Support Vector Machines for Data Fitting and Classification

1
Support Vector Machinesfor Data Fitting and
Classification

• David R. Musicant
• with Olvi L. Mangasarian

UW-Madison Data Mining InstituteAnnual
ReviewJune 2, 2000
2
Overview

• Regression and its role in data mining
• Robust support vector regression
• Our general formulation
• Tolerant support vector regression
• Our contributions
• Massive support vector regression
• Integration with data mining tools
• Active support vector machines
• Other research and futuredirections

3
What is regression?

• Regression forms a rule for predicting an unknown
  numerical feature from known ones.
• Example Predicting purchase habits.
• Can we use...
• age, income, level of education
• To predict...
• purchasing patterns?
• And simultaneously...
• avoid the pitfalls that standard statistical
  regression falls into?

4
Regression example

• Can we use.

• To predict

5
Role in data mining

• Goal Find new relationships in data
• e.g. customer behavior, scientific
  experimentation
• Regression explores importance of each known
  feature in predicting the unknown one.
• Feature selection
• Regression is a form of supervised learning
• Use data where the predictive value is known for
  given instances, to form a rule
• Massive datasets

Regression is a fundamental task in data mining.
6
Part IRobust Regression

• a.k.a. Huber Regression

7
Standard Linear Regression
Find w, b such that
8
Optimization problem

• Find w, b such that

9
Examining the loss function

• Standard regression uses a squared error loss
  function.
• Points which are far from the predicted line
  (outliers) are overemphasized.

10
Alternative loss function

• Instead of squared error, try absolute value of
  the error

This is called the 1-norm loss function.
11
1-Norm Problems And Solution

• Overemphasizes error on points close to the
  predicted line
• Solution Huber loss function hybrid approach

Linear
Quadratic
Many practitioners prefer the Huber loss function.
12
Mathematical Formulation

• g indicates switchover from quadratic to linear

Larger g means more quadratic.
13
Regression Approach Summary

• Quadratic Loss Function
• Standard method in statistics
• Over-emphasizes outliers
• Linear Loss Function (1-norm)
• Formulates well as a linear program
• Over-emphasizes small errors
• Huber Loss Function (hybrid approach)
• Appropriate emphasis on large and small errors

14
Previous attempts complicated

• Earlier efforts to solve Huber regression
• Huber Gauss-Seidel method
• Madsen/Nielsen Newton Method
• Li Conjugate Gradient Method
• Smola Dual Quadratic Program
• Our new approach convex quadratic program

Our new approach is simpler and faster.
15
Experimental Results Census20k
20,000 points11 features
g
Faster!
Time (CPU sec)
16
Experimental Results CPUSmall
8,192 points12 features
g
Faster!
Time (CPU sec)
17
Introduce nonlinear kernel!

• Begin with previous formulation

18
Nonlinear results
Nonlinear kernels improve accuracy.
19
Part IITolerant Regression

• a.k.a. Tolerant Training

20
Regression Approach Summary

• Quadratic Loss Function
• Standard method in statistics
• Over-emphasizes outliers
• Linear Loss Function (1-norm)
• Formulates well as a linear program
• Over-emphasizes small errors
• Huber Loss Function (hybrid approach)
• Appropriate emphasis on large and small errors

21
Optimization problem (1-norm)

• Find w, b such that

• Bound the error by s

22
The overfitting issue

• Noisy training data can be fitted too well
• leads to poor generalization on future data

• Prefer simpler regressions, i.e. where
• some w coefficients are zero
• line is flatter

23
Reducing overfitting

• To achieve both goals
• minimize magnitude of w vector

• C is a parameter to balance the two goals
• Chosen by experimentation
• Reduces overfitting due to points far from
  surface

24
Overfitting again close points

• Close points may be wrong due to noise only
• Line should be influenced by real data, not
  noise

• Ignore errors from those points which are close!

25
Tolerant regression

• Allow an interval of size e with uniform error

26
How about a nonlinear surface?
27
Introduce nonlinear kernel!

• Begin with previous formulation

28
Our improvements

• This formulation and interpretation is new!
• Improves intuition from prior results
• Uses less variables
• Solves faster!
• Computational tests run on DMI Locop2
• Dell PowerEdge 6300 server with
• Four gigabytes of memory, 36 gigabytes of disk
  space
• Windows NT Server 4.0
• CPLEX 6.5 solver

Donated to UW by Microsoft Corporation
29
Comparison Results
30
Problem size concerns

• How does the problem scale?
• m number of points
• n number of features
• For linear kernel problem size is O(mn)

• For nonlinear kernel problem size is O(m2)

• Thousands of data points gt massive problem!

Need an algorithm that will scale well.
31
Chunking approach

• Idea Use a chunking method
• Bring as much into memory as possible
• Solve this subset of the problem
• Retain solution and integrate into next subset
• Explored in depth by Paul Bradley and O.L.
  Mangasarian for linear kernels

Solve in pieces, one chunk at a time.
32
Row-Column Chunking

• Why column chunking also?
• If non-linear kernel is used, chunks are very
  wide.
• A wide chunk must have a small number of rows to
  fit in memory.

Both these chunks use the same memory!
33
Chunking Experimental Results
34
Objective Value Tuning Set Errorfor
Billion-Element Matrix
Given enough time, we find the right answer!
35
Integration into data mining tools

• Method runs as a stand-alone application, with
  data resident on disk
• With minimal effort, could sit on top of a RDBMS
  to manage data input/output
• Queries select a subset of data - easily SQLable
• Database queries occur infrequently
• Data mining can be performed on a different
  machine from the one maintaining the DBMS
• Licensing of a linear program solver necessary

Algorithm can integrate with data mining tools.
36
Part IIIActive Support Vector Machines

• a.k.a. ASVM

37
The Classification Problem
A
A-
Separating Surface
Find surface to best separate two classes.
38
Active Support Vector Machine

• Features
• Solves classification problems
• No special software tools necessary! No LP or QP!
• FAST. Works on very large problems.
• Web page www.cs.wisc.edu/musicant/asvm
• Available for download and can be integrated into
  data mining tools
• MATLAB integration already provided

39
Summary and Future Work

• Summary
• Robust regression can be modeled simply and
  efficiently as a quadratic program
• Tolerant regression can be used to solve massive
  regression problems
• ASVM can solve massive classification problems
  quickly
• Future work
• Parallel approaches
• Distributed approaches
• ASVM for various types of regression

40
Questions?
