Scalable Systems Software Center Al Geist, coordinating P.I.

1
Scalable Systems Software CenterAl Geist,
coordinating P.I.

• Rusty Lusk
• Mathematics and Computer Science Division
• Argonne National Laboratory

2
Outline

• The Scalable Systems Software Center
• Goals
• Participants
• Scope
• Structure
• Issues
• Status
• Experiences
• Lessons

3
Current State of Systems Software for Large-Scale
Machines

• Both proprietary and open-source systems
• Machine-specific, PBS, LSF, POE, SLURM, COOAE
  (Collections Of Odds And Ends),
• Many are monolithic resource management
  systems, combining multiple functions
• Job queuing, scheduling, process management, node
  monitoring, job monitoring, accounting,
  configuration management, etc.
• A few established separate components exist
• Maui scheduler
• Qbank accounting system
• Many home-grown, local pieces of software
• Scalability often a weak point

4
The Scalable Systems Software SciDAC Project

• Research goal to develop a component-based
  architecture for systems software for scalable
  machines
• Software goal to demonstrate this architecture
  with prototype open-source components
• One powerful effect forcing rigorous (and
  aggressive) definition of what components should
  do and what should be encapsulated in other
  components
• http//www.scidac.org//ScalableSystems

5
Participants

• Labs
• ORNL, ANL, LBNL, PNNL, Ames, SNL, LANL
• Universities
• NCSA, SDSC, PSC, Clemson
• Vendors
• Unlimited Scale, IBM, Cray, Intel
• Open to anyone who wants to participate

6
Project Concept
Meta Scheduler
Meta Monitor
Meta Manager
Access Control Security Manager
Meta Services
Interacts with all components
Node Configuration Build Manager
System Monitor
Accounting
Scheduler
Resource Allocation Management
Process Manager
Queue Manager
User DB
Data Migration
High Performance Communication I/O
Usage Reports
User Utilities
Checkpoint / Restart
File System
Testing Validation
Application Environment
7
Structure of Project

• Working Groups
• Node build, configuration, and global
  infrastructure
• Job submission, queue management, scheduling, and
  accounting
• Process management, system monitoring, and
  checkpointing
• Validation and integration
• Quarterly project meetings, weekly working group
  conference calls
• Electronic notebooks for all working documents
• www.scidac.org/ScalableSystems

8
SSS Project Issues

• Put minimal constraints on component
  implementations
• Ease merging of existing components into SSS
  framework
• E.g., Maui scheduler
• Ease development of new components
• Encourage multiple implementations from vendors,
  others
• Define minimal global structure
• Components need to find one another
• Need common communication method
• Need common data format at some level
• Each component will compose messages others will
  read and parse
• Message-framing protocols

9
SSS Project Status Global

• Early decisions on inter-component communication
• Lowest level communication is over sockets (at
  least)
• Message content will be XML
• Parsers available in all languages
• Did not reach consensus on transport protocol
  (HTTP, SOAP, BEEP, assorted home grown),
  especially to cope with local security
  requirements, so multiple protocols are supported
• Early implementation work on global issues
• Service directory component defined and
  implemented
• SSSlib library for inter-component communication
• Handles interaction with service directory
• Hides details of transport protocols from
  component logic
• Anyone can add protocols to the library
• Bindings for C, C, Java, Perl, and Python
• Event manager for asynchronous communication

10
SSS Project Status Individual Component
Prototypes

• Precise XML interfaces not settled on yet,
  pending experiments with component prototypes
• Both new and existing components
• Maui scheduler is existing full-featured
  scheduler, SSS communication added
• QBank accounting system has added SSS
  communication interface, evolving into Gold
• New Checkpoint Manager component being integrated
  now
• System-initiated checkpoints of LAM jobs

11
SSS Project Status More Individual Component
Prototypes

• New Build-and-Configuration Manager completed
• Controls how nodes are configured and built
• New Node State Manager
• Manages nodes as they are installed,
  reconfigured, added to active pool
• New Event Manager for asynchronous communication
  among components
• Components can register for notification of
  events supplied by other components (useful in
  monitoring, fault tolerance)
• New Queue Manager mediates among user (job
  submitter), Job Scheduler, and Process Manager
• Multiple monitoring components, both new and old
• Data warehouse

