Malware

1
Malware
2

• Trap Door
• Logic Bombs
• Trojan Horses
• Worms
• Bacteria
• Viruses
• Mobile Code
• Spyware

3

• Malware collection of techniques/programs that
  produce undesirable effects on a computer system
  or network

• Differentiate based on
• Needs host program
• Independent
• Replicate
• Dont replicate

4
Malware
Needs Host Program
Independent
Worms
Bacteria
Trapdoor
Virus
Logic Bomb
Trojan Horse
5
Trap Doors

• Secret entry point to a program that bypasses
  normal security access procedures

• Legitimate for testing/debugging
• Recognizes some special input, user ID or
  unlikely sequence of events

• Difficult to detect at use
• Must detect during software development and
  software update


6
Logic Bombs

• Code embedded in legitimate program that is set
  to explode when certain conditions met

• Presence/absence certain files
• Date
• Particular user
• Bomb may
• Alter/delete files
• Halt machine
• Other damage

7
Trojan Horses

• Apparently useful program or command procedure
  containing hidden code which performs harmful
  function

• Trick users into running by disguise as useful
  program

• Doesnt replicate itself
• Used to accomplish functions indirectly that an
  unauthorized user not permitted

• Used for destructive purposes

8
(No Transcript)
9
Backdoor Trojans

• Opens backdoor on your computer that enables
  attackers to remotely access and control your
  machine

• Also called remote access Trojans
• Attackers find your machine by scanning ports
  used by Trojan

• Common backdoor Trojans
• Back Orifice
• NetBus

10

• Most anti-virus tools detect Trojans
• Can also check open TCP ports against list of
  known Trojan ports

• Type netstat an command
• Look at listening ports
• Lists of known Trojan port numbers available via
  Google search


11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Anti-Trojan Software

• www.anti-trojan.net
• Anti-Trojan 5.5 trojan scanner 21.95
• Detects more than 9000 different types of trojan
  horses.

• Uses three methods to find them
• Port scan which gives you information if there
  are open ports on your computer.

• registry scan which searches through the system
  registry database for trojans.

• disk scan scans your hard disks for dangerous
  trojan files and removes them safely.

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Worms

• Programs that use network connections to spread
  from system to system

• Once active on a system can behave as another
  form of malware

• Propagates
• Search for other systems to infect
• Establish connection with remote system
• Copy itself to remote system and executes

23
The Great Worm

• Robert Morris released the most famous worm in
  1988

• Crashed 6000 machines on the Internet (10)
• Exploited bug in fingerd program
• Bug in worm crashed machines which prevented the
  worm from spreading

• Estimated damage 100 million
• Three years probation, 400 hrs community service
  , 10,500 fine

24
Worm Code Red

• Scans Internet for Windows NT or 2000 servers
  running IIS minus patch

• Copies itself to server
• Replicate itself for the first 20 days of each
  month

• Replace WEB pages on infected servers with a page
  that declares Hacked by Chinese

• Launch concerted attack on White House Web server
  to overwhelm it

25
Bacteria

• Programs that do not explicitly damage files
• Sole purpose is to replicate themselves within a
  system

• Reproduce exponentially taking up
• Processor capacity
• Memory
• Disk space

26
Viruses

• Infect other programs by modifying them
• First one written in 1983 by USC student Fred
  Cohen to demonstrate the concept

• Approximately 53,000 exist
• Modification includes copy of virus

27
Virus Structure

• Usually pre-pended or postpended to executable
  program

• When program invoked virus executes first, then
  original program

• First seeks out uninfected executable files and
  infects them

• Then performs some action

28
Four Stages of a Virus

• Dormant
• Idle until activated by some event
• Propagation
• Virus places identical copy of itself into other
  programs or system areas on disk


29

• Triggering Phase
• Virus activated to perform function for which it
  was intended

• Based on
• Date
• Count of replications
• Other system events

30

• Execution Phase
• Function performed which may be harmless or
  destructive

• Usually OS or hardware specific
• Takes advantage of details and weaknesses of
  system

31
How Virus are spread

• Peer to peer networks
• Via email attachments
• Via media
• FTP sites
• Chat and instant messaging
• Commercial software
• Web surfing
• Illegal software

32
Types of Viruses

• Parasitic
• Traditional virus and most common
• Attaches itself to executable files and
  replicates

• Memory resident
• Lodges in memory are part of OS
• Infects every program that executes

