RTS Scheduling Approach

• RTS typically control multiple parameters
  concurrently
• Eg. Flight Control System
• Speed, altitude, inclination etc..
• Options
• Use a single process
• Simple/limited approach but can be dangerous
• No OS required
• Use multiple processes
• More complex but more robust
• Use threads
• Light weight relative to processes

3
Cyclic Executive Approach

• Single Process
• while(1)
• Task 1
• Task 2
• ..
• ..
• Task n
• Encapsulate all tasks within single infinite loop

4
Cyclic Executive

• Ok for very well defined / periodic tasks with
  bounded execution times
• Need to ensure that tasks cannot block and halt
  all others
• May need to slow it down to meet particular task
  reqds
• Eg. Above example will run as fast as processor
  can handle tasks
• Possible Strategy
• Run as fast as required by highest freq task
• Use lower harmonics for remaining tasks
• Eg. Highest freq Task is 100 Hz
• Other tasks at 50Hz, 25 Hz etc
• Possible use counters to control sequence
• Possible use of timers to sleep
• Limited scope for aperiodic tasks eg. Interrupts
• Hardware specific?very limited portability

5
Cyclic Executive

• AS Example
• Cyclic executive approach
• Each AS station handles well defined tasks
• Execution time of each task precisely known
• Task schedule customised s.t.total task runtime
  will facilitate/meet response time
• Slack time in each cycle built in for interrupt
  processing
• If total task time exceeded repeatedly, timeout
  fault

6
Multiple Process Approach

• Each process is much more simple as handling a
  small subset of overall system
• Overall system
• More robust and reliable
• More scalable
• Can run on multiprocessor machine
• Modular
• Process code more portable
• Protected
• Each process operates in isolation with dedicated
  memory ? less risk of overall system failure
• Downside
• Requires an OS to schedule multiple processes
• More memory reqd for process overhead
• Communication between processes has to be
  explicitly done (advantage!)

7
Multiple Process

• Generic Process States
• Dormant Process created but not eligible to
  execute
• Ready Process released and eligible to execute
  but not doing so
• May be preempted
• May have been blocked for resources ? move to
  ready
• May have reached end of timeslice
• Executing Process being executed
• Suspended (Blocked) Process waiting for resource
  to be freed or self-suspended
• Terminated Process finished execution

8
Process State Diagram
Pre-empt or Timeslice allocated
Executing
Blocked/ Self suspended
Resource freed
Blocked
Preempted, timeslice up
Ready
Resource freed
Process terminated
Schedule Task
Terminated
Dormant
9
Scheduling for RTS

• Fundamental OS function
• More critical for RTS
• Allocating resources and scheduling tasks to
  ensure that deadlines are met
• Schedule is feasible iff all the tasks start
  after their release time and complete before
  their deadlines
• Scheduling Policy may be determined
• Pre-run-time
• Schedule created offline
• Not unlike Cyclic Executive approach
• Run-time
• Schedule determined online as tasks arrive
• Needs to be done quickly!

10
Scheduling for RTS

• Static versus Dynamic Priority
• Static Priority Scheduling Alg.
• Task priority does not change
• Rate Monotonic Alg.
• Dynamic Priority Scheduling Alg.
• Priority can change over time
• Earliest Deadline First (EDF)
• Preemptive versus non-preemptive
• Preemptive Schedule
• Task can be preempted by other tasks
• Penalty of context switches
• Non preemptive
• Task runs to completion unless blocked over
  resource

11
Task Characteristics Ti

• Precedence Constraints
• Other tasks reqd before task Ti can run
• Release Time
• of task Ti ri
• Phase Fi
• of task Ti release time of 1st instance of
  task Ti
• Execution time ei
• of task Ti time (worst case) for task to
  complete
• Period pi
• interval between consecutive instances of task
  Ti (presuming periodic)
• Absolute Deadline Di
• instant by which task must be complete
• Relative Deadline di
• .. Relative to release time ri

12
Task Characteristics Ti
pi
di
ei
Di
ri
Fi
13
Simplifications

• All tasks are periodic
• Relative deadline is equal to period
• No precedence constraints
• No task has any non-preemptible sections
• Cost of preemption is zero
• Non CPU resources are infinite eg. Memory / I/O
• ? limited use in the real world!

