Dust Collector Valve for Dust Collection System - Maniks

1
High Quality

• Dust Collector Valve
• -Maniks

2
About Us

• Maniks is the most reputed Indian brand with a
  history of 30 years for manufacturing reverse jet
  dust collector valves used in bag-filter
  applications and the sequential timers used in
  conjunction with them. These are used in dust
  collector equipment for cement, steel and such
  other industries. The company was started by Mr.
  Shekhar Kulkarni, an IIT Mumbai alumnus, with a
  vision to substitute imported products with
  Indian make products. The primary aim was to
  produce reliable products with excellent quality
  and service.

3
Introduction

• Dust Collector Syatem
• What is dust collector valve?
• Specifications of dust collector valve
• Working principal
• Working of dust collector valve
• Basic part of dust collector valve
• Main features of dust collector valve
• Applications
• Maniks Client

4
dust collector valve

• Dust Collector System

5
dust collector valve

• What is dust collector valve?
• dust collector valve has just one moving part,
  the diaphragm. The unique springless construction
  provides fast opening and closing of the valve.
  The high speed operation besides saving of
  compressed air helps to provide shock air wave
  for dislodging of dust from filter bags. High
  flow, long life and fast diaphragm action produce
  reliable and economical operation.

6
dust collector valve

• Specifications of dust collector valve
• Electrical Standard Voltage
• AC 50Hz .. 24/220 Volts,
• DC... 24/Volts,
• fluctuation - - 10
• 20 W DC Current
• 19 VA AC Current
• Maximum Medium Temperature 650C
• Maximum Ambient Temperature 550C

7
dust collector valve

• Working principal

8
dust collector valve

• Working of dust collector valve
• Maniks dust collector valves are driven by
  integral solenoid pilot operator. At the point
  when the valve is charged, the trapped air above
  dust collector valve diaphragm is quickly
  exhausted causing quick opening of main diaphragm
  dust collector valve. When the pilot valve is
  discharged, air escapes through drain gap of
  primary dust collector valve to adjust the
  diaphragm pressure and immediately closes the
  valve.

9
dust collector valve

• Duty Cycle The relative duty time cycle for ac
  voltage is 20 and for DC voltage is 10 .This
  implies energised time is maximum 1/5th of
  de-energised time for AC and 1/10th for DC
  voltage.
• Installation Mounting in any location will not
  affect dust collector valve operation. However
  good designing practice is to avoid scale and
  consolidated water entering valve body for
  disturbance free performance. Standard end
  connections of BSP are provided.

10
dust collector valve

• Basic part of dust collector valve
• Diaphragm is essential part of dust
  collector valve These spares are compatible with
  valves of various makes like Maniks, etc. The
  diaphragms are made application-specific by
  manufacturing in various materials like special
  Imported polyester, neoprene and viton( for high
  temperature)

11
dust collector valve

• Main features
• Reliable Function
• Better Performance
• Ease Of Maintenance
• Lower Power Consumption
• Faster Reaching of Peak Pressure
• Preventing air loss
• High Diaphragm life
• Ease of installation
• Better flow characteristics

12
dust collector valve

• Applications
• dust collector valve is used in different field
  such as
• Carbon Black Industry
• Asphalt Plants
• Chemical Plants
• Cement And Rock Industry
• Food Industry
• Foundries
• Iron Steel Industry
• Tobacco Industry
• To Get more Information visit us _at_
  http//www.maniks.com/manufacturer/pulse-jet-valve
  /

13
dust collector valve

• Maniks Top Satisfied Client List

14
dust collector valve

Thank You