33

• Boot sector
• Infects master boot record or boot record
• Spreads when system boots
• Seldom seen anymore
• Stealth
• Designed to hide itself from detection by
  antivirus software

34

• Polymorphic
• Mutates with every infection
• Functionally equivalent but distinctly different
  bit patterns

• Inserts superfluous instructions or interchange
  order of independent instructions

• Makes detection of signature of virus difficult
• Mutation engine creates random key and encrypts
  virus

• Upon execution the encrypted virus is decrypted
  and then run

35

• Metamorphic
• Structure of virus body changed
• Decryption engine changed
• Suspect file run in emulator and behavior analyzed

36
Mobile Code

• Programming that specifies how applications
  exchange information on the WEB

• Browsers automatically download and execute
  applications

• Applications may be viruses

37

• Common forms
• Java Applets Java code embedded in WEB pages
  that run automatically when page downloaded

• ActiveX Controls similar to Java applets but
  based on Microsoft technology, have total access
  to Windows OS

38

• New threat (potential) of including mobile code
  in MP3 files

• Macros languages embedded in files that can
  automatically execute commands without users
  knowledge

• JavaScript
• VBScript
• Word/Excel

39
Macro Viruses

• Make up two thirds of all viruses
• Platform independent
• Word documents are the common vehicle rather than
  executable code

• Concept 1995 first Word macro virus
• Easily spread

40

• Office applications usually have internal
  language to perform repetitive operations

• Macro executes sequence of keystrokes
• Macro can copy itself to other documents, delete
  files, other damage

• Some macros invoked by special key stroke
• Some macros invoked automatically

41

• Three types
• Autoexecute template stored in Words startup
  directory, executed when Word started

• Automacro executes when defined event occurs,
  open/close document, create new document,
  quitting Word

• Command macro global macro file or attached to
  document, executed whenever the user invokes the
  command

42
Technique for spreading macro virus

• Automacro / command macro is attached to Word
  document

• Introduced into system by email or disk transfer
• Document opened and macro executes
• Macro copies itself to global macro file
• When Word started next global macro active

43
Melissa Virus March 1999

• Spread in Word documents via email
• Once opened virus would send itself to the first
  50 people in Outlook address book

• Infected normal.dot so any file opened latter
  would be infected

• Used Visual Basic for applications
• Fastest spreading virus ever seen

44
ILOVEYOU Virus May 2000

• Contained code as an attachment
• Sent copies to everyone in address book
• Corrupted files on victims machine deleted
  mp3, jpg and other files

• Searched for active passwords in memory and
  emailed them to Web site in the Philippines

• Infected approximately 10 million computers and
  cost between 3 and 10 billion in lost
  productivity


45
Preventative measures

• MS offers optional macro virus protection tools
  that detects suspicious Word files

• Office 2000 Word macro options
• Signed macros from trusted sources
• Users prompted prior to running macro
• All macros run
• Antivirus product vendors have developed tools to
  detect and correct macro viruses

46
Anti-virus Approaches

• Prevention
• Do not allow virus to enter system
• Generally impossible to achieve
• Detection
• Determine infection has occurred
• Locate virus

47

• Identification
• Once detection achieved
• Identify specific virus
• Removal
• Remove all traces of virus from infected program
• Restore program to original state

48

• Sometimes removal is not possible then the
  file(s) must be discarded an an unaffected
  version of the file must be restored from backup

• Antivirus software has evolved over four
  generations

49
Antivirus First Generation

• Simple scanner
• Scans for virus signature (bit pattern)
• Scans for length in program size
• Limited to detection of known viruses

50
Antivirus Second Generation

• Does not rely on specific signature
• Uses heuristic rules to search for probable virus
  infection

• Looks for fragments of code often associated with
  viruses

• Integrity checking via checksum appended to each
  program

• Checksum is a encrypted hash

51
Antivirus Third Generation

• Memory resident
• ID virus by its actions rather than structure of
  infected program

• Not driven by signature or heuristic
• Small set of actions
• Intervenes

52
Antivirus Fourth Generation

• Variety of antivirus techniques
• Scanning and activity trap components
• Access control capability
• Limits ability of virus to update files

53
A Modern Virus - Bugbear

• The virus of the year
• Blended threat worm by leveraging multiple
  infection paths

• Comes as an attachment with random subject,
  message body and attachment file name

54

• Executable file may have single or double
  extensions

• Spoofs from header
• Forwards itself to addresses in old emails on
  your system