14
Rate Monotonic Scheduling

• Run time scheduling, Static priority and
  Preemptive
• Priority inversely related to period
• Eg. Given task Ti and Tj where pi lt pj
• Priority of task Ti greater than Tj
• Scheduling decision made when
• Current task execution complete
• New task released
• Recall In real world, RTS tasks with higher freq
  typically require shortest response times and are
  the most critical
• Recall task Ti utilisation ui ei / pi
• Overall CPU Utilisation U

15
RM Example
All Tasks released at time 0
Priority T1 gt T2 gt T3 Overall U
0.9 Sequence 1st inst Task 1 runs to
completion 1st inst Task 2 runs to completion 1st
inst Task 3 runs for 1 unit ..at Eu4, Task 1
released ? preempts Task 3 2nd inst Task 1 runs
to completion ..at Eu 5, Task 2 released 2nd
inst Task 2 runs to completion 1st inst Task 3
runs for 1 unit .. At Eu 8, Task 1 released
? preempts Task3 3rd inst Task 1 runs to
completion 1st inst Task 3 runs for 1 unit ..
At Eu 10, 3rd inst of Task 2 released ?
preempts 3 .. At Eu 15, 1st inst Task 3
completes.. CPU idle Eu 18-20 At Eu 20, all 3
tasks released .. Cycle repeats
Task e p u
T1 1 4 0.25
T2 2 5 0.4
T3 5 20 0.25
1 2 2 3 1 2 2 3 1 3 2 2 1 3 3
2 1 2 1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 Execution Units Eu
16
RM Scheduling

• General schedulability test
• If overall CPU utilisation U lt n(21/n -1)
• where n no of tasks
• RM will definitely produce feasible schedule
• However
• RM may produce feasible schedule where
• U gt n(21/n -1)
• i.e. Sufficient but not necessary condition
• Recall Example CPU U 0.9 but still schedulable
• Depends on particular task characteristics
• May need to perform further schedulability
  analysis
• As Task no increases, bound ? 69

17
Utilisation Bound for RM Alg.
1
0.83
0.78
0.69
0.73
Bound
8
1
2
3
4
5
6
10
No of Tasks
18
RM Schedulability Analysis

• Eg. Taskset T1 T2 T3 T4 where
• p1 lt p2 lt p3 lt p4
• Task 1
• Highest priority.. never preempted
• Will run immediately once released
• For Task1 to be feasibly scheduled
• Only condition is that e1 lt p1
• Include Task 2
• Can only preempted by Task 1
• Will be executed iff can find sufficient time e2
  over period 0, p2
• Say Task 2 completes at time t within 0, p2
• How many times did Task 1 run over 0,t ?
• Each iteration must also complete in this
  interval 0,t

19
RM Schedulability Analysis

• Over interval 0,t, Task 1 completes
• Must satisfy condition
• t e2 e1
• Need to find t over interval 0, p2
• Only need to check this when new instances of
  task 1 are released
• Find integer k such that
• k p1 gt k e1 e2
• k p1 lt p2

20
RM Schedulability Analysis

• Include Task 3
• Can be preempted by Task 1 and 2
• Need to find t over 0,p3 such that
• Need to check only at multiples of p1 and/or p2
• Similar analysis for Task 4
• Can be preempted by Task 1,2,3

21
RM Schedulability Analysis

• General Rule
• Wi(t)
• total work carried out by tasks T1T2T3... Ti
  initiated in interval 0,t
• If Wi(t) lt t , then schedule is feasible
• ?(Wi(t) / t) lt 1
• Wi(t) only changes at finite no of points when
  tasks are released
• Points defined by

22
RM Schedulability Analysis
i ei pi
1 20 100
2 30 150
3 80 210
4 100 400

• Consider Task set
• Check points
• W1 100
• W2 100,150
• W3 100,150,200.210
• W4 100,150,200,210,300,400

