Title: MGCP


1
MGCP
Multinational Geospatial Co-production
Program Production of a test cell
  • Ottó Brunbauer
  • Hungarian Geodetic and Mapping Company Ltd.,
  • Head of Department for GIS
  • Conference 16.11.2006.

2
Overview of the Project I.
  • Background of the project
  • In April 2003, the countries making in a
    common workgroup (VaCWG) the worlds digital map
    in a scale of 1250 000 held a conference in
    Vancouver. There the USAs National Geospatial
    Intelligence Agency initiated -after the
    accomplishment of the 1250 000 scale mapping
    project, with the wider collaboration of the
    geospatial intelligence agencies- the starting of
    a new, Multinational Geospatial Co-production
    Program.
  • The objective of the project is the creation
    of an up-to-date digital map database in 150 000
    and 1100 000 scales, based on cells of 1 x 1
    adjoined geographical coordinates. This database
    meets the national / international requirements
    of anti-terrorism and other global tasks. As a
    result, there will be vectoral maps of the world
    available for the participating countries in the
    ratio of their cooperation.
  • Another objective of the project, in the
    interest of time- and cost-efficiency, that the
    creation of paper based maps to be limited only
    for the areas of necessity. This assures that the
    geospatial data is always up-to-date and it is
    sent to the participants in a timely and adequate
    manner.

3
Overview of the Project II.
  • Implementation of the project in Hungary
  • Responsible for the execution of the project
  • Ministry of Defense Mapping Office
  • Leader of practical execution
  • Ministry of Defense Mapping Company Coordination
    Agency

4
Overview of the Project III.
  • Objective Creation of a digital GIS database
    which is consistent with the data density of 150
    000 scale topographic maps,10x10, on an area of
    altogether 8533km2
  • Duration 2005 october 2006 december

5
The Field of Work
1ºx1º cell 24 segments 317 pcs. ortophotos
200 GByte
47º000 19º000
46º000 18º000
6
Raw Data I.
  • The evaluation is primarily based on the raw data
    of an ortophoto with 50cm field resolution made
    by the Institute of Geodesy, Cartography and
    Remote Sensing under the project Areial
    Photography of Hungary 2005.
  • Scanned and georeferred files of military
    topographic maps in 150.000 scale (resolution
    200 dpi system of reference UTM/WGS84 format
    GEOTIFF)
  • Gazetteer of Hungary (KSH, 2003-2005)
  • GeoNames database
  • Register of geodetic points

7
Raw Data II.
  • Database of towers and high buildings
  • Database of airports and runways
  • Legend for the deliverable controlling map sheet
    (GeoSym legend)
  • DVOF datafile for the area
  • AAFIF datafile for the area

8
Reference System of the Raw Data
Digital ortophotos
DVOF
Topographical maps in 150000 scale
AAFIF
GEONAMES
G.BASE POINTS
Primary raw material
Databases
Auxiliary raw material
9
The evaluation covers
  • surface topology (surface objects)
  • buildings and structures
  • hidrogeology (drainage network, dams, flood
    gates)
  • air transport (airports...)
  • road transport (road network, bridges and
    dependecies of decks...)
  • railway transport
  • Earth and its vegetation
  • public power plants (power plant)

10
Definitons, terms
Object Object attribute Surface
Abstraction of the actual phenomena.
Charasterictics of a given object. Two
dimensional topological primitive. The
geometrical realization of the surface is the
interface.
To every object belongs an attribute table which
contains the typical features of the object. The
filling of this table with data is being done
side by side with the vectoral data extraction.
11
Topological Model

The bases of the semantical model are the objects
which are settled to each other in a given
reference system.
Point-like objects
Functional and other surface objects
Linear objects
Land cover objects
12
Features of Objects
The features of the objects are specified with
the filling of the attribute table.
Object attribute table
13
Principles of Evaluation I.
  • Terms and principles of evaluation of the
    objects
  • good quality of the ortophoto for identification
    the digital image material must be always
    considered as the most reliable source,
    especially in regard to the geometric information
  • unreliable quality of the ortophoto for
    identification additional digital and printed
    sources are serving as reference and auxiliary
    material. These are helpful in situations when
    certain information arent at all or not properly
    displayed on the image material

14
Principles of Evaluation II.
  • Classification of objects
  • Mandatory
  • Conditional
  • Optional Can be evaluated if they are
    unambiguously identifiable on the ortophoto, but
    their evaluation is not mandatory

Must be evaluated in every case
15
Principles of Evaluation III.
  • Classification of attributes of the objects
  • Mandatory Must be given in every case
  • Conditional
  • Optional

Not mandatory to be given
16
Rules of Data Extraction and accuracy I.
The objects are coded by DIGEST (Digital
Geographic Information Exchange Standard) Feature
Attribute Coding Catalog. MGCPs Technical
Reference Document defines the list of obejcts
and attributes that are considered as the minimal
content of the generated data in the programs
frame. During the evaluation of the objects the
maximal acceptable error (absolute error, three
times the medium error) is 25m (CE90), namely
the medium error cannot exceed 8.3m.
17
Rules of Data Extraction and accuracy II.
  • Technical Documents
  • Specification of metadata
  • Semantical interpreter model
  • Evaluation guide
  • Catalog of objects and attributes

18
Evaluation Guide I.
  • Content
  • Basic evaluating guide,
  • well-established procedures and expectations,
  • rules in regard to representation and
    completeness adjusted to each object,
  • hyperlink to the detailed evaluation guides in
    regard to each object,
  • hyperlinks to other auxiliary documents of MGCP.

19
Evaluation Guide II.
Table of Contents Rule system of MGCPs
Evaluation Guide AAFIF general questions General
questions of barrier objects General questions in
regard to the hidrogeology Examples of MGCP
object code dependent files .. .
20
Evaluation Guide III.
General examples of object classes, illustrated
with figures.
21
Evaluation Guide IV.
Conditions of evaluation for each object,
assistance, illustrated with pictures and
figures.
22
Feature and Attribute Catalog
Attributes belonging to specific objects and the
list of their possible value.
23
Hardware/Software Environment
  • Hardware
  • A network consisting of a server and clients that
    are communicating with each other in a closed
    intranet
  • Strong VGA card and processor both on the client
    and the server side, SCSI HDDs
  • Software
  • Intergraph Geomedia Professional 6.0 GIPS
    (Geo-Intelligence Production System)

24
Software Interface I.
25
Software Interface II.
26
Software Interface III.
27
Work Management
MGCP Coordination Office Professional
consultations, basics of technology,
qualification, weekly supervision of execution
FTP server
Intergraph software experts
Secure exchange, storage and supply of datafiles
Technical assistance, guidance, providing
software components
The firm doing the final supervision
Geodezia Co. Ltd. Department for GIS (technology,
project lead, internal supervision)
28
Abstract
  • Complex, based on up-to-date technology
  • Requires high organization and expertise
  • A project creating possibilities that are heading
    towards the future

29
Thank you for your attention!