• Truly distinguishing feature is the size of the
  attachment 50,688 bytes

55
Bugbear What it does

• Copies itself to a randomly named exe file
• Makes registry changes
• Adds itself to the startup folder
• Mails itself to any address found on your
  computer

• Copies itself to open Windows network shares
• Attempts to disable AV and firewalls
• Installs Trojan code and keystroke logger
• Listens on port 36794

56
Advanced Antivirus Techniques-Generic Decryption

• Enables antivirus program to detect most complex
  polymorphic virus

• Contains the following
• CPU emulator
• Virus signature scanner
• Emulation control module

57

• Simulate decryption and execution of virus so can
  be detected

• No damage to real system
• Main question is how long to run intepretation

58
Advanced Antivirus Techniques-Digital Immune
System

• Developed by IBM
• Historically spread of viruses relatively slow
• Antivirus software updated monthly
• But now spreads faster due to
• Integrated mail systems
• Mobil program systems Java, ActiveX

59

• General purpose emulation and detection system
• Objective is to have rapid response and stamp out
  as soon as introduced

60

• Virus enters an organization
• Immune system automatically captures it
• Analyzes it
• Adds detection and shielding for it
• Removes it
• Passes info about virus to systems running IBM
  Antivirus

61

• Monitoring program on each client detects
  suspicious activity and reports it

• Administrative machine encrypts the sample and
  sends it to central virus analysis machine

• Runs infected program in safe environment

62

• Resulting prescription sent back to
  administrative machine

• Administrative machine forwards prescription to
  infected client

• Prescription also sent to other clients
• Subscribers around world receive regular
  antivirus updates

63
(No Transcript)
64
History of Malware

• 1949Theories for self-replicating programs are
  first developed.

• 1981Apple Viruses 1, 2, and 3 are some of the
  first viruses "in the wild" or public domain.
  Found on the Apple II operating system, the
  viruses spread through Texas AM via pirated
  computer games.
• 1983Fred Cohen, while working on his
  dissertation, formally defines a computer virus
  as "a computer program that can affect other
  computer programs by modifying them in such a way
  as to include a (possibly evolved) copy of
  itself". The name 'virus' was thought of by Len
  Adleman.

65

• 1986"Brain" "PC-Write Trojan" The common
  story is that two brothers from Pakistan named
  Basit and Amjad analysed the boot sector of a
  floppy disk and developed a method of infecting
  it with a virus dubbed "Brain" (the origin is
  generally accepted but not absolute). Because it
  spread widely on the popular MS-DOS PC system
  this is typically called the first computer
  virus even though it was predated by Cohen's
  experiments and the Apple II virus. That same
  year the first PC-based Trojan was released in
  the form of the popular shareware program
  PC-Write.
• 1987"Stoned" is the first virus to infect the
  master boot record preventing it from starting up.

66

• 1988One of the most common viruses, "Jerusalem",
  is unleashed. Activated every Friday the 13th,
  the virus affects both .EXE and .COM files and
  deletes any programs run on that day. An
  Indonesian programmer releases the first
  anti-virus software for the brain virus. The
  "Internet Worm" is released and crashed 5000
  computers.
• 1989IBM releases the first commercial anti-virus
  products. Intensive anti-virus research
  commences. The "Dark Avenger" virus appears.

• 1990Symantec launches Norton AntiVirus, one of
  the first anti-virus programs developed by a
  large company. Bulletin Boards (BBS) become a
  common way for virus writers to share code.

67

• 1991"Tequila" is the first widespread
  polymorphic virus found in the wild. Polymorphic
  viruses make detection difficult for virus
  scanners by changing their appearance with each
  new infection. Virus construction kits can be
  downloaded from virus bulletin boards enabling
  almost anyone to write a virus. 9 in early 1991
  reported they had experienced a virus attack. By
  the end of the year that figure increased to
  63.
• 19921300 viruses are in existence, an increase
  of 420 from December of 1990. The Michelangelo
  scare predicts 5 million computers will crash on
  March 6. Only 5,000-10,000 actually go down.

68

• 1994Good Times email hoax tears through the
  computer community. The hoax warns of a malicious
  virus that will erase an entire hard drive just
  by opening an email with the subject line "Good
  Times". Though disproved, the hoax resurfaces
  every six to twelve months. In England, the
  writer if the "Pathogen" virus is found by
  Scotland Yard and sentenced to 18 months in jail.
  This is the first prosecution.

