON

1
THE MOON
2
Definitions

• Year time that a planet takes to go around the
  sun once.
• Revolution motion of a body orbiting another
  body in space
• Prograde rotation counterclockwise spin of a
  planet or moon as seen from above the planets
  North Pole (rotates in the same directions as the
  suns rotation), EARTH

3

• Retrograde rotation the clockwise spin of a
  planet or moon as seen from above the planets
  North Pole. Venus, Uranus
• Greenhouse effect carbon dioxide traps thermal
  energy from sunlight, causes surface temperatures
  to increase
• Gas Giants planets that have deep, massive
  atmospheres rather than hard rocky surfaces like
  those of the inner planets

4

• Satellites natural or artificial bodies that
  revolve around larger bodies such as planets.
  All planets, except MERCURY and VENUS have
  satellites.
• Phases change in the sunlit area of one
  celestial body as seen from another celestial
  body.
• Eclipse an event in which the shadow of one
  celestial body falls on another

5
Measuring Distance in Space

• Astronomical Unit the average distance between
  the Earth and the Sun
• Using the speed of light light travels at about
  300,000 km/s in space
• In 1 second, light travels 300,000 km.
• In 1 minute, light travels nearly 18,000,000 km
  LIGHT MINUTE
• 1 AU 8.3 light minutes

6
Astronomical Unit the average distance between
the Earth and the Sun
7
Solar System Divided into two main parts

• Inner solar system contains four planets that are
  closest to the sun (Mercury, Venus, Earth and
  Mars)
• More closely spaced
• Terrestrial planets
• Dense and rocky

8
Inner Planets
9

• Outer system contains 4 planets farthest from the
  sun. (Jupiter, Saturn, Uranus, Neptune)
• Composed mostly of gas
• GAS GIANTS
• Pluto is now considered a satellite of Neptune
  Its not composed of gas is small, dense and
  rocky

10
The Outer Planets
11
Why did the Earth have such good fortune?

• Its just at the right distance from the Sun
• Warm enough to keep most of its water from
  freezing
• Cool enough to keep its water from boiling away
• Liquid water is a vital part all living things
  depend on

12
The surface of bodies that have no atmosphere
preserve a record of almost all of the
impacts that the bodies have had.
13
LUNAR ORIGIN

• 3 possible explanations for the moons
  formation
• Moon was a separate body captured by Earths
  gravity
• Moon formed at the same time and from the same
  materials as the Earth
• The newly formed Earth was spinning so fast that
  a piece flew off and became the moon

14

• When a moon rock was brought back, scientist
  found that the composition of moon was similar to
  that of the Earths mantle.
• CURRENT THEORY large, Mars-sized object
  collided with Earth while Earth was still
  forming. Collision was so violent that part of
  the Earths mantle was blasted into orbit around
  Earth to form the moon.

15
Origin of the moon
IMPACT
EJECTION
FORMATION
16
Basic Moon Stats

• 384,000 Km away
• 3476 km in diameter (1/4 of Earth)
• Density 3.3 g/cc
• Mass is 1/80 of Earth
• Gravity is 1/6 of Earth

17
Basic Moon Stats

• Temp varies from -175 C to 100 C!!!
• Age is similar to Earth
• No Atmosphere or water
• Revolves once every 27.3 days
• Rotates once every 27.3 days
• Blue Moon 2 full moons in one month (1)

18
Exploration of the Moon

• Apollo Moon Landing Project
• Neil Armstrong walked on moon in 1969
• Ended in 1972
• Humans havent been back since

19

• Perigee-moon is closest to Earth
• Apogee-moon is furthest from Earth

20

• Perigee Apogee
• 356410 km 406700 km
• 5 Variation in distance from Earth!

21
(No Transcript)
22
PHASES OF THE MOON

• The different phases are due to its changing
  position
• WAXING sunlit fraction that we see is getting
  BIGGER (lit on the RIGHT)
• WANING sunlit fraction that we see is getting
  SMALLER (lit on the LEFT)

23
PHASES OF THE MOON
24
PHASES OF THE MOON

• Total amount of sunlight that the moon gets
  remains the same Half the moon is always in
  sunlight
• Because the moons period of rotation is the same
  as its period of revolution on Earth you always
  see the same side of the moon

25
PHASES OF THE MOON
26
(No Transcript)
27
Does the Moon Rotate?

• We always see the same side of the Moon its
  rotation and revolution are equal
• Synchronous Rotation

28
The Moon and The Tides
29
Neap Tide

• Neap Tide-A weaker than average tide due to the
  conflicting gravitational forces of the sun and
  moon

30
Spring Tide

• Spring Tide-A stronger than average tide due to
  the gravitational forces of the sun and moon
  working together (3)

31
ECLIPSES

• When the shadow of one celestial body falls on
  another, an eclipse occurs.

32
SOLAR ECLIPSE

• SOLAR ECLIPSE happens when the moon comes
  between Earth and the sun and the SHADOW OF THE
  MOON FALLS ON PART OF THE EARTH
• Only occurs during NEW MOON PHASE

33
SOLAR ECLIPSE - we see some portion of the Sun's
disk covered or 'eclipsed' by the Moon.
34
Solar Eclipse
35
Solar Eclipse

• During a total solar eclipse, the disk of the
  moon completely covers the disk of the sun.

36
Total Solar Eclipse
37
LUNAR ECLIPSE

• Happens when earth comes between the sun and the
  moon and THE SHADOW OF EARTH FALLS ON THE MOON
• Only occurs during FULL MOON PHASE
• Because the moons orbit is elliptical, the
  distance between the moon and the Earth changes

38
Lunar Eclipse
39

• The shadow of the Earth falls on the moon
• Which gives the moon a reddish tint

40
Lunar Eclipse
41
Annular Eclipse type of solar eclipse

• During an annular eclipse, the disk of the moon
  does not completely cover the sun
• During a total solar eclipse the disk of the moon
  does completely cover the sun only the corona
  is visible

42
annular eclipse
43
Total Solar Eclipse
44
Orbit of the Moon

• The moons orbit around Earth is tilted about 5º
  relative to the orbit of Earth.
• This is why there arent solar and lunar eclipses
  every month

45
Tilt of the Moons Orbit

• Tilt is enough to place the moon out of Earths
  shadow for most full moons and Earth out of the
  moons shadow for most new moons.
