Measuring Forest Trees Height

1
Measuring Forest Trees Height
JWAN M. ALDOSKI Geospatial Information Science
Research Center (GISRC), Faculty of Engineering,
Universiti Putra Malaysia, 43400 UPM Serdang,
Selangor Darul Ehsan. Malaysia.
2
Hypsometer

• - an instrument for measuring heights (of trees)

3
Tree Heights

• Total height height (or stem length) from
  ground line to top of terminal bud.
• Merchantable height stem length (or height)
  from assumed stump height to an arbitrary, fixed
  upper-stem diameter (ib or ob)

4
Scales of Measure

• Degree reads angle from horizontal for
  trigonometric calculations
• Percentage reads directly in feet of height at
  100 feet distance (rise/run) (45 degrees equals
  100 percent slope)
• Topographic reads directly in feet of height at
  66 feet (1 chain or 20 meters) away

This is where your pacing or hipchain really
comes in handy
5
Trigonometry of right triangles
a b(tan A)
6
Measuring Height with degrees
7
Measuring Standing Tree Height
Percentage Scale
Percent slope (rise / run) x 100
If distance from tree (D), or "run" is 100 feet,
The reading from horizontal to Stump height
(A) is 5 feet and tree height above the
horizontal plane (B) or "rise" is 80 feet Total
Tree height equals A B 85 feet
8
General Formula

• H (HT - HB)(HD/BD)
• HT Height to top (BA)
• HB Height to Base (BC)
• Reading will be negative
• (unless tree above you)
• HD Horizontal Distance
• From person to tree
• BD Base Distance
• 66 (for topographic scale)
• Or 100 (for percent scale)
• If you are at scale distance,
• This factor (HD/BD) equals 1
• and can be ignored

9
Sloping Plots
10
Trigonometry of slope correction
11
Slope Correction
12
Slope Correction

• Desired horizontal distance to the tree 100
  feet
• Slope to the tree 32 (slope correction needed)
• Slope correction factor 1.05
• Taped distance to the tree 100 feet 1.05
  105 feet
• The measuring instrument is moved to a taped
  distance of 105 feet
• Angle to tree base 4 Angle to tree top 76
• Tree height 76 feet - 4 feet 72 feet

13
Tree Heights

• Measuring Tools

14
Abney Level
15
Blume-Leiss Altimeter
16
Haga Altimeter
17
Laser Hypsometers
Line of site limitations, expensive
18
Measuring Rod
19
Merritt Hypsometer
20
Merritt Hypsometer Make your own
21
Look Ma! - No Tools
22
Suunto Clinometer
Degree and Topographic Scales
23
Suunto Clinometer
Degree and Percent Scale
24
Clinometer on the cheap
25
Clinometer Toys
26
Spiegel Relaskop
27
Tree Height
Left scale in percent at 100 feet. What is the
tree height?
28
Upper Stem Diameter
Compensates for angle
29
Ultrasonic
Not Limited by Line of Sight like Laser or Optical
30
Apps
31
iHypsometer Lite
32
Merchantable height

• A normal trees merchantability stops at the
  narrowest diameter that the lumber mill can
  handle
• This is usually 4 to 6 inches

33
Vertical Limits to Merchantability

• Stoppers are occurrences in the tree that can not
  be productively sawn through and limit the length
  of a potential log section.

• Forks that are at least 1/3 diameter of main bole
  at point of occurrence and 45 degrees or less in
  angle from the main bole.
• Branches, stubs, remnant bumps. ½ diameter of
  main stem.
• Any embedded metal excluding aluminum.
• Sudden dramatic change in bole diameter

34
Measuring Tree Heights

• Problem Trees

35
Leaning Trees
Measure perpendicular to the lean, angling your
hypsometer (reads normally)
36
Measured from the direction of the lean
Can use Pythagorean Theorem to solve
37
Conversely

• You measure B normally (not full tree height)
• To get true bole length (A), you need angle C
  also
• Then A B/cos C

38
Avoid this mistake
39
Irregular Stems
40
Broken Tree

• Measure height of the stub
• Measure length of the piece on the ground
  (trigonometry may be needed)
• Add the two measurements to obtain total height

41
Recap and Questions
