TreadMarks: Shared Memory Computing on Networks of Workstations

1
TreadMarks Shared Memory Computing on Networks
of Workstations

• C. Amza, A. L. Cox, S. Dwarkadas, P.J. Keleher,
  H. Lu, R. Rajamony,W. Yu, W. ZwaenepoelRice
  University

2
INTRODUCTION

• Distributed shared memory is a software
  abstraction allowing a set of workstations
  connected by a LAN to share a single paged
  virtual address space
• Key issue in building a software DSM is
  minimizing the amount of data communication among
  the workstation memories

3
Why bother with DSM?

• Key idea is to build fast parallel computers that
  are
• Cheaper than shared memory multiprocessor
  architectures
• As convenient to use

4
Conventional parallel architecture
CPU
CPU
CPU
CPU
Shared memory
5
Todays architecture

• Clusters of workstations are much more cost
  effective
• No need to develop complex bus and cache
  structures
• Can use off-the-shelf networking hardware
• Gigabit Ethernet
• Myrinet (1.5 Gb/s)
• Can quickly integrate newest microprocessors

6
Limitations of cluster approach

• Communication within a cluster of workstation is
  through message passing
• Much harder to program than concurrent access to
  a shared memory
• Many big programs were written for shared memory
  architectures
• Converting them to a message passing architecture
  is a nightmare

7
Distributed shared memory
main memories
DSM one shared global address space
8
Distributed shared memory

• DSM makes a cluster of workstations look like a
  shared memory parallel computer
• Easier to write new programs
• Easier to port existing programs
• Key problem is that DSM only provides the
  illusion of having a shared memory architecture
• Data must still move back and forth among the
  workstations

9
Munin

• Developed at Rice University
• Based on software objects (variables)
• Used the processor virtual memory to detect
  access to the shared objects
• Included several techniques for reducing
  consistency-related communication
• Only ran on top of the V kernel

10
Munin main strengths

• Excellent performance
• Portability of programs
• Allowed programs written for a multiprocessor
  architecture to run on a cluster of workstations
  with a minimum number of changes(dusty decks)

11
Munin main weakness

• Very poor portability of Munin itself
• Depended of some features of the V kernel
• Not maintained since the late 80's

12
TreadMarks

• Provides DSM as an array of bytes
• Like Munin,
• Uses release consistency
• Offers a multiple writer protocol to fight false
  sharing
• Runs at user-level on a number of UNIX platforms
• Offers a very simple user interface

13
First example Jacobi iteration

• Illustrates the use of barriers
• A barrier is a synchronization primitive that
  forces processes accessing it to wait until all
  processes have reached it
• Forces processes to wait until all of them have
  completed a specific step

14
Jacobi iteration overall organization

• Operates on a two-dimensional array
• Each processor works on a specific band of rows
• Boundary rows are shared

15
Jacobi iteration overall organization

• During each iteration step, each array element is
  set to the average of its four neighbors
• Averages are stored in a scratch matrix and
  copied later into the shared matrix

16
Jacobi iteration the barriers

• Mark the end of each computation phase
• Prevents processes from continuing the
  computation before all other processes have
  completed the previous phase and the new values
  are "installed"
• Include an implicit release() followed by an
  implicit acquire()
• To be explained later

17
Jacobi iteration declarations
define M define N float grid //
shared array float scratchMN // private
array
18
Jacobi iteration startup
main() Tmk_startup() if (Tmk_proc_id 0
) grid Tmk_malloc(MNsizeof(float))
initialize grid // if Tmk_barrier(0)
length M/Tmk_nprocs begin
lengthTmk_proc_id end length(Tmk_proc_id
1)
19
Jacobi iteration main loop
for (number of iterations) for (i
begin i lt end i) for (j 0 j lt N
j) scratchij (gridi-j
gridij1)/4
Tmk_barrier(1) for (i begin i lt end i)
for (j 0 j lt N j) gridij
scratchij Tmk_barrier(2) // main
loop // main
20
Second example TSP

• Traveling salesman problem
• Finding the shortest path through a number of
  cities
• Program keeps a queue of partial tours
• Most promising at the end

21
TSP declarations
queue_type Queue int Shortest_length int
queue_lock_id, min_lock_id
22
TSP startup
main ( Tmkstartup() queue_lock_id 0
min_lock_id 1 if (Tmk_proc_id 0)
Queue Tmk_malloc(sizeof(queuetype))
Shortest_length Tmk_malloc(sizeof(int))
initialize Heap and Shortest_length // if
Tmk_barrier (0)
23
TSP while loop
while (true) do Tmk_lock_acquire(queue_l
ock_id) if (queue is empty)
Tmk_lock_release(queue_lock_id)
Tmk_exit() // while loop Keep
adding to queue until a long promising tour
appears at the head Path Delete the tour
from the head Tmk_lock_release(queue_lock_id)
// while
24
TSP end of main
length recursively try all cities not
on Path, find the shortest tour
length Tmk_lock_acquire(min_lock_id) if
(length lt Shortest_length) Shortest_length
length Tmk_lock_release(min_lock_id // main
25
Critical sections

