Passive Solar Residential Design and Construction

1
Passive Solar Residential Design and Construction

• Mark M. Feldman, President
• High Desert
• Construction, Inc.
• www.markmfeldman.com

2
Design Determinants The Lot

• Climate
• Microclimate
• Vegetation
• Soil Conditions
• Topography/Drainage
• Solar Availability
• Access
• Privacy
• Views - Good Bad
• Neighbors
• Utilities

3
The Rules of the Road

• Zoning Ordinances
• Relevant Codes (2006 IRC)
• Restrictive Covenants

4
Hierarchy Relationship of Spaces

• Bubble Diagram
• Relationship to Each Other
• Relationship to the Lot

5
Style

• Photos From Magazines
• Personal Photos
• Houses and Details

6
Material Choices

• Durability (lifetime)
• Environmental Consequences
• Cost
• Suitability
• Standardization

7
Budget

• Current and lifetime costs
• Payback periods

8
Start Drawing!

• Plan, elevations, sections, details, K.I.S.S.

9
Models

• Think in 3-D

10
Let the Sun Shine In

• Declination (finding true South)
• Glass to the South
• Sun Angles
• Site Specific
• Amount of Solar
• Orientation

• National Geophysical Data Center (NOAA Satellite
  and Information Service)
• Declination 9 26 E

11
Heat Capacity

• Build with materials that have a high thermal
  mass
• High heat capacity conductivity

12
Work with the Environment

• Go with the flow
• Dont fight Mother Nature
• Consider indigenous design

13
Define Goals

• Day use?
• Night use?
• Energy or dollar conservation (for your home or
  for the planet)?

14
Principles of Heat Transfer

• Conduction
• Convection
• Radiation

Surface area of building
15
Insulation and Weather Stripping

• High quality
• Tight Construction
• Heat loss
• Infiltration/fan pressurization test
• Air to air heat exchangers

16
Heating and Cooling Degree Days

• Types of insulation
• How much insulation is enough

17
Recommended Levels of Insulation

• R-values
• U-values
• Effective u-values

18
Glazing Materials

• Double, triple glazing
• Low e windows
• Wood
• Fiberglass
• Aluminum
• Vinyl windows
• doors

19
Direct Gain
CONS Glare Loss of privacy Fading of
fabrics/pictures Carpets not desirable Large
temperature swings Moveable insulation

• PROS
• Simple
• Inexpensive
• Natural daylight
• View outside

20
Direct Gain Examples

• Clerestory

Window
21
Sunspaces/Greenhouses
CONS Heat loss at night Summertime
overheating Expense
PROS Space for growing food/plants Act as
buffer zone Easily retrofitted Additional
living space
22
Sunspaces/Greenhouses Examples
23
Thermal Mass Walls
PROS Lower temperature swings Time delay
Combined collector/storage Combined
solar/structural No glare or fading
CONS Two south walls Mass wall uses space
No daylight or view Heat loss at night
Cleaning/insects
24
Thermal Mass Example 1
Hallways/Stairs
25
Thermal Mass Example 2

• Water/drum walls

26
Thermal Mass Example 3

• Partial unvented trombe walls

27
Overhangs
28
Control of Passive Solar Systems

• Natural Shading
• Blinds

29
Passive Cooling
30
Daylighting
31
Design Rules of Thumb

• Excerpted from The Passive Solar Energy Book by
  Ed Mazria

32
Passive Solar Domestic Water Heating Systems
Breadbox

• Simple
• Cheap

33
Passive Solar Domestic Water Heating Systems
Thermosiphon 1
34
Passive Solar Domestic Water Heating Systems
Thermosiphon 2
35
Backup Cooling Systems
Evaporative Cooler
36
Backup Heating Systems 1
Conversion Equivalence Chart Electricity 1
KW 3,413 Btu/hr Natural gas 1 Cubic Foot
of Natural Gas 1030 Btu's 1 CCF 100 Cu Ft
1 Therm 103,000 Btu's  1 MCF 1,000 Cu Ft
10 Therms 1,034,000 Btu's 1.034 MMBtu's
Propane 1 Gal Propane 91,600 Btu's 1 Cu Ft
Propane 2,500
37
Backup Heating Systems 2
38
Backup Heating Systems 3
39
Backup Heating Systems 4
40
Backup Heating Systems 5
Heat pumps and Geothermal
