Converting Macromolecular Regulatory Models from Deterministic to Stochastic Formulation

1
Converting Macromolecular Regulatory Models from
Deterministic to Stochastic Formulation

• Pengyuan Wang, Ranjit Randhawa, Clifford A.
  Shaffer, Yang Cao, and William T. Baumann
• Virginia Tech, Blacksburg VA

2
The Fundamental Goal of Molecular Cell Biology
3
The Cell Cycle
4
Cell Cycle Control Mechanism
5
Modeling Techniques

• One method Use ODEs that describe the rate at
  which each protein concentration changes
• Protein A degrades protein B
• with initial condition A(0) A0.
• Parameter c determines the rate of
  degradation.
• Sometimes modelers use creative rate laws to
  approximate subsystems

6
Simulation Budding Yeast Cell Cycle
7
Expermental Data
8
Putting it Together
9
Chen/Tyson Budding Yeast Model

• Contains over 30 ODEs, some nonlinear.
• Events can cause concentrations to be reset.
• About 140 rate constant parameters
• Most are unavailable from experiment and must set
  by the modeler

10
Fundamental Activities of the Modeler

• Collect information
• Search literature (databases), Lab notebooks
• Define/modify models
• A user interface problem
• Run simulations
• Equation solvers (ODEs, PDEs, deterministic,
  stochastic)
• Compare simulation results to experimental data
• Analysis

11
Modeling Process
12
Stochastic Simulation Motivation

• ODE-based (deterministic) models cannot explain
  behaviors introduced by random nature of the
  system.
• Variations in mass of division
• Variations in time of events
• Behavior of small numbers (RNA, DNA)
• Differences in gross outcomes

13
Gillespies Stochastic Simulation Algorithm (SSA)

• There is a population for each chemical species
• There is a propensity for each reaction, in
  part determined by population
• Each reaction changes population for associated
  species
• Loop
• Pick next reaction (random, propensity)
• Update populations, propensities
• Slow, there are approximations to speed it up

14
Question

• Given an existing deterministic model, how do we
  convert it to a formulation capable of stochastic
  simulation?
• Can this be automated?
• Is there a fundamental difference in
  representation?
• SSA is known to be CPU-intensive. How much
  computation resource is really needed to simulate
  the converted model stochastically?

15
Relation between the Two Formulations

• In common both models describe the same reaction
  network.
• Difference the reaction rate equation is
  replaced by a propensity function describing how
  likely that the reaction will fire in next unit
  time.
• Connection although they have different physical
  meanings, propensity function shares the same
  expression as corresponding reaction rate
  equation (written in number of molecules).
• Caveat except for the creative rate laws

16
Missing Information

• Usually ODE models are written in terms of
  normalized concentrations.
• Thus they need to be converted to models in terms
  of number of molecules (population).
• Some information is missing
• Characteristic concentration
• Explicit definition of units
• Volume of the container.

17
Conversion

• The relation between normalized concentration,
  real concentration and population of a species

18
How Units are Used in the Model

• Every parameter and species is assigned the
  correct unit, scaling factors.
• The conversion algorithm follows units to convert
  the model.

19
The Challenge

• Assigning correct units to species and parameters
  is difficult because all the species, parameters,
  and reactions are connected by the whole reaction
  network.
• Once the modeler is forced to provide the
  complete specification, the conversion can be
  automated
• Caveats
• Creative rate laws
• Events

20
Events Need Extra Care
/deterministic events/ If (Agtthreshold) Then
event is triggered. (Here gt means
rising above a threshold)
/stochastic events/ If (Altminimum) Then
minimumA If (minimumltcertain low value AND
Agtthreshold) Then event is triggered
minimumA. (we ask for A truly rising from a
low value, not happening to rise by oscillation.)

• Except for events, all other parts of the model
  are automatically converted by JigCell.

21
Conversion Tool

• Part of the JigCell modeling suite
• Automatically checks unit consistency inside the
  model
• Every two quantities (a parameter, a species, or
  the result of a sub-expression) connected by or
  - in the rate law equation must have same units.
• All species whose values are changed by the same
  reaction must have the same units.
• The unit of the result from the rate law equation
  must be equal to the unit of the reaction rate.

22
The Tool Entering the Data
23
The Tool Error Checking
24
The Tool Error Correction
25
The Tool Results Reactions
26
The Tool Results Unit Types
27
Simulation Experiments Setup

• Model
• A simplified cell cycle model
• A full-sized budding yeast cell cycle model
• Data
• 38 of 45 species in full-sized model use
  realistic characteristic concentration found in
  the literature.
• Cell volume is set to 50fL.
• Simulator
• StochKit, a C stochastic simulator integrated
  into JigCell, running SSA.

28
Distribution of Species on Converted Simplified
Model

• Ensemble result of 10,000 simulations at 200
  minutes simulation time.

29
Simulations on the Converted Full-sized Model

• The same model (except events) can be simulated
  either deterministically or stochastically
• The interesting cases are where they do not agree

30
Mass at Birth, Full-sized Model

• Mean 1.20, CV 2.96. (Compared with 1.21 from
  deterministic simulation)

31
Variance of Mass at Birth vs. Simulation Time vs.
Population
32
Simulation Times
Stochastic Time Stochastic Time Stochastic Time Deterministic Time
Model Wall Total Avg./run Deterministic Time
Simplified 145 12305 1.23 0.029
Full-sized 3862 382267 38.2 0.311

• Even a single run of the stochastic simulation
  takes much more time than the deterministic
  simulation.
• Parallel computing is needed and feasible.

33
Effect of Random Number Generators

• SPRNG

• random()

34
Conclusions

• Improved support for the conversion process
• The JigCell conversion tool
• Deterministic and stochastic formulations are not
  fundamentally different
• Deterministic modelers like to take short cuts
• Real experience with stochastic simulations on
  meaningful models
• Events
• Runtimes
• Approximation results

35
Future Work

• Initial conditions distribution
• Truly growing volume
• Our previous model had growing mass but fixed
  volume, which is not realistic
• Change to growing volume will change the reaction
  rate (propensity function)
• Simulations on mutants of particular interest
