The Axial Skeleton

1
The Axial Skeleton

• Chapter 7

2
I. Skeletal Divisions (206 bones)

• Axial Skeleton (80 bones)
• Forms longitudinal axis of the body
• Consists of
• Skull
• Vertebral column
• Ribs
• Sternum

3

• Appendicular Skeleton (126 bones)
• Consists of
• Pectoral girdle
• Pelvic girdle
• Bones of the limbs

4
II. The Skull (22 bones)

• Functions
• Protects
• Guards entrances to digestive respiratory
  systems

5

1. Cranium (braincase) (8 bones)

6
1. Occipital Bone (1 bone)

• Forms posterior inferior surfaces

7
2. Parietal Bones (2 bones)

• Forms superior lateral surfaces

8
3. Frontal Bone (1 bone)

• Forms anterior portion of skull roof of orbits

9
4. Temporal Bones (2 bones)

• Surrounds protects sense organs of inner ear

10
5. Sphenoid Bone (1 bone)

• Cross-brace that strengthens sides of skull
  (looks like a bat)

11
6. Ethmoid Bone (1 bone)

• Forms roof of nasal cavity, part of nasal septum

12

1. Facial Bones ( 14 bones)

13
1. Maxillary Bones (2 bones)

• Supports the teeth

14
2. Palatine Bones (2 bones)

• Forms portion of hard palate

15
3. Lacrimal Bones (2 bones)

• Forms medial wall of orbits

16
4. Nasal Bones (2 bones)

• Supports superior portion of bridge of nose

17
5. Zygomatic Bones (2 bones)

• Forms rim lateral wall of orbits

18
6. Vomer Bone (1 bone)

• Forms interior portion of bony nasal septum

19
7. Inferior Nasal Conchae (2 bones)

• Creates turbulence in air passing through nasal
  cavity
• WHY???

20
8. Mandible Bone (1 bone)

• Lower jaw

21

• Sinuses
• Makes bones lighter
• Produces mucus to moisten clean air in and near
  the sinuses

22

• E. Sutures- Immovable joints connected with dense
  fibrous connective tissue
• Lambdoidal Suture- between occipital parietal
  bones
• Coronal Suture- between frontal and parietal
  bones
• Sagittal Suture- between parietal bones

23

• 4. Squamosal Sutures- between temporal
  parietal bones
• 5. Fontanels- fibrous area between cranial
  bones in infants
• a. allow skull to be distorted/squished to
  ease delivery
• b. the frontal fontanel persists until a child
  is nearly 2 yrs. old

24
Sutures of the Skull
25
F. Associated Bones of the Skull (7)

• Auditory Ossicles (6 bones)
• 3 bones per ear
• malleus, incus staples

26

• Hyoid Bone (1 bone)
• Supports larynx
• Only free standing bone not connected to another
  bone

27
III. The Vertebral Column

• - 33 total bones

28
A. Functions of the V.C.

• Provide a column of support
• Bear the weight of the head, neck trunk
• Protect the spinal cord
• Helps maintain an upright body position
• (Sitting/Standing)

29
B. Divisions of the V.C.

• Cervical Region
• a) Made of 7 vertebrae
• b) Constitutes the neck region
• c) Labeled C1-C7 (Superior to Inferior)
• i. C1 is called the Atlas
• -holds up the head
• - Articulates w/ occipital condyles
• - Allows yes movement
• ii. C2 is called the Axis
• - Pivots around the Atlas
• - Allows no movement

30

• Thoracic Region
• a) Made of 12 vertebrae
• b) Constitutes the chest/upper back region
• c) Labeled T1-T12 (Superior to Inferior)
• d) Articulate with the ribs

31

• Lumbar Region
• a) Made of 5 vertebrae
• b) Constitutes the lower back region
• c) Labeled L1-L5 (Superior to Inferior)
• d) Large, weight-bearing bones
• e) Provides site for muscle attachment

32

• 4. Sacrum
• a) Made of 5 fused vertebrae
• b) Constitutes the posterior portion of the
  pelvis
• c) Provides protection for reproductive,
  digestive, urinary organs

33

• 5. Coccyx
• a) Made of 3-5 fused vertebrae
• b) Also known as the tailbone

34
5 Divisions of the V.C.
Cervical Thoracic Lumbar Sacrum Coccyx
35
C. Spinal Curvatures

• 1) Thoracic Curvature
• 2) Sacral Curvature
• - 1) 2) are known as Primary or
  Accommodation curves b/c they appear in fetal
  development

36

• 3) Cervical Curvature
• 4) Lumbar Curvature
• - 3) 4) are known as Compensation curves
  b/c they develop as we learn to walk (help
  shift weight over legs)

37
4 Spinal Curvatures
38
IV. The Thoracic Cage

• A. Consists of the thoracic vertebrae, ribs,
  sternum

39
B. Functions

1. Protects the heart, lungs, thymus other
   structures
2. Serves as an attachment point for muscles

40
C. The Ribs

1. 12 pair of curved, flat bones
2. Originate on or between thoracic vertebrae
3. End in the wall of the thoracic cavity

41
D. Kinds of Ribs

• True/Vertebrosternal Ribs
• a) First 7 pairs, most superior
• b) Connected to sternum by cartilaginous
  extensions

42

• False/Vertebrochondral Ribs
• a) Ribs 8-12
• b) The cartilage on the ends of these ribs fuse
  together with rib 7

43

• 3) Floating Ribs
• a) Last 2 pairs (11th 12th)
• b) Not connected to sternum at all

44
E. The Sternum (breastbone)

1. Flat bone
2. Forms the anterior midline of the thoracic wall

45
F. Divisions of the Sternum

• Manubrium
• a) Most superior part of the sternum
• b) Triangular shaped
• c) Articulates w/ the clavicles the cartilage
  of the 1st pairs of ribs

46

• Body
• a) Tongue shaped
• b) Costal Cartilage from pairs 2-7 attach here

47

• Xiphoid Process
• a) Most inferior part of sternum
• b) Smallest part of sternum
• c) The diaphragm some abdominal muscles
  attach here

48
The Thoracic Cage
