4th ITU Green Standards Week
The New Revolution Of Urban Rail Transit
Informatization

• Wuhan Research Institute Of
• Posts Telecommunication
• FiberHome Group
• Jie Dong

2
Market Size Of Urban Rail Transit Informatization
During the "Twelfth Five-Year", the
national Rail Transit will put into operation to
2500 Km. At the end of 2020, the total mileage
will reach to 7000 Km, where the informatization
is a very important part of the construction.
The Total Investment Of Urban Rail Transit(One
Hundred Million)
The Applications Of The Rail Transit
Informatization
Proportion Of The Rail Transit Informatization
Passengers Information Display System Carriage
Video Monitoring Train Operation
Monitoring Voice Trunking Service ..
15000
13500
43
12000
10500
Informatization 4 ,960
9000
3000
0
2011-2015
2016-2020
3
Technology Status And Development Trend
The requirement of Rail Transit Informatization
are rising Control Center use the
real-time monitoring to control the running
train, and provide a wealth of real-time
information service for passengers. It will
improve the operational management, efficiency
and quality of service.

• Now the Digital Broadcast Television and WLAN
  technology can not meet the requirements of
  High-Bandwidth services during the High-Speed
  movement

Restricting The development of Rail Transit
Informatization
TD-LTE technology with High-Bandwidth, High
Mobility, Seamless Handover performance. It is
one of the most mature and advanced communication
technology, which will meet the wireless
communication requirements of the Rail Transit.
4
The advantages of TD-LTE Technology
TD-LTE WLAN
Anti-Interference Capability Private Band, Low Interference Use ICIC,IRC Anti-Interference Tech,Solve the in-system interference problem Public Band, Inevitable External Interference Lack of Anti-Interference Tech within the system
Throughput Rate At 10MHz bandwidth. Uplink and downlink resources 1 1, the downlink peak is 20Mpbs and the uplink peak reach to 8Mbps. Also the uplink and downlink rate are adjustable. In the actual project, using 20MHz bandwidth, downlink peak is 15Mbps and uplink peak is 2Mbps.
Mobility With Anti-Frequency Shift algorithm, supports over 300Km/H movement, fully meet the speed requirements of Urban Rail Transit. WLAN as a fixed wireless access technology, mainly used in slow movements. No Anti-Frequency Shift algorithm.
Band Flexibility Supports 1.4/3/5/10/15/20MHz network according to the requirements Limited to 20MHz Bandwidth of 2.4G
Costs Of Construction And Maintenance Can use the Leaky Coaxial Cable The output power of AP is so low that we need to place an AP each 200 meters, so it is not suitable for Leaky Coaxial Cable, also the construction is difficult and maintenance costs will be high.
Coverage Distance Single RRU can cover 1.2Km in tunnels Single AP 200m
5
LTE Wireless Communication System For Rail
Transit
Control Subsystem
Base Station Subsystem
On Train Subsystem
6
Requirements Of Rail Transit Wireless
Communication System
Carriage Video Monitoring (CCTV)
CBTC Signal System
Passenger Information System (PIS)
Train Operation Monitoring
Voice Trunking Service
7
Requirements Of Rail Transit Wireless
Communication System PIS Transmission
To achieve the High-Bandwidth Real-time video
transmission between ground and train during the
High-Speed movement.
8
Requirements Of Rail Transit Wireless
Communication System Carriage Video Monitoring
Train Monitoring
To achieve the bidirectional High-Bandwidth
Real-time Carriage Video Monitoring between
ground and train during the High-Speed movement.
9
Requirements Of Rail Transit Wireless
Communication System Train Operation
Monitoring
Train Operation Monitoring by using the
Rail Transit wireless communication system, it
can uploaded the train Operation data to the
ground centers near real-time. Its effectively
support the Maintenance Department manage the
train databases. To achieve a low rate
Train to Ground data transmission in the
High-speed movement near real-time.
10
Requirements Of Rail Transit Wireless
Communication System Voice Trunking Service
Voice Trunking Service by using the Rail
Transit wireless communication system, The driver
can use real-time voice communication with the
ground control center and accept emergency
dispatch. To achieve a low rate voice
intercom and trunked dispatching in the
High-speed movement at real-time.
11
Requirements Of Rail Transit Wireless
Communication System CBTC Signal System
CBTC Signal System by using the Rail
Transit wireless communication system, it realize
the bidirectional transmission of CBTC data
between the train and the ground, ensure the
train operation safety. To achieve a low
rate\ high reliability bidirectional transmission
in the High-speed movement near real-time.
12
Requirements Of Rail Transit Wireless
Communication System
Services Direction Of Data Flow Bandwidth Needs Real-Time Requirement Others
PIS Real-time Broadcast Ground -gtTrain H Real-Time The underlying high quality broadcast channel(Downlink)
PIS Record Broadcast Ground -gtTrain H Non Real-Time The underlying multicast channel
Train Real-Time Video Monitoring (Train To Center) Train -gt Ground H Real-Time The underlying high quality real-time data channel
Ground Real-Time Video Monitoring (Ground To Drive) Ground -gtTrain H Real-Time The underlying high quality real-time data channel
Train Operation Monitoring Train -gt Ground L Quasi Real-Time
Public Internet On Train Bidirectional H Non Real-Time
Voice Trunking Service Bidirectional L Real-Time Underlying dedicated channel, Trunking-specific signaling support
CBTC Signal System Bidirectional L Real-Time Underlying redundant dedicated channel
13
TD-LTE Based Five Applications Of The Rail Transit
Carriage Video Monitoring (CCTV)
Passenger Information System (PIS)
CBTC Signal System
TD-LTE Based Five Applications Of The Rail
Transit
Train Operation Monitoring
Voice Trunking Service
14
The Innovation Of Industry Informatization
Innovation 2
Innovation 1
Innovation 3
By using one LTE Wireless Network to achieve
several existing Rail Transit network functions,
achieve the Multi-network integration,
Multi-system integration and Multi-service
integration
By using Wireless Dispatch Compensation Algorithm
to solve Handover and Time Delay problems during
the High-speed movement, to ensure the voice and
video transmission at real-time
Based on TD-LTE technology, achieve the
high-bandwidth transmission during the High-speed
movement
Industry Informatization Multi-Network Integration
Industry Informatization High Bandwidth
Industry Informatization High Mobility
15
FiberHome Mature Commercial TD-LTE Products