23
RM Schedulability Analysis

• Task 1 is RM Schedulable iff
• e1lt100 (True)
• Task 1/2 is RM Schedulable iff
• e1 e2 lt 100 or .(True)
• 2 e1 e2 lt 150 . (True)
• Task 1/2/3 is RM Schedulable iff
• e1 e2 e3 lt 100 or . (False)
• 2 e1 e2 e3 lt 150 or .. (True)
• 2 e1 2e2 e3 lt 200 or (True)
• 3 e1 2e2 e3 lt 210 . (True)

24
RM Schedulability Analysis

• Task 1/2/3/4 is RM Schedulable iff
• e1 e2 e3 e4 lt 100 or . (False)
• 2e1 e2 e3 e4 lt 150 or .. (False)
• 2e1 2e2 e3 e4 lt 200 or (False)
• 3e1 2e2 e3 e4 lt 210 or . (False)
• 3e1 2e2 2e3 e4 lt300 or . (False)
• 4e1 3e2 2e3 e4 lt400 . (False)
• Task 4 not RM schedulable
• Can also plot results
• Check whether Wi(t) falls on or below Wi(t) t
  line

25
RM Schedulability Analysis

• Wi(t)
• W1
• Interval 0,100
• W1(t) e1 20
• W2 checkpoints100,150
• Interval 0,100 W2(t)
• 20(1) 30(1) 50
• Interval 0,150 W(t)
• 20(2) 30(1) 70

26
RM Schedulability Analysis

• W3 checkpoints100,150,200,210
• W3(t)
• Interval 0,100
• W3(t) 20(1) 30(1) 80(1) 130
• Interval 0,150
• 20(2) 30(1) 80(1) 150
• Interval 0,200
• 20(2) 30(2) 80(1) 180
• Interval 0,210
• 20(3) 30(2) 80(1) 200

27
RM Schedulability Analysis
W1
W2
100
100
Wi(t) t
70
50
20
100
150
100
Time
Time
28
RM Schedulability Analysis
W3
W4
430
Wi(t) t
210
200
Wi(t) t
?
180
150
130
100
200
150
400
Time
Time
29
RM Schedulability Analysis

• Sporadic Tasks
• So far have only considered periodic tasks
• ? unrealistic
• Can view sporadic task as infrequent periodic
  task if can specify
• Minimum interarrival time between release of
  successive sporadic tasks
• Maximum execution time
• If so, can set these as highest priority relative
  to true periodic tasks
• ? Simply treat as additional task in RM analysis

30
Earliest Deadline First (EDF)

• Dynamic priority and preemptable
• Ready task whose absolute deadline is the
  earliest given highest priority
• Task priorities are reevaluated when tasks
  released/completed
• EDF is an optimal uniprocessor sched alg
• If all tasks are periodic
• Task 1n CPU U
• If U lt1, then task set is EDF schedulable

31
EDF Example
All Tasks released at time 0
Overall U 0.9 Sequence 1st inst Task 1 runs 1st
as earliest deadline of 4 1st inst Task 2 runs to
completion 1st inst Task 3 runs for 1 unit
..note Deadline is 20 ..at Eu4, Task 1 rel.
? preempy Task 3 as deadline is 8 2nd inst Task
1 runs to completion ..at Eu 5, Task 2
released 2nd inst Task 2 runs to completion as
deadline is 10 1st inst Task 3 runs for 1 unit
.. At Eu 8, Task 1 released ? preempts
Task3 3rd inst Task 1 runs to completion 1st inst
Task 3 runs for 1 unit .. At Eu 10, Task 2 rel..
Preempts task 3 as deadline is 15 .. At Eu 12,
Task 1 runs as deadline 16 lt 20 At Eu 15 Task 2
released and runs with deadline 20 At Eu 16 Task
1 rel with deadline 20 ? no preemption
Task e p u
T1 1 4 0.25
T2 2 5 0.4
T3 5 20 0.25
1 2 2 3 1 2 2 3 1 3 2 2 1 3 3
2 2 1 1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 Execution Units Eu
32
EDF Example
All Tasks released at time 0
Overall U 0.93 Sequence 1st inst Task 1 runs
1st as earliest deadline of 3 1st inst Task 2
runs to completion .. At Eu3, 2nd inst Task 1
rel runs as deadline is 6 1st inst Task 3 runs
..at Eu5, Task 2 rel. ? doesnt preempt Task
3 as deadline is also 10 .. Task 3
completes .. At Eu 6, Task 1 released deadline
9 ?runs .. At Eu 7 Task 2 runs to completion
.. At Eu 9, Task 1 rel ? deadline 12 ..runs
.. At Eu 10, Task 3 rel. deadline 20, Task 2
also rel with deadline 15 ?Task 2 runs ..
At Eu 15, Task 1 and 2 released with deadlines
16,20 ? Task 1 runs .. At Eu16, Task 2
runs .. At Eu 18 Task 1 rel with deadline 21
but Task 3 has deadline 20 ? Task 3 runs
Task e p u
T1 1 3 0.33
T2 2 5 0.4
T3 2 10 0.2
1 2 2 1 3 3 1 2 2 1 2 2 1 3 3
1 2 2 3 3 1
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18 19 20 Execution Units Eu
33
EDF vs RM

