Title: Dickson K.W. Chiu


1
CSIT600c Web Services Programming Java Web
Services Programming
  • Dickson K.W. Chiu
  • PhD, SMIEEE
  • Deitel et al., Java Web Services for Experienced
    Programmers

2
Java Web Services DevelopmentPack (JWSDP)
  • Now integrated into J2EE 1.4
  • Provides a convenient all-in-one package
  • Geared for developers
  • Contains
  • JAXP (Java API for XML Processing)
  • JAX-RPC (Java API for XML-based RPC)
  • SAAJ (SOAP with Attachments API for Java)
  • JAXR (Java API for XML Registries)
  • JAXM (Java API for XML Messaging)
  • See http//java.sun.com/webservices/

3
JAX-RPC and JAXM
  • Both based on SOAP with Attachments
  • For web service programming
  • Sun recommends JAX-RPC easier to program
  • SAAJ / JAXM
  • Interoperability (e.g. calling other clients)
  • Non-blocking option

4
JAX-RPC
  • Java API for XML-based RPC
  • RPC requests and responses represented using SOAP
  • Both Web service endpoints and clients use
    JAX-RPC
  • Services are described using WSDL
  • Key technology for Web Services in the upcoming
    J2EE 1.4 platform

5
Remote Procedure Call (RPC)
  • RPC, COM, CORBA, RMI
  • Synchronous communication - calling process
    blocks until there is a response
  • Tightly coupled - client must find recipients and
    know method arguments
  • Non persistent

6
JAX-RPC Design Goal
  • Easy to use programming model
  • Defining a service
  • Using a service
  • Hides all the plumbing complexity of SOAP
    messaging
  • SOAP and WSDL-based interoperability
  • Interoperate with any SOAP compliant peers
  • Extensibility and Modularity
  • Support future versions of XML specification,
    i.e., XMLP (SOAP 1.2 and beyond)
  • Message handler architecture

7
JAX-RPC Architecture Diagram
8
What happen during an RPC?
  • To call a remote procedure, the HelloClient
    program invokes a method on a stub, a local
    object that represents the remote service.
  • The stub invokes routines in the JAX-RPC runtime
    system.
  • The runtime system converts the remote method
    call into a SOAP message and then transmits the
    message as an HTTP request.
  • When the server receives the HTTP request, the
    JAX-RPC runtime system extracts the SOAP message
    from the request and translates it into a method
    call.
  • The JAX-RPC runtime system invokes the method on
    the tie object.
  • The tie object invokes the method on the
    implementation of the HelloWorld service.
  • The runtime system on the server converts the
    method's response into a SOAP message and then
    transmits the message back to the client as an
    HTTP response.
  • On the client, the JAX-RPC runtime system
    extracts the SOAP message from the HTTP response
    and then translates it into a method response for
    the HelloClient program.

9
What happen during an RPC?
10
Service Description and WSDL
JAX-RPC describes a Web Service as a
collection of remote interfaces and methods
Tools are used to convert between WSDL documents
and sets of Java remote interfaces
WSDL describes a Web Service as a collection of
ports and operations
  • JAX-RPC service endpoint mapped to WSDL service
    description
  • WSDL enables export of a JAX-RPC service endpoint
    across heterogeneous environments
  • JAX-RPC specifies the standard WSDLlt-gt Java
    mapping
  • Mapping between service endpoint interface and
    WSDL definitions
  • Binding to specific protocol and transport
  • XML lt-gt Java data types

11
WSDL Mapping
  • wsdlportType mapped into a Java Interface
    (Service Definition Interface) that extends
    java.rmi.Remote
  • wsdloperation mapped into a method of the
    Service definition interface
  • wsdlmessage's are mapped into parameters of the
    method
  • wsdltype's of wsdlmessage's are mapped into the
    types of the parameters

