LC/NPE Substrate Control: Substrate Control Daemon

1
LC/NPE Substrate ControlSubstrate Control Daemon

• Fred Kuhns
• fredk_at_arl.wustl.edu
• Applied Research Laboratory
• Washington University in St. Louis

2
Single Interface Example
LC

• LC Ingress
• One queue per slice with reserved bandwidth
  (really one per scheduler)
• One queue for best effort traffic to each GPE
• One scheduler for CP with queues for reserved
  traffic plus BE
• LC Egress
• At least one scheduler for each physical
  interface
• One queue for each active slice with MI defined
  for the associated scheduler
• One best effort queue for each board (GPE, CP,
  NPE?)
• Substrate sets scheduler rates according to
  aggregate allocations
• Manage scheduler rates to control aggregate
  traffic to interfaces and boards.

Ingress
wrr
qxs1
SchedNPE1
qxs2
...
Map fpMI to Q dip, dp, pr
qxsn
...
CP
qps1
qps2
SchedGPE1
GPE
...
qpsn
...
qBE
wrr
...
interface 1
GPE
SchedCP
NPE
Egress
wrr
qs1
...
qs2
NPE
SchedI1
...
qsn
BWI1
qGPE
src addr proto port/icmp
...
qCP
3
Common Definitions and Types

• See slides titled Types.ppt
• For all commands the message context ID is used
  to identify the context within which a command is
  to be executed.
• The special value of 0 (cid 0) indicates a
  privileged operation performed by the substrate.
• Otherwise the context ID is an identifier
  indicating a user specific context in the command
  is to be interpreted and executing. In most
  cases this is either the fastpath ID or an
  internal slice ID.
• uint16_t miid Meta-Interface number.
• If fpid 0 then miid is the endpoint ID (epid).
• int32_t retCode_t Most calls return success (0)
  or an error code.
• If a command results in an error then the first
  4-Byte of the reply message contains an error
  code
• If a command doesnt return any data then it
  should at least return a retCode_t code of 0, but
  this is not required.

4
NPE Tables
0
31
8
16
24
sid
interface number
rate (Kbps/683)
rate (Kbps/683)
interface number
Scheduler Rate table
0
31
8
16
24
qid
Length in Pkts (28b)
unused
Length in Bytes (32b)
Threshold in Bytes (32b)
Quantum (32b)
Length in Pkts (28b)
unused
Length in Bytes (32b)
Threshold in Bytes (32b)
Quantum (32b)
QParams Table
5
Line Card Tables or Both
0
31
8
16
24
sid
0
31
8
16
24
sid
destination Mac (high order 4 Bytes)
interface number
rate (Kbps/683)
dest MAC
Not Used
source Mac (high order 4 Bytes)
src MAC
Not Used
interface number
rate (Kbps/683)
Scheduler Rate table
destination Mac (high order 4 Bytes)
dest MAC
Not Used
source Mac (high order 4 Bytes)
src MAC
Not Used
Ingress/Egress Dynamic MAC Table
0
31
8
16
24
qid
Length in Pkts (28b)
unused
Length in Bytes (32b)
Threshold in Bytes (32b)
Quantum (32b)
Length in Pkts (28b)
unused
Length in Bytes (32b)
Threshold in Bytes (32b)
Quantum (32b)
QParams Table
6
Fast Path Commands SRM to SCD