• With RM, priorities fixed
• Lowest period tasks guaranteed proc time
• Only higher period tasks will miss deadlines
• In overload conditions, same lower priority tasks
  lose out
• Bound on CPU utilisation must be considered
• EDF, dynamic priority
• More flexible.. Less predictable
• All tasks may miss deadlines
• Schedulable if CPU U lt1
• May react poorly to overload condition

34
Conventional OS Scheduling

• Time Sharing Emphasis
• Balance needs of interactive and CPU intensive
  traffic
• Complex alg
• Constantly adjust process priority
• CPU intensive processes lose priority as they run
• As a process waits, priority is increased ? will
  get CPU slot sooner
• Unix command nice
• nice -20 process_high_priority
• nice 20 process_low_priority
• nice will work but underlying sched alg unchanged
• Windows RealTime Threads
• Somewhat equivalent

35
POSIX.4 RT Scheduling

• Defines two main scheduling policies
• SCHED_FIFO and SCHED_RR
• Each have attributes
• Also have SCHED_OTHER
• Currently a single attribute priority
• struct sched_param
• int sched_priority
• Eg. Could implement EDF by extending structure to
  include
• struct timespec sched_deadline
• struct timespec sched_timerequired

36
POSIX.4 RT Scheduling

• SCHED_FIFO
• Simple priority based preemptive scheduler
• Most common in RTS
• FIFO used to schedule processes within each
  priority level
• If no other process exists at higher priority,
  process runs until complete
• Next process at that priority (if present) then
  allocated CPU
• Highest priority process guaranteed processor
  time

37
POSIX.4 RT Scheduling

• SCHED_RR
• Round robin used to timeslice among processes at
  same priority level
• System provided timeslice
• Use for lower priority tasks

38
POSIX.4 RT Scheduling

• Setting scheduling policy and attribute
• include ltsched.hgt
• struct sched_param scheduling_parameters
• int scheduling_policy
• int i
• scheduling_parameters.sched_priority17
• isched_setscheduler(getpid( ),SCHED_FIFO,
  scheduling_parameters)
• getpid( ) used to determine process ID
• Process set to FIFO, priority 17

39
POSIX.4 RT Scheduling

• Process priority ranges differ among OS
• Need this info before setting priority level
• int sched_rr_min, sched_rr_max
• int sched_fifo_min, sched_fifo_max
• sched_rr_minsched_get_priority_min(SCHED_RR)
• sched_rr_maxsched_get_priority_max(SCHED_RR)
• sched_fifo_minsched_get_priority_min(SCHED_FIFO)

• sched_fifo_maxsched_get_priority_max(SCHED_FIFO)

• Eg. 256 priority levels
• FIFO range 128-255
• RR range 0-127

40
POSIX.4 RT Scheduling

• Eg.
• includeltsched.hgt
• int i
• struct sched_param my_sched_params
• // determine max FIFO priority level
• my_sched_params.sched_priority
  sched_get_priority_max(SCHED_FIFO)
• // Set priority
• isched_setparam(getpid (),my_sched_params)