• Successfully developed the TD-LTE 1-channel,
  2-channel, 8-channel base station.
• Products passed the laboratory tests and field
  tests of MIIT.
• In 2011, FiberHome join the construction of
  TD-LTE scale trial network in 6 cities ,finished
  the construction of the Guangzhou-scale TD-LTE
  trial network with 122 sites.
• In 2012, FiberHome was responsible for Ningbo
  scale TD-LTE trial network construction task.
• In 2013 and 2014, Winning of China Telecom LTE
  tender Winning China Unicom LTE tender
  Winning China Mobile LTE tender.

Macro BBU
RRU
Guangzhou Trial Network Project
Publicly Display Of Tender Results
Small Cell
16
The Experience In Commercial Rail Systems
Integration Projects
FiberHome Group has nearly 10 years of
experience in the rail transportation
construction and project management.
Train Operation Monitoring
Live TV
PIS
Equipment Maintenance
Video Monitoring
Value-added services
17
Wireless Industry Dream of FiberHome

• Into the Twelve Five, FiberHome build Wireless
  Industrial Park with the international advanced
  level of research?development and production,
  committed to
• To be the best Wireless Communication Network
  Optimization Solutions provider
• To be the mainstream provider of 3G / 4G
  wireless access services integrated solutions
• Promote capital operation and internationalizatio
  n strategy, to achieve the domestic leading and
  international well-known level

FiberHome Wireless Industrial Park
18