12
WSDL Mapping Example
  • lt!------------------- WSDL Document
    -------------------------------------gt
  • ltmessage nameGetLastTradePriceInputgt
  • ltpart nametickerSymbol typexsdstring/gt
  • lt/messagegt
  • ltmessage nameGetLastTradePriceOutput?
  • ltpart nameresult typexsdfloat/gt
  • lt/messagegt
  • ltportType nameStockQuoteProvidergt
  • ltoperation nameGetLastTradePrice
    parameterOrdertickerSymbolgt
  • ltinput messagetnsGetLastTradePriceInput/gt
  • ltoutput messagetnsGetLastTradePriceOutput/gt
  • lt/operationgt
  • lt/portTypegt
  • public interface StockQuoteProvider extends
    java.rmi.Remote
  • float getLastTradePrice(String tickerSymbol)
  • throws java.rmi.RemoteException

13
Supported Java Type
  • See J2EE tutorial
  • Note all objects are passed by copy
  • Java primitive types
  • String, Date, Calendar, BigInteger, BigDecimal
  • Multi-dimensional Java arrays
  • JAX-RPC value type classes youve written for
    your applications, based on the above
  • JavaBean Components also based on the above

14
Developing a JAX-RPC Web Service
  1. Define service endpoint
  2. Implement Service endpoint
  3. Compile code and generate WSDL
  4. Packaging WAR and deploy

15
0. Setting the Port
  • If you do not use the default port 8080, edit
  • ltINSTALLgt/j2eetutorial14/examples/common/build.pro
    perties
  • ltINSTALLgt/j2eetutorial14/examples/jaxrpc/staticstu
    b/config-wsdl.xml
  • ltINSTALLgt/j2eetutorial14/examples/jaxrpc/dynamicp
    roxy/config-wsdl.xml
  • ltINSTALLgt/j2eetutorial14/examples/jaxrpc/appclient
    /config-wsdl.xml
  • ltINSTALLgt/j2eetutorial14/examples/jaxrpc/webclient
    /config-wsdl.xml
  • ltINSTALLgt/j2eetutorial14/examples/jaxrpc/webclien
    t/web/response.jsp
  • ltINSTALLgt/j2eetutorial14/examples/security/basica
    uthclient/SecureHello.wsdl
  • ltINSTALLgt/j2eetutorial14/examples/security/mutual
    authclient/SecureHello.wsdl

16
1. Service Endpoint Definition
  • Specified in Service Definition Interface
  • Could be generated from WSDL document using a
    tool or
  • Could be written in Java programming language
    directly
  • No assumption about type of client that would use
    this service definition interface
  • package hello
  • import java.rmi.Remote
  • import java.rmi.RemoteException
  • public interface HelloIF extends Remote
  • public String sayHello(String s) throws
    RemoteException

17
2. Service Implementation
  • Service implementation class is an ordinary Java
    class
  • Invocation done inside the servlet container
  • JAX-RPC defines Servlet-based Endpoint model
  • Other endpoint models (e.g., stateless session
    beans) will be defined in J2EE 1.4 / EJB 2.1
  • Optional ServiceLifecycle interface for
    initialization and destruction callbacks
  • package hello
  • public class HelloImpl implements HelloIF
  • public String message new String("Hello ")
  • public String sayHello(String s)
  • return new String(message s)

package hello import java.rmi.Remote import
java.rmi.RemoteException public interface
HelloIF extends Remote public String
sayHello(String s) throws RemoteException
18
3. Compiling / WSDL generation
  • Use the ant tool simplifies the job
  • Compile HelloIF.java and HelloImpl.java, go to
    the ltINSTALLgt/j2eetutorial14/examples/jaxrpc/hello
    service/ directory and type the following ant
    build
  • compile-service compiles HelloIF.java and
    HelloImpl.java, writing the class files to the
    build subdirectory
  • generate-wsdl runs wscompile, creating
    MyHelloService.wsdl and mapping.xml
  • Customize wsdl generation with config-interface.xm
    l
  • lt?xml version"1.0" encoding"UTF-8"?gt
  • ltconfiguration xmlns"http//java.sun.com/xml/ns/j
    ax-rpc/ri/config"gt
  • ltservice name"MyHelloService"
    targetNamespace"urnFoo"
  • typeNamespace"urnFoo" packageName"hellose
    rvice"gt
  • ltinterface name"helloservice.HelloIF"/gt
  • lt/servicegt
  • lt/configurationgt

