Windows XP Boot Process

1
Windows XP Boot Process

• 70-270 MCSE Guide to Microsoft Windows XP
  Professional

2
Booting Windows XP (Page 1)

• Boot process phases
• Boot phase begins when computer is first powered
  on
• Or begins when Restart is chosen from "Shut Down
  Windows" dialog box
• Windows XP load phases
• Begins when boot phase is completed
• Configuration is selected

3
Booting Windows XP (Page 2)

• Boot Phase Steps
• Power-on self test (POST)
• Initial startup
• Boot loader
• Select operating system
• Detect hardware
• Select configuration

• Windows XP Load Phase
• Load the kernel
• Initialize the kernel
• Services load
• Windows XP system startup
• Log on

4
Power-on Self Test (Page 1)

• First step in boot sequence (the POST) for any
  computer with an operating system
• Determines
• Amount of real memory that exists
• Whether or not all necessary hardware components
  are present and functioning
• The specific tests vary depending on how the BIOS
  (Basic Input/Output System) is configured

5
Power-on Self Test (Page 2)

• If POST is successful, computer boots itself
• If the tests are unsuccessful, the computer
  reports error by
• Emitting a series of beeps (number of beeps
  identifies the errordiffers from one BIOS to
  another)
• Also possibly might display error message and a
  code on the screen

6
Power-on Self Test (Page 3)

• Software that performs POST resides in called the
  CMOS (complementary metal oxide semiconductor)
• Battery-powered chip that also can hold basic
  configuration information so POST can check
  installed RAM, number and type of hard drives,
  type of keyboard and mouse, the boot sequence
  (Which drive first?), etc.
• In Windows XP, BIOS no longer stores information
  about devices and drivers connected to system
  (replaced by the HAL)

7
Power-on Self Test

• The following screen shows results of sample
  successful POST completion

8
Power-on Self Test
9
Power-on Self Test (Page 4)

• After POST completes, each adapter with a BIOS
  performs its own self-test (POST), i.e.
• Video card
• SCSI (small computer system interface) cards
  which are interfaces that provide much faster
  data transmission rates than standard parallel
  and serial ports used for printers, scanners,
  etc.
• Adapters issue their own reports on monitor

10
Power-on Self Test (Page 5)

• At this point there still is no operating system
  in RAM
• POST application in the BIOS is in control
• Output on screen is in basic, text-only form

11
Initial Startup (Page 1)

• The BIOS finds the first sector of the first hard
  drive which contains the Master Boot Record (MBR)
  and transfers control to it
• It is the job of MBR ultimately to load the Ntldr
  program (the boot loader program) and pass
  control of the boot process on to it (either
  directly or indirectly)

12
Initial Startup (Page 2)

• The Master Boot Record (con.)
• In FAT partitions, because the boot sector is
  only one sector in size, MBR points to another
  location on disk which then points to the boot
  loader
• In NTFS partitions, boot sectors may be up to 16
  sectors in size so it is large enough to store
  the code to find the boot loader
• If booting from a floppy, the first sector
  contains the partition boot sector

13
Initial Startup (Page 3)

• BIOS stores information as to the order in which
  drives are checked to see which is the startup
  drive (as stored in CMOS)
• If floppy drive is in the sequence, partition
  boot sector is loaded and runs the MBR from the
  floppy
• If the floppy does not have a partition boot
  sector, the message "Non-system disk or disk
  error " appears
• Remove disk, and turn machine off an then ondo
  not reboot to avoid viruses

14
Initial Startup (Page 3)

• Ntldr is stored on the system partition
• This is the partition where the MBR expects to
  find the system
• Ultimately its job is to boot the Windows XP
  operating system which is stored on the boot
  partition
• The system itself actually can be stored on any
  partition
• The system and boot partitions may or may not be
  the same

15
Boot Loader (Page 1)

• Collection of files on system partition used to
  initiate loading of operating system
• Required files to boot Windows XP are Ntldr,
  Ntdetect.com and Boot.ini
• Other optional boot loader programs are
  Bootsect.dos and Ntbootdd.sys

