4th ITU Green Standards Week

1
4th ITU Green Standards Week
Introduction of Government Cloud and Smart Haidian

• Jianwu He
• Economy and Informationization Office Haidian
  District Beijing

2
4th ITU Green Standards Week
Overall Architecture of Smart Haidian
3
4th ITU Green Standards Week
Background of Building Administrative Cloud

• Capable of self-control, and be able to access to
  resources by lowering the overall cost (compute,
  storage and network transmission)
• Enables unified management of computing and
  storage resources, to achieve the commissions
  Bureau supply-demand about resources
• Unified management of data storage, to dig deeply
  and to analyze quickly and intelligence of large
  amounts of data from different departments
• Enable to achieve high fault-tolerant computing
  and storage capacity, and effectively improve the
  security of computing and data storage

4
4th ITU Green Standards Week
Background of Building Administrative Cloud

• Based on distributed computing and storage
  (Hadoop architecture) big data platform to
  support the future development direction of
  important and intelligent analysis of large data
  storage, and has three major advantages
• High availability, can provide outstanding fault
  tolerance ability
• High scalability, through the PC server and
  storage can realize resource linear expansion
• Low cost, does not require the use of expensive
  high-end servers and memory, greatly reduce the
  construction cost of the data center

5
4th ITU Green Standards Week
Architecture of Government Cloud
6
4th ITU Green Standards Week
The Construction of Network Infrastructure
To lay a solid foundation for cloud computing
network of e-government and other kinds of
applications
7
4th ITU Green Standards Week
The Comprehensive Administrative Service
Management System
8
4th ITU Green Standards Week
The Approval Process Management System

• The whole district transact three linkage
  approval
• Investment in fixed assets of collaborative
  approval
• Establishment of enterprise collaborative
  approval
• Enterprise single matter approval
• Online administrative approval
• The other application systems

9
4th ITU Green Standards Week
Statistics
The Approval Management System
Monitor
Query
The whole district transact three linkage approval
Investment in fixed assets of collaborative
approval

• Individuals48
• Enterprises75
• To provide basic information on matters, legal
  basis, the application materials, the post
  responsibility, classification, subject matters
  of module management
• Each item has a unique code, easy to query and
  management

• Matters need in the center office, the
  Legislative Affairs Office and other relevant
  departments to audit and release
• Ensure matters of standard, egality and
  uniqueness

Establishment of enterprise collaborative approval

• Associate issues with the user, different users
  to view different matters
• Associate matters and process
• Associate issues with the theme odules

• Matters can be enabled after the audit
• Items can be deactivated, closure matters still
  can query the management information

Enterprise single matter approval
Online administrative approval
The other application systems
10
4th ITU Green Standards Week
The Approval Process Management System

• Provide support and management for 48 individual
  events, 75 enterprise approval process and 4
  stages of the approval process
• Provides a unified workflow engine, process
  scheduling and approval of business support
  system
• Provides visual process design, implementation
  and business process alignment, easy to review
  and revise
• To realize the dynamic real-time monitoring of
  each process node, provides overtime warning
  function.

11
4th ITU Green Standards Week
Multilevel Linkage Approval Function
12
4th ITU Green Standards Week
User management Authentication
13
4th ITU Green Standards Week
Grid Service Management Integrated Information
Network

• Letters for the grid community service
  information platform
• Acquisition of Basic Data
• Sharing, exchange, application of database
• Has been basically completed the construction of
  grid database system integrated data center,
  integration of the information resources, the
  realization of Haidian District ", matter, thing,
  organization" scientific, precise, intelligent
  management.
• Construct the District Public Security Bureau
  special database, the District Family Planning
  Commission special database, Human Social
  Security special database, the District
  Comprehensive Management special database,
  special database, the District Board of Education
  special database, the District Civil Affairs
  Bureau, the District CDPF special database, the
  District Health Bureau special database.
• Establish the data maintenance and updating
  mechanism, ensure the timeliness and accuracy of
  data the data to ensure the legal department to
  maintain the authority and accuracy of data.