19
4. Packaging the WAR file (i)
  • Use Deploytool to create a standalone WAR module

20
4. Packaging the WAR file (ii)
  • Use Deploytool to create a standalone WAR module

21
4. Packaging the WAR file (iii)
  • Enter context root
  • Add alias hello
  • Update the endpoint address to hello (see
    previous slide)
  • Save and Deploy

22
4. Another way to deploy the WAR file
  • To create the WAR file that contains the service
    code
  • asant create-war
  • Set your admin port, username, and password in
    ltINSTALLgt/j2eetutorial14/examples/common/build.pro
    perties.
  • To deploy the WAR file
  • asant deploy-war
  • Note this may create different
  • naming

23
JAX-RPC Clients
  • Independent of how an XML based RPC service
    (service endpoint) is implemented on the server
    side
  • Generates a Java based client side representation
    for a service from WSDL document
  • Not tied to a specific XML based protocol,
    transport or any JAX-RPC implementation specific
    mechanism
  • Can use either J2SE or J2EE
  • 3 programming modes
  • Static stub-based least dynamic, easiest to
    program - you know everything about the services
    and pre-generate the stub
  • Dynamic proxy - call location dynamic
    (URL/service/name), information about the service
    by looking up WSDL document at run time (but
    signature of method fixed)
  • Dynamic invocation interface (DII) everything
    dynamic, but more tedious and more time to set up
    a call

24
WSDL Generated
  • lt?xml version"1.0" encoding"UTF-8"?gt
  • ltdefinitions name"MyHelloService"
    targetNamespace"urnFoo" xmlnstns"urnFoo"
    xmlns"http//schemas.xmlsoap.org/wsdl/"
    xmlnsxsd"http//www.w3.org/2001/XMLSchema"
    xmlnssoap"http//schemas.xmlsoap.org/wsdl/soap/"
    gt
  • lttypes/gt
  • ltmessage name"HelloIF_sayHello"gt
  • ltpart name"String_1" type"xsdstring"/gtlt/mes
    sagegt
  • ltmessage name"HelloIF_sayHelloResponse"gt
  • ltpart name"result" type"xsdstring"/gtlt/messa
    gegt
  • ltportType name"HelloIF"gt
  • ltoperation name"sayHello" parameterOrder"Str
    ing_1"gt
  • ltinput message"tnsHelloIF_sayHello"/gt
  • ltoutput message"tnsHelloIF_sayHelloRespons
    e"/gtlt/operationgtlt/portTypegt
  • ltbinding name"HelloIFBinding"
    type"tnsHelloIF"gt
  • ltsoapbinding transport"http//schemas.xmlsoa
    p.org/soap/http" style"rpc"/gt
  • ltoperation name"sayHello"gt
  • ltsoapoperation soapAction""/gt
  • ltinputgt
  • ltsoapbody encodingStyle"http//schemas.x
    mlsoap.org/soap/encoding/" use"encoded"
    namespace"urnFoo"/gtlt/inputgt
  • ltoutputgt
  • ltsoapbody encodingStyle"http//schemas.x
    mlsoap.org/soap/encoding/" use"encoded"
    namespace"urnFoo"/gtlt/outputgtlt/operationgtlt/bindin
    ggt

25
WSDL Mapping - binding, port, service
  • wsdlservice is mapped into an implementation of
    javax.xml.rpc.Service interface
  • JAX-RPC runtime provides the implementation
  • A javax.xml.rpc.Service class acts as a factory
    of either
  • Instance of a generated stub class
  • Dynamic proxy for a service port
  • Instance of the object javax.xml.rpc.Call for the
    dynamic invocation of a remote operation on a
    service port

26
Static Stub - Client Code
  • package staticstub
  • import javax.xml.rpc.Stub
  • public class HelloClient
  • private String endpointAddress
  • public static void main(String args)
  • System.out.println("Endpoint address "
    args0)
  • try
  • Stub stub (Stub) (new
    MyHelloService_Impl().getHelloIFPort())
  • stub._setProperty(javax.xml.rpc.Stub.E
    NDPOINT_ADDRESS_PROPERTY, args0)
  • HelloIF hello (HelloIF) stub
  • System.out.println(hello.sayHello("Duk
    e!"))
  • catch (Exception ex)
  • ex.printStackTrace()
  • // output Hello Duke!