• NPE Only
• retCode_t set_fastpath(fpid, copt_t, VLAN,
  rcnts_t, Mem)
• Message context ID 0
• fpid Fast-Path ID. Unique within SPP node.
• copt Code option identifier, 0 is invalid, IPv4
  1, I3 2
• uint16_t VLAN Ethernet VLAN tag, used in
  datapath to identify fastpath instance.
• rcnts_t cntr_t Qs, Fltrs, Buffers, Stats
• struct uint32_t offset, size Mem2 SRAM and
  DRAM allocation, values are relative to the start
  of an SRAM block set aside for fastpath use.Mem
  sram(offset, size), // SRAM version 1 all
  same size dram(offset, size) // DRAM not
  used in version 1
• Create fastpath specific mappings for queues,
  TCAM filters and the stats table.
• Initialize queue parameters to reasonable
  values (threshold, weight).
• Update VLAN Table with the code option ID (copt)
  and SRAM Address
• SCD knows starting address of SRAM, so add offset
• Assume there is an SRAM table read by the
  microengines which maps VLAN to buffer limits,
  this may be the VLAN table.
• Treat as a transaction, either it completes fully
  or no changes are recorded.
• uint32_t retCode_t 0 Success, app defined

7
Fast Path Commands SRM to SCD

• NPE Only
• retCode_t enable_fastpath(fpid_t)
• Message context ID 0
• fpid_t fast path identifier
• uint32_t retCode_t 0 Success, app defined
• enable by setting code option field of VLAN table
  entry for fp
• retCode_t disable_fastpath(fpid)
• Message context ID 0
• uint16_t fpid fast path identifier
• retCode_t 0 Success, 1 Pending, 2 Invalid
  fpid, else error code
• First, disable fp by setting code option field of
  VLAN table to 0
• It is not an error to call disable an already
  disabled fastpath
• SRM will periodically call disable_fastpath()
  until Success or Error.
• Then check all fast path queue lengths
• If any queue has non-zero length then return
  Pending
• If all queues are empty then return Success
• retCode_t rem_fastpath(fpid_t)
• Message context ID 0
• fpid_t fast path identifier

8
BW and Scheduler Control SRM to SCD

• Common Message
• Message context ID 0
• uint16_t sid Scheduler Id There are 5
  schedulers per QM and 4 QMs so 0 lt sid lt 20,
  (NBO)
• uint8_t MAC6 6 Byte Ethernet address
• LC and NPE schedule parameters
• retCode_t set_sched_params(sid, ifn, BWmax,
  BWmin)int32_t ifn Interface numberuint32_t
  BWmax Kbps, Maximum scheduler rateuint32_t
  BWmin Kbps, Minimum assignable rate for this
  scheduler.
• If BWmin is different from a previous call then
  may need to reassign weights for all associated
  queues
• Must convert the rate I send (Kbps) to that
  expected by the hardware. Value X Mbps / 0.683
  BW Kbps / 683 (So no floating point needed)
• Update scheduler parameters table in SRAM. The
  low 16-bit word is the converted rate value and
  the upper 16-bits is the interface number (ifn).
  The interface number must be the same value that
  TX uses. To set only the Rate (preserves the
  existing interface number) SParamssid
  (SchedParamssid 0xFFFF0000) (0xFFFF
  Value)To set the interface number (ifn,
  preserves the existing rate value)
  SParamssid (SParamssid 0xFFFF) (ifn ltlt
  16)To set both SParamssid (ifn ltlt 16)
  (0xFFFF Value)
• NPE Encap Control Block
• retCode_t set_encap_cb(sid, srcIP, dMAC)
• Must update the table which associates
  encapsulation header IP source addresses with a
  schedulerSchedAddrssid ipaddr, destination
  MAC
• retCode_t create_mi(fpid, mi, sid)
• retCode_t delete_mi(fpid, mi)
• retCode_t set_mi_bw(fpid, mi, bw)
• LC Dynamic MAC Table
• retCode_t set_sched_mac(sid, dstMAC, srcMAC)
• Must update the table which associates Ethernet
  source and destination addresses with a
  schedulerSchedAddrssid.smac smac (6 Bytes
  over 2 4B words)SchedAddrssid.dmac dmac (6
  Bytes over 2 4B words)

9
System Configuration SRM to SCD

• Common Message context ID 0
• SRM to SCD NPE Only
• retCode_t start_mes()
• The SCD starts the IXP microengines running the
  code that is automatically loaded when the SCD is
  launched
• Returns Success (0), Error (-1)
• retCode_t stop_mes()
• The SCD stops the IXP microengines if they are
  running
• Returns Success (0), Error (-1)