69

• 1995The "Concept" macro virus appears. Written
  in Microsoft's WordBasic it can run on PCs and
  Macs running Microsoft Word. Being so easy to
  write, macro viruses become extensively
  widespread.
• 1998Currently harmless and yet to be found in
  the wild, StrangeBrew is the first virus to
  infect Java files. The virus modifies CLASS files
  to contain a copy of itself within the middle of
  the file's code and to begin execution from the
  virus section.

70

• 1999The Melissa virus, W97M/Melissa, executes a
  macro in a document attached to an email, which
  forwards the document to 50 people in the user's
  Outlook address book. The virus also infects
  other Word documents and subsequently mails them
  out as attachments. Melissa spread faster than
  any other previous virus and infected hundreds of
  thousands of PCs.
• The "Chernobyl" virus hit in April making the
  hard drvie inaccessible causing wide spread
  damage.

71

• Tristate is the first multi-program macro virus
  it infects Word, Excel, and PowerPoint files.

• Bubbleboy is the first worm that would activate
  when a user simply opened and E-mail message in
  Microsoft Outlook (or previewed the message in
  Outlook Express). No attachment is necessary.
  Bubbleboy was the proof of concept Kak spread
  widely using this technique.

72

• 2000The "Love Bug", also known as the "ILoveYou"
  and "LoveLetter" virus, sends itself out via
  Outlook, much like Melissa. From the Phillipines,
  the virus comes as a VBS attachment and deletes
  files, including MP3, MP2, and JPG. It also sends
  usernames and passwords to the virus' author.
  "LoveLetter" spread over the US and Europe in 6
  hours and infected 2.5 million PCs causing an
  estimated 8.7 billion in damage.
• "W97M.Resume.A", a new variation of the "Melissa"
  virus, is determined to be in the wild. The
  "resume" virus acts much like "Melissa", using a
  Word macro to infect Outlook and spread itself.

73

• The "Stages" virus, disguised as a joke email
  about the stages of life, spreads across the
  Internet. Unlike previous viruses, "Stages" is
  hidden in an attachment with a false ".txt"
  extension, making it easier to lure recipients
  into opening it. Until now, it has generally been
  safe to assume the text files are safe.
• August 2000 saw the first Trojan developed for
  the Palm PDA. Called "Liberty" and developed by
  Aaron Ardiri the co-developer of the Palm Game
  Boy emulator Liberty, the Trojan was developed as
  an uninstall program and was distributed to a few
  people to help foil those who would steal the
  actual software. When it was accidentally
  released to the wider public Ardiri helped
  contain its spread.

74

• 2001The Anna Kournikova virus, also known as
  VBS/SST, which masquerades as a picture of Tennis
  Star Anna Kournikova, operates in a similar
  manner to Melissa and The Love Bug. It spreads by
  sending copies of itself to the entire address
  book in Microsoft Outlook. It is believed that
  this virus was created with a so-called virus
  creation kit, a program which can enable even a
  novice programmer to create these malicious
  programs.
• In May, the HomePage email virus hit no more than
  10,000 users of Microsoft Outlook. When opened,
  the virus redirected users to sexually explicit
  Web pages. Technically known as VBSWG.X, the
  virus spread quickly through Asia and Europe, but
  was mostly prevented in the U.S. because of
  lessons learned in earlier time zones. The author
  of the virus is said to live in Argentina, and
  have authored the Kournikova virus earlier in the
  year.

75

• The Code Red I and II worms attacked computer
  networks in July and August. According to
  Computer Economics they affected over 700,000
  computers and caused upwards of 2 billion in
  damages. A worm spreads through external and
  (then) internal computer networks, as opposed to
  a virus which infects computers via email and
  certain websites. Code Red took advantage of a
  vulnerability in Microsoft's Windows 2000 and
  Windows NT server software. Microsoft developed a
  patch to protect networks against the worm, and
  admits that they too were attacked. Other major
  companies affected include ATT, and the AP.

76

• On July 25, W32/Sircam Malicious Code appears,
  spreading through e-mail and unprotected network
  shares. The code affects both the infected
  computer as well as all those in its e-mail
  address book.
• The W32/Nimda worm, taking advantage of back
  doors left behind by the Code Red II worm, is the
  first to propagate itself via several methods,
  including e-mail, network shares and an infected
  Web site. The worm spreads from client to Web
  server by scanning for back doors.

