LU Decomposition

• Major All Engineering Majors
• Authors Autar Kaw
• http//numericalmethods.eng.usf.edu
• Transforming Numerical Methods Education for STEM
  Undergraduates

2
LU Decomposition http//numericalmethods.e
ng.usf.edu
3
LU Decomposition
LU Decomposition is another method to solve a set
of simultaneous linear equations Which is
better, Gauss Elimination or LU
Decomposition? To answer this, a closer look at
LU decomposition is needed.
4
LU Decomposition
Method For most non-singular matrix A that one
could conduct Naïve Gauss Elimination forward
elimination steps, one can always write it as A
LU where L lower triangular
matrix U upper triangular matrix
5
How does LU Decomposition work?
If solving a set of linear equations If A
LU then Multiply by Which gives Remember
L-1L I which leads to Now, if IU
U then Now, let Which ends with and AX
C LUX C L-1 L-1LUX
L-1C IUX L-1C UX
L-1C L-1CZ LZ C (1) UX
Z (2)
6
LU Decomposition
How can this be used?

• Given AX C
• Decompose A into L and U
• Solve LZ C for Z
• Solve UX Z for X

7
Is LU Decomposition better than Gaussian
Elimination?

• Solve AX B

T clock cycle time and nxn size of the matrix
Forward Elimination
Decomposition to LU
Back Substitution
Forward Substitution
Back Substitution
8
Is LU Decomposition better than Gaussian
Elimination?

• To solve AX B
• Time taken by methods
• T clock cycle time and nxn size of the matrix
• So both methods are equally efficient.

Gaussian Elimination LU Decomposition

9
To find inverse of A
Time taken by Gaussian Elimination Time taken by
LU Decomposition
10
To find inverse of A
Time taken by Gaussian Elimination Time taken by
LU Decomposition
Table 1 Comparing computational times of finding
inverse of a matrix using LU decomposition and
Gaussian elimination.
n 10 100 1000 10000
CTinverse GE / CTinverse LU 3.288 25.84 250.8 2501
For large n, CTinverse GE / CTinverse LU n/4
11
Method A Decomposes to L and U
U is the same as the coefficient matrix at the
end of the forward elimination step. L is
obtained using the multipliers that were used in
the forward elimination process
12
Finding the U matrix
Using the Forward Elimination Procedure of Gauss
Elimination
Step 1
13
Finding the U Matrix
Matrix after Step 1
Step 2
14
Finding the L matrix
Using the multipliers used during the Forward
Elimination Procedure
From the first step of forward elimination
15
Finding the L Matrix
From the second step of forward elimination
16
Does LU A?
?
17
Using LU Decomposition to solve SLEs
Solve the following set of linear equations using
LU Decomposition
Using the procedure for finding the L and U
matrices
18
Example
Set LZ C Solve for Z
19
Example
Complete the forward substitution to solve for Z
20
Example
Set UX Z Solve for X The 3
equations become
21
Example
Substituting in a3 and using the second equation
From the 3rd equation
22
Example
Substituting in a3 and a2 using the first equation
Hence the Solution Vector is
23
Finding the inverse of a square matrix
The inverse B of a square matrix A is defined
as AB I BA
24
Finding the inverse of a square matrix
How can LU Decomposition be used to find the
inverse? Assume the first column of B to be
b11 b12 bn1T Using this and the definition
of matrix multiplication First column of
B Second column of B
The remaining columns in B can be found in the
same manner
25
Example Inverse of a Matrix
Find the inverse of a square matrix A
Using the decomposition procedure, the L and
U matrices are found to be
26
Example Inverse of a Matrix

• Solving for the each column of B requires two
  steps
• Solve L Z C for Z
• Solve U X Z for X

Step 1
This generates the equations
27
Example Inverse of a Matrix
Solving for Z

28
Example Inverse of a Matrix
Solving UX Z for X


29
Example Inverse of a Matrix
Using Backward Substitution
So the first column of the inverse of A is


30
Example Inverse of a Matrix
Repeating for the second and third columns of the
inverse Second Column Third Column


31
Example Inverse of a Matrix
The inverse of A is


To check your work do the following
operation AA-1 I A-1A
32
