4G LTE Outdoor Wireless Applications
3
Billion 4G LTE Outdoor Wireless Router

• Highlight Features
• High Performance and Fully Support for Multiple
  LTE Frequency Bands
• Embedded High-Performance Dual-Polarized MIMO
  Antenna for Maximum Bandwidth and Service
  Coverage
• Carrier-Grade Wireless-LAN, simultaneous
  dual-band Wireless up to 2000Mbps (5GHz and
  2.4GHz), Wi-Fi Hotspot with Captive Portal
• IP67 hardened enclosure with industrial-grade
  components, designed for the toughest industrial
  environments
• Full VPN security, including IPSEC, PPTP, L2TP,
  GRE,
• Device security considerations, including Full
  firewall security, SPI firewall, NAT, VLAN,
  Filtering, Access Control List, etc.
• Package Includes PoE Injector and Mounting Kit

4
Instant Outdoor WiFi Hotspot Setup with 4G LTE
The BiPAC 4700NZ(L) 4G/LTE IP67 Outdoor WiFi
Router integrates the latest generation of LTE
fixed wireless networks and the 11N wireless
technology providing an instant high-performance
4G LTE connectivity to outside harsh
environments Wi-Fi Hotspot applications.

• Requirements
• Provide mobile WiFi internet access in outdoor
  extreme environment
• The box is water-proofed and hard solid without
  cracking
• 3. Special antenna design to extend the 4G LTE
  signal service coverage bandwidth
• 4. Support authentication and advertisement
  with WiFi hotspot customizable captive portal
  design
• 5. Instant setup easily

5
4G LTE Outdoor Fixed Wireless with WiFi for
Internet Access

• Requirements
• Provide Fixed Wireless WiFi internet access in
  outdoor extreme environment
• The box is water-proofed and hard solid without
  cracking
• 3. Special antenna design to extend the 4G
  LTE signal service coverage bandwidth
• 4. Connect with other Outdoor WiFi client to
  provide internet access for users of those WiFi
  clients

6
Provide 4G Fixed Wireless WiFi Internet Access
for Remote Office

• Requirements
• Provide 4G Fixed Wireless WiFi internet access
  for remote office
• Support VPN to connect to headquarter

7
4G/LTE Outdoor WiFi Dual WAN Router
8
Outdoor 4G/LTE Series
BiPAC 4700AZ(L) 4G/LTE Outdoor IP67 (VPN) 11AC
Wireless Dual WAN Router

• Support LTE frequency bands
• MIMO antenna for maximum bandwidth and service
  coverage
• Embedded directional Optimize antenna design
  per LTE band
• Dual-polarization antenna technology ensures
  faster and efficient bi-directional transmission
• Availability and Resilience
• Dual-WAN ports (4G Ethernet WAN)
• Auto fail-over between 4G and EWAN
• Carrier-Grade Wireless-LAN,
• Simultaneous dual-band 11AC Wireless up to
  2000Mbps (5GHz and 2.4GHz),
• Wi-Fi Hotspot with Captive Portal
• Giga LAN and Giga Ethernet WAN
• LAN 1 x 10/100/1000 Mbps, EWAN 1 x
  10/100/1000 Mbps
• Lightweight and compact design
• Easily installed by single person
• Supports Power over Ethernet (PoE)
• Precise alignment achievable with multi-angel,
  multi-position pole mount brackets
• IPSec, PPTP, L2TP, and GRE support with powerful
  encryption
• ( BiPAC 4700AZ only)
• Designed for challenging/rugged deployments

BiPAC 4700AZ(L)
Note Different SKU has different band
combinations, please confirm it with our sales.
9
Outdoor 4G/LTE Series
BiPAC 4700NZ(L) 4G/LTE Outdoor IP67 (VPN) 11N
Wireless Dual WAN Router
BiPAC 4700NZ(L)

• Support LTE frequency bands
• MIMO antenna for maximum bandwidth and service
  coverage
• Embedded directional Optimize antenna design
  per LTE band
• Dual-polarization antenna technology ensures
  faster and efficient bi-directional transmission
• Availability and Resilience
• Dual-WAN ports (4G Ethernet WAN)
• Auto fail-over between 4G and EWAN
• Carrier-Grade Wireless-LAN,
• Support 2.4GHz 11N Wireless 300Mbps,
• Wi-Fi Hotspot with Captive Portal
• Giga LAN and Giga Ethernet WAN
• LAN 1 x 10/100/1000 Mbps, EWAN 1 x
  10/100/1000 Mbps
• Lightweight and compact design
• Easily installed by single person
• Supports Power over Ethernet (PoE)
• Precise alignment achievable with multi-angel,
  multi-position pole mount brackets
• IPSec, PPTP, L2TP, and GRE support with powerful
  encryption
• ( BiPAC 4700NZ only)
• Designed for challenging/rugged deployments

Note Different SKU has different band
combinations, please confirm it with our sales.
