Organization and Emergence ofSemantic Knowledge
A Parallel-Distributed Processing Approach

• James L. McClelland
• Department of Psychology
• and
• Center for Mind, Brain, and Computation
• Stanford University

2
Some Phenomena in Conceptual Development

• Progressive differentiation of concepts
• Illusory correlations and U-shaped developmental
  trajectories
• Conceptual reorganization
• Domain- and property-specific constraints on
  generalization
• Acquired sensitivity to an objects causal
  properties
• What underlies these phenomena?

3
Naïve Domain Theories?

• Mechanisms of learning are thought to be too weak
• They learn by contiguity and generalize by
  similarity
• But generalization is domain dependent.
• .. so it is proposed instead that development
  begins with initial constraints, in the form of
  innately pre-specified proto-theories that guide
  inference and learning.

4
An Alternative ViewSensitivity to Coherent
Covariation

• Coherent Covariation
• The tendency of properties of objects to co-occur
  in clusters.
• e.g.
• Has wings
• Can fly
• Is light
• Or
• Has roots
• Has rigid cell walls
• Can grow tall

5
Our Answer in More Detail

• Domain general mechanisms sensitive to experience
  underlie the development and elaboration of
  conceptual knowledge.
• These mechanisms exploit the principles of
  parallel-distributed processing.
• Models built on these principles are sensitive to
  coherent covariation.
• This sensitivity is the main cause of all of the
  phenomena.

6
Principles of Parallel Distributed Processing
/h/ /i/ /n/ /t/

• Processing occurs via interactions among
  neuron-like processing units via weighted
  connections.
• A representation is a pattern of activation.
• The knowledge is in the connections.
• Learning occurs through gradual connection
  adjustment, driven by experience.
• Both representation and processing are affected.

H I N T
7
Principles of Parallel Distributed Processing
/h/ /i/ /n/ /t/

• Processing occurs via interactions among
  neuron-like processing units via weighted
  connections.
• A representation is a pattern of activation.
• The knowledge is in the connections.
• Learning occurs through gradual connection
  adjustment, driven by experience.
• Both representation and processing are affected.

H I N T
8
Principles of Parallel Distributed Processing
/h/ /i/ /n/ /t/

• Processing occurs via interactions among
  neuron-like processing units via weighted
  connections.
• A representation is a pattern of activation.
• The knowledge is in the connections.
• Learning occurs through gradual connection
  adjustment, driven by experience.
• Both representation and processing are affected.

H I N T
9
Principles of Parallel Distributed Processing
/h/ /i/ /n/ /t/

• Processing occurs via interactions among
  neuron-like processing units via weighted
  connections.
• A representation is a pattern of activation.
• The knowledge is in the connections.
• Learning occurs through gradual connection
  adjustment, driven by experience.
• Both representation and processing are affected.

H I N T
10
Differentiation in Developmentand in a simple
PDP network
11
(No Transcript)
12
The Rumelhart Model
13
QuilliansHierarchicalPropositional Model
14
The Rumelhart Model Target output for robin
can input
15
The Training Data
All propositions true of items at the bottom
levelof the tree, e.g. Robin can fly, move,
grow
16
Forward Propagation of Activation
17
Back Propagation of Error (d)
aj
wij
ai
di Sdkwki
wki
dk (tk-ak)
Error-correcting learning At the output
layer Dwki edkai At the prior layer Dwij
edjaj
18
The Rumelhart Model
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
What Drives Progressive Differentiation?

• Waves of differentiation reflect coherent
  covariation of properties across items.
• Patterns of coherent covariation are reflected in
  the principal components of the property
  covariance matrix.
• Figure shows attribute loadings on the first
  three principal components
• 1. Plants vs. animals
• 2. Birds vs. fish
• 3. Trees vs. flowers
• Same color features covary in
  component
• Diff color anti-covarying
  features

23
Now wait just a minute

• Didnt you tell the network the taxonomic
  organization directly?
• Pine ISA Tree, Plant
• Robin ISA Bird, Animal
• Yes we did.
• We do think names kids hear for things affect
  their conceptual representations.
• But labels arent necessary as long as an items
  properties exhibit coherent covariation.

24
Properties Coherent Incoherent
CoherenceTraining Patterns
Items
No labels are provided Each item and each
property occurs with equal frequency
25
Properties Coherent Incoherent
ISCANHAS
Contexts
Items
Note coherence is present between, not within
training experiences!
26
Effects of Coherence on Learning
CoherentProperties
Incoherent Properties
27
Effect of Coherence on Representation
28
Effects of Coherent Variation on Learning in
Connectionist Models

• Attributes that vary together create the acquired
  concepts that populate the taxonomic hierarchy,
  and determine which properties are central and
  which are incidental to a given concept.
• Labeling of these concepts or their properties is
  in no way necessary.
• But it is easy to learn names for such concepts.
• Arbitrary properties (those that do not co-vary
  with others) are very difficult to learn.
• And it is harder to learn names for concepts that
  are only differentiated by such arbitrary
  properties.

