CSCI 548/B480: Introduction to Bioinformatics Fall 2002

1
CSCI 548/B480 Introduction to
BioinformaticsFall 2002
Topic 5 Machine Intelligence - Learning and
Evolution

• Dr. Jeffrey Huang, Assistant Professor
• Department of Computer and Information Science,
  IUPUI
• E-mail huang_at_cs.iupui.edu

2
Machine Intelligence

• Machine Learning
• The subfield of AI concerned with intelligent
  systems that learn.
• The computational study of algorithms that
  improve performance based on experience.
• The attempt to build intelligent entities
• We must understand intelligent entities first
• Computational Brain
• Mathematics
• Philosophy staked most of the ideas of AI but to
  make it a formal science the mathematical
  formalization is needed in
• Computation
• Logic
• Probability

3
Behavior-Based AI vs. Knowledge Based

• Definitions of Machine Learning
• Reasoning
• The effort to make computers think and solve
  problem
• The study of mental faculties through the use of
  computational models
• Behavior
• Make machines to perform human actions requiring
  intelligence
• Seeks to explain intelligent behavior in terms of
  computational processes
• Agents

4
Operational Agents

• Operational Views of Intelligence
• The ability to perform intellectual tasks
• Prove theorems, play chess, solve puzzle
• Focus on what goes on between the ears
• Emphasize the ability to build and effectively
  use mental models
• The ability to perform intellectually challenging
  real world tasks
• Medical diagnosis, tax advising, financial
  investing
• Introduce new issues such as critical
  interactions with the world, model grounding,
  uncertainty
• The ability to survive, adapt, and function in a
  constantly changing world
• Autonomous agents
• Vision, locomotion, and manipulation, many I/O
  issues
• Self-assessment, learning, curiosity, etc.

5
Building Intelligent Artifacts

• Symbolic Approaches
• Construct goal-oriented symbol manipulation
  systems
• Focus on high end abstract thinking
• Non-symbolic approaches
• Build performance-oriented systems
• Focus on behavior
• Need both in tightly coupled form
• Difficult in building such systems
• Growing need to automate this process
• Good approach Evolutionary Algorithms

6

• Behavior-Based AI
• Behavior-Based AI vs. Knowledge-Based
• "Situated" in environment
• Multiple competencies ('routines')
• Autonomy
• Adaptation and Competition
• Artificial Life (A-Life)
• Agents Reactive Behavior
• Abstracting the logical principles of living
  organism
• Collective Behavior Competition and Cooperation

7
Classification vs. Prediction

• Classification
• predicts categorical class labels
• classifies data (constructs a model) based on the
  training set and the values (class labels) in a
  classifying attribute and uses it in classifying
  new data
• Prediction
• models continuous-valued functions, i.e.,
  predicts unknown or missing values

8
ClassificationA Two-Step Process

• Model construction describing a set of
  predetermined classes
• Each tuple/sample is assumed to belong to a
  predefined class, as determined by the class
  label attribute
• The set of tuples used for model construction
  training set
• The model is represented as classification rules,
  decision trees, or mathematical formulae
• Model usage for classifying future or unknown
  objects
• Estimate accuracy of the model
• The known label of test sample is compared with
  the classified result from the model
• Accuracy rate is the percentage of test set
  samples that are correctly classified by the
  model
• Test set is independent of training set,
  otherwise over-fitting will occur

9
Classification Process
Model Construction
Classification Algorithms
IF rank professor OR years gt 6 THEN tenured
yes
Use the Model in Prediction
(Jeff, Professor, 2)
Tenured?
10
Supervised vs. Unsupervised Learning

• Supervised learning (classification)
• Supervision The training data (observations,
  measurements, etc.) are accompanied by labels
  indicating the class of the observations
• New data is classified based on the training set
• Unsupervised learning (clustering)
• The class labels of training data is unknown
• Given a set of measurements, observations, etc.
  with the aim of establishing the existence of
  classes or clusters in the data