10
NPE GPE Info

• Common Message context ID 0
• uint32_t IP 4-Byte IP address (NBO)
• uint16_t PORT UDP Port number (NBO)
• uint16_t QID Slice relative queue id, must be
  converted by SCD to the tuple of qid, QM id and
  scheduler ID.
• SRM to SCD
• NPE Only
• retCode_t set_encap_gpe(fpid, gpeIP, npeIP)
• retCode_t unset_encap_gpe(fpid)
• unset_encap_gpe() set_encap_gpe(fpid,0,0)
• uint16_t fpid Fast path id, globally unique
• RMP to SCD
• NPE Only
• retCode_t set_gpe_info(exPort, ldPort, exQID,
  ldQID)
• retCode_t unset_gpe_info()
• Set context ID to the global fast path ID

11
Queues

• Common
• if cid 0 then qid is absolute otherwise SCD
  must convert from fastpath relative.
• uint16_t miid Meta-Interface number.
• uint32_t qlen Length of packet queue in Bytes
• uint32_t threshold the maximum number of
  packets queued before dropping
• uint32_t bw Kb/s, SCD must convert to the
  associated weight.
• uint8_t list_type Explicit list (0) or range
  specification (1)
• uint16_t qid_list List of queue identifiers
  to associate with meta-interface mi. In C or C
  this would be an array of integers 0, ..., n.
  If using a range then the list has the first and
  one past the last id of the range. For example
  4, 8 is the same as 4, 5, 6, 7.
• RMP to SCD
• NPE Only
• retCode_t bind_queue(u16 miid, u8 list_type,
  u16 qid_list)
• retCode_t unbind_queue(u8 list_type, u16
  qid_list)
• LC and NPE
• bw_t actual_bw set_queue_params(u16 qid, u32
  threshold, u32 bw)
• If a parameter is -1 then do not update in table.
• u32 threshold, u32 bw get_queue_params(u16 qid)
• u32 pktCnt, u32 byteCnt get_queue_len(u16 qid)
• SRM to SCD
• LC (Ingress and Egress)

12
Lookup Table (TCAM)

• Common LC cid 0, NPE cid fpid
• If cid 0 then fid is absolute, otherwise it is
  fastpath relative and must be converted.
• uint32_t fid Filter ID. If cid 0 then
  absolute, otherwise relative.
• uint16_t dbid Database ID. NPE dbid0 LC
  Ingress dbid0, Egress dbid1
• struct fltr
• uint8_t keyN N-Byte key value, defined by
  code option.
• uint8_t maskN N-Byte mask for key lookups,
  defined by code option.
• uint8_t resultM M-Byte result vector,
  defined by code option.
• SRM to SCD (ctx 0) RMP to SCD (ctx fpid)LC
  and NPE
• ret_t write_fltr(dbid, fid, key, mask, result)
• The SCD can lookup the database object with id
  dbid to get the key and result byte widths.
• The RMP will prepend the VLAN tag and change the
  slice MI numbers to the correct values
• ret_t update_result(dbid, fid, result)
• If fid is a valid entry then updates result
  vector. Otherwise no change to the database.
• fltr get_fltr_bykey(dbid, key)fltr
  get_fltr_byfid(dbid, fid)
• Returns a filter if key/fid matches a valid
  entry. Otherwise 0 (does not return an error)
• result lookup_fltr(dbid, key)
• Returns a result if key/fid matches a valid
  entry, otherwise 0 (does not return an error)

