Climatology Lecture 7

1
ClimatologyLecture 7

• Horizontal Motion in the Atmosphere
• Continued
• Michael Palmer

2
Wind

• Pressure gradient force
• Coriolis Force
• Geostrophic wind
• Gradient wind
• Friction and the Ekman spiral

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Wind

• Pressure gradient force
• Coriolis Force
• Geostrophic wind
• Gradient wind
• Friction and the Ekman spiral

8

• Geostrophic wind only applies to straight
  parallel isobars, but isobars are usually curved,
  and often arent parallel
• For air moving in a curve, we must consider an
  additional force

9
Centripetal force

• Tie a Spice Girls CD to some string and spin it
  around your head
• The tension you maintain on the rope pulls the CD
  around in a circle
• Inward force - centripetal

10
Centrifugal force

• Fairground ride
• Body thrown out against side
• Centrifugal force - outward

11
Which force do we work with?

• Both the same!
• Force apparent to a rotating body
• outward centrifugal
• Force apparent to external observer
• inward - centripetal

12
Pressure gradient force

• Identical pressure gradient in each case

LOW
LOW
LOW
HIGH
HIGH
HIGH
13
Centrifugal force

• Force due to circular motion, as viewed by air

LOW
LOW
LOW
HIGH
HIGH
HIGH
14
Sub-geostrophic winds

• Wind speed less than geostrophic
• Cyclonic curvature - sub-geostrophic

Geostrophic Balance PGF CF
PGFCF Ce
15
Super-geostrophic winds

• Wind speed more than geostrophic
• Anticyclonic curvature - super-geostrophic

Geostrophic Balance PGF CF
PGFCeCF
16
(No Transcript)
17
(No Transcript)
18
??? Question ???

• When air blows around curved isobars will the
  wind speed be the same as of straight isobars?
• assuming the pressure gradient is the same

19
??? Question ???

• When air blows around curved isobars will the
  wind speed be the same as of straight isobars?
• assuming the pressure gradient is the same
• Answer No, and the size of the difference
  depends on amount of curvature

20
Gradient wind

• Pressure gradient force
• Coriolis force 2wVsin Ø
• Centrifugal force V2/r
• V is the wind speed
• r is the radius of curvature
• Balance

21
Wind

• Pressure gradient force
• Coriolis Force
• Geostrophic wind
• Gradient wind
• Friction and the Ekman spiral

22
Friction

• Friction reduces wind speed
• Coriolis force is reduced
• Flow crosses isobars from high towards low
  pressure
• Applies near surface but not at upper levels
  where friction is insignificant

23
(No Transcript)
24
(No Transcript)
25
Cyclonic

• Cyclonic circulation produces convergence near
  surface

26
Anticyclonic

• Anticyclonic circulation produces divergence near
  surface

27

• Friction reduces with altitude

Free atmosphere
LOW
Near surface
28
Surface pressure change

• Net inflow Net
  outflow
• P Increase P
  Decrease
• System Declines System Declines

LOW
29
Vertical motion

• Upward Downward

Free atmosphere
LOW
Near surface
30
Conclusions

• Curved flow is described by gradient wind
• Cyclonic curvature gives sub-geostrophic winds
• Anticyclonic curvature gives super-geostrophic
  winds
• PGF, CF, Friction and centrifugal forces describe
  wind systems adequately

31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
Readings for todays lecture

• Barry and Chorley 1997 p76-86
• Briggs et al. 1997 Fundamentals of the Physical
  Environment p78-88
• Henderson-Sellers and Robinson 1999 p56-74
• Linacre and Geerts 1997 Climates and Weather
  Explained p127-145
• McIlveen 1992 Chp 7 p181?