14
4th ITU Green Standards Week
Grid Service Management Integrated Information
Network

• Community Service Management
• Non emergency system and social management
  system, Informational City Management System,
  Video System And Social Management System
• The integration of information acquisition method
• Finish the three level mesh and data storage
  layer, and set up user accounts according to the
  three level name of the grids, each grid division
  for the scope of authority

15
4th ITU Green Standards Week
Acquisition Of Basic Data
16
4th ITU Green Standards Week
Acquisition Of Basic Data
Data Update Mechanism
Establish the data maintenance and updating
mechanism, ensure the timeliness and accuracy of
data the data to ensure the legal department to
maintain the authority and accuracy of data.
17
4th ITU Green Standards Week
Community Service Management
18
4th ITU Green Standards Week
Community Service Management
(1)Non emergency system and social management
system

• Through the handheld terminal acquisition
  community service to manage the problem

• Realize the Internet Letters Data access

(2)Informational City Management System, Video
System And Social Management System
(3)The integration of information acquisition
method

• Include the Urban Management Supervisors team
  into the grid work of Social Service Management
  information platform

19
4th ITU Green Standards Week
Nansha River Basins Flood Prevention System
20
4th ITU Green Standards Week
Nansha River Basins Flood Prevention System

• Nansha River Basins Flood Prevention System
  mainly include
• 1 basic application subsystem Integrated
  Information Service System
• 4 professional application subsystemSmall
  watershed flood-forecast, flood-control
  dispatching system, torrent disasters warning and
  water quality monitoring.

21
4th ITU Green Standards Week
Nansha River Basins Flood Prevention System

• Water Affairs Information Acquisition
• The main monitoring targets are water gates, dam,
  watercourse, drains and so on, and the system can
  collect, upload and share the water regimen,
  rainfall ,real image information automatically.
  Then do the data processing at fastest speed and
  show the results with visualize image so that
  provide decision support.
• There are 37 water affairs information gathering
  points 11 video monitor points , 10 water level
  monitor points, 4 water quality monitor points, 5
  flows monitor points (return flow and water
  level values), 7 rainfall monitor points.
• Water Affairs Integrated Information Service
• Provide the direct-viewing results of spatial
  database and related attribute information
  inquiry, retrieval, analysis and dissemination.
• Flood control and drainage dispatching simulation
  system
• In real-time scheduling, the system will generate
  a set of plans to one object for decision makers
  reference. Scheduling plans management system is
  mainly for all sectors of scheduling plans
  information management.

22
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• Comprehensive information service subsystem helps
  schedulers to clear the goals and the major
  problems of flood control by rainfall analysis,
  disaster analysis, project operation analysis and
  so on.

Situation Analysis
Plan Generation
Plan Simulation
Plan Comparison
Plan Management
23
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• The system can achieve the function of
  flood pre-discharge dispatching of reservoir and
  real-time management by integrating the weather,
  real-time water regimen and flood forecast
  information, combining the water gate real time
  running status information and the intelligence
  scheduling model.

Situation Analysis
Plan Generation
Plan Simulation
Plan Comparison
Plan Management
24
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• Plan Simulation visualization shows results with
  presentation of concise, simple and visualize
  information. System adopts conceptual diagram and
  3D electronic sand to show the simulation
  results

Situation Analysis
Plan Generation
Plan Simulation
Plan Comparison
Plan Management
25
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• Plan comparison system mainly does the comparison
  of engineering application, application effects
  etc. from sets of plans, which for decision
  makers reference.

Situation Analysis
Plan Generation
Plan Simulation
Plan Comparison
Plan Management
26
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• In real-time scheduling, the system will generate
  a set of plans to one object for decision makers
  reference. Scheduling plans management system is
  mainly for all sectors of scheduling plans
  information management

Situation Analysis
Plan Generation
Plan Simulation
Plan Comparison
Plan Management
27
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• Small Watershed Flood Forecast
• The goals of the system are the improvement of
  both the timeliness and accuracy of flood control
  decision making, providing the technical support
  for flood control and reducing the loss,
  according to the functions that real-time flood
  warning, flood submergence analysis, loss
  assessment, flood control regulation simulation
  etc.
• Flash Flood Warning
• Judge the warning situation according to status
  of monitoring
• Judge the warning sending objects
• Adopt both automatically and manually sending
  ways to post warning messages
• The relevant departments should launch the
  appropriate response plan according to the
  warning results and information release
  conditions. The system will trace all towns'
  implementation till the response action is end.

28
4th ITU Green Standards Week
Flood control and drainage dispatching simulation
 system

• Water Quality Monitoring
• Mainly realized the function of real-time water
  quality information monitoring. System evaluates
  water quality data in terms of national
  Evaluation Criteria. If the water is detected has
  exceed, then send message to crews, which
  provides support for watershed management.

29
4th ITU Green Standards Week
Thank you
