A Quick Intro to Java for C and C Programmers

1
A Quick Intro to Java for C and C Programmers

• Scott Hudson
• HCI 631
• Fall 1999

2
About this lecture

• Will be assuming you are a fluent C or C
  programmer.
• This is going to be a quick introduction to the
  language.
• I'm not going to teach anything much about
  object-oriented programming.

3
What is Java

• Java is a programming language designed by James
  Gosling at Sun
• Designed to be "squirted" across a network into a
  device, the primary device right now being a web
  browser
• Interpreted from byte codes (virtual machine
  approach)
• Dynamically loaded
• gt very portable (except...)

4
What is Java

• "A pretty good object oriented language with C
  camouflage on"
• Once was "The latest thing" and massively hyped

5
Why was there hype about Java?

• At the right place at the right time (fills
  important need on the web)
• Highly portable
• Seen by lots of companies as a way to break the
  Microsoft monopoly
• gt huge amounts of money involved
• gt major corporate politics/warfare (Sun
  Netscape vs. Microsoft)

6
Beyond the Hype

• Not much fundamentally new here
• we have seen almost all the concepts in other
  languages before
• But, its fairly well designed
• more than can be said for a lot of things
• Its better than C for many/most uses
• It was built by someone who knew the "landscape"
  of programming languages and has some taste

7
Beyond the hype

• In my opinion its the best current language with
  wide platform support (backing of many solid
  implementations)

8
Goals

• Downloadable into a wide range of
  devices/platforms
• Good OO language to replace C
• Relatively small/simple/clean language
• Camouflaged as C for sneak attack when C was
  the dominant language
• C programmers will feel at home
• Lots of checking and safety

9
Major differences from C

• Generally simplified
• No pointers
• Actually everything is a pointer (reference), but
  their are no dangling pointers!
• No pointer dereferencing (where you used to say
  "-gt" you now always use ".")
• Garbage collection added
• Big big win

10
What's been added from C (all in C)

• O-O concepts information hiding
• Stronger typing
• Real constants (not just macros)
• Overloading (two functions with the same name,
  but different parameter types)
• New comment style ("//" to eol)

11
What's been added beyond C

• More checking
• Exceptions (they were in C, but..)
• (Limited) signature based typing ("interfaces" --
  a big win)
• Runtime type identification (plus other
  reflection capabilities)
• Built in threads and synchronization

12
What's been added beyond C (cont.)

• Packages (collections of classes in a namespace)
• Dynamic runtime loading
• Strings (as objects)
• A root class (Object)
• Unicode characters (16 bit chars)
• 64 bit longs, bytes, booleans
• (literals true and false)

13
What's been added beyond C (cont.)

• A (small) container library (hashtables, etc.)
• Special "doc" comments / ... /
  post-processing to produce hyperlinked API
  documentation
• html special _at_directives in the comments

14
Things that are missing (but we probably won't
miss)

• Virtual functions (everything is virtual!)
• Virtual base classes
• Virtual destructors
• Implicit constructor invocation (and other
  constructor/destructor weirdness)

15
Things that are missing (but we probably won't
miss)

• Arcane type conversion rules (and generally loose
  typing)
• 16 different meanings for const
• extern (now have strong load-time checking)
• -gt operator (member pointers)
• (scope operator)

16
Things that are missing (but we probably won't
miss)

• void
• Null terminated strings
• Declaration vs. definition (always done together,
  need not declare before use)
• (Brain dead) multiple inheritance
• Templates

17
Things that are missing (but we probably won't
miss)

• Operator functions
• Macros, include files, and conditional
  compilation (the preprocessor)

18
Other things that are missing (that we might
miss)

• Independent functions
• Pointers to functions
• Default parameters
• Unsigned types
• Bare metal performance(?)

19
So is it too slow?

• Can get roughly 4x of C code performance (on
  many things you care about) using JIT compilers
• Plenty fast for interactive apps
• Spend a lot of time in native drawing code anyway
• Faster development time gt more optimization time
  gt faster code!

20
More details on differences with C Lexical
level

• Designed to look almost exactly like C (which
  is almost identical to C)
• Minor differences, but not worth mentioning

21
More details on differences with C Syntactic
level

• Designed to look a lot like C
• which was designed as a superset of C
• but cleaned up most egregious parts
• Changes
• inheritance syntax
• initialization in constructors
• split definition vs. declaration (and scope
  operator)
• protection declaration

22
More details on differences with CControl Flow

• All C/C flow control constructs except goto
• added labeled break and continue to handle the
  few remaining legit uses
• if/else for while do/while switch/case/break
• return break continue
• throw try/catch/finally to support exceptions

23
More details on differences with CControl Flow
(cont.)

• Now have real booleans
• can't test integers and pointers directly
• "if (ptr)" must be "if (ptr ! null)"

24
Classes

• The major construct in Java (like most object
  oriented languages) is the class.
• Classes are a type definition They define the
  data and operations of an object.
• You can create several instances of objects
  several things with that data and those
  operations

25
Classes

• For C programmers you can think of this for now
  as a struct with the functions operating on the
  struct "inside" the struct.
• For C programmers you can think of this as a
  class.

