Burhani Hardware and Fittings: vacuum chamber and other tools

1
(No Transcript)
2
Vacuum Chamber

• A vacuum chamber is an unbending nook from which
  air and different gases are expelled by a vacuum
  pump.
• made of metals , shield applied outer attractive
  fields relying upon divider thickness,
  recurrence, resistivity, and penetrability of the
  material utilized.
• different ports, secured with vacuum spines, to
  permit instruments or windows to be introduced in
  the dividers of the chamber. In low to
  medium-vacuum applications -fixed with elastomer
  o-rings.
• In higher vacuum applications, the ribs have
  blade edges machined onto them, which cut into a
  copper gasket when the rib is rushed on.

3
Bubble-Emission Leak Test

• To recognize, find, and fairly evaluate a leak
  through the emission of bubbles.
• First part creates a weight differential between
  within and outside of the specimen.
• This pressure differential will begin to drive
  the interior gas or fluid of the example from the
  higher weight (within example) towards the lower
  pressure (outside of example) through a leak way.


4
The second part of a Bubble Emission Leak
Testing System is a submersion liquid. This
liquid, which as a rule is water, will empower
the administrator to distinguish the bubbles
discharging from a leaking example. The
submersion liquid can now and again be an oil, or
acidic shower, or other fluid substance. The
liquid demonstrations a medium empowering visual
discovery of air bubbles on.
Bubble-Emission Leak Test
5
Pac Vac Leak Detector

• The Pack-Vac Leak Detector allows the user to
  perform a vacuum test in less than 30 seconds
• . Drop in your sealed package, close the lid and
  engage the vacuum device. Now watch for bubbles.
  As easy as 1-2-3.
• Simple, reliable, repeatable leak detection.
  Continual testing on the production line will
  detect sealing problems before they snowball.

6
Pressure pot for Rasin Casting

• A pressure pot is required for bubble-free and
  air-trap-free resin castings. This eliminates air
  bubbles and air traps in the cured castings.
• This is especially critical in creating clear
  resin castings as trapped air can mar the
  appearance of a crystal clear casting.

7
Pressure pot for Rasin Casting

• The ArtMolds Pressure Pot is designed for use in
  applying pressure to force air out of resin and
  to force resin into thin sections of a mold.
• This pressure pot includes a gauge and all the
  other fittings.
• However, you will also need to purchase an air
  compressor of at least 3.5 H.P. and a ¼-inch
  adapter/coupling to attach the air compressor to
  the pot.

8
Contact us on 91 9677296252

Website https//bhftech.org/
 Email us on bhftech.info_at_gmail.com
Address 110 General Patters Road. State Bank
Street. Chennai 60002. India.