16
Windows XP Startup Files
17
Boot Loader (Page 2)

• The boot loader first switches processor into
  32-bit mode
• Previously it had been running in real mode as if
  it were an 8088 or 8086 machine
• Next it starts the appropriate file system, FAT,
  FAT32 or NTFS
• The ability to access any of the file systems is
  programmed into Ntldr

18
Boot Loader (Page 3)

• Primary functions of the boot loader are to
• Select the operating system to load if there is
  more than one from which to choose
• Detect hardware
• Select a configuration
• Ntldr stays in control throughout boot loader
  process until it loads and passes control to
  Windows XP kernel (Ntoskrnl.ext)

19
Selecting the Operating System

• Ntldr reads Boot.ini and displays the Boot
  selection menu (if necessary)
• Contains operating system choices, if more that
  one, from which the user may choose
• It also is possible from this screen to press
  ltF8gt to reach the "Troubleshooting and Advanced
  Startup" screen (more later)
• Will auto select first option after a specified
  number of seconds
• Change default O/S or time in Boot.ini

20
Boot Selection Menu
21
Detecting Hardware

• If the user selects Windows XP (or if it is the
  only O/S present), Ntldr executes Ntdetect.com
• Used to collect a list of hardware currently
  installed in computer
• From hardware list, creates system profile
• Later will be compared to Windows XP Registry
  entries for discrepancies that could lead to
  problems

22
Selecting a Configuration

• Next boot loader selects a configuration
• Known as the hardware profile
• If there is one hardware profile, it is selected
• If there is more than one, system tries to select
  one that matches detected hardware
• If system cannot make automatic selection, user
  is prompted for manual selection

23
Troubleshooting and Advanced Startup
Options (Page 1)

• Windows XP combines the boot and recovery options
  of Windows NT and Windows 95/98
• Provides several options to restore a
  malfunctioning system to functional state
• Before timer expires, or Windows XP kernel starts
  to load, press ltF8gt to access Windows Advanced
  Options Menu

24
Troubleshooting and Advanced Startup Options
25
Troubleshooting and Advanced Startup
Options (Page 2)

• Contents of menu may include
• Safe Modeboots Windows XP with only minimum
  system files and drivers
• May be able to boot into a functioning system
  when some drivers are corrupted
• Might allow replacing or removing the problem
  driver before rebooting
• Safe Mode with Networkingsame as above but with
  networking components
• If network drivers are not the problem

26
Troubleshooting and Advanced Startup
Options (Page 3)

• Contents of menu may include (con.)
• Safe Mode with Command Promptsame as above but
  not to the GUI environment
• Enable Boot Loggingenables or disables boot
  process, and writes details to log file
  Ntbtlog.txt in systemroot folder
• Records process of steps between boot menu and
  logon prompt which could provide clues to which
  driver, system or procedure is causing the problem

27
Troubleshooting and Advanced Startup
Options (Page 4)

• Contents of menu may include (con.)
• Enable VGA Modenormal boot but with only basic
  VGA video driver (in case there is a bad video
  driver)
• Last Known Good Configurationstate of Registry
  during last successful user logon
• Could be useful if a new driver or software
  recently has been installed, or the Registry was
  recently modified

28
Troubleshooting and Advanced Startup
Options (Page 5)

• Contents of menu may include (con.)
• Directory Services Restore Modeonly on Windows
  XP domain controllers, restores Active Directory

29
Troubleshooting and Advanced Startup
Options (Page 6)

• Contents of menu may include (con.)
• Debugging Modenormal boot but sends debugging
  information to another system over a serial cable
• If no other option helps in restoring system, may
  help determine where in boot process the problem
  occurs
• Complex information usually used by high-end
  programmersconsult Microsoft Windows XP
  Professional Resource Kit

30
Activity

• Try one or more of following boot options (press
  ltF8gt function key during boot)
• Safe Mode
• Safe Mode with Command Prompt
• Enable VGA Mode
• Last Known Good Configuration
• Reboot normally when done