13
NPE Filter Interface

• SRM to SCD (ctx 0) RMP to SCD (ctx fpid)LC
  and NPE
• subKeyWrap_t type, rxip, rxport, coptKey14
• subResult_t actions, sindx, daddr, dport,
  sport, qid
• subFltr_t subKeyWrap, coptMask14, subResult
• scdCode_t write_npe_fltr(fid, subFltr)
• The SCD can lookup the database object with id
  dbid to get the key and result byte widths.
• The RMP will prepend the VLAN tag and change the
  slice MI numbers to the correct values
• scdCode_t update_npe_result(fid, subResult)
• If fid is a valid entry then updates result
  vector. Otherwise no change to the database.
• fltr get_npe_fltr_bykey(subKeyWrap)fltr
  get_npe_fltr_byfid(fid)
• Returns a filter if key/fid matches a valid
  entry. Otherwise 0 (does not return an error)
• scdCode_t lookup_npe_fltr(subKeyWrap)
• Returns a result if key/fid matches a valid
  entry, otherwise 0 (does not return an error)
• scdCode_t rem_npe_fltr_bykey(subKeyWrap)scdCode_
  t rem_npe_fltr_byfid(fid)
• Returns 0 on success or an error.

14
IPv4 TCAM Filter Formats (on NPE)
Defined by the IPv4 Code Option, 112bits
Substrate defined
daddr
saddr
sport
dport
tcp/proto
vlan
if
T
RX port
11
1
16
4
32
32
16
16
16
Represents input meta-interface
6
8
2
T 0 Normal Lookup T 1 substrate only lookup
Result, 128 bits
TX IP daddr
TX dport
TX sport
rsv
QM
rsv
L
D
rsv
sindx
Sch
qid
32
16
12
15
16
3
11
3
1
1
2
16
TX IP address and sport represents the output
meta-interface. The dport is provided by the
slice. (RMP maps miid to tx tunnel params, use
dport provided by slice)
global stats index (SCD maps slices sindx to
global value)
20-bit internal qid (SCD maps slices miid to QM
and Sch. SCD Also maps slices qid to global qid
value)
D Drop packet L Local delivery
Slice parameters
Key Input miid, IPv4 fltr daddr, saddr, sport,
dport, tcp/proto
Result Flags Drop, GPE, sindx, Output miID, QID
15
Reading Statistics

• Common
• if cid 0 then sindx is absolute, otherwiseSCD
  must convert fastpath relative index.
• uint8_t flags
• uint32_t handle opaque reference to periodic
  event
• uint32_t sindx stats index
• RMP to SCD, RLI/GIU to SCDLC and NPE
• stats read_stats(sindx, flags)
• struct stats uint32_t cnt, tstamp
• Uses flags L and W
• result clear_stats(sindx)
• result success or error code
• handle create_periodic(sindx, P, cnt, flags)
• uint32_t P periodic interval in milliseconds
• uint16_t cnt Number of samples to keep in a
  history buffer
• Uses all 3 flags
• retcode del_periodic(handle)
• retcode set_callback(handle, udp_port)
• push model every (cnt?period) milliseconds send
  the last cnt samples to the clients UDP port
  udp_port.
• stats get_periodic(handle)

16
Accessing Memory

• common
• Message context id NPE equals fpid for LC must
  equal 0.
• uint32_t offset Offset in from start of
  assigned SRAM block.
• uint32_t len Number of bytes to read/write
• uint8_t dataX Data buffer with X Bytes.
• uint32_t kpa Kernel physical address
• SRM to SCD LC and NPE
• result write_mem(kpa, len, data)
• Message context ID must 0.
• Can read any valid physical address on the
  xscale.
• data read_mem(kpa, len)
• Message context ID must 0.
• Can read any valid physical address on the
  xscale.
• RMP to SCD NPE Only
• result write_sram(offset, len, data)
• Offset is relative to the starting address of
  SRAM block allocated to slice. SCD must verify
  the write operation is within bounds.
• data read_sram(offset, len)
• Read len bytes from SRAM block and return to
  client. First verify offset and len with within
  bounds for slice.

17
New Commands

• NPE Only
• retCode_t set_src_hwaddr(hwaddr_t)
• context must be 0
• retCode_t set_iface_table(ipAddr_t16)
• context must be 0
