Nuclear Chemistry

1
Nuclear Chemistry
2
Radioactivity

• One of the pieces of evidence for the fact that
  atoms are made of smaller particles came from the
  work of Marie Curie (1876-1934).
• She discovered radioactivity or radioactive
  decay, the spontaneous disintegration of the
  nuclei of some elements.

3
Isotopes

• Isotopes different numbers of NEUTRONS
• Some isotopes more stable than others

4
Band of Stability

• Shows the ratios of protons to neutrons in a
  stable nucleus

5
Radioisotopes

• isotopes with unstable nucleus
• undergo radioactive decay
• Elements with atomic number 83 and up are
  radioactive
• Bismuth and beyond..

6
Radioactivity or Radioactive Decay

• describes the spontaneous change(s) that
  radioisotopes undergo to become stable

7
Radioactivity or Radioactive Decay

• An unstable nucleus gives off particles and/or
  energy
• This changes the atomic number (p) and forms a
  new element with a more stable nucleus
• Transmutation- the change in the identity of the
  element after it undergoes radioactive decay

8
Nuclear Reactions vs. Normal Chemical Changes

• Normal Chemical Reactions involve rearranging
  atoms. The elements dont change.
• Nuclear reactions involve the nucleus
• The nucleus opens, and protons and neutrons are
  rearranged
• The opening of the nucleus releases a tremendous
  amount of energy that holds the nucleus together

9
Radiation

• The penetrating rays (energy or particles)
  emitted by a radioactive source

10
Types of Radiation

• Alpha
• Beta
• Gamma
• Positron Emission
• Electron Capture

11
Types of Radiation

• Alpha (a) a positively charged helium nucleus
• Beta (ß) an electron
• Gamma (?) pure energy called a ray rather than
  a particle

12
Other Nuclear Particles

• Neutron
• Positron a positive electron
• Proton usually referred to as hydrogen-1

13
Penetrating Ability
14
Equations

• Radioactive Decay is represented with an equation
• Protons and masses on both sides of the equation
  MUST balance

15
Balancing Nuclear Reactions

• In the reactants (starting materials on the
  left side of an equation) and products (final
  products on the right side of an equation)
• Atomic numbers must balance
• and
• Mass numbers must balance
• Use a particle or isotope to fill in the missing
  protons and neutrons

16
Alpha Radiation
17
Nuclear Reactions

• Alpha emission
• Masses (top numbers) add up to 238 on both sides
  of arrow
• The number of protons (bottom numbers) are both
  equal

Note that mass number (A) goes down by 4 and
atomic number (Z) goes down by 2.
Nucleons (nuclear particles protons and
neutrons) are rearranged but conserved
18
Nuclear Reactions

• Alpha emission
• Try this one
• Po 210 undergoes alpha radiation

19
Beta Decay
20
Nuclear Reactions

• Beta emission

Note that mass number is unchanged and atomic
number goes up by 1.
21
Nuclear Reactions

• Beta emission
• Try this one
• Uranium 238 undergoes beta decay

22
Gamma Radiation

• High energy photon, usually released with alpha
  or beta particles
• What are photons?
• Gamma rays have very high energy, and must be
  shielded using lead or concrete

23
Gamma Radiation
24
Alpha, Beta, Gamma Charges
25
Sum up the 3 main types
26
Nuclear Fission
27
Nuclear Fusion
28
Nuclear Reaction
29
Nuclear Power Plants
30
So you say you want to meltdown your own power
plant? Heres your chance to play Homer Simpson.
31
Nuclear Power Pros and Cons

• Lots of energy
• No green house gases
• Uses very little fuel

• Very small chance of massive disaster
• Potential target for terrorists
• Nuclear waste

32
Accidents can happen

• The worst nuclear accident in US history occurred
  on Three Mile Island in PA 1979
• The reactor meltdown was caused by several
  mechanical errors as well as human error creating
  a coolant leak
• The reactor that had the melt down is no longer
  in use. The other reactor is slated to remain in
  use until 2034
• London Calling by The Clash is about this
  accident

33
Chernobyl April 1986

• Chernobyl Nuclear Power Plant Pripyat, Ukraine
  April 1986
• During a test, the reactor received a power
  spike, causing several explosions
• Radiation was picked up several hundred miles
  away, prompting the Soviet Union to admit the
  accident, 3 days after it happened

34
Japan Fukushima Power Plant March 2011
35
Radiation Detection

• Film Badges exposure of film measures radiation
  exposure
• Geiger Counters- detect radiation through
  electric pulses in ionized gas
• Scintillation Counters- measure radiation from
  substances that emit visible light when energy is
  absorbed

36
Radiation Detection
37
Uses of Radiation

• Radioactive dating can determine the approximate
  age of an object
• There are many uses of radiation in the medical
  field
• Detect and kill cancerous cells
• X-Rays
• Many others
• Disinfect foods

38
Personal Dose Chart
39
Effects of Radiation on the Body
40
Half Life

• Time it takes for ½ a sample to decay
• No two radioisotopes decay at the same rate
• Can be as short as a few seconds or take billions
  of years.

41
(No Transcript)
42
(No Transcript)
43
Half Life

• Uranium-238 has a half-life of 4.5 billion years.
  Its stable ending element is lead (Pb)

44
Half Life
45
Half Life
46
Half Life

• A 2.5 g sample of an isotope of strontium-90 was
  formed in a 1960 explosion of an atomic bomb at
  Johnson Island in the Pacific Test Site. The
  half-life of Sr-90 is 28 years.
• How many years will it take for 0.625 grams of
  Sr-90 to remain?
• What year will this be?

47
Half Life

• A 2.5 g sample of an isotope of strontium-90 was
  formed in a 1960 explosion of an atomic bomb at
  Johnson Island in the Pacific Test Site. The
  half-life of Sr-90 is 28 years.
• How many years will it take for 0.625 grams of
  Sr-90 to remain? 56 years
• What year will this be? 2016

48
Half Life

• The half-life of an isotope is 3.0 years. If 20
  mg of this isotope disintigrates over a period of
  12 years, how many mg of this isotope will remain?

49
Half Life

• The half-life of an isotope is 3.0 years. If 20
  mg of this isotope disintigrates over a period of
  12 years, how many mg of this isotope will
  remain?
• 2.5 mg
