Immunodeficiency

1
Immunodeficiency

• Mitzi Nagarkatti
• Professor and Chair,
• Dept. Pathology, Microbiology and Immunology
• Deputy Director, Basic and Translational Research
• SC Cancer Center
• USC School of Medicine
• Tel. [phone]
• E-mail mnagark_at_uscmed.sc.edu

2
Objectives

• Definition
• Primary Immunodeficiencies
• Characteristics
• Types of primary immunodeficiency disorders
• Mode of inheritance
• Diagnosis and Treatment
• Secondary Immunodeficiency
• Human Immunodeficiency Virus
• Transmission
• Therapy and prevention of AIDS

3
Immunodeficiency

• Defect in 1 or more components of immune system
• Types
• Primary or Congenital
• Born with the immunodeficiency
• Inherited (Mutation in gene controlling immune
  cells)
• Susceptible to recurrent, severe infection
  starting in children
• Cannot recover without treatment
• gt125 immunodeficiency disorders
• Secondary or Acquired As a consequence of other
  diseases or environmental factors
• (e.g. infection, malignancy, aging, starvation,
  medication, drugs) Human Immunodeficiency Virus

4
Hematopoiesis
Progenitor
Progenitor
5
Hematopoietic Stem Cell (HSC) deficiency

• HSC are multipotent (differentiate into all blood
  cell types)
• Self renewing cells
• Lineage negative (mature B/T cell, granulocyte,
  Mf markers absent)
• CD34, c-Kit, Stem cell Ag (Sca-1) on cell
  surface
• Defect in HSC results in Reticular Dysgenesis
• Affects development of all leukocytes
• Patients are susceptible to all infections
  (bacterial, viral, parasitic and fungal)
• Fatal without treatment
• Treated with bone marrow or HSC transplantation

6
Allogeneic BM/HSC Transplantation
TCR
T cell
MHC
Thymus
MHC
Thymic Stromal Cells
MHC-matched for atleast1-2 alleles T cell
depleted
7
Hematopoiesis
Progenitor
Progenitor
8
Myeloid Progenitor Cell Differentiation Defect

• Myeloid Progenitor Cells develop into
  neutrophils and monocytes
• Defect in differentiation from myeloid progenitor
  cells into neutrophils results in
• Congenital Agranulocytosis
• Recurrent bacterial infections seen in patients
• Treated with granulocyte-macrophage colony
  stimulating factor (GM-CSF) or G-CSF

9
Defective Neutrophils

• Patients have neutrophils that are defective in
  production of reactive oxygen species that is
  responsible for killing of phagocytosed
  microrganisms.
• Nitroblue tetrazolium test reduction by
  superoxide (-ve)
• This results in accumulation of granulocytes, Mf
  and T cells forming granulomas. These patients
  suffer from
• Chronic Granulomatous Disease.
• Have recurrent bacterial infections
• Commensals become pathogenic
• X-linked or autosomal recessive
• Treated with IFN-g against infections

10
Inheritance

• 22 pairs of autosomes and 1 pair of sex
  chromosomes (X and Y)
• Autosomal recessive (most AA normal Aa carrier
  aa affected)
• Autosomal dominant (Aa affected aa is normal)
• X-linked (XX carrier daughter XY affected son)

Carrier x Normal Mother Father Xx XY
Carrier x Carrier Mother Father Aa Aa
Normal x Affected Mother Father aa Aa
Autosomal Recessive Autosomal Dominant
X-linked
11
Leukocyte Adhesion deficiency

• Adhesion molecule (e.g.CD18) may be lacking on T
  cells and monocytes.
• Autosomal recessive
• Results in defective extravasation
• Recurrent infections
• Impaired wound healing
• Treated with BM (depleted of T cells and
• HLA matched) transplantation
• or with gene therapy

12
Hematopoiesis
Progenitor
Progenitor
13
Defect in Lymphoid Progenitor

• Results in Severe Combined Immunodeficiency
  (SCID)
• Lack T, B and/or NK cells
• Thymus does not develop
• Myeloid and erythroid cells are normal.
• Generally lethal
• Susceptible to bacterial, viral and fungal
  infections.
• In infants, passively transferred maternal Abs
  are present.
• Live attenuated vaccines (e.g. Sabin polio) can
  cause disease.

