Best Practices and Techniques for Building Secure ASP.NET Applications

1
Best Practices and Techniques for Building Secure
ASP.NET Applications

• Patrick Hynds, CriticalSites
• MSDN Regional Director for Boston, MCSD, MCSEI,
  MCDBA, MCT, MCP Site Builder

2
Experience / Background

• Services
• Integration (Design, Best Practices)
• Development (Ecommerce, Commercial)
• Technology Consultant Coaching
• Notables
• Built 1st Windows logo certified .Net app
• Regularly present at
• TechEd US and TechEd Hong Kong
• .Net Users Groups worldwide (INETA Speaker)
• and many other international events
• Security Editor for .Net Developers Journal

3
Agenda

• Threat modeling
• Security Starting with IIS
• Beyond the Web Server
• Authentication
• Authorization
• Configuration settings
• Storing secrets
• Data validation

4
Internal Threats

• Disgruntled employee
• Bad faith business partner
• Human engineering
• Virus proliferation
• Credential reuse outside your org
• Improper configuration of security settings
• At home backups

5
External Threats

• Random script kiddie
• Slighted prospect
• Unscrupulous Competitor
• Zombie Army Enlistment
• Warez Hijacking
• Determined, Professional Attack
• Being first to get hit by a new exploit

6
Agenda

• Threat modeling
• Security Starting with IIS
• Beyond the Web Server
• Authentication
• Authorization
• Configuration settings
• Storing secrets
• Data validation

7
Anonymous Authentication

• Resource Access as anonyomous
• IUSR_Machinename (i.e. IUSR_Typhon)
• Process identity
• LocalSystem or
• IWAM_Machinename (i.e. IWAM_Typhon)
• Anonymous user is completely configurable

8
Basic Authentication

• Process identity IWAM or LocalSystem
• Resource access as authenticated user
• Pros
• Least common denominator
• All HTTP clients support basic auth
• Supports one hop delegation
• Cons
• Clear text password (Base64 Encoded)
• Over the wire
• On the server
• Needs to be protected via SSL

9
Digest Authentication

• Pros
• No clear text password over the wire
• Works through proxies
• Password is not known to IIS
• Cons
• Medium secure
• Internet Explorer 5 and higher
• No delegation
• Requires Active Directory
• Password in AD (reversible encryption)

10
Windows Integrated Authentication

• Security Support Provider (SSPI)-based
• NTLM or Kerberos
• IIS asks the client what protocol it supports
• Protocol can be enforced
• NTAuthenticationProviders
• Negotiate
• NTLM
• Kerberos

11
NTLM Authentication

• Pros
• Works out-of-the-box
• Provides automatic logon/no logon dialog box
• Cons
• Enterprise only does not work through Proxy
  Servers (keep-alive connection required)
• No delegation
• Configured to be compatible with older clients

12
Kerberos Authentication

• Strong, scalable, fast, supports delegation
• Limited client support
• Internet Explorer 5 and Windows 2000
• Issues
• DC has to be client accessible
• Service Principal Name
• Domain Administrator needs to be involved
• Delegation needs to be enabled
• Unconstrained!
• Setup
• Best description in designing secure Web-based
  applications

13
Client Certificate Authentication

• Pros
• Very secure
• Flexible
• Integrity, confidentiality
• Cons
• Higher management costs for PKI
• Usability
• Scalability and performance

14
Authentication Grid
Scheme Security Limitations/Comments Client Support Scenario
Anonymous None All All
Basic Low Clear Text Password, use only with SSL All All
Digest Medium IIS 5 and higher IE5 and higher in domain infrastructure All
NTLM Medium Doesnt work over proxies Internet Explorer only Only Intranet, doesnt work with Proxies
Kerberos High IIS 5.0 and higher IE 5 on W2000 or XP in domain infrastructure Only Intranet, DC needs to be accessible by the client
IIS Client Cert Mapping High PKI Management makes client certs expensive, IIS 5.0 and higher All newer browsers All
AD Client Cert Mapping Very High PKI Management makes client certs expensive, IIS 5.0 and higher All newer browsers All
15
Agenda

• Threat modeling
• Security Starting with IIS
• Beyond the Web Server
• Authentication
• Authorization
• Configuration settings
• Storing secrets
• Data validation

16
Windows Authentication

• Can be used in combination with Basic, NTLM,
  Digest, Kerberos, and so forth
• User is authenticated by IIS
• Easiest of all
• Request flow
• Client makes request
• IIS authenticates request, forwards to ASP.NET
• Impersonation turned on?
• ASP.NET returns response to client

