Calibration testing Services in Mechanical Testing

1
Mechanical Testing Calibration Laboratory
Singapore
2

• Calibration Company Singapore performs a good
  range of Mechanical Testing activities.
• In quality Calibration Services Tensile, Yield,
  Proof (0.2, 0.5, 1), Elongation, Reduction
  Area, Compression test, Procedure qualification
  record (PQR), Welding Procedure Specification
  (WPS), Bend Test(Transverse bend, Side bend, Face
  bend, Root bend)

3

• Hardness Test in calibration laboratory Singapore
  includes Rockwell hardness (HRA, HRB, HRC)
  Rockwell superficial hardness (HR15T, HR30T,
  HR45T, HR15N, HR30N, HR45N,) Brinell Harness
  Test, Vickers Hardness Test, Micro Vickers
  Hardness Test.
• Impact test Charpy Impact Test (U- Notch
  V-Notch) in accordance with ASTM Standards Pull
  out and obtrude Test, Drift expansion test,
  Flattening and Flaring Test, Fracture Test,
  Re-bend Test, Macro Structure.

4
Computerized universal testing machine (utm)

• Range of Equipment
• Calibration Company Singapore has the potential
  to check up to 600 kN using computerized UTM with
  a least count of 0.001 kN

5
Properties determined

• Tensile Strength
• Yield Strength
• 0.2 0.5 Proof Stress
• Elongation Reduction

6
Properties determined

• Compression Strength
• Bend Test (Root, Face Sidebend)
• Re-bend Test
• Crush Test
• Flattening, Flaring Drift Test

7
Impact testing machine

• Range of Equipment
• o 2 to 300 J
• o Verified by NIST.

8
Capability of the Equipment

• Charpy Impact Test for both U V Notched
  Specimens
• Charpy impact test in weld and HAZ locations
• Ability to check with a temperature range of (RT
  to -196C)
• Notch Verification done using profile projector

9
Rockwell hardness test

• Range of Equipment
• o 15 kgf -150 kgf of (Diamond 1/16 Ball
  Indenter)
• o Fully automated Rockwell Hardness Testing
  machine.

10
Capability of Testing

• Calibration Company Singapore has capability to
  perform Rockwell hardness Test with scale of
  HR30N, HRA, HRB HRC
• Standard Test blocks available
• HRA - 3 ranges
• HRB - 3 ranges
• HRC -3 ranges
• HR 30N - 1 range
