The Planets Digital Preservation Project

1
The Planets Digital Preservation Project

• DLF, April 2007
• Adam Farquhar

2
Outline

• The Digital Preservation problem
• The Planets project
• Goals
• Status
• Architecture
• The Planets testbed
• The Planets interoperability framework
• Preservation planning

3
Digital information at risk

• Our society risks a gaping hole in the cultural
  and scientific record unless we act now
• European National Libraries and Archives
• Have the legal responsibility and the legislative
  framework to safeguard digital information
• Must provide sustained access to cultural and
  scientific knowledge
• Have limited ability to ensure that todays
  digital information will be accessible for future
  generations
• Meeting the challenge of preserving access goes
  beyond the capabilities of any single institution

4
EU Support for digital preservation

• Major initiative in the Information Science and
  Technology (IST) Framework Programme 6 Call 5
• Two Integrated Projects funded Planets (BL),
  Caspar (CCLRC)
• Coordinated action DPE (HATII at Glasgow)
• Planets builds on strong digital archiving and
  preservation programmes at European, National and
  institutional levels
• Addresses core digital preservation challenges
• Use an empirical approach to learn what works and
  why
• Four year project starting June 2006 with 15me
  budget

5
Losing digital information hurts everyone

• An NHS doctor needs a 1987 clinical study found
  on Google Scholar
• She tries to open the dvi file, but cant
• A father shows his children the computer game he
  wrote in school
• He wrote the game in PDP assembler
• He stored the program on paper tape
• A small business owner wants to market the energy
  saving device it developed in 1985
• She carefully stored all of the files
• Now she doesnt have the applications to read the
  documents, spread-sheets, and CAD drawings
• The CAD company is long out of business

6
Losing digital information costs opportunity

• A university research lab has provided its data,
  technical reports, software on-line since 1984
  and on the web since 1990. The professor retires
  and closes the lab in 2004
• A university IP officer wants to defend a patent
  challenge
• A biographer wants review the unpublished work
• A former student wants to revive a line of
  research
• The digital files
• Some are damaged
• Some rely on applications that are out-of-use
• Some rely on hardware that is unavailable
• Some rely on an environment that no longer exists
• Some rely on information that no-one recorded

7
Losing digital information costs money

• An oil company collected extensive data for a
  reservoir and want to exploit it in 2007
• All documents and data are held in v1.3 of an
  integrated management product
• They now use v9.0 and cant read or access it
• An oilfield services company collects dipmeter
  data in the 1970s
• Stored on 7-Track tapes
• Recorded in optimised formats
• Difficult and expensive to repeat measurement data

8
How big is the problem?

• Who is touched by digital preservation problems?
• Individual consumers
• Small and medium sized enterprises
• Large corporations
• University libraries, faculties, institutes
• Publishers
• Libraries
• Local, regional, national governments
• every person or organisation that keeps digital
  material for more than 15 years!
• Estimates suggest Europe loses 3bn per year in
  business value

9
Planets

• Four-year EU-Funded (FP6) Digital Preservation
  research and technology development project.
• Increase Europes ability to ensure long-term
  access to its cultural and scientific heritage
• Improve decision-making about long term
  preservation
• Ensure long-term access to valued digital content
• Control the costs of preservation actions through
  increased automation, scaleable infrastructure
• Ensure wide adoption across the user community
  and establish market place for preservation
  services and tools
• Build practical solutions
• Integrate existing expertise, designs and tools
• Share and build

10
Planets

• Brings together Archives, Libraries, researchers
  and technology companies
• Builds on strong digital archiving and
  preservation programmes
• Addresses core challenges
• Focuses on needs of Libraries and Archives
• Will provide an interoperable framework to enable
• Third-parties to provide tools and services
• Vendors to integrate preservation services
• Content owners to ensure long-term access to
  their digital content
• Will use an empirical approach to gather evidence
• Outreach shows potential to make a difference

11
Planets partners I

• The British LibraryNational Library,
  NetherlandsAustrian National LibraryState and
  University Library, DenmarkRoyal Library,
  Denmark
• National Archives, UKSwiss Federal
  ArchivesNational Archives, Netherlands

