Verification of Bakery algorithm variants for two processes

1
Verification of Bakery algorithm variants for two
processes
EUROCON 2003

• David Dedic
• Nova Vizija d.o.o.
• alec

Robert Meolic Faculty of EECS Maribor
2
Verification of Bakery algorithm variants for two
processes

• About our work on this project
• mutual exclusion algorithm
• formal verification by checking equivalence
  relations and model checking with ACTL
• free, open-source, written in
  Maribor
• About this presentation
• does formal verification have sense?
• an overview of our paper
• demonstration of EST under Windows

3
Formal verification of hardware
Source from Internet in 2001
4
Formal verification of software

• software is complex
• can something goes wrong? - the software will!
• a few words from Gerard J. Holzmann, author
  ofSPIN model checker Trends in software
  verification

The 12th International FME Symposium, Pisa,
Italy, September 8-14, 2003
5
What is wrong with software?

• term software crisis launched in 1968
• first we thought better education of programmers
  would solve it
• the we thought that better programming techniques
  would solve it
• then we thought that investing more money would
  solve it
• but, programming is a human activity, and humans
  can find ways to make mistakes in any context
• Source Gerard J. Holzmann

6
Software can be mastered!

• do software really get more complex faster than
  our ability to analyze it improves?
• 1968 OS/360 5 million lines of assembly
• 2003 Windows XP 64 million lines of C/C
• increase of 64 times (26) in 35 years
• Moore's curve 223 (gt 8 million x)
• and
• better algorithms
• software becomes easier to analyze
• Source Gerard J. Holzmann

7
Mutual exclusion algorithms
CS Critical Section
while (true) outsideCS()
wantToEnterCS(i) insideCS()
finishedInCS(i)
8
Wow, so many solutions!

• Dijkstras algorithm, 1965
• Dekkers algorithm, 1965
• Knuths algorithm, 1966
• Hymans algorithm, 1966
• Lamports bakery algorithm, 1974
• Petersons algorithm, 1981
• Fischers algorithm, 1985
• Lamports one-bit algorithm, 1986
• there are some more...

WRONG!
Real-time!
9
Bakery algorithm

• principle of serving customers at a bakery
• each process receives a ticket number
• the process with the lowest number enter CS

no relying on a lower-level mutual exclusion
there are some variants of the algorithm
10
Bakery algorithm
PROCESS Pi loop forever i0 ltnon-critical
sectiongt i1 Choosing(i) 1 i2
Number(i) 1 max(Number1,,NumberN) i3
Choosing(i) 0 for j in 1..N do
begin i4 loop exit
when Choosing(j) 0 end loop i5
loop con exit when
Number(j) 0 or Number(i) lt Number(j) or
(Number(i)
Number(j) and i lt j) end loop
end i6 ltcritical sectiongt i7
Number(i) 0 end loop
TICKET
compare it
11
Bakery algorithm for 2 processes
PROCES P1-BAKERY loop forever a0
ltnon-critical sectiongt a1 c1 1 a2 n1
n2 1 a3 c1 0 a4 loop
exit when c20 end loop a5
loop con1 exit when n20 or n1ltn2
end loop a6 ltcritical sectiongt a7 n1
0 end loop
PROCES P2-BAKERY loop forever b0
ltnon-critical sectiongt b1 c2 1 b2 n2
n1 1 b3 c2 0 b4 loop
exit when c10 end loop b5
loop con2 exit when n10 or n2ltn1
end loop b6 ltcritical sectiongt b7 n2
0 end loop
12
Three variants
PROCES P1-BAKERY loop forever a0
ltnon-critical sectiongt a1 c1 1 a2 n1
n2 1 a3 c1 0 a4 loop
exit when c20 end loop a5
loop con1 exit when n20 or
n1ltn2 end loop a6 ltcritical
sectiongt a7 n1 0 end loop
PROCES P1-BEN-ARI loop forever a0
ltnon-critical sectiongt a1 n1 1 a2 n1
n2 1 a5 loop con1 exit when
n20 or n1ltn2 end loop a6
ltcritical sectiongt a7 n1 0 end
loop
PROCES P1-STEP loop forever a0
ltnon-critical sectiongt a2 n1 n2
1 a5 loop con1 exit when
n20 or n1ltn2 end loop a6
ltcritical sectiongt a7 n1 0 end loop
13
Simple process algebra
Process P1-BAKERY
10 states / 12 transitions

• We also need other processes
• P2-BAKERY (11 st / 13 tr)
• NPLUS (9 st / 12 tr)
• N1 and N2 (3 st / 12 tr each)
• C1 and C2 (2 st / 6 tr each)

Composition of all processes218 states / 381
transitions
14
Testing equivalence

• describe the external behaviour with smaller and
  simpler process
• check if the composition and and the given
  process are testing equivalent

15
Model checking

• a popular verification method
• more interesting properties can be proved
• After process P1 intends to enter its critical
• section, process P2 can enter its critical
  section
• at most once before P1 does
• AG request1! NOT ENOT enter1! U
• enter2! ENOT enter1! U enter2!

TRUE for Bakery algorithm
16
Thank you!
