Query Processing in Mobile P2P Databases

1
Query Processing in Mobile P2P Databases
IGERT Seminar Presentation Bo Xu joint work with
Ouri Wolfson
2
Talk outline

• Introduction
• System Model
• The MARKET Algorithm
• Evaluation
• Extension to CTS
• Conclusion and Future Work

3
Query Processing Environments
Motivation a general purpose query processing
strategy mobile disconnected wireless ad-hoc
networks
4
Store-and-forward to deal with sparseness
A
QA
r
Q
Q
q
A
A
qA
5
Issues with Store-and-forward

• How to manage limited memory, power, and
  bandwidth?
• Which reports to save/transmit?

6
Difficulty of Store-and-forward
Case Each mobile node is interested in every
data-item
Assume that the trajectories of all nodes is
known a priori at a central server. If memory,
energy, and bandwidth are bounded at mobile
nodes, then the problem of determining whether a
set of data-items can be disseminated to all the
mobile nodes is NP-complete.
Mobile P2P Trajectories unknown a priori
Heuristics needed
7
Talk outline

• Introduction
• System Model
• The MARKET Algorithm
• Evaluation
• Extension to CTS
• Conclusion and Future Work

8
Mobile P2P Database
Pdas, cell-phones, sensors, hotspots, vehicles,
with short-range wireless capabilities
C
A
B

• Applications coexist
• Variable report sizes
• A peer can be a produce, consumer, and broker

9
Queries

• A query Q maps each report R to a match degree
• Examples
• Top parking slots given my current location
• Profile with expertise children-periodontics
• Similarity between two images

match(R,Q)e-?t-?d

10
Query/report Dissemination

• Two peers within transmission range exchange
  queries and reports
• Least relevant reports that do not fit in local
  broker database are purged
• Exchange not necessarily synchronous (periodic
  broadcast)

11
Talk outline

• Introduction
• System Model
• The MARKET Algorithm
• Evaluation
• Extension to CTS
• Conclusion and Future Work

12
Ranking Factors

• Rank of a report R is determined by
• Demand What fraction of peers are querying R
• Probability that a peer is interested in R
• Supply What fraction of peers already have R
• Probability that a peer has R
• Size of R

13
Rank of a report
expected benefit demand(R)(1?supply(R))
14
Report Ranking sample demand
Queries relation is FIFO maintained
15
Rank of Reports

• Demand for R
• Qis are the members of the queries relation
• Size of the queries relation determined based on
  Hoeffdings inequality

E.g., if n108, then with 95 chance the demand
estimation error is smaller than 0.08
16
How does peer O determine supply(R)?

• A parametric formula giving the supply is beyond
  the state of the art
• O machine-learns supply(R) based on meta-data of
  R
• Age of R
• Number of times O sighted R from other peers
• etc.

17
Computing Supply by Machine-learning
MAchine LEarning based Novelty rAnking (MALENA)
Reports database of O
Report
Report
aro
fin
aro
fin
report
-
id
report
-
id
description
description


R1
1 1
R1
1 1


R4
2 4
R4
2 4


R2
3 2
R2
3 2


R7
4 2
R7
4 2
aro The age rank order within Os reports
database fin The number of times O has sighted
the report from other peers
18
MALENA
Examples created
negative
positive
Request R2
19
MALENA Implementation Considerations

• Minimize overhead
• No need to actually store examples
• Model incrementally built
• Bayesian learning a simple but effective method

20
Talk outline

• Introduction
• System Model
• The MARKET Algorithm
• Evaluation
• Extension to CTS
• Conclusion and Future Work

21
Comparison with RANDI (MDM07)
mobility modelrandom way point, average motion
speed1 mile/hour transmission range100 meters,
mean of reports database size100Kbytes queries
database size100 queries report size uniformly
distributed between 1K and 2K bytes 0.1 report
produced per second
1 peer within transmission range
20 peers within transmission range
MARKET half as good as ideal benchmark MARKET
twice better than RANDI
RANDIMARKET-supply
22
Comparison with LRU and LFU
mobility modeliMotes traces mean of reports
database size150Kbytes queries database size10
queries report size uniformly distributed between
2K and 20K bytes 0.1 report produced per second,
transmission size100Kbytes
throughput (matches/peer)
response-time bound (second)
(results obtained by Fatemeh Vafaee)
23
Evaluation of MALENA (TAAS09)
turn-over peers enter/exit system injection
number of peers that have a report
initially mobility modeliMotes traces, reports
database size100 reports 2 reports produced per
second, transmission size10 reports
MALENA always follows the best indicator
24
Application K-nearest-neighbors
query-point
sink