31
Boot Configuration and Selecting an Operating
System (Page 1)

• Controlled through configuration of the Boot.ini
  file
• Located in the root directory of the system
  partition (usually drive C\)
• To view the file, uncheck "Hide Protected
  operating system files" in Folder Options
• Updated from the "System and Recovery" dialog
  window on the Advanced tab of Control Panel's
  System applet

To Sample"Boot.ini"
32
Boot Configuration and Selecting an Operating
System (Page 2)

• Used by boot loader to display the list of
  available operating systems
• Consists of two sections boot loader and
  operating systems

To Sample"Boot.ini"
33
Sample "Boot.ini"
Return
34
boot loader

• Settings
• Timeoutnumber of seconds system waits for user
  to select an operating system
• If set to zero (0), the default operating system
  is loaded automatically
• If set to (-1), waits indefinitely (this value
  only can be set in text editoran invalid value
  in System applet in "Control Panel"
• Defaultshows path to default O/S

To Sample"Boot.ini"
35
operating systems (Page 1)

• Lists available operating systems as follows
• Path to boot partition for operating system
• Text displayed in boot loader screen
• Optional parameters (switches) provide options
  many of which are equivalent to ltF8gt "Windows
  Advanced Options Menus"
• As well as a few other options

To Sample"Boot.ini"
36
operating systems (Page 2)

• Switches
• /BASEVIDEOsame as Enable VGA Mode
• /BAUDRATEnbaud rate for Debugging Mode
• /BOOTLOGsame as Enable Boot Logging
• /CRASHDEBUGstarts Debugging Mode but remains
  inactive until STOP error occurs

37
operating systems (Page 3)

• Switches (con.)
• /DEBUGstarts Debugging Mode and allows access by
  the remote computer
• /DEBUGPORTcom1com21394sets port for
  Debugging Mode
• /FASTDETECTcom1com2specifies serial ports
  to skip during hardware scan
• All if no port specified
• Included in every entry by default when the
  operating system is installed

38
operating systems (Page 4)

• Switches (con.)
• /MAXMEMnsets maximum RAM O/S can use
• /NOGUIBOOTboots without showing splash screen
• /NODEBUGdisables Debugging Mode
• /NUMPROCnsets maximum number of processors on
  multiprocessor machine that O/S may use

39
operating systems (Page 5)

• Switches (con.)
• /SAFEBOOTMINIMALboots to Safe Mode
• /SAFEBOOTNETWORKboots to Safe Mode with
  Networking
• /SAFEBOOTMINIMAL(ALTERNATESHELL)boots to Safe
  Mode with Command Prompt
• /SOSdisplays device driver names when they are
  loaded

40
Advanced RISC Computing Pathnames (Page 1)

• Advanced RISC Computing pathname is a path naming
  convention that is used in the "Boot.ini" file
• Defines the hard disk, partition and folder where
  Windows XP Professional and any other operating
  systems reside
• Created automatically when an operating system is
  installed into a partition

To Sample"Boot.ini"
41
Advanced RISC Computing Pathnames (Page 2)

• The parts of the path are
• scsi(n) or multi(n)whether the drive type is
  SCSI or other (multi) and the adapter number
• disk(n)the SCSI bus number
• rdisk(n)which disk contains the O/S
• partition(n)selects partition with the O/S
• \pathselect path with the O/S

To Sample"Boot.ini"
42
Editing Boot.ini

• Options for editing (see next slides)
• Use Control Panel to edit indirectly
• Use text editor (i.e. Notepad) to change the
  Boot.ini file directly

43
Using Control Panel

• Safest way to proceed
• Select System applet in "Control Panel", then
  select Advanced tab, and the Startup and Recovery
  ltSettingsgt button
• Options to modify
• Choose "Default operating system" (the default
  boot selection)
• Select "Time to display list of operating
  systems" (delay interval before boot selection
  starts automatically)

44
Startup and Recover Dialog
45
Using a Text Editor

• Use Notepad or any other text editor
• The ltEditgt button in the "Startup and Recovery"
  window launches Notepad and opens the Boot.ini
  file
• Be careful when editing file
• Windows XP might not boot if there is an
  incorrect configuration
• Create backup copy of the file before making
  changes