29
Where are we on that list of Phenomena?

• Progressive differentiation of concepts
• Illusory correlations and U-shaped developmental
  trajectories
• Conceptual reorganization
• Domain- and property-specific constraints on
  generalization
• Acquired sensitivity to an objects causal
  properties

30
Illusory Correlations

• Rochel Gelman found that children think that all
  animals have feet.
• Even animals that look like small furry balls and
  dont seem to have any feet at all.

31
A typical property thata particular object
lacks e.g., pine has leaves
An infrequent, atypical property
32
Conceptual Reorganization (Carey, 1985)

• Carey demonstrates that young children discover
  the unity of plants and animals as living things
  with many shared properties only around the age
  of 10.
• She suggests that the coalescence of the concept
  of living thing depends on learning about diverse
  aspects of plants and animals including
• Nature of life sustaining processes
• What it means to be dead vs. alive
• Reproductive properties
• Can reorganization occur in a connectionist net?

33
Conceptual Reorganization in the Model

• Suppose superficial appearance information, which
  is not coherent with much else, is always
  available
• And there is a pattern of coherent covariation
  across information that is contingently available
  in different contexts.
• The model forms initial representations based on
  superficial appearances.
• Later, it discovers the shared structure that
  cuts across the different contexts, reorganizing
  its representations.

34
Organization of Conceptual Knowledge Early and
Late in Development
35
Inference and Generalizationin the PDP Model

• A semantic representation for a new item can be
  derived by error propagation from given
  information, using knowledge already stored in
  the weights.
• Crucially
• The similarity structure, and hence the pattern
  of generalization depends on the knowledge
  already stored in the weights.

36
Start with a neutral representation on the
representation units. Use backprop to adjust the
representation to minimize the error.
37
The result is a representation similar to that of
the average bird
38
Use the representation to infer what this new
thing can do.
39
Inference and Generalizationin the PDP Model

• A semantic representation for a new item can be
  derived by error propagation from given
  information, using knowledge already stored in
  the weights.
• Crucially
• The similarity structure, and hence the pattern
  of generalization, depends on the knowledge
  already stored in the weights.

40
Domain Specificity

• What constraints are required for development and
  elaboration of domain-specific knowledge?
• Are domain specific constraints required?
• Or are there general principles that allow for
  acquisition of conceptual knowledge of all
  different types?

41
Differential Importance (Marcario, 1991)

• 3-4 yr old children see a puppet and are told he
  likes to eat, or play with, a certain object
  (e.g., top object at right)
• Children then must choose another one that will
  be the same kind of thing to eat or that will
  be the same kind of thing to play with.
• In the first case they tend to choose the object
  with the same color.
• In the second case they will tend to choose the
  object with the same shape.

42

• Can the knowledge that one kind of property is
  important for one type of thing while another is
  important for a different type of thing be
  learned?

43
Adjustments to Training Environment

• Among the plants
• All trees are large
• All flowers are small
• Either can be bright or dull
• Among the animals
• All birds are bright
• All fish are dull
• Either can be small or large
• In other words
• Size covaries with properties that differentiate
  different types of plants
• Brightness covaries with properties that
  differentiate different types of animals

44
Testing Feature Importance

• After partial learning, model is shown eight test
  objects
• Four Animals
• All have skin
• All combinations of bright/dull and large/small
• Four Plants
• All have roots
• All combinations of bright/dull and large/small
• Representations are generated by
  usingback-propagation to representation.

45
Similarities of Obtained Representations
Brightness is relevant for Animals
Size is relevant for Plants
46

• In Rogers and McClelland (2004) we also address
• Conceptual differentiation in prelinguistic
  infants.
• Many of the phenomena addressed by classic work
  on semantic knowledge from the 1970s
• Basic level
• Typicality
• Frequency
• Expertise
• Disintegration of conceptual knowledge in
  semantic dementia
• How the model can be extended to capture causal
  properties of objects and explanations.
• What properties a network must have to be
  sensitive to coherent covariation.

47
Coherence Requires Convergence
A
A
48
Semantic Representation in the Brain

• Damage to temporal pole is associated with
  semantic dementia, a domain-general loss of
  semantic information
• Imaging and lesion studies suggest that other
  brain areas are associated with more specific
  types of information.
• We suggest that the temporal pole serves as the
  convergent semantic representation in the brain.
• With bi-directional connections to regions
  containing modality specific information.
• The interface with language occurs via
  connections between language areas and temporal
  pole.

49

• In summary
• Sensitivity to coherent co-variation in
  experience can explain many aspects of conceptual
  development.
• PDP networks subject to a domain-general
  architectural constraint provide the necessary
  mechanisms.
• Our simulations do not prove domain general
  learning methods will turn out to be fully
  sufficient.
• There is still room for domain- or
  content-specific constraints
• And the framework is fully compatible with their
  integration.
• But our findings suggest it may be worth
  exploring how far we can go without them.