26
class point_list int x int y
point_list next double distance_to(point_list
other) double dx, dy
dx (double)(x - other.x) dy
(double)(y - other.y) return
Math.sqrt(dxdx dydy) double
distance_to_next() if (next
null) return 0 else
return distance_to(next)
27
What have we got here.

• Three instance variables
• C fields
• Two methods
• C member functions
• Note There are no functions in Java, just
  methods (notice that we had to say Math.sqrt() to
  get a square root).

28
What have we got here.

• If we had two points pt1 and pt2, then we could
  compute the distance between them as
• pt1.distance_to(pt2)
• Except... we have some problems here what are
  they? (p, v, c, after)

29
Problem 1 self containment

• Looks like a point_list contains a point_list
• class point_list ...
• point_list next
• But, recall everything is a pointer, so this is a
  pointer (reference) to a point_list, so we are ok

30
Like C Two forms of data primitive and objects

• Primitive types
• byte 8 bit signed integer
• short 16 bit signed integer
• int 32 bit signed integer
• long 64 bit signed integer
• boolean true of false
• char 16 bit unicode character
• float single precision
• double double precision

31
If its not a primitive its an object

• Note this includes strings arrays
• Declaring instance variables of object types
  actually declares references to objects of that
  class
• null is a possible value
• need to be initialized to refer to object
• Referenced with . instead of -gt
• (back to problems)

32
Problem 2 Visibility

• Classes also provide information hiding and the
  default is to not allow full access to instance
  variables or methods.
• So a better version would be...

33
public class point_list protected int x
protected int y protected point_list next
public double distance_to(point_list other)
double dx, dy dx
(double)(x - other.x) dy (double)(y
- other.y) return Math.sqrt(dxdx
dydy) public double
distance_to_next() if (next
null) return 0 else
return distance_to(next)
34
Specifying protection Members can be

• public
• protected
• private
• ltunlabeledgt

• Accessible to all
• Accessible to classes within the same package and
  subclasses
• Accessible only within the class itself
• Inside package protected
• Outside package private
• (no subclass access outside package).

35
Specifying protection Classes can be

• public, unlabeled, or private
• Almost all classes are public (anybody can use
  them)
• Can have private or local classes
• only accessible in package
• rare
• can protect constructors instead

36
Point of style

• Its a good idea for all but the simplest classes
  to not have any public instance variables.
• Instead have a protected variable with read and
  write access methods.
• This lets you change your mind later without
  breaking all the code that uses yours.


37
Point of style

• protected int _x
• public int x() return _x
• public void set_x(int val)
• _x val
• Seems tedious, but
• This has saved my sorry butt many times!
  (back to problems)

38
Problem 3 no constructor

• Haven't provided a way to create any useful
  objects of this type
• Java initializes instance variables
• int et al. 0
• boolean false
• float, double 0.0
• char \0
• Object null

39
Initialization

• You can also explicitly initialize instance vars
• protected int x 0

  protected int y 0
  protected point_list
  next null

40
Declaring constructors

• Typically, you want provide a constructor.
• If you don't provide a constructor, one (that
  does nothing and takes no parameters) will be
  provided for you.
• Constructor looks like a method with the same
  name as the class but no return type

41
Declaring constructors

• public point_list(
• int xv,
• int yv,
• point_list nxt)
• x xv y yv next nxt

42
Declaring multiple constructors

• Often want to provide several constructors
• Java does not do default parameters
• public point_list(int xv, int yv)
• this(xv,yv, null)
• public point_list()
• this(0,0)

43
Declaring multiple constructors

• Notice that we can "chain" constructors together
  using "this()".
• We can also invoke the super class constructor
  using "super()".
• Must be the first thing in the constructor.
• (back to problems)

44
Some misc. basics

• All parameters are pass-by-value.
• However, for all object types we are passing
  references by values, so...
• Can return at most one value.
• Arithmetic, etc. operations (precedence, etc.)
  are the same as C/C, except...

45
Some misc. basics

• Arithmetic, etc. operations are the same as
  C/C, except...
• Use of comma operator is limited to for
  statements.
• Can apply bitwise operations to booleans (but not
  mixed int/boolean) to get non-shortcutting
  operations.
• and ! mean "refer to the same object".