12
SSS Project Status Still More Individual
Component Prototypes

• New Process Manager component provides SSS
  interface to MPD scalable process manager
• Speaks XML through SSSlib to other SSS components
• Invokes MPD to implement SSS process management
  specification
• MPD itself is not an SSS component
• Allows MPD development, especially with respect
  to supporting MPI and MPI-2, to proceed
  independently
• SSS Process Manager abstract definitions have
  influenced addition of MPD functionality beyond
  what is needed to implement mpiexec from MPI-2
  standard
• E.g. separate environment variables for separate
  processes

13
Schematic of Process Management Component in
Scalable Systems Software Context
NSM
SD
Sched
EM
MPDs
SSS Components
QM
PM
PM
SSS XML
application processes
mpdrun
simple scripts or hairy GUIs using SSS XML
QMs job submission language
XML file
mpiexec
(MPI Standard args)
interactive
Prototype MPD-based implementation side
SSS side
Other managers could go here instead
14
Other Accomplishments

• APItest is a component test framework, capable of
  conducting unit tests on components
• Well-suited to complicated network such as this
  one
• Allows testing of one component at a time without
  testing all at once
• Used on SSS components this year
• SSS-OSCAR is a public, open-source release of the
  current state of the component system, tested for
  compatibility. (Get from web page)
• Tested subset of components on 5000-node cluster
  at NCSA
• SSS component architecture put into production on
  clusters at ORNL, PNNL, ANL (ANL story follows)

15
New Challenges on Chiba City

• Medium-sized, middle-aged cluster at Argonne
• Dedicated to computer science scalability
  research, not applications
• Also used by friendly, hungry applications
• New requirement support research requiring
  specialized kernels and alternate operating
  systems, for OS scalability research
• Want to schedule jobs that require node rebuilds
  (for new OSs, kernel module tests, virtual
  nodes, etc.) as part of normal job scheduling
• Requires major upgrade of Chiba City systems
  software

16
Chiba Commits to SSS

• Fork in the road
• Major overhaul of old, crufty, Chiba systems
  software (open PBS Maui scheduler homegrown
  stuff), OR
• Take leap forward and bet on all-new software
  architecture of SSS
• Problems with leaping approach
• SSS interfaces not finalized
• Some components dont yet use library (implement
  own protocols in open code, not encapsulated in
  library)
• Some components not fully functional yet
• Solutions to problems
• Collect components that are adequately functional
  and integrated (PM, SD, EM, BCM)
• Write stubs for other critical components
  (Sched, QM)
• Do without some components (CKPT, monitors,
  accounting) until ready

17
Features of Adopted Solution

• Stubs adequate, at least for time being
• Scheduler does FIFO reservations backfill,
  improving
• QM implements PBS compatibility mode (accepts
  user PBS scripts) as well as asking Process
  Manager to start parallel jobs directly
• Process Manager wraps MPD, as described above
• Single ring of daemons runs as root, managing all
  jobs for all users
• Daemonss started by Build-and-Config manager at
  boot time
• An MPI program called MPISH (MPI Shell) wraps
  user jobs for handling file staging and multiple
  job steps
• Python implementation of most components
• Each component lt 400 lines
• Demonstrates feasibility of using SSS component
  approach to systems software
• Running normal Chiba job mix for over six months
  now
• Only systems software on this machine
• Moving forward on meeting new requirements for
  research support

18
Lessons Learned This Approach Really Works!

• Components can use one anothers data
• Functionality only needs to be implemented once
• E.g., broadcast of messages
• Components are more robust, since they focus on
  one task
• Code volume shrinks because of less duplication
  of functionality
• Easy to add new functionality
• File staging
• MPISH
• Rich infrastructure on which to build new
  components
• Communication, logging, location services
• Need not be limited by existing subcomponents of
  existing systems
• Can replace just the functionality needed (get to
  solve the problem you want to solve, without
  re-implementing everything).
• E.g. having queue manager accept requests for
  rebuilt nodes before starting jobs.

19
Summary

• The Scalable Systems Software SciDAC project is
  addressing the problem of systems software for
  terascale systems.
• Component architecture for systems software
• Definitions of standard interfaces between
  components
• An infrastructure to support component
  implementations within this framework
• A set of component implementations, continuing to
  improve
• Prototype software suite released
• Experimental production use of the component
  architecture and some of the component
  implementations
• Encourages development of sharable tools and
  solutions
• Scalability testing under way