Generated by wscompile before writing this
program (i.e., static and implementation-specific)
27
Static Stub build and run
  • To automate the rest of the steps, go to the
    ltINSTALLgt/j2eetutorial14/examples/jaxrpc/staticstu
    b/ directory and type the following asant build
  • generate-stubs wscompile -genclient -d build
    -classpath build config-wsdl.xml
  • ltconfiguration xmlns"http//java.sun.com/xml/ns/
    jax-rpc/ri/config"gt
  • ltwsdl location"http//localhost8080/hello-ja
    xrpc/hello?WSDL
  • packageName"staticstub"/gt
  • lt/configurationgt
  • compile-client compiles src/HelloClient.java and
    writes the class file to the build subdirectory.
  • package-client packages the files created by the
    generate-stubs and compile-client tasks into the
    dist/client.jar file.
  • Run the client - asant run

28
Dynamic Proxy-based Client
  • Client calls a remote procedure through a dynamic
    proxy
  • Client gets information about the service by
    looking up its WSDL document at runtime - call
    location (URL/service/name)
  • But the signature (parameters and their types) of
    the method is fixed
  • The Service class that is created during runtime
  • Similar usage of asant
  • However, only the service endpoint interface
    class of the sample target is used but not the
    generated stub

29
Example Dynamic Proxy-based Client
  • package dynamicproxy
  • import java.net.URL
  • import javax.xml.rpc.Service
  • import javax.xml.rpc.JAXRPCException
  • import javax.xml.namespace.QName
  • import javax.xml.rpc.ServiceFactory
  • import dynamicproxy.HelloIF
  • public class HelloClient
  • public static void main(String args)
  • try
  • String UrlString args0 "?WSDL"
  • String nameSpaceUri "urnFoo"
  • String serviceName
    "MyHelloService"
  • String portName "HelloIFPort"
  • System.out.println("UrlString "
    UrlString)
  • ServiceFactory serviceFactory
    ServiceFactory.newInstance()
  • Service helloService
  • serviceFactory.createService(hello
    WsdlUrl,
  • new QName(nameSpaceUri,
    serviceName))
  • dynamicproxy.HelloIF myProxy
  • (dynamicproxy.HelloIF)
    helloService.getPort
  • (new QName(nameSpaceUri,portName),
  • dynamicproxy.HelloIF.class)
  • System.out.println(myProxy.sayHello(B
    uzz))
  • catch (Exception ex)
  • ex.printStackTrace()

30
Dynamic Invocation Interface (DII) Client
  • Dynamic invocation of an operation on the target
    service endpoint
  • Enables broker model
  • Client finds (through search criteria) from a
    UDDI directory and invokes a service during
    runtime through a broker
  • Note the code in the following example does not
    show the lookup and simply hardcode the services
    in strings
  • Used when service definition interface is not
    known until runtime
  • Set all operation and parameters during runtime
  • From the Service object create Call object first
  • Similar usage of asant