46
Some misc. basics

• Like C can declare variables anywhere a
  statement is legal
• including inside parens of for statements
• Same scoping rules
• scope limited to enclosing block ...
• Don't have to declare before use.

47
Hierarchical Types and Inheritance

• The big wins in object-oriented programming come
  from hierarchical typing and inheritance.

48
Hierarchical Types and Inheritance

• Two things of importance
• Inheritance the ability to derive the
  implementation of something from some existing
  code (AKA getting someone else to do the work for
  you).
• Substitutability the ability to write code that
  doesn't care about exactly what type it operates
  over (so you can substitute related but different
  types).

49
Inheritance

• In Java (like most OO languages) you can base the
  implementation of a class on another class.
• Basically, you take what is in the other class
  (the base or superclass) and then extend it to do
  new and/or different things.
• The new class (the derived class or subclass)
  preserves the API of the superclass

50
Inheritance

• The new class preserves the API of the superclass
• so it does everything the superclass did
• Consequently, an instance of a subclass can be
  substituted for an instance of a superclass
• a variable that references the superclass can
  safely be used to reference the subclass

51
Declaring inheritance in class declarations

• Suppose we wanted to create a colored_point_list
  which keeps a color value with each point...

52
Declaring inheritance

• public class colored_point_list
  extends point_list
• protected Color _pt_color
• public Color pt_color() return _pt_color
• public void set_pt_color(Color val)
  _pt_color val
• public colored_point_list(
• int xv, int yv, point_list nxt, Color clr)
• super(xv,yv,nxt)
• set_color(clr)

53
Declaring inheritance

• Note the extends clause
• Gives the base class we are derived from
• If there is no extends clause we automatically
  inherit from Object (the Java root class).
• Java only supports single inheritance, so you
  only get to list one thing.

54
Declaring inheritance

• Note also that we call the superclass constructor
  (might as well let them do the work here) using
  the special form
• "super(...)"
• Like "this()" this must be the first thing in the
  constructor.

55
Get substitutability

• If we have a piece of code which declares a
  variable of type point_list, we can safely let it
  operate on an object of type colored_point_list.

56
Another (different) use of Super

• Can use super to refer to a method in the
  superclass that has been overridden by the
  subclass
• public class grid8_point_list extends point_list

• public void set_x(int val)
• int rounded (val / 8)8 ((val8 gt
  4)?10)
• super.set_x(rounded)
• ...

57
Notes on this example

• public class grid8_point_list extends point_list

• public void set_x(int val)
• int rounded (val / 8)8 ((val8 gt
  4)?10)
• super.set_x(rounded)
• ...
• Boy its a good thing we put that set_x() in
  there
• We call set_x() dont set x directly

58
This

• Sometimes you need to refer to the object itself
  in one of its methods (pass it somewhere).
• Reserved word this is used for this purpose. As
  in
• manager.put_in_table(this)
• Note that instance variable references such as
  "_x" above are really shorthand for "this._x".

59
Abstract classes

• Its not necessary to completely define a class
• This is useful to define the API to something
  without requiring a particular implementation
  (see also interfaces).
• This is useful also if you have a lot of common
  functionality to put in a base class but details
  (i.e., implementation of particular methods) have
  to be provided by various subclasses.

60
Abstract classes

• (Must) declare the class "abstract"
• Declare each missing method abstract and put a
  semicolon where the body would be.
• abstract public class stack
• abstract public void push(Object obj)
• abstract public Object pop()
• abstract public boolean empty()

61
Abstract classes

• Can't instantiate an abstract class (but can
  declare variables).

62
Interfaces

• Syntactically an interface declaration looks a
  lot like a class declaration (replace "class"
  with "interface").
• But, no variables and methods don't have bodies.
• Basically interfaces define an API, but no
  implementation

63
Interfaces

• Interfaces are used as a "promise".
• Class can say "implementsinterface_name" after
  extends clause
• This means that the class promises to implement
  the API of the interface.
• It doesn't say anything about how its going to do
  it, just that it will
• The compiler checks that it does.

64
Interfaces

• Can inherit from (implement) multiple
  interfaces.

