Cognitive Neuroscience PSYC 768 Neuroscience 101

1
Cognitive NeurosciencePSYC 768Neuroscience 101

• Raja Parasuraman

2
OverviewFunctional NeuroanatomyNeurophysiology
Elements of Neurochemistry
3
Early Views of the Brain

• Galen
• Vesalius (1542)
• Leonardo da Vinci

4
Functional Neuroanatomy of Cognition
Stimulus
Response
Anatomical subdivisions
Carving the mind at its joints
5
Nervous System Organization
Peripheral (PNS)
Somatic (SNS)
Autonomic (ANS)
Spinal Cord
Forebrain
Midbrain
Hindbrain
Cortex
Cortical Areas
6
Major Brain Structures
Forebrain
Midbrain and Hindbrain
7
The Brain is a 3-D Structure

• Forebrain
• (Neommamalian brain)

II. Midbrain (Paleomammalian brain)
III. Hindbrain (Reptilian brain)
II and III sometimes collectively known as the
brainstem
http//www9.biostr.washington.edu/da.html
(University of Washington Digital Anatomist
Project)
8
The Triune Brain (Paul McLean)
Increasing Functional Complexity
Increasing Evolutionary Age
9
Development and Evolution
paleomammalian
reptilian
neomammalian
Ontogeny recapitulates phylogeny
10
The Hindbrain

• Medulla
• Life support functions
• Regulation of respiration, muscle tension, etc.
• If damaged
• death
• coma
• Pons
• Arousal and sleep (reticular formation)
• Consciousness
• If damaged
• coma
• sleep disorders

11
The Hindbrain (contd.)

• Cerebellum
• Coordination of movements (under cortical
  control)
• Cognitive functions?
• If damaged
• Motor disorders

12
The Midbrain

• Tectum
• Superior colliculus
• Eye movements
• Inferior colliculus
• Auditory orientation
• Tegmentum
• Reticular formation
• Arousal and sleep
• Substantia nigra
• Motor initiation
• If damaged
• Parkinsons disease

13
The Forebrain

• Basal ganglia
• Monitoring of voluntary movements
• If damaged
• Motor disorders (Huntingdons disease)
• Thalamus
• Sensory relay center
• If damaged
• Attentional disorders

14
The Limbic Lobe

• Cingulate gyrus
• Hypothalamus
• Amygdala
• Hippocampus
• Phylogenetically older than neocortex (allocortex
  and mesocortex)
• These structures are involved in various aspects
  of emotional behavior

15
The 4 Major Cortical Lobes
16
Brodmanns Areas (original)
17
Brodmanns Areas (simplified functional)
18
Cortical Areas

• Occipital Lobe
• Primary visual cortex (Striate cortex V1 Area
  17)
• Secondary visual areas (Extrastriate cortex V2
  Areas 18, 19)
• Demarcated from the parietal and temporal lobes
  by the parieto-occipital sulcus

19
Cortical Areas

• Parietal Lobe
• Primary somatosensory cortex Postcentral gyrus
• Association areas play a role in attention and
  spatial processing
• Demarcated from the frontal lobe by the central
  sulcus (or Rolandic fissure)

20
Cortical Areas

• Temporal Lobe
• Primary auditory cortex Superior temporal gyrus
  (A1 Areas 41, 42)
• Inferior temporal gyrus plays a role in visual
  object recognition
• Medial temporal lobe (hidden in this view) plays
  a role in memory formation
• Demarcated from the parietal lobe by the lateral
  sulcus (or Sylvian fissure)

21
Cortical Areas

• Frontal Lobe
• Primary motor cortex Precentral gyrus (Motor
  strip Area 4)
• Homunculus in motor and somatosensory cortices

22
Cortical Areas

• Frontal Lobe
• Primary motor cortex Precentral gyrus (Motor
  strip Area 4)
• Homunculus in motor and somatosensory cortices
• Prefrontal cortex plays a role in higher
  cognitive functions
• Dorsolateral prefrontal cortex
• Anterior cingulate and medial prefrontal cortex
• Orbitofrontal cortex

23
Cortical Regions
http//www.med.harvard.edu/AANLIB/cases/caseNA/pb9
.htm (Harvard Brain Anatomy and Pathology Project)
24
Cortex

• Outer layer (bark) of forebrain
• Approximately 3 mm thick and 2000 sq. cm in area
• About 20 billion neurons, plus 200 billion glial
  cells
• Convoluted cortex is folded on itself
• Gyrus (gyri) protuding surfaces or bulges
• Sulcus (sulci) grooves or enfolded regions
• Large sulci (fissures)
• Longitudinal
• Central (Rolandic)
• Lateral (Sylvian)
• Degree of convolution higher in primates, highest
  in humans

25
Cortical Layers

• I Molecular layer mostly dendrites
• and long axons few cell bodies
• II External granular layer small pyramidal
  cells
• III Outer pyramidal layer medium and large
  pyramidal cells input from other cortical
  columns
• IV Internal granular layer mostly granule
  cells input layer from thalamus
• V Inner pyramidal layer large pyramidal cells
  motor output to spinal cord
• VI Multiform layer mostly spindle cells

26
Cortical Columns (Vernon Mountcastle)

• Oriented perpendicular to the cortical surface
• 30-50 um diameter, spanning the 3 mm depth of the
  cortical layers
• Each column contains approximately 100 neurons
• Shape is quasi-hexagonal, because each cortical
  column is typically surrounded by six other
  columns
• Columns function as modules