12
Planets partners II

• Tessella Plc
• IBM Netherlands
• Microsoft Research, Cambridge
• Austrian Research Centers
• Hatii at University of Glasgow
• University of Freiburg
• Technical University of Vienna
• University at Cologne

13
The Team
14
Planets approach

• Planning services that empower organisations to
  define, evaluate, and execute preservation plans
• Methodologies, tools and services for
  Characterisation of digital objects
• Innovative solutions for Preservation Actions
• An Interoperability Framework provides services
  distributed services
• A Testbed enables objective evaluation of
  protocols, tools, services and plans
• Outreach, workshops and training to engage the
  user and vendor communities

15
Project architecture reflects problem structure
Digital Content
Preservation Action Services
Org. Context
Test Bedevaluation and validation services
External Context
Characterisation Services
Interoperability Framework
16
Status

• Fall 06
• Built the team
• Gathered initial requirements
• Conducted workshops and surveys
• Winter 07
• Built specifications
• Evaluated component technologies
• Spring 07
• Finalised many technical and implementation
  decisions
• Started to build tools and services
• Summer 07
• Initial prototypes completed
• First experiments conducted

17
Key technology choices

• Extensive use of XML throughout architecture
• Extensive use of web services
• Extensive use of Java and open source components
• JSF (Java Server Faces) for user interfaces
• Workflows
• BPEL Business process execution language to
  describe experiments and plans
• Eclipse BPEL workflow designer
• Repository and interfaces
• JSR-170 Repository API
• Access to digital archives
• Jackrabbit to manage intermediate storage and
  data
• Sandbox technology for some third-party tools
• JBoss application server

18
Testbed

• Provides a foundation for objective evaluation
• Load content
• Experiment collect data, evaluate results,
  compare outcomes
• Validate preservation plans
• Benchmark tools and services
• Consists of
• Data storage, hardware, Planets software, testbed
  software
• Benchmark and other content
• Provides resources for
• The project partners
• The preservation community
• External organisations
• Tool and service certification

19
Testbed Screen Shot
20
Testbed Screen Shot
Run Experiment
21
Interoperability Framework

• Provide the glue to hold the Planets tools and
  services together
• Provide service registries
• Characterisation services
• Preservation action services
• Provide shared services
• Security, authentication, authorisation
• Monitoring, logging, auditing
• Intermediate data, repository, file system space
• Execute and manage workflows
• Enable third-parties to provide tools and
  services
• Enable vendors to integrate preservation services

22
Applications
Testbed
Preservation Planning
CharacternServices
.
Workflow Designer
Admin Tool
Interoperability Framework
Service Bus
Security
Monitoring
Workflow Execution Engine
Transaction Manager
Work Space
Exception Handling
Database Layer
23
Interoperability Framework Workflow design
24
Preservation planning
Preservation Policy
Plans
Preservation Planner
Plan Evaluator
Content Profile
Usage Profile
Sample Content
Plan
Actions
25
Preservation plan execution
Delivery
Adaptor
Executor
Repository
Plan
Content
26
Content characterisation

• Characterise content to support preservation
• Reduce up-front metadata costs
• E.g., Harvard segmented images based on tool
  parameters
• Build on TNAs PRONOM for file-format
  identification
• Define a characterisation language (XCDL)
• Define an extraction language (XCEL)
• Define an pluggable interpreter
• Extend to measure loss due to actions
• All transformations cause loss
• Leverage understanding to improve file formats
• Address a root cause of digital obsolescence

27
Preservation actions

• Transform content
• Wrap third-party transformation tools
• Fill gaps with new tools
• Preserve relational databases
• Build on Swiss Archive work
• Preserve Office content
• Build on MSFT tools

• Transform environments
• Modular emulation of the full hardware/software
  environment
• Provides full look-and feel
• Superb for highly dynamic content
• Leverage Virtual Machine technology
• Layered durable emulation
• Build on IBM Universal Virtual Computer (UVC)
• Establish abstract device drivers

28
Conclusion

• Planets
• Is a major EU co-funded digital preservation
  project
• Addresses the needs of Libraries and Archives
• Has made substantial progress towards a
  service-oriented preservation infrastructure
• Looks forward to working with the international
  Digital Library community to test, evaluate,
  refine, improve

29
Questions?
Thanks! http//www.planets-project.eu/ info_at_plane
ts-project.eu