• Query K-nearest-neighbors of a fixed location
  (query-point)
• Reports current locations of mobile sensors
• match(Q,R) in reverse proportion to the distance
  from query point

25
Itinerary based KNN processing
Phase I Query delivered to the sensor closest to
query point
Phase II Query traverses an itinerary to collect
answers
Phase III Answers returned to sink
26
Simulation Results
mobility modelrandom way point, average motion
speed1 mile/hour transmission range100 meters
report size24 bytes, query size16 bytes mean
of reports database size100 reports one location
report produced at each sensor per second
MARKET is especially suitable for sparse
environments
27
Talk outline

• Introduction
• System Model
• The MARKET Algorithm
• Evaluation
• Extension to CTS
• Conclusion and Future Work

28
TrafficInfo Disseminating Traffic Information in
VANETs
29
What does relevance mean in TrafficInfo
B
B
A
A
A report is relevant if it changes the route
30
Which factors indicate relevance of report?

• Distance to the reported road segment
• Type of road segment
• Speed variance

31
Conceptual Learning Procedure

• An example is created for a received report
• The example is labeled positive if the report
  changes route and negative otherwise
• Individual vs. group
• How to deal with aggregation?

32
Conclusion
sensor-rich environment
short-range wireless

• Query processing

Mobile P2P

?

• Store-and-forward enables in-network processing
  in mobile disconnected networks
• Ranking is important for dealing with memory,
  bandwidth, and energy constraints

33
Future Work

• Multimedia reports
• Utilization of metadata
• Integration of stateless and stateful approaches
• Starvation/fairness

34
Thanks! Questions?
35
802.11 Basics

• 3 modes transmitting, receiving, listening
  (order of power consumption)
• When listening if detecting a message destined
  to host ? receive-mode
• Time divided into slots, 20microsecs each
• Transmission
• Listen for 1 time slot
• If channel free start broadcast (observe
  collision possible)
• Broadcast may last for many time slots

36
Energy Efficiency of a Broadcast
successfully receive the broadcast from x
Collisions occur at neighbor
Throughput (Th) (expected number of neighbors
that successfully receive broadcast) ? (broadcast
size) Power efficiency (PE)
37
Computation of Throughput
X
Y
Conditions for successful reception at an
arbitrary node Y

1. No green node inside starts to broadcast at the
   same time slot with X
2. No transmission from any purple node overlaps
   with that from X

38
Energy Constraints

• Energy consumed by a 802.11 network interface for
  transmitting a message of size M bytes
• Enf?Mg
• For 802.11 broadcast, g266?10-6 Joule,
  f5.27?10-6Joule/byte
•


39
Experimental MP2P Projects (Pedestrians)

• 7DS Columbia University (web pages)
• iClouds Darmstadt Univ. (incentives)
• MoGATU UMBC (specialized query processing,
  e.g., collaborative joins)
• PeopleNet NUS, IIS-Bangalore (Mobile commerce,
  information type ? location baazar)
• MoB Wisconsin, Cambridge (incentives,
  information resources e.g. bandwidth)
• Mobi-Dik Univ. of Illinois, Chicago (brokering,
  physical resources, bandwidth/memory/power
  management)

40
Vehicular Projects

• Inter-vehicle Communication and Intelligent
  Transportation
• CarTALK 2000 is a European project
• VICS (The Vehicle Information and Control System)
  is a government-sponsored system in Japan with an
  11-year track record
• FleetNet, an inter-vehicle communications system,
  is being developed by a consortium of private
  companies and universities in Germany
• IVI (Intelligent Vehicle Initiative) and VII
  (Vehicle Infrastructure Integration), the US DOT
• MP2P provides data management capabilities on top
  of these communication systems
• Grassroots, TrafficView, SOTIS, V3 P2P
  dissemination of traffic info to reduce travel
  times