11
Classification and Prediction

• Data Preparation
• Data cleaning
• Preprocess data in order to reduce noise and
  handle missing values
• Relevance analysis (feature selection)
• Remove the irrelevant or redundant attributes
• Data transformation
• Generalize and/or normalize data
• Evaluating Classification Methods
• Predictive accuracy
• Speed and scalability
• time to construct the model
• time to use the model
• Robustness handling noise and missing values
• Scalability efficiency in disk-resident
  databases
• Interpretability understanding and insight
  provided by the model
• Goodness of rules
• decision tree size
• compactness of classification rules

12
From Learning to Evolutionary

• Optimization
• Accomplishing abstract task Solving problem
• searching through a space of potential
  solution
• finding the best solution
• ? an optimization process
• Classical Exhaustive Methods??
• Large Space?? Special machine learning technique
• Evolution Algorithms
• Stochastic Algorithms
• Search methods model some phenomena
• Genetic Inheritance
• Darwinian strife for survival

13

• the metaphor underlying genetic algorithms is
  that of natural evolution. In evolution, the
  problem each species faces is one of searching
  for beneficial adaptations to a complicated and
  changing environment. The knowledge that each
  species has gained is embodied in the makeup of
  chromosomes of its members
• - L. David and M. Steenstrup, Genetic Algorithms
  and Simulated Annealing, pp. 1-11, Kaufmann,
  1987

14
The Essence Components

• Genetic representation for potential solutions to
  the problem
• A way to create an Initial population of
  potential solutions
• An evaluation function that plays the ole of the
  environment, rating solutions in term of their
  fitness
• i.e. the use of fitness to determine survival
  and reproductive rates
• Genetic operators that alter the composition of
  children

15
Evolutionary Algorithm Search Procedure
16
Historical Background

• Three paradigms emerged in the 1960s
• Genetic Algorithms
• Introduced by Holland (MSU) ? De Jong (GMU)
• Envisioned for broad range of adaptive systems
• Evolution Strategies
• Introduced by Rechenberg
• Focused on real-valued parameter optimization
• Evolutionary Programming
• Introduced by Fogel and Koza
• Applied to AI and machine learning problem
• Today
• Wide variety of evolutionary algorithms
• Applied to many area of science and engineering

17
Examples of Evolutionary AI

• Parameter Tuning
• Pervasiveness of parameterized models
• Complex behavioral changes due to non-linear
  interactions
• Example
• Weights of an Artificial Neural networks
• Parameters of a heuristic evolution function
• Parameter of a rule induction system
• Parameter of membership functions
• Goal evolve over time useful set of discrete/
  continuous parameter

18

• Evolving Structure
• Effect behavior change via more complex
  structures
• Example
• Selecting/constructing the topology of ANNs
• Selecting/constructing the feature sets
• Selecting/constructing plans/scenarios
• Selecting/constructing membership functions
• Goal evolve useful structure over time
• Evolving Programs
• Goal acquire new behaviors and adapt existing
  ones
• Example
• Acquire/adapt behavioral rules sets
• Acquire/adapt arm/joint control programs
• Acquire/adapt task-oriented programming code

19
How Does Genetic Algorithm Work?

• A simple example of function optimization
• Find max f(x)x2, for x? 0, 4
• Representation
• Genotype (chromosome) internally points in the
  search space are represented as (binary) string
  over some alphabet
• Phenotype the expressed traits of an individual
• With a precision for x in 0,4 of 10-4 it
  needs14 bits
• 8,000 ? 213 lt 10,000 lt 214 ? 16,000
• Simple fixed length binary
• Assigned 0.0 to the string 00 0000 0000 0000
• Assign 0.0 bin2dec(binary string)4/(214 -1)
• the string 00 0000 0000 0001 and so on
• Phenotype 4.0 genotype 11 1111 1111 1111

20
00000000000000 00000000000001 11111111111111
0.0 4/(214 -1) 4.0
genotype
Phenotype

• Initial population
• Create a population (pop_size) of chromosomes,
  where each chromosome is a binary vector of 14
  bits
• All 14 bits for each chromosome are initialized
  randomly
• Evaluation function
• Evaluation function eval for binary vectors v is
  equal to the function f
• eval(v) f(x)
• ex eval(v1) f(x1) fitness1