65
Substitutability for interfaces

• Can declare variables and parameters with
  interface types
• Variable can then refer to object of any type
  that implements the interface
• Has promised to implement the API ( compiler has
  checked) so this is completely type safe!
• Gives you a lot of flexibility to reimplement,
  etc.
• Advice use this whenever you can

66
Packages

• Classes are organized into collections of related
  things
• what constitutes one package is entirely up to
  you.
• Each source file belongs to a particular package
• listed at the top with the package declaration
  package sub_arctic.lib

67
Packages

• Note its possible to leave the package
  declaration out which indicates the special
  "unnamed package
• don't do this! it just gets confusing to everyone
  concerned

68
Packages

• Package names have multiple parts (subpackages)
  separated by "."
• java.awt and java.awt.image
• But, these don't have a special relationship
  between them
• Packages are primarily to segregate the name
  space
• class names must be unique within the package,
  but not across all packages

69
Packages

• Also have an effect on protection rules
• recall protected members can be accessed by
  classes in same package

70
Imports

• You can use package names to disambiguate types.
• Recall we had an example that used the class
  Color.
• Comes from the library package java.awt and its
  full name is java.awt.Color.
• If you get tired of writing out the full name,
  you can "import" the class import
  java.awt.Color

71
Imports

• If you get two classes with the same name from
  different packages you use full names to
  disambiguate.
• Since compiler knows how to find packages, this
  eliminates the need for includes
• you can also import from compiled code without
  the source!)

72
Packages

• java.lang. is imported automatically.

73
Static members

• Instance variables belong to (have a copy in)
  each instance.
• Can also declare variables that belong to the
  whole class.
• Do this with static
• class a_class
• protected static int count 0
• public a_class() count

74
Static members

• There is only one copy of the static variable
• belongs to the class (shared by all instances).
• You can also have static methods.
• These can be invoked without an instance (using
  the class name) Math.sqrt(3.1415d)

75
Initialization of statics

• You can use conventional initializers (after )
• Executed when the class is loaded
• Also have special static initialization blocks
  (outside of methods)
• static ... some code ...
• Also executed when class is loaded
• Java loader takes care of loading classes you
  depend on first

76
Final members

• You can declare classes, methods, and variables
  final.
• For variables this means they can't be assigned
  to after initialization (AKA constants)
• public static final double PI2 Math.PIMath.PI
• For methods, this means you cannot override the
  method in subclasses.
• For classes this means all the methods are final.

77
Final members

• You can declare final variables in interfaces
• Java idiom to collect a bunch of reusable
  constants together put them in an interface and
  "implement" them in the classes where they are
  used.

78
Strings

• In Java, strings are objects of class String
• not array's of char, although there are
  operations to get back and forth
• Special literal e.g "abc" represents a String
  object.
• Character escapes such as \n similar to C.

79
Strings

• Strings are immutable
• operations create new strings, don't modify
  existing ones.
• "" is used for string concatenation, and is
  treated specially
• Any with at least one String operand is treated
  as string concatenation
• The other operand is converted to a string (this
  also works for String parameters)

80
Conversion to Strings

• For primitive types there is a standard (and
  obvious) conversion
• For Objects, the toString() method is called
• Object provides one (prints class name and unique
  id)
• Or you can override

81
Arrays

• Arrays are also objects in Java
• Can declare as "int foo" or "int foo"
• both declare a variable which refers to an array
  of ints (initialized to null)

82
Arrays

• Array size is not part of the type
• that gets established by the instance
• int foo new int52
• ...
• foo new int42
• Each array object has a read-only field length
• foo.length 42

83
Arrays

• Note that arrays are collections of Object
  references.
• All set to null by default.
• Can initialize arrays to refer to particular
  object with special form similar to C/C
• init foo 3, 5, 9
• Object bar "one", new Stack(), new
  Integer()

84
Array types

• Arrays are hierarchically typed
• If sub is a subclass of base then sub is a
  subclass of base
• So you could have
• base base_var new sub42

85
Checking types at runtime

• Can determine if an object qualifies as a
  particular type at runtime using expression "obj
  instanceof aclass"
• "null instanceof aclass" is always false.

86
Checking and converting types at runtime

• Can convert to a sub- or super-class with a C
  style cast expression "(aclass)expr"
• Does runtime type check and throws an exception
  if this is not a legal conversion (i.e., object
  being cast is not of that type or a subclass
  thereof).

87
Output to stdout

• java.lang.System has lots of useful stuff for
  accessing the local environment including
• System.out, System.err, and System.in (for
  stdout, stderr, and stdin).
• Two operations of particular interest
  System.out.print() and System.out.println() print
  anything convertible to a string with or without
  a newline.

88
Threads

• Threads are built into the language
• Concurrent threads can greatly simplify program
  structure and design for a number of things
• They also make testing and debugging nearly
  impossible
• So unless your programs all work without testing
  (and/or there is no reasonable way around it), I
  advise Just say no!

89
Threads

• They also make testing and debugging nearly
  impossible
• So unless your programs all work without testing
  (and/or there is no reasonable way around it), I
  advise Just say no!

90
Good luck...

• ... and, as always, if you or any of your
  programming team are caught or killed, I will
  disavow that I ever taught you anything about
  Java.

91
(No Transcript)