50
Thanks for your attention!
51
(No Transcript)
52
Proposed Architecture for the Organization of
Semantic Memory
name
action
motion
Temporal pole
color
form
valance
53
Generalization of different property types

• At different points in training, the network is
  taught one of
• Maple can queem
• Maple is queem
• Maple has queem
• Only weights from hidden to output are allowed to
  change.
• Network is then tested to see how strongly
  queem is activated then same relation is paired
  with other items.

queem
54
Generalization to other concepts after training
with can, has, or is queem
55
(No Transcript)
56
Overview

• The PDP Framework for Processing, Representation
  and Learning
• Complimentary Learning Systems in Hippocampus and
  Neocortex
• Differentiation and Reorganization of Conceptual
  Knowledge
• Inference and Generalization
• How the Complimentary Learning Systems Cooperate
• What kinds of innate constraints are necessary?

57
Modeling Inductive Inference(Osherson et al,
1990)

• General
• If a dolphin, a whale, and a zebra have biotin in
  their blood, how strong is the implication that
  all mammals have biotin in their blood?
• Specific
• If a seal and a cow have biotin in their blood,
  how strong is the implication that a horse has
  biotin in its blood?

58
PDP (as in Rogers McClelland, 2004)

• Train a network on the item-feature matrix (50
  animals have a 0 or 1 for each of 85 features)

Animals
Hidden Layers
Features
59
PDP

• Add a new feature, and train the net using the
  given examples. Only allow the weights to the new
  feature node to change, and train to a threshold
  of 0.85.

Animals
Hidden Layers
Features
60
Results

• Using Osherson et als similarity-based model
  with the networks hidden representations, which
  emphasize coherent covariation, results in
  improved performance
• Kemp, Perfors and Tenenbaums Bayes Tree model
  seems to do even better, but we suspect possible
  over-fitting.

61
Use the hippocampal memorysystem to store a
memoryfor the learning episode.
Hippocampus
sparrow
If the pattern can be reinstated at a later time,
it can be usedto support further inferences.
62
Relation-specificrepresentations

• IS Representations (top) reflect idiosyncratic
  appearance properties.
• HAS representations are similar to the
  context-general representations (middle).
• Can representations collapse differences between
  plants, since there is little that plants can do.
• The fish are all the same, because theres no
  difference in what they can do.

63
What About Causal Knowledge?

• Young children can attribute causal powers to
  objects based on single observations of scenarios
  in which the objects participate.
• Gopniks blickett experiments
• Causal powers are central to childrens
  generalization of category membership
• They assign the same name to objects with
  different appearance properties but similar
  causal powers.
• Do we need an innate mechanism for causal
  inference, as Gopnik suggests, to address these
  findings and other aspects of childrens causal
  reasoning abilities?

64
My Perspective

• Causal relations are not that different than
  other kinds of relations.
• Domain general mechanisms that are sensitive to
  experience underlie the development and
  elaboration of causal as well as other forms of
  conceptual knowledge.
• These mechanisms acquire sensitivity to causal
  structure through gradual learning.

65
Extension of the Model toCausal Inference (In my
dreams?)

• Networks can learn to form internal
  representations that capture causal powers of
  objects, based on the consequences of their
  participation in events.
• Appearance properties dont covary that that well
  with the causal powers of objects.
• Furthermore, the names of (man-made) objects
  co-vary with their causal powers, not with their
  appearance.
• Radio
• Telephone
• Razor
• Switch
• Thus, it would be natural for networks to learn
  to generalize names for objects based on their
  causal powers, rather than their appearance.

Item
Context (External and Internal)
Sequelae
66
But havent you still left something under the
rug?

• No, not really
• everything is right out in the open.
• Heres the situation
• Each example of an item always activates the same
  input unit.
• Each context always activates the same context
  unit.
• Each property always activates the same property
  unit.
• Each item, context, and property unit is like one
  of Fodors atomic concept representations
• A representation R expresses the property P in
  virtue of its being a law that things that are P
  cause tokenings of R.
• Such stipulations are by no means unproblematic
• But everyone has this problem, including Jerry

67
This Problem is Solved by Distributed
Representations

• The localist input, context and output units can
  be replaced with distributed patterns of
  activation
• (Rogers McClelland, Chapter 5 Rogers et al,
  2005 Dilkina and McClelland).
• The units correspond to atomic microconcepts
• Each item, context, and property is represented
  by a (possibly somewhat variable) ensemble of
  them.
• The number of possible concepts that can be
  distinguished is now far greater (2N vs N).
• Networks can learn
• Which microconcepts are important (and which
  combinations are important)
• Which microconcepts should be treated as
  equivalent
• Which microconcepts should be ignored
• All of this depends on patterns of covariation.
• This is a very good thing for everyone (even
  Jerry!)
• it makes it possible for a system with finite
  resources to cover the space of possible concepts
  that might turn out to be needed.
