MULTIMODE TO SINGLEMODE FIBER CONVERTER
VERSITRON INC
2
MULTIMODE TO SINGLMODE CONVERTER
Multimode to Singlemode fiber media converters
provide an efficient solution for converting your
100Base and 1000Base multimode networks to
singlemode networks and vice versa. It is
designed to use across a variety of topologies
and network architectures for shorter data
transmission distances with ethernet LAN and WAN
connectivity. It uses SFP technology to convert
either 100BaseFX fiber or 1000Base Gigabit fiber.
3
MULTIMODE TO SINGLE-MODE MEDIA CONVERTER WORKING
Single mode fiber converters pass only one
wavelength. It transmits signals to a longer
distance than multimode media converters.
Multimode to single mode fiber conversion is used
to extend longer distances. A Fiber to fiber
converters extend a multimode network across a
single mode fiber effectively up to 140 km in
affordable yet powerful way. Multimode to
single mode media converters feature SFP
transceivers that support a wide variety of data
rates and network protocols.
4
FEATURES

• It support a broad range of single mode fiber
  options such as bi-directional single fiber,
  short reach to long reach and CWDM.
• Fiber to fiber media converters are designed to
  FCC Part 15 Class B, CE / CISPR 22 Class B,
  IEC60950 Safety standards.
• Multimode to Singlemode converter data speed is
  1000Mbps, full duplex.
• It provides two SFP slots that support standard
  SFP fiber transceivers.
• Mounting options include wall mounting, panel
  mounting, Din-Rail support.
• Compliance with IEEE 802.3z 1000Base-SX/LX and
  IEEE 802.3u 100Base-FX standards.
• Plug-and-play design enables for a quick and easy
  installation.
• LEDs for ease of network monitoring.

5
APPLICATIONS
LOCAL AREA NETWORKS
ENTERPRISE NETWORKS
CAMPUS NETWORKS
FIBER TO THE BUILDING
FIBER TO THE CURB
DATA CENTERS
TELECOM
POINT-TO-POINT FIBER NETWORKS
6
FACTORS TO CONSIDER WHEN CHOOSING FIBER TO FIBER
MEDIA CONVERTER

• Data Rates It depends on the Bandwidth of fiber.
• Fiber Modes There are two types of fiber modes.
  Single mode and Multimode. Based on the
  requirement you can choose.
• Packet Length Supported Most of the single mode
  to multimode converters have packet length
  limitations.
• Mounting Consider the available space and other
  application constraints choose the fiber to fiber
  media converters. Desktop, wall, Rack Mounting.
• Power Consumption Ensure that the media
  converter has low power consumption.