31
DII Client Example
  • package dii
  • import javax.xml.rpc.Call
  • import javax.xml.rpc.Service
  • import javax.xml.rpc.JAXRPCException
  • import javax.xml.namespace.QName
  • import javax.xml.rpc.ServiceFactory
  • import javax.xml.rpc.ParameterMode
  • public class HelloClient
  • private static String qnameService
    "MyHelloService"
  • private static String qnamePort "HelloIF"
  • private static String BODY_NAMESPACE_VALUE
    "urnFoo"
  • private static String ENCODING_STYLE_PROPERTY
  • "javax.xml.rpc.encodingstyle.namespace.uri
    "
  • private static String NS_XSD
    "http//www.w3.org/2001/XMLSchema"
  • private static String URI_ENCODING
  • "http//schemas.xmlsoap.org/soap/encoding/
    "
  • public static void main(String args)
  • ServiceFactory factory
    ServiceFactory.newInstance()
  • Service service factory.createServic
    e(new QName(qnameService))
  • QName port new QName(qnamePort)
  • Call call service.createCall(port)
  • call.setTargetEndpointAddress(args0)
  • call.setProperty(Call.SOAPACTION_USE_P
    ROPERTY, new Boolean(true))
  • call.setProperty(Call.SOAPACTION_URI_P
    ROPERTY, "")
  • call.setProperty(ENCODING_STYLE_PROPER
    TY, URI_ENCODING)
  • QName QNAME_TYPE_STRING new
    QName(NS_XSD, "string")
  • call.setReturnType(QNAME_TYPE_STRING)
  • call.setOperationName(new
    QName(BODY_NAMESPACE_VALUE, "sayHello"))
  • call.addParameter(String_1,
    QNAME_TYPE_STRING,
  • ParameterMode.IN)
  • String params "Murph!"
  • String result (String)
    call.invoke(params)
  • System.out.println(result)
  • catch (Exception ex)
  • ex.printStackTrace()

32
JAXM
  • Java API for XML Messaging
  • Java support for sending and receiving SOAP XML
    document oriented messages
  • Two JAXM API Programming Models
  • Point-to-point model simpler
  • JAXM Provider-based" (like a "messaging server")
    model - supports Asynchronous messaging
  • Design Goals
  • Build on SOAP with Attachments
  • Add support to plug higher-level messaging
    protocols (e.g., ebXML)
  • Design for easy porting of applications from one
    container to another specifically from web
    containers to that of J2EE
  • Dont attempt to build a full-fledged messaging
    API (e.g., JMS)

33
JAXM Point-to-Point Model
  • Synchronous Request-response interaction
  • Calling process blocks until there is a response
  • Connection established directly to the ultimate
    recipient
  • No persistence
  • can be difficult to scale

34
JAXM Provider Model
  • Asynchronous (or Synchronous you choose)
  • Sender is not blocked, Receiver does not have to
    be available
  • Reliable - Message can be stored and forwarded
    (routed) until it can be delivered
  • JAXM Provider works behind the scene

35
JAXM Provider
  • Offers message routing and reliable messaging as
    all messages go through it
  • Assign message identifiers and keeping track of
    messages
  • JAXM client makes JAXM method calls, and the
    provider (working with container) makes
    everything happen
  • JAXM providers are responsible for producing an
    error message and sending it to the offending
    JAXM client when receiving a malformed message
  • Responsibility of JAXM application to consume
    error messages and take corrective actions

36
JAXM client
  • Not using JAXM provider
  • Just a standalone J2SE application
  • Point to point operation
  • Establishes a connection directly with the
    service (using a URL)
  • Synchronous only
  • Request/response interaction
  • Using JAXM provider
  • Maintains a connection with JAXM provider, and
    all messages go through the provider
  • JAXM client deployed in a web or EJB container
  • MessageDrivenBean
  • JAXMServlet
  • Send and receive messages synchronously or
    asynchronously

37
JAXM vs. JMS
  • Similarities
  • Both supports Messaging Provider model
  • Reliable, secure message delivery
  • Routing
  • Both supports asynchronous message delivery
  • Differences
  • JAXM provider could be lightweight while JMS
    provider is usually heavyweight
  • JAXM supports standalone mode while JMS does not
  • JAXM client is interoperable over any SOAP
    compatible client while JMS client is
    interoperable only with other JMS client over the
    same messaging system
  • Delivery endpoint model is different