14
Types of SCID

• RAG-1/2 (Recombinase activating gene) deficiency
  Required for TCR and Ig gene rearrangement
• IL-2R gene defect
• Adenosine deaminase (ADA) deficiency
• Adenosine Inosine Uric
  acid
• T, B and NK cell deficiency due to toxicity of
  accumulated metabolites
• First successful gene therapy done in patient

ADA
15
DiGeorge syndrome
16
Precursor T cell differentiation defect

• Athymic - DiGeorge Syndrome
• Lack of T helper (Th) cells , Cytotoxic T cells
  (CTL) and T regulatory (Treg) cells
• B cells are present but T-dependent B cell
  responses are defective
• Anti-viral and anti-fungal immunity impaired
• Developmental defect in the 3rd and 4th
  pharyngeal pouch
• Results in facial defect and congenital heart
  disease
• Treated with thymic transplant
• Autosomal dominant trait

17
Nude Athymic mouse
nu/nu gene (autosomal recessive) Hairless Should
be maintained in pathogen-free environment T
helper cell defect Results in impaired cytotoxic
T cell activity and Th-dependent B cell responses
due to Th cell defect Accept xenografts
18
Hyper IgM Syndrome
X-linked Agammaglobulinemia (x-LA)

• Absence of Igs and B cells
• Arrest at Pre-B cell stage (H-chain rearranged
  not L chain)
• Deficiency in IgG, IgA and IgE
• Increased IgM in serum
• B cells express IgD and IgM on membrane
• X-linked
• Recurrent infections
• e.g. IgA deficiency
• Due to defect in isotype switching
• Recurrent respiratory, gastrointestinal and/or
• genitourinary infection

Selective Ig class deficiency
19
Common Variable Immunodeficiency

• B cells are normal
• Defect in maturation to plasma cells
• Decreased IgM, IgG and IgA or only IgG and IgA
• Susceptible to bacterial (e.g. pneumococci)
  infections
• Low Ab titers against DPT or MMR Vaccines
• Usually not detected in children because of
• maternal Abs
• Also called Late-onset hypogammaglobulinemia,
• Adult-onset agammaglobulinemia or Acquired
• agammaglobulinemia
• Ig replacement therapy and antibiotics

20
Other Immunodeficiencies

• Bare lymphocyte syndrome
• Lack MHC class II on B cells, macrophages and
  dendritic cells
• Complement Deficiency

21
Primary Immunodeficiencies
Stem Cell
Reticular Dysgenesis
Lymphoid Progenitor
Myeloid Progenitor
Severe combined Immunodeficiency SCID
Congenital Agranulocytosis
Pre-B
Monocyte
Pre-T
Neutrophil
x-linked agglobulinemia xLA
Mature B
Thymus
DiGeorge Syndrome d
Chronic Granulomatous Disease (x or r)
Mature T
Plasma Cell
Memory B
Common Variable Hypogglobulinemia / x-linked
hyperIgM syndrome/Selective Ig deficiency
Bare Lymphocyte Syndrome
22
Adaptive Immunity Deficiency

• T cell deficiency
• Susceptible to intracellular bacterial infection
• e.g. Salmonella typhi, Mycobacteria
• Susceptible to viral, parasitic and fungal
  infection
• B cell deficiency
• Susceptible to extracellular bacterial infection
  e.g. Staphylococcal infection

23
Secondary or Acquired Immunodeficiencies

• Agent-induced immunodeficiency e.g. infections,
  metaboic disturbance, trauma, corticosteroids,
  cyclosporin A, radiation, chemotherapy
• HIV

24
Human Immunodeficiency Virus

• Discovered in 1983 by Luc Montagnier and Robert
  Gallo
• Retrovirus (RNA virus)
• HIV-1 (common) and HIV-2 (Africa)
• Patients with low CD4 T cells
• Virus prevalent in homosexual, promiscuous
  heterosexual, i.v. drug users, transfusion,
  infants born to infected mothers
• Opportunistic infections with Pnuemocystis
  carinii, Candida albicans, Mycobacterium avium,
  etc.
• Patients with HIV have high incidence of cancers
  such as Kaposi sarcoma