41
RANk-based DIssemination (RANDI)

• Ranking of reports
• Bandwidth/energy aware
• Exchange enhances
• Consumer functionality
• Broker functionality
• Consumer Answer local query (pull)
• Broker Transmit reports most likely requested by
  future-encountered peers (push)
• Transmission trigger
• Encounter
• New reports

42
RANDI
When two peers meet they conduct a two-phase
exchange
local query
Phase 1
answers
satisfied as a consumer (pull)
more reports
Phase 2
enhanced as a broker (push)
Phase 1 Exchange queries and receive answers
(pull) Phase 2 Exchange more reports using
available energy/bandwidth (push)
Combination of unicast (thin line) and
broadcast (thick lines) to enable overhearing.
43
RANDI (Contd)
To solve problem with static peers Two
interaction modes which combine pull and push
new reports

• Query-response triggered by discovery of new
  neighbors

• Relay triggered by receipt of new reports
• Disseminate to existing neighbors

44
7DS
P2P mode each node periodically broadcasts its
query and receives reports from neighboring
peers. No strategy to determine query frequency
and transmission size. Cache management based on
web-page expiration time.
45
PeopleNet
Reports are randomly selected for exchanging and
saving upon encountering.
46
7DS
Each peer periodically broadcasts its query and
receives reports from neighboring peers. No
strategy to determine query frequency and
transmission size. Cache management based on
web-page expiration time.
47
PeopleNet
Reports are randomly selected for exchanging and
saving upon encountering.
Peer A
Peer B
Peer A
Peer B
before exchange
after exchange
48
Mobile Local Search Applications

• transportation
• Announce sudden stop, malfunctioning brake light,
  patch of ice
• Floating car data
• Dissemination of multi-media traffic information
  (picture, video, voice)
• Search close-by taxi customer, parking slot,
  ride-share
• social networking (wearable website)
• Personal profile of interest at a convention
• Singles matchmaking
• Floating BBS
• mobile electronic commerce
• Sale on an item of interest at mall
• Music-file exchange
• emergency response
• Search for victims in a rubble
• asset management and tracking
• Sensors on containers exchange security
  information gt remote checkpoints
• tourist and location-based-services
• Closest ATM

49
Applications Common features

• Mobile/stationary peers
• Resources of interest
• in a limited geographic area
• Short time duration
• Can be solved by fixed servers, but
• Unlikely solution
• Proposed mp2p paradigm can enhance fixed solution
  (reliability, performance, coverage)

50
MARKET
When two peers meet they conduct a two-phase
exchange
Local query
Phase 1
answers
satisfied as a consumer (pull)
more reports
Phase 2
enhanced as a broker (push)
Phase 1 Exchange subscriptions and receive
answers (pull) Phase 2 Exchange more
publications using available energy/bandwidth
(push)
Combination of unicast (thin line) and
broadcast (thick lines) to enable overhearing.
51
MARKET (Contd)
To solve problem with static peers Two
interaction modes which combine pull and push
new publications

• Query-response triggered by discovery of new
  neighbors

• Relay triggered by receipt of new publications
• Disseminate to existing neighbors

52
Query in static disconnected network
A
Q
r
Q
q
Q
A
In-network query processing may not be possible
53
Query in static connected sensor network
A
QA
A
Q
A
r
A
A
Q
q
qA
A
Q
Q
A
Data transmission delay is 0.
Answer can be obtained instantaneously
54
Query in static disconnected network
A
Q
r
Q
q
Q
A
In-network query processing may not be possible
55
Query in mobile disconnected network
Query processing enabled by mobility and
store-and-forward
qA
A
QA
r
q
A
One hop case
56
Query in mobile disconnected network
A
QA
r
Q
Q
q
A
A
qA
The answer is disseminated only after an answer
node receives query
Multil-hop case
Query can be in network processed, but it is
delayed
Query processing alogrithm doesnt control
motion.
First stage query disseminated during encounter