38
Using SAAJ API to call a Web Service
  • Steps
  • Create SOAP message
  • Populate SOAP message
  • Add attachments (optional)
  • Initialize SOAP connection
  • Send SOAP message
  • Analyze response message
  • Code based on J2EE tutorial p.398 request.java
  • Library files required
  • H/Sun/Appserver/lib/j2ee.jarH/Sun/Appserver/li
    b/saaj-impl.jarH\Sun\AppServer\lib\endorsed\xerc
    esImpl.jarH\Sun\AppServer\lib\endorsed\dom.jar.
  • Example based on URL
  • http//www.mindreef.net/tide/scopeit/start.do?refe
    rerxmethodsurlhttp//services.xmethods.net/soap
    /urnxmethods-delayed-quotes.wsdl

39
SAAJ Example Code
  • import javax.xml.soap.
  • import java.util.
  • import java.net.URL
  • public class Request
  • public static void main(String args)
  • try
  • SOAPConnectionFactory soapConnectionFactory
    SOAPConnectionFactory.newInstance()
  • SOAPConnection connection
    soapConnectionFactory.createConnection()
  • SOAPFactory soapFactory
    SOAPFactory.newInstance()
  • MessageFactory factory
    MessageFactory.newInstance()
  • SOAPMessage message factory.createMessage(
    )
  • SOAPHeader header message.getSOAPHeader()
  • SOAPBody body message.getSOAPBody()
  • header.detachNode()

40
SAAJ Example Code (2)
  • Name bodyName soapFactory.createName(
    "getQuote", "m",
  • "urnxmethods-delayed-quotes")
  • SOAPBodyElement bodyElement
    body.addBodyElement(bodyName)
  • Name name soapFactory.createName("symbol")
  • SOAPElement symbol bodyElement.addChildEle
    ment(name)
  • symbol.addTextNode(args0)
  • URL endpoint new URL("http//64.124.140.30
    9090/soap")
  • SOAPMessage response connection.call(messa
    ge, endpoint)
  • connection.close()
  • response.writeTo(System.out)
  • catch (Exception ex)
  • ex.printStackTrace()
  • ltSOAP-ENVEnvelope xmlnsSOAP-ENV
  • "http//schemas.xmlsoap.org/soap/envelope/"gt
  • ltSOAP-ENVBodygt
  • ltmgetQuote xmlnsm" urnxmethods-delayed-quotes
    "gt
  • ltsymbolgtXXXXlt/symbolgt
  • lt/mgetQuotegt
  • lt/SOAP-ENVBodygt
  • lt/SOAP-ENVEnvelopegt

41
SAAJ Result Message
  • ltsoapEnvelope
  • soapencodingStyle"http//schemas.xmlsoap.org/so
    ap/encoding/"
  • xmlnssoap"http//schemas.xmlsoap.org/soap/envel
    ope/" xmlnsxsi"http//www.w3.org/2001/XMLSchema-
    instance" xmlnsxsd"http//www.w3.org/2001/XMLSch
    ema" xmlnssoapenc"http//schemas.xmlsoap.org/soa
    p/encoding/"gt
  • ltsoapBodygt
  • ltngetQuoteResponse xmlnsn"urnxmethods-dela
    yed-quotes"gt
  • ltResult xsitype"xsdfloat"gt4.15lt/Resultgt
  • lt/ngetQuoteResponsegt
  • lt/soapBodygt
  • lt/soapEnvelopegt

42
Adding Attachment with SAAJ
  • // We're using a HTTP image repository here
  • // to get the data for an image
  • URL url new URL ("http//images.wombats.com/w.jp
    g")
  • // Create a JAF DataHandler with this URL
  • DataHandler dh new DataHandler(url)
  • // Create and Add an AttachmentPart
  • message.addAttachmentPart(
  • message.createAttachmentPart(dh))

43
Summary Calling Web Services in Java
  • Use JAX-RPC
  • Static Stub you know everything about the
    services and pre-generate the stub
  • Dynamic Proxy call location dynamic
    (URL/service/name), information about the service
    by looking up WSDL document at run time (but
    signature of method fixed)
  • DII everything lookup at run time, i.e., call
    and parameters prepared at runtime
  • Send SOAP messages with SAAJ
  • for most flexibility
  • target is not RPC
Write a Comment
User Comments (0)
About PowerShow.com