25
Kaposi Sarcoma
26
Incidence of HIV
CDC 2008
27
Course of AIDS
Dissemination of virus Seeding of lymphoid
organs
Anti-HIV Ab/CTL
ACUTE CHRONIC AIDS PHASE PHASE
AIDS (lt200cells/mm3)
28
Structure of HIV
env
(Envelope)
(p24)
(p17)
Protease
Matrix Capsid
Integrase
gag
pol
29
Abs are ineffective to control HIV

• Virus grows intracellularly
• Abs develop after 3 weeks.
• Thus cannot be used as a diagnostic test
  initially (Reverse transcriptase is a sensitive
  test)
• Abs are not neutralizing

30
Role of T cells in development of AIDS

• Initially Th cells control viral load
• Cytopathic virus
• Syncitium formation with infected/uninfected
  cells
• Surviving Th cells are anergic
• Destruction of infected Th cells by CTL
• CTL that develop are ineffective because of high
  viral mutations
• Lack of Th affects CTL activation
• Resistance to CTL by downregulation of class I
  MHC on target cells

31
Animal Models

• Primate Model
• HIV grows in chimpanzees but do not develop AIDS
• Simian immunodeficiency virus (SIVagm in African
  green monkey no disease SIVmac in Macaques
  AIDS like)
• Feline immunodeficiency virus (FIV)
• Mouse Model
• Grows in Severe Combined Immunodeficiency (SCID)
  mice reconstituted with human lymphocytes

32
Viral Replication
33
Coreceptors of HIV

• Chemokine receptors
• T cell-tropic (Syncitium-inducing X4 virus
  strain)
• Macrophage-tropic (Nonsyncitium-inducing R5
  virus strain)

CCR5 Ligands are RANTES (Regulated on
activation, normal T cell expressed and
secreted), MIP1a, MIP1b (Macrophage Inflammatory
Protein)
34
Therapy

• Inhibit binding of gp120 with CD4 by
• Use of soluble CD4
• Use of anti-CD4 Abs
• Use of anti-gp120
• Inhibit binding of HIV to coreceptors by
  chemokines such as RANTES

35
Host Factors influencing course

• Transmission of HIV
• Sexual contact
• Breast feeding
• Transfusion
• During birth
• Sharing needles
• Resistance to HIV in individuals
• CCR5D32
• Some HLA types (HLA-A2) are resistant while
  others (HLA-B35) are susceptible)

36
Therapeutic targets
























Inhibit binding
Kuby, 2007
37
Treatment and Prevention

• Highly active anti-retroviral therapy (HAART
  combination therapy) IL-2 (to reconstitute the
  immune system)
• Vaccines Proteins, DNA, subunit and recombinant
  virus (SIV-HIV chimeric virus )

38
Problems with therapy

• HIV-1 infection gives rise to AIDS despite the
  presence of Abs
• Low immunogenicity of virus
• Vaccine alone leads to destruction of CD4 T
  cells
• Integration of virus in host genome
• Virus undergoes mutations
• High rate of virus replication (109 viruses/day)
• Live attenuated may result in AIDS
• Heat killed organism is not antigenic
• Vaccine administered through oral or respiratory
  route (Route of exposure to HIV is through
  genital tract)
• Lack of animal models and in vitro testing system
• Drugs do not cross blood-brain barrier to reach
  virus in brain

39
Summary

• Primary immunodeficiencies are inherited
• They can affect hematopoietic stem cells,
  lymphoid or myeloid cells.
• Secondary immunodeficiencies are due to
  infections, aging, cancer or chemical exposure
• HIV affects immune system by eliminating CD4 T
  cells
• Vaccine development has been hindered by lack of
  an experimental model, antigenic variation, rapid
  proliferation of the virus

40
Reading

• Immunology
• By Male, Brostoff, Roth and Roitt
• 7th Edition
• Pages299-324
