Fast Signal Processing Algorithms

1
Fast Signal Processing Algorithms

• Motivations

2
Motivation

• Why signal processing
• What is digital signal processing
• Why fast algorithms
• What algorithms

3
Why Signal Processing?

• Signals are buried in noise
• Signals are mixed with interferences
• Useful features are to be extracted from signals
  (spectral analysis)
• Signals are made suitable for transmission
• .

4
Why DSP?

• Digital signals can be the results of sampling
  continuous-time signals (such as voice signals)
  or discrete in nature (such as text in emails)
• Signals are expressed as numbers
• Signal processing can be realized by mathematical
  operations using computers

5
Why DSP?

• The purposes of DSP are
• Enhance the signals (noise reduction,
  interference elimination etc)
• Present signal in a simple way (source coding)
• Extract feature of signals
• .

6
What is DSP?
Output
DSP DSP chips or General purpose computer
Input

• Input and output are discrete sequences.

7
Why Fast Algorithms?

• For achieving a specific signal processing task,
  we wish that
• Less computation
• Less memory occupation
• Short time delay

8
What Algorithms

• Two Fundamental problems in DSP
• Signal analysis spectral analysis, discrete
  orthogonal transforms etc
• System analysis Behavior of discrete systems
  with discrete input sequence system impulse
  response, system functions, and input-output
  relationship
• We will focus on the algorithms for signal
  analysis

9
What Algorithms

• The focus of the subject will be
• Orthogonal transforms
• DFT
• DCT (Discrete Cosine Transform)
• Discrete Hartkey Transforms
• Discrete Hadamard transforms
• Multirate techniques
• Polyphase decomposition and filtering
• Discrete Wavelet Transforms

10
Fast Signal Processing AlgorithmsWeek 1

• Discrete Fourier Transform

11
Outline

• What is spectrum
• Spectrum analysis of analog signals
• Spectral analysis of discrete sequence
• Discrete Fourier Transform (DFT) and Fast Fourier
  Transform (FFT)

12
What is spectrum

• Light Spectrum Sun light contains a range of
  components differing in
• Color ? Wavelength ?Frequency
• The detailed structure of a beam of light in
  terms of those components is called the spectrum

13
What is spectrum

• Spectrum analysis refers to the task of working
  out the spectrum, that is
• What color (wavelength or frequency) component
  does the light beam contain
• How strong are those components (magnitude)

14
Electromagnetic Spectrum
15
Spectrum Analysis of Signals

• A signals is also a wave and can also be
  considered as a combination of components with
  different frequencies. The detailed structure is
  also called the spectrum of the signal.
• Therefore signal spectrum analysis refers to the
  task that, for a given signal
• Determines what frequency components it contains,
  and
• the details of (amplitude, and phase) of those
  components

16
Spectrum of analog signals

• For a time-continuous signal s(t)
• It can be decomposed as Fourier series if it is
  periodic with period T

where
and where
17
Spectrum of analog signals

• For a time-continuous signal s(t)
• If the s(t) is not periodic, Fourier Transform
  can be used

where
is the Fourier Transform of x(t)
and is referred to as the spectrum of the signal
18
Spectrum of analog signals

• The spectrum of a periodic time-continuous signal
  consist of discrete frequency components, called
  harmonics
• The spectra of non-periodic time-continuous
  signals are continuous in frequency.

19
Spectrum of Discrete signals

• Lets assume that the discrete-time signal
  results from periodic sampling of a
  continuous-time signal with sampling interval Ts

that is
20
Spectrum of Discrete signals

• Therefore the Fourier Transform of x(n) is

21
Spectrum of Discrete signals
Considering that
is called normalized angular frequency

22
Spectrum of Discrete signals
For simplicity the spectrum of discrete x(n) is
defined as

is the normalized angular frequency. The above
is also called the Discrete-time Fourier
Transform (DTFT)
23
Spectrum of Discrete signals
Assuming that sampling frequency Fs is higher
than the Nyquist frequency (double of the highest
frequency component), then