46
Activity

• Before starting this activity, you should backup
  boot.ini
• Modify "timeout" value using Notepad
• Set the "timeout" value back to its original
  value (30) using Startup and Recovery dialog in
  System applet in "Control Panel"
• Return to Notepad and open boot.ini to confirm
  the change

47
Activity
See next slide

• Before starting this activity, you should backup
  boot.ini
• In Notepad, create one or more additional
  operating system entries, i.e.
• An additional Windows XP Professional entry but
  booting in VGA Mode
• A fictional entry for Windows 2000 on an
  alternate partition

48
Sample "Boot.ini"

• boot loader
• timeout30
• defaultmulti(0)disk(0)rdisk(0)partition(1)\WINDOW
  S
• operating systems
• multi(0)disk(0)rdisk(0)partition(1)\WINDOWS"Micro
  soft Windows XP Professional" /fastdetect
• multi(0)disk(0)rdisk(0)partition(1)\WINDOWS"Micro
  soft Windows XP Pro VGA Mode" /fastdetect
  /basevideo
• multi(0)disk(0)rdisk(3)partition(2)\WINNT"Microso
  ft Windows 2000" /fastdetect

To Sample"Boot.ini"
49
Windows XP Load Phase

• Stages
• Loading the kernel
• Initializing the kernel
• Services load
• Windows XP system startup
• Logging on

50
Loading the Kernel (Page 1)

• Once Windows XP is selected as O/S to boot, a
  "Starting Windows" text message and the XP
  splash screen are displayed
• During this time the boot loader loads the kernel
  into memory (consists of)
• Windows XP kernel (Ntoskrnl.exe)
• Hardware abstraction layer (HAL), the file that
  is named Hal.dll

51
Loading the Kernel (Page 2)

• The kernel is the central module of an operating
  system
• Loads first and remains in main memory at all
  times
• Essential that it is as small as possible while
  still providing services required by the O/S and
  applications

52
Loading the Kernel (Page 3)

• The kernel (con.)
• Communicates between processes and the hardware
• Responsible for memory management, process and
  task management, and disk management

53
Loading the Kernel (Page 4)

• The Hardware Abstraction Layer (HAL) is an O/S
  programming component
• Functions as an interface between the systems
  hardware and software
• Applications do not access hardware directly but
  access the abstract layer provided by the HAL

54
Loading the Kernel (Page 5)

• Hardware Abstraction Layer (con.)
• Like APIs, allows applications to be
  device-independent
• They abstract information from systems such as
  caches, I/O buses and interrupts
• Use this data to give the software a way to
  interact with the specific requirements of the
  hardware on which it is running

55
Loading the Kernel (Page 6)

• Before kernel and HAL begin to execute, the boot
  loader loads the Registry key HKLM\SYSTEM
• Retrieves configuration based upon Registry
  subkey HKLM\SYSTEM\Select data value
• CurrentControlSet is created (not written to
  Registry yet) from one of the following
• ControlSet00x, a per either the Select or
  LastKnownGoodRecovery (if Last Known Good
  Configuration was selected) data value, Default,
  etc.

See next slide (HKLM\SYSTEM\Select)
56
Loading the Kernel
Return
57
Loading the Kernel (Page 7)

• Loads drivers listed in Registry subkey
• HKLM\SYSTEM\CurrentControlSet\Services
• These drivers are loaded and/or initialized
  according to their Registry settings

See next slide (HKLM\SYSTEM\CurrentControlSet\Serv
ices
58
Loading the Kernel
Return
59
Initializing the Kernel (Page 1)

• Registry key HKLM\HARDWARE created by kernel
  using information it received from boot loader
  program Ntdetect.com
• Creates CloneControlSet by making a copy of
  CurrentControlSet
• Never modifiedintended as a backup
• Initializes drivers that were loaded by the boot
  loader

60
Initializing the Kernel (Page 2)

• If the driver experiences an error while loading,
  a message with the error level reported is
  reported to the kernel
• Ignoreerror is ignored and no message is
  displayed to user
• Normalboot process continues with message
  displayed to user