77

• Computer Associates International, Inc. (CA), the
  world's leading provider of eBusiness management
  solutions, released its "2001 Top 10 Virus
  Threats" list. The list is based on reports
  tracked by the company's eTrust Global Antivirus
  Research Centers. The list, in order of
  frequency, is as follows
• 1. Win32.Badtrans.B, 2. Win32.Sircam.137216, 3.
  Win32.Magistr, 4. Win32.Badtrans.13312, 5.
  Win32.Magistr.B, 6. Win32.Hybris.B, 7. Win95.MTX,
  8. Win32.Nimda.A, 9. VBS.VBSWG.Generic, 10.
  Win32.Goner.A

78

• 2002The Klezworm infects executables by creating
  a hidden copy of the original host file and then
  overwriting the original file with itself. The
  hidden copy is encrypted, but contains no viral
  data. The name of the hidden file is the same as
  the original file, but with a random extension.
• Nimda is a mass-mailing worm that utilizes
  multiple methods to spread itself. The name of
  the virus came from the reversed spelling of
  "admin". The worm sends itself out by email,
  searches for open network shares, attempts to
  copy itself to unpatched or already vulnerable
  Microsoft IIS web servers, and is a virus
  infecting both local files and files on remote
  network shares.

79
Virus Detection and Prevention Tips

• Do not open an email from an unknown,
  suspicious or untrustworthy source

• Do not open any files attached to an email
• Turn off preview pane in email client
• Enable macro virus protection in all your
  applications

• Beware of pirated software
• Dont accept files while chatting or messaging

80

• Do not download any files from strangers.
• Exercise caution when downloading files from the
  Internet.

• Turn on view file extensions so you can see what
  type of file you are downloading

• Save files to disk on download rather than launch
  application

• Update your anti-virus software regularly.
• Back up your files on a regular basis.

81
Antivirus Features

• Signature scanning
• Heuristic Scanning
• Manual Scanning
• Real Time scanning
• E-mail scanning
• Download scanning

• Script scanning
• Macro scanning
• Price
• Update subscription cost

82
Norton Antivirus 2003
83
Options
84
Script Blocking
85
Scanning
86
(No Transcript)
87
E-Mail Scanning
88
Instant Messenger
89
Live Update
90
Live Update
91
Spyware
92
Spyware

• Spyware is software/hardware that spies on what
  you do on your computer

• Often is it employs a user's Internet connection
  in the background (the so-called "backchannel")
  without their knowledge or explicit permission.

• Installed without the users knowledge with
  shareware/freeware

93
Spyware Capabilities

• Record addresses of Web pages visited
• Record recipient addresses of each email you
  send

• Record the sender addresses of each email you
  receive

• Recording the contents of each email you
  send/receive

• Record the contents of IM messages
• Record the contents of each IRC chat
• Recording keyboard keystrokes
• Record all Windows activities

94
Who Uses Spyware

• Corporations to monitor computer usage of
  employees

• Computer crackers to capture confidential
  information

• Parents to monitor use of family computer
• Advertising and marketing companies to assemble
  marketing data to serve personalized ads to
  individual users

95
Spyware Software

• Keystroke loggers
• Invisible KeyKey Monitor
• KeyLogger Stealth
• Spector
• E-mail monitors
• IamBigBrother
• MailGuard
• MailMarshall
• MIMEsweeper

• Surveillance
• iOpus STARR
• Silent Watch
• SpyAgent
• WinSpy

96
www.spychecker.com
97
(No Transcript)
98
Spyware use examples

• Real networks profiling their users' listening
  habits

• Aureate/Radiate and Conducent Technologies whose
  advertising, monitoring, and profiling software
  sneaks into our machines without our knowledge or
  permission
• Comet Cursor which secretly tracks our
• web browsing
• GoHip who hijacks our web browser and alters our
  eMail signatures

99
Ad-Adware

• From www.lavasoftUSA.com
• Scans system for known spyware and allows you to
  safely remove them

• Allows backup before delete

100
(No Transcript)
101
(No Transcript)
102
(No Transcript)
103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
(No Transcript)
107
(No Transcript)
108
TSAdBot

• TSAdBot, from Conducent Technologies
  (formerly TimeSink), is distributed with many
  freeware and shareware programs, including the
  Windows version of the compression utility PKZip.
  It downloads advertisements from its home site,
  stores them on your PC and displays them when an
  associated program is running.
• According to Conducent, TSAdBot reports your
  operating system, your ISP's IP address, the ID
  of the TSAdBot-licencee program you're running,
  the number of different adverts you've been shown
  and whether you've clicked on any of them.