• All accesses to shared variables are surrounded
  by a pair
• Tmk_lock_acquire(lock_id)
• Tmk_lock_relese(lock_id)

26
Implementation Issues

• Consistency issues
• False sharing

27
Consistency model (I)

• Shared data are replicated at times
• To speed up read accesses
• All workstations must share a consistent view of
  all data
• Strict consistency is not possible

28
Consistency model (II)

• Various authors have proposed weaker consistency
  models
• Cheaper to implement
• Harder to use in a correct fashion
• TreadMarks usessoftware release consistency
• Only requires the memory to be consistent at
  specific synchronization points

29
SW release consistency (I)

• Well-written parallel programs use locks to
  achieve mutual exclusion when they access shared
  variables
• P(mutex) and V(mutex)
• lock(csect) and unlock(csect)
• acquire( ) and release( )
• Unprotected accesses can produce unpredictable
  results

30
SW release consistency (II)

• SW release consistency will only guarantee
  correctness of operations performed within a
  request/release pair
• No need to export the new values of shared
  variables until the release
• Must guarantee that workstation has received the
  most recent values of all shared variables when
  it completes a request

31
SW release consistency (III)

• shared int x
• acquire( )// wait for new value of x
• xrelease ( )
• // export x2

• shared int x
• acquire( ) x 1release ( )
• // export x1

32
SW release consistency (IV)

• Must still decide how to release updated values
• TreadMarks uses lazy release
• Delays propagation until an acquire is issued
• Its predecessor Munin used eager release
• New values of shared variables were propagated at
  release time

33
SW release consistency (V)
Eager release
Lazy release
34
False sharing
accesses y
accesses x
x y
page containing x and y will move back and
forthbetween main memories of workstations
35
Multiple write protocol (I)

• Designed to fight false sharing
• Uses a copy-on-write mechanism
• Whenever a process is granted access to
  write-shared data, the page containing these data
  is marked copy-on-write
• First attempt to modify the contents of the page
  will result in the creation of a copy of the
  page modified (the twin).

36
Creating a twin
37
Multiple write protocol (II)

• At release time, TreadMarks
• Performs a word by word comparison of the page
  and its twin
• Stores the diff in the space used by the twin
  page
• Informs all processors having a copy of the
  shared data of the update
• These processors will request the diff the first
  time they access the page

38
Creating a diff
39
Example
Before
First write access
x 1 y 2
x 1 y 2
twin
After
Compare with twin
x 3 y 2
New value of x is 3
40
Multiple write protocol (III)

• TreadMarks could but does not check for
  conflicting updates to write-shared pages

41
The TreadMarks system

• Entirely at user-level
• Links to programs written in C, C and Fortran
• Uses UDP/IP for communication (or AAL3/4 if
  machines are connected by an ATM LAN)
• Uses SIGIO signal to speed up processing of
  incoming requests
• Uses mprotect( ) system call to control access to
  shard pages

42
Performance evaluation (I)

• Long discussion of two large TreadMarks
  applications

43
Performance evaluation (II)

• A previous paper compared performance of
  TreadMarks with that of Munin
• Munin performance typically was within 5 to 33
  of the performance of hand-coded message passing
  versions of the same programs
• TreadMarks was almost always better than Munin
  with one exception
• A 3-D FFT program

44
Performance Evaluation (III)

• 3-D FFT program was an iterative program that
  read some shared data outside any critical
  section
• Doing otherwise would have been to costly
• Munin used eager release, which ensured that the
  values read were not far from their true value
• Not true for TreadMarks!

45
Other DSM Implementations (I)

• Sequentially-Consistent Software DSM (IVY)
• Sends messages to other copies at each write
• Much slower
• Software release consistency with eager release
  (Munin)

46
Other DSM Implementations (II)

• Entry consistency (Midway)
• Requires each variable to be associated to a
  synchronization object (typically a lock)
• Acquire/release operations on a given
  synchronization object only involve the variables
  associated with that object
• Requires less data traffic
• Does not handle well dusty decks

47
Other DSM Implementations (III)

• Structured DSM Systems (Linda)
• Offer to the programmer a shared tuple space
  accessed using specific synchronized methods
• Require a very different programming style

48
CONCLUSIONS

• Can build an efficient DSM entirely in user
  space
• Modern UNIX systems offer all the required
  primitives
• Software release consistency model works very
  well
• Lazy release is almost always better than eager
  release