21

• Parameters
• pop_size 24,
• Prob. of Xover, pc 0.6,
• Prob. of mutation, pm 0.01
• Recombination using genetic operations
• Crossover (pc)
• v1 01111100010011 gt v1 01110101011100
• v2 00010101011100 gt v2 00011100010011
• Mutation (pm)
• v2 00011100010011 gt v2 00011110010011

22

• Selection M(t) from M(t1) using roulette wheel
• Total fitness of the population
• Probability of selection probi for each
  chromosome vi
• Cumulative prob qi
• Generate random numbers rj, from 0,1, where j
  1pop_size
• Select chromosome vi such that qi-1 lt rj lt qi

23
(No Transcript)
24
Homing to the Optimal Solution
25
Best-so-far Curve
26
Optimal Feature Subset

• Search for the Subsets of Discriminatory Features
• Combination optimization problem
• Two general approaches to identifying optimal
  subsets of features
• Abstract measurement for important properties of
  good feature sets
• Orthogonality (ex. PCA), information content, low
  variance
• Less expensive process
• Fall in suboptimal performance if the abstract
  measures do not correlate well with actual
  performance
• Building a classifier from the feature subset and
  evaluating its performance on actual
  classification tasks.
• Better classification performance
• the cost of building and testing classifiers
  prohibits any kind of systematic evaluation of
  feature subsets
• suboptimal in practice large numbers of
  candidate features cannot be handled by any form
  of systematic search
• 2N possible candidate subsets of N features.

27
Inductive Learning

• Learning From Examples
• Decision Tree (DT)
• Information Theory (IT)
• Question what are the BEST attributes
  (Features) for building the decision tree?
• Answer BEST attribute is the one that it is
  MOST informative and for whom
  ambiguity/uncertainty is least
• Solution Measure (information) contents using
  the expected amount of information provided by
  the attribute

28
Classification by Decision Tree Induction

• Decision tree
• A flow-chart-like tree structure
• Internal node denotes a test on an attribute
• Branch represents an outcome of the test
• Leaf nodes represent class labels or class
• distribution
• Decision tree generation consists of two phases
• Tree construction
• At start, all the training examples are at the
  root
• Partition examples recursively based on selected
  attributes
• Tree pruning
• Identify and remove branches that reflect noise
  or outliers
• Use of decision tree Classifying an unknown
  sample
• Test the attribute values of the sample against
  the decision tree

Exs. Class Size Color Surface
1 A Small Yellow Smooth
2 A Medium Red Smooth
3 A Medium Red Smooth
4 A Big Red Rough
5 B Medium Yellow Smooth
6 B Medium Yellow Smooth
29

• Entropy
• Define an entropy function H such that
• where pi the probability associated with ith
  class
• For a feature, the entropy is calculated for each
  value.
• The sum of the entropy weighted by the
  probability of each value is the entropy for that
  feature
• Example Toss a fair coin
• if the coin is not fair, i.e. Pheads 99,
  then
• So, by tossing the coin you get very little
  (extra) information (that you didnt expect)

30

• In general, if you have p positive examples, and
  n negative examples
• For p n ? H 1
• i.e. originally there is most uncertainty on the
  eventual outcome (picking up an example) and most
  to gain by picking the example.

31
Decision Tree Induction

• Basic algorithm (a greedy algorithm)
• Tree is constructed in a top-down recursive
  divide-and-conquer manner
• At start, all the training examples are at the
  root
• Attributes are categorical (if continuous-valued,
  they are discretized in advance)
• Examples are partitioned recursively based on
  selected attributes
• Test attributes are selected on the basis of a
  heuristic or statistical measure (e.g.,
  information gain)
• Conditions for stopping partitioning
• All samples for a given node belong to the same
  class
• There are no remaining attributes for further
  partitioning
• Majority voting is employed for classifying the
  leaf
• There are no samples left