or
We have
24
Spectrum of Discrete signals
It is not convenient to have continuous spectrum
if the spectrum analysis is done by computers.
For this reason we take N samples of the spectrum
with their frequencies uniformly distributed
between
25
Discrete Fourier Transform
that is
The above equation is referred to as the
Discrete Fourier Transform (DFT) of the sequence
x(n) for n0, 1, N-1
26
Discrete Fourier Transform
It can be shown that
The above equations are the DFT pair.
27
DFT
The inverse transform saying that x(n) can be
considered as linear combination of complex
exponential sequence
X(k) is the complex amplitude of the kth complex
exponential sequence. Hence X(k) give the
spectrum.
28
Discrete Fourier Transform
DFT in Matrix form
29
Discrete Fourier Transform
It can be shown that
Recall the definition of unitary matrix, the DFT
is also called an unitary transform up to the
factor of N
30
DFT Some properties
Circular time shift by L samples of x(n)
31
DFT Some properties
Multiplication in the frequency domain. Assume
that There are two signals x1(n) and x2(n)
The inverse DFT of y(n) is
Multiplication in the frequency domain means a
circular Convolution in the time domain
32
Spectrum of Non-periodic Signals
Lets have a look of the DTFT again

• The spectrum is determined by all the signal
  samples.
• For example, the signal lasts 1 year, and the
  spectrum can only be obtained after 1 year!

33
Spectrum of Discrete signals

• There are two ways to solve the problem
• Block-based spectrum analysis
• Running-based (sample based,or sliding-window
  based) analysis

34
Spectrum of Discrete signals
Block-based spectrum analysis we usually take a
period of observation and compute its spectrum

Each observation is a time-duration limited
signal
35
Spectrum of Discrete signals

• How to determine the segment size?
• The resolution of DFT in spectrum (space between
  adjacent DFT bins) is
• Larger segment size gives more accurate spectrum
  estimation (higher resolution)

36
Spectrum analysis of non-periodic signals

• We could increase the segment size until the DFT
  does not yield more details of the spectrum.
• The segment size is called natural segment size.

37
Spectrum analysis of non-periodic signals

• How do we computer DFT of the segment?
• Assume that a segment contains L signal samples.
  We would like to use N-point DFT for two reasons
• Fast computation e.g FFT.
• Change the resolution of spectrum analysis
• Note that NgtL

38
Spectrum analysis of non-periodic signals

• The N-point DFT of L-point signal samples is

• The computation can be performed by
• padding some zeros so that the signal length is N
• Compute the N-point DFT using FFT

39
Spectrum analysis of non-periodic signals
Consider the long signal again

There are two sharp edges for each segment,
which may results in some high frequency
components which in fact do not exist
40
Spectrum analysis of non-periodic signals

A window function is applied to each segment to
smooth the edges.
41
Spectrum analysis of non-periodic signals

• Many window functions have been proposed and
  studied
• Hamming
• Hanning
• Blackman
• etc

42
Fact computation of DFTs

sliding window
43
Spectrum of Discrete signals
Assuming there are N samples within the
observation period, the DTFT reduces to
Note the spectrum is still continuous in
frequency
44
DFT zero padding
We want to compute the spectrum of a signal
For equidistant frequencies
Where gives the resolution. N-point DFT
gives the spectrum at the following frequency
points
45
DFT zero padding
If N is small, the resolution will be too low and
the results will not be satisfactory. For this
reason we increase the length of DFT by padding
zeros to the sequence
The DFT will be
46
DFT zero padding
It is equivalent to
and the resolution now is
47
DFT zero padding
For example, we have a sequence of 128 samples,
the sampling frequency is 1kHz, the 128 point
DFT will give the spectrum of the signal with
frequency resolution of 1/128 kHz. However, if
we pad 128 zeros and do 256 point DFT, the
resolution will be 1/256 kHz. Therefore zero
padding is used to increase the resolution of
spectrum analysis
48
Fast Computation

• We should be able to determine the block size
  based on
• Given resolution requirement
• We wish to have efficient algorithms for compute
  the
• block-based DFT
• We should also have efficient algorithms for
  sliding
• window based
