Modular Conveyor

1
Modular Conveyor

• SAIFI CON-FAB SYSTEM PVT. LTD.

2
COMPANY INTRODUCTION

• Saifi Con Fab System Pvt Ltd is a leading
  manufacturer of conveyors and belt conveyor
  automation solution. Saifi has over 20 years
  experience in providing materials handling
  systems, logistics efficiencies and factory
  automation solutions. Our commitment to genuine
  customer care and quality of service has enabled
  us to gain new and repeat business and maintain
  our reputation as one of Indias leading
  suppliers of belt conveyors, roller conveyors,
  pallet conveyors and more.
• To provide the optimum solution for materials
  handling requirements through the use of
  state-of-the-art 3D design, supply and
  integration of proven quality equipment to
  achieve the best return on investment.

3
What is Conveyor System?

• The Conveyor system is essential for constant
  transport of products starting with one region
  then to the next in numerous business and modern
  offices. There, they can help to diminish
  creation times and lessen in general work costs
  fundamentally.
• There are two main industrial classes of belt
  conveyors

4
What is Conveyor System?

• The Conveyor system is essential for constant
  transport of products starting with one region
  then to the next in numerous business and modern
  offices. There, they can help to diminish
  creation times and lessen in general work costs
  fundamentally.
• There are two main industrial classes of belt
  conveyors
• Material handling such as those moving boxes
  along inside the factory area.
• Bulk material handling such as those used to
  transport large volumes of resources.

5
Types of Conveyor Systems
6
Modular Conveyor

• Modular belts are made up of interlinking plastic
  modules. This creates ultimate strength with very
  low friction making it a very desirable belt
  which is a great alternative to flat belting.
• Modular belt conveyors can be extremely
  versatile. They have no tracking issues, are easy
  to clean and can accommodate bends and inclines
  with ease. They can withstand varying
  temperatures of hot and cold and can function
  comfortably in wet conditions.
• Power is provided by motors that use either
  variable or constant speed reduction gears.

7
Modular Conveyor Design Factors

• Modular Conveyors should be designed by keeping
  in mind the use, working condition and other the
  conveying requirements of your company, securing
  you financially and growth of your business.
• Things to be consider when choosing a belt
  conveyor automation
• Size of items being moved.
• Weight of item.
• Shape of item.
• The company should take the right decision and
  opt for only customized conveyors avoiding
  unnecessary waste of time, money and manpower

8
Modular Conveyor Design Parameters
9
Objectives
10
Modular Conveyor Automation Maintenance

• Ensure that components must be in proper
  alignment and make necessary adjustments.
• Check all safety measures and controlling
  equipment.
• Regular supervision for any signs of misalignment
  or improper belt tracking.
• Remove any material build-up on components and
  clean up any spills along the system.
• Observe that all guards and covers must be in
  place

11
Modular Conveyor Automation Benefits
12
Modular Conveyor Automation

• Applications

• Industries

• Packaging
• Cooling Towers
• Warehouse
• Sorting
• Shopping Centres
• Material Handling
• Draining
• Drying
• Cleaning Washing

• Distribution Warehousing
• E-Commerce
• Shipping Logistics
• Manufacturing
• Fulfilment Centres
• Retail
• FMCG
• Automotive

13
Conclusion

• The introduction of a modular belt conveyor for
  the production line, radically changed the
  process.
• The belt created very little tension, friction
  and traction. With the ease associated in
  cleaning the belt and reduction in its frequency,
  productivity increased.
• No additional maintenance to the system was
  performed, and the rejections at the end of the
  line were lowered. Additionally, by the end of
  the year, a competitors belt on another line was
  being replaced.

14
THANK YOU