A cortical column is a complex processing and
distributing unit that links a number of inputs
to a number of outputs via overlapping internal
processing chains" (Mountcastle, 1998).
27
Modular Structure of Cortex
Functional Columns
I
II
III
IV
V
VI
Six Structural Layers
Basic Information Processing Unit?
28
Neuronal Information Processing

• Neuron to neuron communication
• action potentials
• postsynaptic potentials
• Neurochemical innervation of cortex (subcortex)

29
Neuronal Conduction

• Resting neuron membrane potential - 70 mV
• Active postsynaptic potential generated by input
  to neuron
• Passive current flow through neuron
• Depolarization (membrane potential ?)
• Hyperpolarization (membrane potential ?)
• Repolarization (return to resting membrane
  potential)

30
Neuronal Conduction (contd.)

• If net potential at axon hillock gt threshold, ion
  channels open (active process), and action
  potential generated (exchange of Na and K ions)
• Na ions in Rising phase of AP
• K ions in Falling phase of AP
• AP duration approximately 1-2 ms (refractory
  period)

31
Neuronal Conduction The Problem

• Action potential decays over length of axon due
  to resistance and capacitance
• Not a problem over short axonal distances (e.g.,
  retina) but is for long distances (e.g., spinal
  motor neurons)
• Resistance is reduced (and axonal speed
  increased)
• However fat motor neurons needed to reach distant
  muscles would exceed width of spinal cord

32
The Solution Myelin and Saltatory Conduction

• Myelin (glial cell membrane) insulates axon and
  reduces resistance and increases speed of
  conduction
• AP regenerated at gaps in myelin (Nodes of
  Ranvier) where ion channels are found
• Saltatory conduction (jumps) represents a
  tradeoff between signal loss due to axonal length
  and speed

33
Saltatory Conduction
34
Myelin and Saltatory Conduction (contd.)

• Unmyelinated neurons are the fastest in the
  nervous system, but can only conduct over short
  distances
• Myelinated neurons are slower, but can conduct
  over longer distances ( 100 m/s)

Unmyelinated (no Nodes of Ranvier), fastest,
short distance
Myelinated (many nodes), slow, longer distance
Myelinated (few nodes), faster, shorter distance
35
Synaptic Transmission

• Synapse Gap between axon of one neuron and
  dendrite (or cell body) of another cell
• presynaptic neuron
• postsynaptic neuron
• Synaptic transmission involves communication
  across the synapse from one neuron to another
• chemical
• electrical

36
Synaptic Transmission (contd.)

• Chemical transmission involves
• voltage-gated Ca2 ion channels in the
  presynaptic neuron
• receptors (specialized ion channels) in the
  postsynaptic neuron

37
Chronology of Events at Synapse

• Action potential arrives at axon terminal
• Vesicles containing neurotransmitter fuse with
  presynaptic membrane (with help of Ca2)
• Neurotransmitter released into synaptic cleft
  (gap)
• Neurotransmitter diffuses across cleft and binds
  with postsynaptic receptors

38
Chronology of Events at Synapse (and beyond)

• Binding (lock and key) of NT and receptor results
  in postsynaptic potential (PSP)
• Depending on postsynaptic receptor, the PSPs can
  be excitatory or positive (EPSP) or inhibitory or
  negative (IPSP)
• Spatial and temporal summation of EPSPs and IPSPs
  at axon hillock leads to action potential, and so
  the process of neuronal communication continues
• Action potential On or off a digital signal
• PSPs Can have multiple values, positive or
  negative an analog signal

39
Discovery of The First Neurotransmitter

• Acetylcholine (ACh)
• Discovered by Otto Loewi (1924)
• Vagus nerve stimulation of heart muscle
• Chemical stimulation of second heart
• Henry Dale showed that ACh is also involved at
  the neuromuscular junction
• Curare (as in poison darts) occupies receptor
  sites in muscles, hence preventing ACh to work
  and causing paralysis

40
Routes to Paralysis and Intoxication
41
We now understand the microstructure of
neurotransmitter receptors
42
Classes of Neurotransmitters

• Acetylcholine
• Amino acids
• excitatory
• glutamate
• aspartate
• inhibitory
• gamma-aminobutyric acid (GABA)
• glycine
• taurine4
• Biogenic amines
• serotonin
• histamine
• catecholamines
• dopamine
• norepinephrine
• Neuropeptides
• Over 50 known

Underlined NTs have been linked to different
aspects of cognitive functioning
43
Key Historical Figures
Sir Charles Sherrington 1857-1952
Sir Henry Dale 1875-1968
Otto Loewi 1873-1951
All Nobel Prize Winners
Eric Kandel 1934 - present
Sir John Eccles 1903-1997
44
Internet Resources

• www.cogneurosociety.org (Cognitive Neuroscience
  Society)
• www.sfn.org (Society for Neuroscience)
• http//www.humanbrainmapping.org/ (Organization
  for Human Brain Mapping)
• http//www9.biostr.washington.edu/da.html
  (University of Washington Digital Anatomist
  Project)
• http//www.med.harvard.edu/AANLIB/home.html
  (Harvard Brain Anatomy and Pathology Project)
• http//www.univie.ac.at/anatomie2/plastinatedbrain
  /main.html (The Plastinated Brain)
• http//www-medlib.med.utah.edu/kw/sol/sss/subj2.ht
  ml University of Utah Medical School)