61
Initializing the Kernel (Page 3)

• Driver error levels (con.)
• Severedisplays message if Last Known Good
  Configuration is not in use, restarts using LKGC
  if LKGC is in use, boot process continues after
  message
• Criticaldisplays message if Last Known Good
  Configuration is not in use, restarts using LKGC
  if LKGC is in use, boot process fails after
  message
• All events saved to the System log

62
Services Load (Page 1)

• Kernel starts Session Manager
• Starts programs that correspond to key entries
  under Registry key
• HKLM\SYSTEM\CurrentControlSet\Control\Session
  Manager\BootExecute
• A REG_MULTI_SZ data type, i.e. an array
• The default entry Autocheck makes sure these
  files are consistent, and tries to repair them if
  they are not

See next slide (HKLM\SYSTEM\CurrentControlSet\Cont
rol\Session Manager\BootExecute
63
Services Load
Return
64
Services Load (Page 2)

• Paging files are set up as per
• HKLM\SYSTEM\CurrentControlSet\Control\Session
  Manager\Memory Management

See next slide (HKLM\SYSTEM\CurrentControlSet\Cont
rol\Session Manager\Memory Management
65
Services Load
Return
66
Services Load (Page 3)

• Session Manager writes to Registry
• CurrentControlSet
• CloneControlSet
• Windows (Win32) subsystem loaded as per Registry
  entry
• HKLM\SYSTEM\CurrentControlSet\Control\Session
  Manager\Subsystems
• Default subsystem, and also the subsystem in
  which the user shell always executes

See next slide (HKLM\SYSTEM\CurrentControlSet\Cont
rol\Session Manager\Subsystems
67
Services Load
Return
68
Windows XP System Startup

• At this point, Windows is considered fully
  started which is signaled by appearance of a
  Windows XP logon screen
• Win32 subsystem starts winlogon.exe which
  launches Local Security Authority (Lsass.exe)
  process

69
Logging On

• The user logs on successfully with logon name, as
  well as a password if required
• Clone control set is copied to the Last Known
  Good control set completing the boot process

70
Multiple-boot Systems (Page 1)

• Windows XP operating system can coexist
  peacefully with other operating systems
• Operating system uses one or more file systems to
  organize the data within volumes, i.e. FAT or NTFS

71
Multiple-boot Systems (Page 2)

• Not all file systems and operating systems are
  compatible
• MS-DOS, Windows 95/98, Windows NT, Windows 2000,
  Windows Server 2003 and Windows XP can share
  files through FAT volumes
• Windows NT, Windows 2000, Windows Server 2003 and
  Windows XP can share files through NTFS volumes

72
Multiple-boot Systems (Page 3)

• File system and operating system compatibility
  (con.)
• Windows and UNIX do not have a common file
  system, but Linux can access FAT volumes
• Only Windows 2000, Windows Server 2003 and
  Windows XP support dynamic disks
• When selecting file systems for partitions in a
  multiple-boot system, keep these factors in mind
  if you wish to share files between the partitions

73
Multiple Windows Operating Systems (Page 1)

• Different versions of Windows can be installed on
  the same system, i.e.
• Windows 3.1, Windows 3.11, Windows 95/98, Windows
  NT, Windows 2000, Windows Server 2003, even
  Linux/Unix
• Even the same version of Windows XP can be
  installed on separate partitions

74
Multiple Windows Operating Systems (Page 2)

• Why? User needs to run software versions that
  require an older O/S
• Just remember to specify different partitions for
  each installation
• To run an application under two O/Ss, run the
  setup program twice, once while booted to each
  operating system

75
Multiple Installation Order

• Order in which you install operating systems is
  important
• Install older operating systems first, i.e.
• MS-DOS, Windows 95/98, Windows 2000/2003, etc.
• This really is a warning, not necessarily an
  absolute requirement
• When installing Windows XP, it recognizes the
  previously installed older O/S and leaves it alone

76
(No Transcript)