17
Security Flow for a Request (ASP.NET)
18
Forms Authentication

• Uses cookie to authenticate
• Enables SSL for logon page
• Often used for personalization

19
Forms Authentication Flow
20
Forms Authentication Configuration

• Enable anonymous access in IIS
• Configure ltauthenticationgt section
• Set mode to Forms
• Add the ltformsgt section
• Configure ltauthorizationgt section
• Deny access to anonymous user
• Create logon page
• Validate the user
• Provide authentication cookie
• Redirect the user to the requested page

21
ltformsgt Section Attributes

• loginUrl unauthenticated request are redirected
  to this page
• name name of the authentication cookie
• path path of the authentication cookie
• protection All None Encryption Validation
• timeout authentication cookie expiration (min)

ltauthentication mode"Forms"gt ltforms
name".ASPXAUTH" loginUrl"login.aspx"
protection"All" timeout"30" path"/"
/gt lt/authenticationgt
22
demo
Forms Authentication
23
Authorization

• Process of determining whether a user is allowed
  to perform a requested action
• File-based authorization
• Performed by FileAuthorizationModule
• Performs checks against Windows ACLs
• Custom handle AuthorizeRequest event
• Application level (global.asax)
• HTTP module (implement IHttpModule)
• URL-based authorization
• Performed by UrlAuthorizationModule

24
Windows Users(Check Roles)

• If User.IsInRole("BUILTIN\Administrators") then
• Response.Write("You are an Admin")
• Else If User.IsInRole("BUILTIN\Users") then
• Response.Write("You are a User")
• Else
• Response.Write("Invalid user")
• End if

25
Non-Windows Users(Attach Roles)

• Handle AuthenticateRequest event
• Create GenericPrinciple
• Attach roles to Identity
• Assign new Principle to User

Sub Application_AuthenticateRequest(s As Object,
e As EventArgs) If Not (User Is Nothing) Then
If User.Identity.AuthenticationType
"Forms" Then Dim Roles(1) As String
Roles(0) "Admin" User new
GenericPrinciple(User.Identity,Roles) End
If End If End Sub
26
Non-Windows Users (Check Roles)

• if User.IsInRole("Admin") then
• Response.Write ("You are an Administrator")
• Else
• Response.Write ("You do not have any role
  assigned")
• End if

27
demo
Custom Authentication with Roles
28
Configuration Settings

• Review production configuration
• ltcustomErrorsgt RemoteOnly or On
• Make sure that verbose remote errors are not
  enabled
• Do not reveal exception details in custom error
  pages
• ltcompilationgt disable debugging
• Review IIS scriptmaps
• Only enable ones you need
• Use IIS lockdown (Windows 2000/IIS 5)
• Shared servers
• Use configuration lockdown
• ltlocation allowOverridefalse/gt
• Isolate by process (IIS 6) and/or with lttrustgt
  level

29
Machine.Config

• Some settings vary by .Net Framework version
• HTTPGet
• HTTPPost
• HTTPSoap

30
demo
Machine.Config for Security
31
Accounts

• Administrator
• Deception planning against hackers
• Service Accounts

32
Storing Secrets

• Do avoid secrets when you can
• Consider using integrated authentication
• Use layered protection when you need secrets
• Access control settings
• Data Protection API (DPAPI)
• Use aspnet_setreg for ASP.NET secrets
• ltprocessModelgt, ltidentitygt, ltsessionStategt
• http//support.microsoft.com/default.aspx?scidkb
  EN-US329290

33
demo
Random Salt in the DB
34
Data Validation

• Validate all input data
• Use ASP.NET validation controls
• Use regular expressions for other cases (e.g.,
  web service parameters)
• Use parameterized stored procedures or queries
  for data access to prevent SQL Injection

35
The Future / Whidbey

• Indigo
• NGSCB (Next Generation Secure Computing Base)
• Dynamic Compilation Switch
• New Login controls

36
Summary

• Security is a war! Dont fight fair.
• Defense in Layers
• Not a part time job or nice to have feature
  anymore
• Make Security part of every aspect of your
  projects
• should be about 12 of effort per project

37
Resources

• How ASP Security Works
• An overview of ASP Security http//msdn.microsoft.
  com/library/dotnet/cpguide/cpconhowaspnetsecurityw
  orks.htm
• Key Concepts in Application Security
• A basic review of the major components needed to
  secure applications http//msdn.microsoft.com/lib
  rary/dotnet/cpguide/cpconkeyconceptsinsecurity.htm

38
Questions
