ARC Conference Orlando

1
welcome
2
NAMUR - the Users Voice
User requirements and NAMUR recommendations for
the interoperability across the manufacturing
enterprise in the context of international
standards
Dr. Hasso Drathen General Manager of NAMUR
and Head of Intellectual Property Services of
Process Management Technology, Bayer Technology
Services
3
86 Member Companies
4
European User Association of Measurement,
Automation and Process Control Technology in
Chemical, Petrochemical and Pharmaceutical
Industries
General Assembly
Board of Management
Office
-??-
VKE
Anlage 1
Division 5 Explosion Protection Services
Division 6 Project Group List of Characteristics
Division 1 Engineering and Construction
Division 2 Systems and Solutions
Division 4 Maintenance and Services
Division 3 Field Devices
5
Well known NAMUR Recommendations
NE01 Noncontacting Initiators and Accompanying
Switching Amplifiers - IEC 60947-5-6
"Low-voltage switch gear and control gear Part
5-6 Control Circuit Devices and Switching
Elements - Direct Current Interface for
Proximity Sensors and Switching Amplifiers
(NAMUR) NE06 Electrical Standard Signals and
Device Technology IEC 60381 Analogue signals
for process control systems Part 1 Direct
current signals NE12 Explosion protection of
analyser houses IEC 61285 Industrial-process
control - safety of analyzer houses NE31 Safety
of process plants using process control systems
and ISA S84 Programmable Electronic Systems
for Use in Safety Applications IEC 61511
Functional Safety - Safety Instrumented Systems
for the Process Industry Sector NE33
Requirements to be met by systems for
recipe-based operations and ISA S88 Batch
Control Systems IEC 61512 Batch Control NE58
Execution of process control projects subject to
validation, and NE68, NE71, NE72 are part of GAMP
- Good Automated Manufacturing Practice - Part 2
6
NAMUR Recommendation
7
Requirements and Offers
8
The Challenges for the Interoperability of
Device Data
basic engineering data
supply data
procurement data
Data sheet with user requirements to
instrumentation and systems
device data from the vendor
plant maintenance data
material management data
detail engineering data
construction data
9
Data Flow and Interfaces of the Planning Process
in PCE
Data for a PCE-loop
Requirem. description
Purchasing department
Equipment data
PLANNING PROCESS
DOKUMENTATION
Loops
Hook-ups
Maintenance
10
Data Flow and Interfaces of the Planning Process
in PCE
See NAMUR NE 55 or ISA S20
Data for a PCE-loop
Requirem. description
Vendor
Purchasing department
Equipment data
PLANNING PROCESS
Updates, Traceability
DOKUMENTATION
Detail engineering
Loops
Hook-ups
Plant maintenance, Material management
Maintenance
11
Using the Lists of Characteristics (LOC)
Manufacturer
Customer
Internet
Planning system
shipping
equipment data as build
inquiry data
inquiry
Sales system
Purcha- sing system
equip-ment data
Deve- lopment system
equip-ment data
further orders
shipping
After sales service
Mainte- nance system
equipment data
updates
12
General Data Modelof the Device Specifications
in the NE100

• NE 100 Version 1.0 contains device specifications
  for 41 types of measuring equipment.
• Each device specification consists of two Lists
  of Characteristics (LOC)- the LOC requirements
  and
• - the LOC device

Specification form (device specification)

• Data regarding location (LOC requirements)
• Design data (e.g. nominal size of connection
  flange)
• Characteristics of medium (e.g. viscosity)
• Environmental conditions (e.g. minimum ambient
  temperature)
• Quality and safety requirements (e.g. Ex zone)

• Data regarding equipment (LOC device)
• Design characteristics (e.g. material)
• Electric characteristics (e.g. load)
• Certificates (e.g. test certificate)
• Measuring accuracy (e.g. hysteresis)
• CAE data (e.g. connecting points)
• etc.

13
PROLIST Working Groups

• Working groups
• 1. Data model
• 2. LV Switchgear
• 3. Sensors
• 4. Remote Operated Valves Fittings
• 5. Signal Adjustment
• 6. Electric Drives
• 7. CAE Applications
• 8. Fieldbus

14
NE 100for International Standardisation

• The data model used in NE 100 corresponds to the
  most important standards in this area IEC 61360
  and ISO 13584.
• There exists a standard that describes how to
  arrange a technical description of a measuring
  device. This is the IEC/PAS 61987-1.
• The device descriptions of NE 100 using the LOCs
  will be arranged according to IEC/PAS 61987-1,
  beginning with version 1.1.
• The device descriptions developed for other
  fields, as for remote-operated fittings, signal
  adjustment or electric drives will be proposed
  for incorporation into IEC standards.

15
Main Task of the Project Group Lists of
Characteristics

• Development and maintenance of the device
  specifications (LOCs)
• Immediate availability of the lists of
  characteristics (by means both of the internal
  data base and NE 100) to the members of the
  project group (manufacturers and customers) for
  direct use
• Internationalisation of the device specifications
  by means of IEC standard
• Consideration of possibilities how to use the
  characteristics in order to optimise internal
  and external company processes

16
Join the NAMUR Activities
www.NAMUR.de office_at_NAMUR.de
17
Thank you
benefits by process automation