32
Algorithm

• Select a random subset W (called the window) from
  the training set T
• Build a DT for the current W
• Select the best feature which minimizes the
  entropy H (or max. gain)
• Categorize training instances (examples) into
  subsets by this feature
• Repeat this process recursively until each subset
  contains instances of one kind (class) or some
  statistical criterion is satisfied
• Scan the entire training set for exceptions to
  the DT
• If exceptions are found insert some of them into
  W and repeat from step 2

33

• Information Gain
• The information gain from the ? attribute test is
  defined as the difference between the original
  information requirement and the new requirement
• Note that the Remainder(?) is an weighted (by
  attribute values) entropy function
• Maximize Gain(?) ? Minimize Remainder(?) and
  then ? is the most informative attribute
  (question)

34
The ID3 Algorithm and Quinlans C4.5

• C4.5
• Tutorial http//yoda.cis.temple.edu8080/UGAIWWW/
  lectures/C45/
• Matlab program http//www.cs.wisc.edu/olvi/uwmp/
  msmt.html
• See 5/ C5.0
• Tutorial http//borba.ncc.up.pt/niaad/Software/c5
  0/c50manual.html
• Software for Win2000 http//www.rulequest.com/dow
  nload.html

35
Exs. Class Size Color Surface
1 A Small Yellow Smooth
2 A Medium Red Smooth
3 A Medium Red Smooth
4 A Big Red Rough
5 B Medium Yellow Smooth
6 B Medium Yellow Smooth

• Example

36

• Noise and Overfitting
• Question what about two or more examples with
  the same description but different
  classifications?
• Answer Each leaf node reports either MAJORITY
  classification or relative frequencies
• Question what about irrelevant attributes (noise
  and overfitting)?
• Answer Tree pruning
• Solution An information gain close to zero is a
  good clue to irrelevance, actual number of ()
  and (-) exs. In each subset i, pi and ni vs.
  expected numbers pi and ni assuming true
  irrelevance
• Where p and n are the total number of positive
  and negative exs to start with.
• Total deviation (regarding statistical
  significant)
• Under the null hypothesis, D chi-squared
  distribution

37
Extracting Classification Rules from Trees

• Represent the knowledge in the form of IF-THEN
  rules
• One rule is created for each path from the root
  to a leaf
• Each attribute-value pair along a path forms a
  conjunction
• The leaf node holds the class prediction
• Rules are easier for humans to understand
• Example
• IF age lt30 AND student no THEN
  buys_computer no
• IF age lt30 AND student yes THEN
  buys_computer yes
• IF age 3140 THEN buys_computer yes
• IF age gt40 AND credit_rating excellent
  THEN buys_computer yes
• IF age gt40 AND credit_rating fair THEN
  buys_computer no

38
Decision Tree

• Avoid Overfitting in Classification
• The generated tree may overfit the training data
• Too many branches, some may reflect anomalies due
  to noise or outliers
• Result is in poor accuracy for unseen samples
• Two approaches to avoid overfitting
• Prepruning Halt tree construction earlydo not
  split a node if this would result in the goodness
  measure falling below a threshold
• Difficult to choose an appropriate threshold
• Postpruning Remove branches from a fully grown
  treeget a sequence of progressively pruned trees
• Use a set of data different from the training
  data to decide which is the best pruned tree

39

• Approaches to Determine the Final Tree Size
• Separate training (2/3) and testing (1/3) sets
• Use cross validation, e.g., 10-fold cross
  validation
• Use all the data for training
• but apply a statistical test (e.g., chi-square)
  to estimate whether expanding or pruning a node
  may improve the entire distribution
• Use minimum description length (MDL) principle
• halting growth of the tree when the encoding is
  minimized

40
Decision Tree

• Enhancements to basic decision tree induction
• Allow for continuous-valued attributes
• Dynamically define new discrete-valued attributes
  that partition the continuous attribute value
  into a discrete set of intervals
• Handle missing attribute values
• Assign the most common value of the attribute
• Assign probability to each of the possible values
• Attribute construction
• Create new attributes based on existing ones that
  are sparsely represented
• This reduces fragmentation, repetition, and
  replication
